cogeco Digital Adapter Setup Manual

What you need to know
Cogeco is upgrading the TV service in your area to bring you the
enhanced viewing experience of Digital TV on all your TV channels.
This means you will now have access to the full experience of
Digital service, including an improved High Definition channel offering.
In order to deliver a high quality Digital television service, high
definition channels, access to Cogeco On Demand plus allow us
to deliver faster Internet speeds and other future services, we are
progressively phasing out our Analogue tier channels and moving
these to Digital.
What you need to do
When the switch to Digital is complete, the Analogue Value Pack
you currently receive will no longer be available. To continue to
receive all of your current channels, including specialty channels,
you'll need a Digital Adapter for each TV in your house. Otherwise
you will only receive a basic channel package that reduces the
number of channels you can access.
Your new Digital Adapter will allow you to keep all your channels
without interruption.
Every TV will need one device
Digital Adapter
Digital Adapter
A Digital Adapter will allow
you to receive the channels
you currently have. It will not
provide Cogeco On Demand
programming or our On Screen
Channel Guide.
What's included in this Install Kit?
Digital 3-Foot Power Remote 2 AA Remote Adhesive
Adapter Coax Cable Cord Control Batteries Control Fasteners
Infrared IR
You'll be In order to Use these if
Extender
connecting operate you want to
the Digital the Digital If you prefer to stick the Digital
Adapter Adapter you Adapter to
hide the
to the cable must use the your TV.
Digital Adapter
wall outlet and remote control
behind your
Note:
to your TV included with
TV, you will
Please be
(or TV and this kit. need to
careful. We
VCR). Programming
connect this
can't be
instructions
Note: to your Digital responsible for
for the remote Adapter so
Each TV will any damage
control are
your new
need to be done to any
included in remote
connected to a surface you
this guide.
control
Digital Adapter stick these to.
or a Digital can send
signals to it.
Receiver,
but not both.
Using Your Remote Control
To program the remote to control your
TV's power and volume, do the following:
S ET
1. Turn on your TV.
2. Press and hold "Set" until the red
light on the remote blinks twice.
Release "Set."
S E T
3. Enter 9 - 9 - 1. The red light on the
remote will blink twice.
4. Point the remote at the TV and press
"CH +" one or more times until the TV
turns off.
VOL CH CH +
+ - + -
/ /
Note: You may need to press "CH +" numerous times.
5. Press "Set" once to lock in the code.
The red light on the remote will blink
twice.
S E T
L AN G
6. Press Power to turn your TV on on.
If you need more help, please refer to the
programming guide included with the remote.
To control the volume, press and hold
the volume up "Vol +" or volume down
button "Vol -". To change the channel,
press the channel up "CH +" or channel
down "CH -" button, or press the channel
number and enter.
Using the Remote Control
Signal Receiver
If you want to hide the Digital Adapter
behind the TV, or if the Digital Adapter
will not reach the front of the TV, you
can hide it and use the Remote Control
Infrared IR Extender. Plug the smaller
end of the Remote Control Infrared IR
Extender into the "IR In" port on the
back of the Digital Adapter. Position
the other end of the Remote Control
Infrared IR Extender where it can be
seen from the front of the TV.
Troubleshooting
If the remote control does not work:
• Make sure the batteries are inserted correctly.
• Make sure your remote can "see" the front of the
Digital Adapter (or the front of the Remote Control
Infrared IR Extender).
• If you are using the Remote Control Infrared IR
Extender, make sure it is connected firmly to the
Digital Adapter.
If there is no light illuminated on the front of the
Digital Adapter:
• Make sure the power cord is attached to the Digital
Adapter and plugged into a live electrical outlet.
If there is no picture on the TV and the light on
the Digital Adapter is blinking:
• Make sure that you have followed the activation
process for the digital Adapter, on the back of this
document.
• Wait approximately 24 hours. If the light is still
blinking, call Cogeco at 1-877-776-6636.
If there is no picture on the TV and the light on
the Digital Adapter is solid:
• Make sure the TV and Digital Adapter are both set to
the same channel (both 3, or both 4).
• Try switching the TV and Digital Adapter to the other
channel (3 or 4).
• If you're also connected to a VCR, make sure the
VCR is turned on.
• Make sure the Digital Adapter is connected directly
to the cable outlet in your wall.
• Make sure all the cables are firmly connected.
If the audio is in a language you don't expect
to hear:
• You may have accidently changed it to an alternate
language option. Press the "LANG" button on your
remote control one or two times.
If you need additional support,
you can reach us at 1-877-776-6636.
Happy
We're
50th!
here to
:)
help you!
Yay!
Digital
Adapter
Easy Setup
Guide
