ALCON AQ500h User Manual

Hotspot series
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
l
AX500h User manua
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AQ500h and is the answer not in the manual?

Questions and answers

Summary of Contents for ALCON AQ500h

  • Page 1 AX500h User manua...
  • Page 2 AX500h User manua Copyright Notice Copyright Incorporated 2006. All rights reserved. Disclaimer Incorporated shall not be liable for technical or editorial errors or omissions contained herein; nor for incidental or consequential damages resulting from furnishing this material, or the performance or use of this product. Incorporated reserves the right to change the product specification without notice.

  • Page 3: Table Of Contents

    AX500h User manua Table of Contents Introduction ....................5 Features .....................5 Minimum Requirements ................5 Physical Specification ................6 Installation ....................6 Configuring the Clients ................7 Configuration Wizard..................7 Status ......................9 System Profile ..................9 DHCP IP Assignment ................9 DDNS ....................10 Online Users..................10 Traffic Statistics ..................10 Network Setup..................12 WAN Interface ..................12 LAN Interface..................13...
  • Page 4 AX500h User manua SNMP ....................36 Centralized Control ................37 Version ....................37 Backup....................39 Restore ....................39 Diagnostic.....................40 Access Control ..................41 Authentication Setting................41 Login Page Management..............42 RADIUS ....................46 Group Configuration ................47 Authentication Policy ................47 Local Account ..................49 Service Plan ..................50 On-Demand User .................51 Guest User ...................52 Walled Garden..................52 Log ......................54 View Log....................54...

  • Page 5: Introduction

    The AQ500h solves this solution by requiring all users to authenticate themselves before they are allowed to use the Internet. Authentication is simple and easy, all users need to attempt to connect to some web site, and the AQ500h will automatically redirect them to an authentication page, where they enter their username and password.

  • Page 6: Physical Specification

    Installation Installation of the AQ500h is simple: 1. Plug in the network cable from the WAN interface of the AQ500H to your DSL modem or cable modem. 2. Plug in a network cable from your computer to one of the four LAN interfaces on the AQ500h.

  • Page 7: Configuring The Clients

    (LAN), you will need to know how to change the IP, net mask, and gateway of your client computer, or at least know how to get that information to update your AQ500h should your IP, net mask, and gateway of your virtual server should ever change.
  • Page 8 AX500h User manua Click the page in the path “TRAFFIC CONTROL > Bandwidth Group”. Step.2 Then add one bandwidth group. Click the ACCESS CONTROL from the top menu. Then, click Step.3 Authentication Policies and configure authentication type. If you choose RADIUS for authentication type, please enter RADIUS page under the ACCESS CONTROL to set radius server.

  • Page 9: Status

    System Profile This page shows the administrator basic network information about how the AQ500h is configured. DHCP IP Assignment This page shows what IP addresses have been assigned by the AQ500h and to which MAC addresses they have been assigned.

  • Page 10: Ddns

    DDNS data as needed. Online Users This page shows what users are connected through the AQ500h, their username, login time, what service they are currently using, their MAC and IP address, the remote server they are connected to, and how much of the bandwidth they are using.
  • Page 11 AX500h User manua...

  • Page 12: Network Setup

    AX500h User manua Network Setup Under these pages, the administrator could configure the network interfaces. WAN Interface This page allows the administrator to configure the WAN interface. Just pick the desired mode to get WAN’s IP and enter the pertinent information for that option.

  • Page 13: Lan Interface

    AX500h User manua LAN Interface This page allows the administrator to configure the LAN interface and DHCP server. Enter pertinent information for all the fields and click “Update” to finalize the configuration. Administrator could enable or disable the DHCP server, assign fixed IP for a specific MAC address and control the PnP mechanism.

  • Page 14: Port Trigger

    AX500h User manua Port Trigger When the firewall is enabled, all ports, unless specified under Firewall Rules, will be closed. This is very inconvenient for those services that receive responding packets on uncertain high range ports. Therefore, we have this port trigger function that opens up a certain port, or ports, automatically when in need.

