netsys NH-800SP User Manual

8 ports managed hpna ip dslam
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
N
N
N
8
P
O
R
T
S
M
a
8
P
O
R
T
S
M
a
8
P
O
R
T
S
M
a
U
S
E
U
S
E
U
S
E
H
-
8
0
0
S
P
H
-
8
0
0
S
P
H
-
8
0
0
S
P
n
a
g
e
d
H
P
N
A
n
a
g
e
d
H
P
N
A
n
a
g
e
d
H
P
N
A
R
'
S
M
A
N
U
R
'
S
M
A
N
U
R
'
S
M
A
N
U
I
P
D
S
L
A
M
I
P
D
S
L
A
M
I
P
D
S
L
A
M
A
L
A
L
A
L

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NH-800SP and is the answer not in the manual?

Questions and answers

Summary of Contents for netsys NH-800SP

  • Page 1 ’ ’ ’...

  • Page 2: Copyright

    In the interest of improving internal design, operational function, and/or reliability, NETSYS reserves the right to make changes to the products described in this document without notice. NETSYS does not assume any liability that may occur due to the use or application of the product(s) or circuit layout(s) described herein.

  • Page 3: Foreword

    NH-800SP 8 PORTS Managed HPNA IP DSLAM USER’S MANUAL Ver_B2 Foreword The HPNA networking solution delivers cost-effective, high-performance broadband access to multiunit buildings (hotels, apartment, and multi-tenant unit office buildings) and enterprise campus environments such as manufacturing, educational campuses, and medical facilities. HPNA technology dramatically extends Ethernet over existing Category 1/2/3 wiring at...

  • Page 4: Safety Warnings

    NH-800SP 8 PORTS Managed HPNA IP DSLAM USER’S MANUAL Ver_B2 Safety Warnings For your safety, be sure to read and follow all warning notices and instructions before using the device. DO NOT open the device or unit. Opening or removing covers can expose you to dangerous high voltage points or other risks.

  • Page 5: Hpna Ip Dslam

    NH-800SP 8 PORTS Managed HPNA IP DSLAM USER’S MANUAL Ver_B2 HPNA IP DSLAM The HPNA IP DSLAM has 8x 1Mbps HPNA ports and 2 x 10/100M Ethernet ports. The switch is an one rack-unit (1RU) high, 10-inches deep. It is a standard Rack mounted size.
  • Page 6 NH-800SP 8 PORTS Managed HPNA IP DSLAM USER’S MANUAL Ver_B2 Power Level : Supports High/Low power level settings. Spanning tree: Supports IEEE-802.1d spanning tree to avoid loop and MAC bridge with redundant link. MAC address filtering: Supports MAC address filtering security, and MAC learning enable/disable.

  • Page 7: Table Of Contents

    NH-800SP 8 PORTS Managed HPNA IP DSLAM USER’S MANUAL Ver_B2 Table of Contents COPYRIGHT ................................ 1 FOREWORD ................................ 2 SAFETY WARNINGS ............................3 HPNA IP DSLAM ..............................4 CHAPTER 1. UNPACKING INFORMATION....................... 10 1.1 Check List ....................................10 1.2 Package Contents ..................................10 1.3 Product Guide.....................................
  • Page 8 NH-800SP 8 PORTS Managed HPNA IP DSLAM USER’S MANUAL Ver_B2 2.2 Front Panel....................................15 2.3 LED Indications ..................................17 2.3 Rear Panel....................................18 CHAPTER 3. INSTALLATION ..........................19 3.1 Hardware Installation .................................19 3.2 Pre-Installation Requirements..............................19 3.3 General Rules .....................................20 3.4 Connecting the IP DSLAM .................................20 3.5 Connecting “MDI-X”...
  • Page 9 NH-800SP 8 PORTS Managed HPNA IP DSLAM USER’S MANUAL Ver_B2 4.2.2.1. Web Management Home Overview..............................32 4.2.2.3. Port Statistics...................................34 4.2.2.4. Administrator ...................................35 4.2.2.4.1. IP Address....................................36 4.2.2.4.2. Switch Setting....................................37 4.2.2.4.3. Console Port Information................................40 4.2.2.4.4. HPNA Speed Control and port Enable/Disable........................41 4.2.2.4.5. Filter Database...................................42 4.2.2.4.6.
  • Page 10 NH-800SP 8 PORTS Managed HPNA IP DSLAM USER’S MANUAL Ver_B2 APPENDIX C: V-LAN SET UP EXAMPLE ......................73 APPENDIX D: COMPLIANCE AND SAFETY INFORMATION ................76 WARRANTY ............................... 79 CHINESE SJ/T 11364-2006..........................80...

