Summary of Contents for Goodway GPW-1200
- Page 1 $1.00 PRESSURE WASHERS GPW-1200 • GPW-1000 • GPW-1000-P GPW-2003 • GPW-2502 OPERATING & MAINTENANCE INSTRUCTIONS ®...
- Page 2 Effective date – June 1, 2004 MADE IN U.S.A. SAVE THESE INSTRUCTIONS Goodway reserves the right to improve products. Contact the factory for the latest configuration and uses. © Copyright 2004 Goodway Technologies Corporation, Stamford, CT, U.S.A. Goodway is a Trademark of Per K. Reichborn.
-
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS To prevent operator injury and damage to the equipment, please read and observe the following basic safety precautions: 1. Read all the instructions before using the product. 2. To reduce the risk of injury, close supervision is necessary when the product is used near children. -
Page 4: Ground Fault Circuit Interrupter Protection
WARNING: To reduce the risk of electrocution, keep all connections dry and off the ground. Do not touch plug with wet hands. CAUTIONS: GPW-1200/GPW-1000/GPW-1000-P 1. When machine is shut down, a small amount of water is left in pump and plumbing; therefore, THE MACHINE MUST NOT BE STORED UNDER FREEZING CONDITIONS. - Page 5 4. The Goodway GPW-1000 and GPW-1000P may be used with warm water supply at a maximum of 180°F (82°C), and the GPW-1200 at a maximum of 140°F (60°C) to improve cleaning. IF WARM WATER SUPPLY IS USED, THE TIME IN NO. 3 SHOULD BE REDUCED FURTHER.
- Page 6 3. Connect the end of the high pressure hose to the fitting on the side of the machine. OPERATING INSTRUCTIONS: GPW-1200 1. Connect water hose capable of delivering a minimum of 1.8 GPM (6.8 LPM) to inlet and turn on faucet. Consult the Goodway catalog for heavy-duty water supply hose. DO NOT RUN PUMP DRY.
- Page 7 2. Plug into grounded outlet of proper voltage for the machine. Make sure the outlet is fused for a minimum of 15 Amps. Any additional extension cord must be grounded and be a minimum of 12-3 gauge wire. Goodway offers a 20 amp, 10-3 gauge, 50' (15.2m) cord – see catalog.
-
Page 8: Operation
OPERATION 1. Connect water hose capable of delivering a minimum of 2.5 GPM (13 LPM) to inlet and turn on faucet. Consult the Goodway Catalog for heavy-duty water supply hose. DO NOT RUN PUMP DRY. 2. Connect the air supply line to the hose barb fitting using a "... - Page 9 Make sure the outlet is fused for a minimum Amps listed on the units nameplate. Any additional extension cord must be grounded and be a minimum of 10-3 gauge wire. Goodway offers a 20 Amp, 10-3 gauge, 50' (15.2m) cord – see catalog.
- Page 10 Multi-Jet Nozzle ( P/N PWN-002) NOTE: Maximum pressure with nozzle (P/N PWN-002) is 1,000 PSI (70 BAR). Supplied with a hardened stainless steel spray tip containing four orifices each marked with orifice numbers as follows: Orifice No. Spray Pattern Usage 00045 Solid Jet Concentrated Cleaning...
- Page 11 To stop soap application, pull the nozzle back. MIXING RATIOS: GPW-1200/GPW-1000/GPW-1000-P The mixing ratio of chemicals to water depends on the viscosity of the chemicals being used.
- Page 12 For mix ratio of 1 tablespoon per gallon of water, prepare a premix solution of 1 part chemical to 7 parts of water. For mix ratio of 1 teaspoon per gallon of water, prepare a premix solution of 1 part chemical to 22 parts of water.
- Page 13 TROUBLESHOOTING: GPW-1200/GPW-1000/GPW-1000-P Problem Probable Causes Remedy Spray Pressure Foreign matter trapped Disassemble pump low or fluctuating in the check valve of and clean the pump TROUBLESHOOTING: GPW-2003/GPW-2502 Problem Probable Causes Remedy Pressure and/or Worn packing seals Replace packing seals delivery drops...
- Page 14 MAINTENANCE: GPW-1200 The GPW-1200 is shipped with the proper amount of oil. Due to the possibility of spillage in shipment, the oil level should be checked prior to the first use of the machine, as well as prior to each use of the machine.
- Page 15 DISASSEMBLY: GPW-1000/GPW-1000-P The entire unit can be removed from the case by removing the cover, the four motor mounting screws, chemical dip tube and high pressure hose and then lifting entire motor-pump and plumbing assembly out of housing. DISASSEMBLY: GPW-2003/GPW-2502 Access to the internal parts is gained by removing the front cover, allowing for pump lubrication and component repair/replacement.
- Page 16 GPW-1200...
- Page 17 GPW-1000...
- Page 18 GPW-1000-P...
- Page 19 GPW-2003/GPW-2502...
- Page 20 We Are Here to Serve You! For Sales Call: 1-800-333-7467 For Service Call: 1-800-370-2855 Goodway Technologies Corporation manufactures and distributes a complete line of Tube/Pipe Cleaning Systems, Duct Cleaning Systems, Vacuums, Steam Cleaners, Pressure Washers and other maintenance related equipment.