  • Page 15: Real Dmz

    AX500h User manua packets. Step1: Add data into cgi_screen and press the update button name=test Trigger_Port:10-20 Incoming_Port:25-96 Step2: The screen will show the data as above Step1: Click the delete checkbox on the exist data item and press the update button name=test Trigger_Port:10-20 Incoming_Port:25-96...

  • Page 16: Software Dmz

    Software DMZ This page allows the administrator to add computers into the software DMZ. The AQ500h is designed such that the software DMZ supports only IP addresses that are in the subnet of the WAN interface. If you wish to put servers into your LAN using a virtual IP, please see the section on One to One NAT.

  • Page 17: Ddns

    AX500h User manua DDNS Under this page, the administrator can fill in the Manage Name 、 Manage Server 、User Name、Password、IP Address and Domain Name in the page, or click the Status> DDNS to inquire, delete, or modify. Multi DMZ This function allows the administrator to map real IP addresses to virtual IP addresses in the LAN of the device.

  • Page 18: Alias Ip

    AX500h User manua Alias IP Alias IP function allows the administrator to set more than one IP for the LAN interface. In effect, the machine can have more than one LAN subnet. Use the following picture as an example; you can see that an Alias IP of 172.16.2.254/24 has been set for this machine.

  • Page 19: Change Wan Mac Address

    AX500h User manua Change WAN MAC address Some ISPs bind user accounts to a specific MAC addresses. Therefore we provide this simple and easy-to-use function for the user to change the machine’s WAN MAC address when needed. Just enter the new WAN MAC and click on Update, the system will write-in the new MAC and then automatically reboot to allow the configuration to take effect.

  • Page 20: Firewall

    Service Management This page allows the administrator to add new port filtering rules or remove existing rules on the AQ500h, as well as enable or disable the firewall entirely. There are two default rules for the firewall that cannot be deleted, ICMP and other services.

  • Page 21: Access Rules

    Access Rules This page allows the administrator to enable or disable existing port filtering rules on the AQ500h. To enable, simply check the box next to the service/port listed and click update at the button. To disable, uncheck the box next to the service/port listed and click update.

  • Page 22: Mac Filter

    AX500h User manua MAC Filter Filter traffic from LAN to WAN according by Ethernet MAC address. Provide MAC filter function to enable/disable. Provide each MAC filter item to enable/disable. To allow or deny traffic when packets match Ethernet MAC address. Provide Add/Update/Delete function.

  • Page 23: Anti-Dos

    Anti-DoS This page allows the administrator to enable or disable built in anti-DoS functionality of the AQ500h. Certain DoS attacks are the consequence of using legitimate services and as such the administrator can configure the minimum rate after which the device will trigger the anti-DoS functionality.
  • Page 24 AX500h User manua...

  • Page 25: Web Url Filter

    AX500h User manua Web URL Filter This function allows the administrator to block/log any access to any website by matching and filtering the IP or FQDN of the target site. This function provides fuzzy or exact match for FQDN filtering. It does not only take exact FQDN such as www.yahoo.com, it also allows input of regular expressions that contain wild characters for fuzzy match.

  • Page 26: Web Content Filter

    AX500h User manua you want to delete and then click on Submit to delete the selected items. Clicking the Edit icon will bring the corresponding entry back to the Add New Filter String text fields. You can then change the information as needed and then click on Update to update this entry.
  • Page 27 AX500h User manua Configuration: Enable/Disable this function by clicking on the corresponding radio button. Choose whether you want to log, block or do both when a content match is found. Then, choose the type of the string to match. Ether Text type or Fuzzy type.