  • Page 11: Chapter 1. Unpacking Information

    NH-800SP 8 PORTS Managed HPNA IP DSLAM USER’S MANUAL Ver_B2 Chapter 1. Unpacking Information 1.1 Check List Carefully unpack the package and check its contents against the checklist. 1.2 Package Contents 1 x 8 ports HPNA IP DSLAM 1 x User’s manual CD...

  • Page 12: Product Guide

    NH-800SP 8 PORTS Managed HPNA IP DSLAM USER’S MANUAL Ver_B2 1.3 Product Guide Product Name： ： ： ： 2ports 100 Mbps Fast Ethernet plus 8Ports HPNA With SNMP Management IP DSLAM 1.4 Product Features Compliant with HomePNA Ver. 1.1 and IEEE 802.3 and 802.3u Provides 2 x 10/100Mbps Fast Ethernet RJ-45 Ports plus 8 x 1Mbps RJ-45 HPNA ports (Note：Connecting Ethernet equipments...
  • Page 13 NH-800SP 8 PORTS Managed HPNA IP DSLAM USER’S MANUAL Ver_B2 Supports protocol base V-LAN Supports IEEE-802.1p QOS Supports IP Multicast / IGMP v1/2 with 512 groups Supports IEEE 802.1d Spanning trees for MAC bridge with redundant link Supports port Mirroring(Sniffer)

  • Page 14: Product Specifications

    NH-800SP 8 PORTS Managed HPNA IP DSLAM USER’S MANUAL Ver_B2 1.5 Product Specifications Compliant with HomePNA 1.1 / IEEE 802.3 & 802.3u Ethernet Standards 10/100Mbps Ethernet ports: 2 x RJ-45 MDI Ethernet port: 1 x RJ-45 1 Mbps symmetrical HPNA port: 8 x RJ-45...
  • Page 15 NH-800SP 8 PORTS Managed HPNA IP DSLAM USER’S MANUAL Ver_B2 POTS/ISDN Low pass filter Spectrum: 0 ~ 1Mhz Internal switching power adapter Input: AC 85-265 volts/50-60Hz/1A . Dimensions: 435 x 230 x 44 mm Weight : About 3 Kgs Operating Temperature: 0℃ ~ 50℃(32F ~ 122F) Storage Temperature: - 20℃...

  • Page 16: Chapter 2. General Description

    NH-800SP 8 PORTS Managed HPNA IP DSLAM USER’S MANUAL Ver_B2 Chapter 2. General Description 2.1 Hardware Description This section describes the important parts of the IP DSLAM. It features the front and rear panel drawings showing the LED, connectors, and switches.
  • Page 17 NH-800SP 8 PORTS Managed HPNA IP DSLAM USER’S MANUAL Ver_B2 HPNA IP DSLAM has embedded Splitter between every HPNA ports and POTS ports. It permits you to delivers broadband service on the same lines as Plain Old Telephone Service (POTS), PBX, ISDN traffic and HPNA Signal.

  • Page 18: Led Indications

    NH-800SP 8 PORTS Managed HPNA IP DSLAM USER’S MANUAL Ver_B2 2.3 LED Indications The following describes the function of each LED indicator. (Table 2-1) Table 2-1 LED Indicators Description and Operation LEDs Color Status Descriptions This LED light is located at the left side on the front panel. It will light up (ON) to PWR.

  • Page 19: Rear Panel

    NH-800SP 8 PORTS Managed HPNA IP DSLAM USER’S MANUAL Ver_B2 2.3 Rear Panel The following figure shows the rear panel. (Figure 2.3) Figure 2.3 Rear Panel description Note: AC Power Socket: The power cord should be plug into the socket. The AC Socket accepts AC power 100 to 240 voltage.

  • Page 20: Chapter 3. Installation

    NH-800SP 8 PORTS Managed HPNA IP DSLAM USER’S MANUAL Ver_B2 Chapter 3. Installation 3.1 Hardware Installation This chapter describes how to install the 8 ports HPNA IP DSLAM. To establish network connection, you may install the HPNA IP DSLAM on any level surface (table, shelf, 19 inch rack or wall mounting). However, please take note of the following minimum site requirements before you begin.

  • Page 21: General Rules

    NH-800SP 8 PORTS Managed HPNA IP DSLAM USER’S MANUAL Ver_B2 3.3 General Rules Before making any connections to the HPNA IP DSLAM, note the following rules: Ethernet Port (RJ-45) All network connections to the IP DSLAM’s Ethernet port must be made using Category 5 UTP for 100Mbps and Category 3,4 UTP for 10Mbps.No more than 100 meters (about 328 feet) of cabling may be use between HPNA IP DSLAM or with...

