Cellular Phone Parts List - Samsung GT-S5260 Service Manual

Exploded View and Parts List

4-2. Cellular phone Parts list

Design LOC
QAR01
QCR67
QMO01
QJK01
QME03
QSP01
QCA01
QMP01
QLC01
QME01
QKP02
QFR01
QBC00
QLB01
QRE01
QVO01
QCK02
QRF06
QSD01
AUDIO-RECEIVER
SCREW-MACHINE
MOTOR DC-SPHV8400
MODULE-EARJACK/FPCB ASSY
TOUCH/PANEL-EU COMMON (WHITE)
MODULE-SPK/INTENNA (GT-S5260)
CAMERA MODULE-3M CAMERA MODULE
A/S ASSY-PBA MAIN (COMM)
ASSY LCD-MODULE ASSY(GT-S5260)
ASSY MODULE-KEY PBA/MIC/BRACKET
ASSY KEYPAD-SUB
ASSY CASE-FRONT
ASSY COVER-BATT
ASSY BRACKET-LCD
ASSY CASE-REAR
PMO KEY-VOLUME
PMO KEY-HOLD
PMO COVER-USB
PMO COVER-SD