  • Page 28: Application Filter

    AX500h User manua The Query button allows you to search the filter list. Just enter the IP or FQDN you want to search and click on this button. If a match is found, the information will show up on the Add New Filter String text fields. The Filter String List will be separated into pages when there are too many entries to show on one page.
  • Page 29 AX500h User manua Configurations: Enable/Disable，use the radio button to enable or disable this application filter function. Checking the corresponding Log/Block box of an application to log/block that application. You can certainly check both. Click the Update button at the bottom of the page to finalize your setting. Click the Reset to clear all the un-finalized check box.

  • Page 30: Traffic Control

    AX500h User manua Traffic Control The Traffic control feature is a unique and special service. It allows the administrator to control and use the bandwidth as per the needs. Link Bandwidth This Option allows to Enable or Disable the traffic control feature. The bandwidth of up- and down- links of the WAN provided by the ISP have to be specified as shown: Service Management...
  • Page 31 AX500h User manua...

  • Page 32: Ip Management

    AX500h User manua IP Management This function allows the administrator to set traffic limit on a specific IP address. Select the specific service to set the limit on, enter the IP address and its range, set the priority and then finally set the traffic limit for both upload link(LAN to WAN) and download link(WAN to LAN).

  • Page 33: Bandwidth Group

    AX500h User manua Bandwidth Group This function allows the administrator to set traffic limit on a bandwidth group. Set the priority and then finally set the traffic limit for both upload link (LAN to WAN) and download link (WAN to LAN). Click on “Add” to finalize the configuration.
  • Page 34 AX500h User manua...

  • Page 35: System Service

    Administrator This page allows the administrator to change information about the administrator account, as well as open the AQ500h for remote administration. Just enter the new information and check the desired options then click on “Update” to make to change.

  • Page 36: Upnp

    AX500h User manua UPNP This page allows the administrator to enable or disable the UPNP functionality of the AQ500h. SNMP The network environment has become more and more diverse and complicated these days. Debugging and management of networking devises has also become increasingly difficult. SNMP is a framework that manages network devices over UDP protocol.

  • Page 37: Centralized Control

    AX500h User manua 『Set Community』: When a community is set, the devices of the same community could be accessed. 『Trusted host』: Only the host with this IP could access the devices in the community. Username and Password: username and password is required when using SNMP v3. The password is usually longer than 8 characters.
  • Page 38 AX500h User manua The above message will appear on the screen during the upgrade. Please follow the instruction to ensure a successful upgrade.

  • Page 39: Backup

    This page allows the administrator to restore settings from a backup file to the AQ500h. Click on “Browse” and a menu of working directory on the local machine will pop up. Open the file to restore and then click on “Restore” to restore the machine.

  • Page 40: Diagnostic

    AX500h User manua Diagnostic Under this page, the administrator could use some web diagnostic tools to diagnose the machine. First, choose the network diagnose tools, put in the IP or Domain Name, then click on the Update button to see the result.

  • Page 41: Access Control

    Access Control This function allows the administrator to control user’s access to the Internet through AQ500h. When the authentication mechanism is enabled, the user’s browser will be redirected to an authentication page where they will have to enter a valid account name and password to get access to the Internet. Once authenticated, the user will get access to the internet instantly and a small window will pop up to show the user the remaining credit.

  • Page 42: Login Page Management

    AX500h User manua Failed Login Page: You can choose default or redirecting URL to customize the login page when users fail to the internet. Login Popup Window: If you Enable this option, it will cause a popup window displaying account credit when a customer authenticates Login Page Management 1.
  • Page 43 AX500h User manua Customized Logo Image 1. Super administrator logins to the system, and then inputs the following URL in the browser in order to customize the login logo image and top banner image. http://IP_Address:Port/cgi-bin/axtwgwpgax_cust_login.cgi NOTE: Only super administrators should know this URL. 2.
  • Page 44 AX500h User manua 4. Click “Submit” button to update the login page to the desired format and style. Customized Login Page 1. Super administrator logins to the system, and then input the following URL in the browser in order to customize the login page.
  • Page 45 AX500h User manua again. Customize account Login/Logout pop-up Page Choice one of the Login/Logout page you want to edit, chick “Download default file” to download a “Template.htm” file, Use this file to create your own Login/Logout page file. When finish editing Login/Logout page, upload it to system in the field “Login popup page :”...

