WARNING
FOR YOUR SAFETY - This product must be installed and serviced by authorized
personnel, qualified in pool/spa installation. Improper installation and/or operation can
create a hazard which can cause serious injury, property damage, or death. Improper
installation and/or operation will void the warranty.
Advertisement
Table of Contents
Related Manuals for Jandy Ray-Vac
Summary of Contents for Jandy Ray-Vac
- Page 1 Installation Data Installation Manual WARNING FOR YOUR SAFETY - This product must be installed and serviced by authorized personnel, qualified in pool/spa installation. Improper installation and/or operation can create a hazard which can cause serious injury, property damage, or death. Improper installation and/or operation will void the warranty.
-
Page 2: Table Of Contents
Pool Cleaner Line........2 Troubleshooting........10 SECTION 8 SECTION 4 Exploded Views Head and Hose Installation Hose............. 11 Attaching Ray-Vac Head to Hose.... 2 Heads........... 12 Connecting Ray-Vac Head to Pool Wall...2 Hose Length Adjustment......3 Equipment Information Record Date of Purchase Purchased From... -
Page 3: Safety Information
Page 1 SECTION 1. Safety Information 1A. Safety Instructions READ AND FOLLOW THESE SAFETY INSTRUCTIONS! PLEASE SAVE THESE INSTRUCTIONS Caution 1. Handrails which extend into the water must be removed or substituted with a figure four design so as not to obstruct the movement of the cleaner. 2. -
Page 4: General Information
Pusher Jet Silicon & Hose Ray-Vac Hose Head Push Hose On To Here Figure 3. Attaching Pusher Jet Hose to Ray-Vac Head A and B are Equal Lengths Figure 1. Pool Cleaner Line Location... -
Page 5: Hose Length Adjustment
If Locate the pool cleaner wall fitting in the pool. the Ray-Vac extends beyond 5' out of the pool, the Determine the size of the wall fitting. The most hoses are too long (see Figs. 6-8). -
Page 6: Section
Page 4 If your Ray-Vac hoses are the correct length, proceed to Section 5, "Speed Adjustment Booster Floats Pump Installation" or Section 6, "Speed Coupler Adjustment Non-Booster Pump Installation." If your Ray-Vac hoses are NOT the correct length, use one of the following steps to correct... -
Page 7: Section
Page 5 To disconnect hose sections To reconnect hose sections: Remove the "C" clip from the coupler. Place mender sleeve loosely over hose Slide mender sleeve off hose. coupler small end first. Pull hose off the coupler. Place mender ferrule over hose section. Remove mender ferrule from hose (5/8"... -
Page 8: Speed Adjustment With Booster Pump
Insert quick disconnect fitting back into pool wall Locate where the Ray-Vac hose is connected to fitting (see Fig. 5). the pool wall. Turn the quick disconnect fitting and remove the hose from the pool wall fitting. - Page 9 (follow steps 1-10). Each letter NOTE: Information in this table is a "guideline" only. down will decrease pressure approximately 2 psi. 13. When the Ray-Vac speed is properly adjusted, turn off all pumps. 14. Remove the pressure gauge and filter screen case from the pool wall.
-
Page 10: Speed Adjustment Without Booster Pump 6A. Speed Adjustment
Before cleaning main filter, be sure to turn the Jandy 3- port valve so the line to the Ray-Vac is closed. Figure 15. Ray-Vac Energy Filter and Jandy Valve NOTE: If your pool filter is a diatomaceous earth (D.E.) type you must leave the Ray-Vac line closed... - Page 11 Figure 17. Cleaning Finger Screen for your cleaner hose length (see Table 2). If the Ray-Vac sticks in an obstacle (i.e. corners, ladders, skimmers, etc.) it is possible to increase Length of hose the pull out by changing the backup jet size.
-
Page 12: Troubleshooting
Debris is passing by main filter. Main filter element damaged. Replace as necessary. Valve to Ray-Vac was not closed. Close valve to Ray-Vac before cleaning the main filter. Cleaner beaches on Insufficient water above top step. Cleaner needs a minimum of 5" of water to operate top step. -
Page 13: Exploded Views
Page 11 SECTION 8. Exploded Views 8A. Hose... -
Page 14: Heads
Page 12 8B. Heads Gunite Head... - Page 15 Page 13 Vinyl Liner/Fiberglass Head...
-
Page 16: Limited Warranty
DE grids, or cartridge elements; or damage caused by running the pump with insufficient quantities of water. LIMITATION OF LIABILITY: This is the only warranty given by Jandy Pool Products, Inc. No one is authorized to make any other warranties on behalf of Jandy Pool Products, Inc. THIS WARRANTY IS IN LIEU OF ALL OTHER WARRANTIES, EXPRESSED OR IMPLIED, INCLUDING BUT NOT LIMITED TO ANY IMPLIED WARRANTIES OF FITNESS FOR A PARTICULAR PURPOSE AND MERCHANTABILITY.