  • Page 46: Radius

    AX500h User manua {RX_BYTES} Number of data received The popup window size is fixed. Don’t create a page larger then default. RADIUS The radius feature is an optional setting for those who want to use an external Radius server as their authentication system in place of the authentication system provided by the device.

  • Page 47: Group Configuration

    AX500h User manua Group Configuration This function allows the administrator to manage the Group ID. There are two fields in this configuration for each Group ID, including Group Name and Bandwidth Profile. The administrator can modify following settings of this function： 1.
  • Page 48 AX500h User manua The administrator can modify following settings as the following screen： 1. Policy ID: In this field, you can select profile6 in the drop- down menu and select the check box in the Default field. Then the Authentication Policy will change to the profile6 Configuration.

  • Page 49: Local Account

    AX500h User manua (3) Receipt Footer: Set the receipt footer here or use the default. (4) Printer Baud Rate: Select the desired transmission baud rate. The default value is 9600. (5) Monetary Unit: Select the desired monetary unit for different region. (6) Remark: Enter the remark and it will show at the bottom of the receipt.

  • Page 50: Service Plan

    AX500h User manua Service Plan This page allows the administrator may configure up to 10 billing rules. Status: Select to enable or disable this billing rule. Type: Set the billing rule by Data (the maximum volume is 2002 Mbyte) or Time (the maximum day is 24305 days). Expired Info: If the user doesn’t activate the account by the time, after the time-limit, the account will expire.

  • Page 51: On-Demand User

    AX500h User manua On-Demand User In the On-demand User List, you can go on the user information configurations.

  • Page 52: Guest User

    AX500h User manua User Name / Password: You can add a username and password for On Demand User. Service Plan: You can select a service plan for On Demand User. Add: After completing the field “On Demand User Add”, click on “Add” to finalize the configuration.
  • Page 53 AX500h User manua Update to finalize the setting. The added walled garden websites will remain on the list after the page is refreshed. Use the following picture as an example, there are two wall garden pages--test: www.ibm.com and test2:axtronics.com.tw. To delete a walled garden page, just delete the display name and corresponding URL and then click on Update to delete the page.

  • Page 54: Log

    This page displays the log of the AQ500h. Log Settings This page allows the administrator to configure the logging function of the AQ500h. To enable this mechanism, choose the enable it, set the log schedule and choose the log matching criteria and the click “Update” to...

  • Page 55: Web Statistics

    AX500h User manua finalize the setting. Web Statistics This page saves all of the visited web sites from users of the AQ500hss, ranked in order of most frequented. Packet Statistics This page shows statistics relating to the network traffic in terms of packets counts on each links.

  • Page 56: Misc

    AX500h User manua MISC Reboot This function allows the administrator to reboot the box from the User Interface. We try to provide a few trouble shooting tips and configuration HOWTOs with this list. If you run into any problem while using our products, please consult this list before contacting our technical support team.
  • Page 57 AX500h User manua please make sure there is nothing wrong with the cable also). Please check and see if the LED indicator for the connection lights up. For example, if you connect the product’s LAN interface with a pc, please see if the LED indicator of LAN interface lights up.
  • Page 58 AX500h User manua By Console port: you can connect the machine and PC with the console port and then restart the machine. The terminal will display a list like the following example. Please select the action "r" to restore factory setting. After resetting, you can try and access the machine again.
  • Page 59 AX500h User manua This issue has something to do with our DNS relay function. Please disable it if you do not need to use any particular DNS server. Please note that DNS relay function basically captures all the DNS query packets from LAN and redirects it to the DNS server specifically configured.
  • Page 60 AX500h User manua How come your XXX function does not work with other brand of routers? Please note that certain of our special features, such as remote centralized management via CMS, utilize some proprietary protocols. Other brands of routers do not come with these protocols and hence would not work.