  • Page 22: Connecting "Mdi-X" Station Port

    NH-800SP 8 PORTS Managed HPNA IP DSLAM USER’S MANUAL Ver_B2 3.5 Connecting “MDI-X” Station Port 1. You can connect the “9” port on the IP DSLAM to any device that uses a standard network interface such as a Cable modem, ADSL modem, Ethernet Switch, workstation or server, or also to a network interconnection device such as a bridge or router (depending on the port type implemented).

  • Page 23: Connecting "Mdi" Port (Tx)

    NH-800SP 8 PORTS Managed HPNA IP DSLAM USER’S MANUAL Ver_B2 3.6 Connecting “MDI” Port (TX) Prepare straight through shielded or unshielded twisted-pair cables with RJ-45 plugs on both ends. Use 100Ω Category 5 cable for connections. Connect one end of the cable to “TX” port of the IP DSLAM, and the other end to a standard RJ-45 station port on cable modem, ADSL router, wireless bridge, etc.
  • Page 24 NH-800SP 8 PORTS Managed HPNA IP DSLAM USER’S MANUAL Ver_B2 Figure 3.1 HPNA Application Diagram...

  • Page 25: Chapter 4. Management Configuration

    NH-800SP 8 PORTS Managed HPNA IP DSLAM USER’S MANUAL Ver_B2 Chapter 4. Management Configuration 4.1 In-Band Management Console port (RS-232) Configuration (Change IP Address By Terminal) You can configure the product with the local serial console port, If one of the RJ11 port is not in use, you can disable it, that procedure is to connect a notebook computer to the RS-232 port, then boot windows O/S system, and run “Hyper-terminal”...
  • Page 26 NH-800SP 8 PORTS Managed HPNA IP DSLAM USER’S MANUAL Ver_B2 3. Connects PC with the IP DSLAM, you will find login manual window on the screen then enter Login name ：”admin” ; password：”123” you will find Main Menu window on the screen of the following: 4.
  • Page 27 NH-800SP 8 PORTS Managed HPNA IP DSLAM USER’S MANUAL Ver_B2 5. For Example: “Set IP Address”, please follow these steps: Step1. Choose HPNA IP DSLAM Static Configuration, and you can enter next page.
  • Page 28 NH-800SP 8 PORTS Managed HPNA IP DSLAM USER’S MANUAL Ver_B2 Step2. Choose Administration Configuration, and you can enter next page.
  • Page 29 NH-800SP 8 PORTS Managed HPNA IP DSLAM USER’S MANUAL Ver_B2 Step3. Choose IP Configuration, and you can enter IP configuration page...
  • Page 30 NH-800SP 8 PORTS Managed HPNA IP DSLAM USER’S MANUAL Ver_B2 Step4. Choose Edit item to Change IP address, Subnet Mask and Gateway Use CTRL+A button to back actions choice Choose Save item to save change and back to System Configuration page Choose Previous Menu item to quit System Configuration page Choose Main Menu item to quit HPNA IP DSLAM’s Configuration page and back to Main Manual...

  • Page 31: Remote Network Management

    NH-800SP 8 PORTS Managed HPNA IP DSLAM USER’S MANUAL Ver_B2 4.2 Remote Network Management 4.2.1 IP Setting You must setup the “IP Address” with the local serial console port (RS-232 Port), and then you can use this IP address to control...

  • Page 32: Web Management Function

    NH-800SP 8 PORTS Managed HPNA IP DSLAM USER’S MANUAL Ver_B2 4.2.2 Web Management Function 1. Provide a Web browser to manage and monitor the switch, the default values as follows: If you need change IP address in first time, you can use console mode to modify it.

  • Page 33: Web Management Home Overview

    NH-800SP 8 PORTS Managed HPNA IP DSLAM USER’S MANUAL Ver_B2 4.2.2.1. Web Management Home Overview There is a easy to manage from the HPNA web ui, A screen is displayed as shown in Figure 4.2.2.1. Figure 4.2.2.1 Select the Menu Level 4.2.2.2.
  • Page 34 NH-800SP 8 PORTS Managed HPNA IP DSLAM USER’S MANUAL Ver_B2 Actual: Display the negotiation result. Duplex status: Display full-duplex or half-duplex mode. Configure: Display the user setup, Actual: Display the negotiation result. Flow control: Display flow control status enable or disable mode...

  • Page 35: Port Statistics

    NH-800SP 8 PORTS Managed HPNA IP DSLAM USER’S MANUAL Ver_B2 User can see single port counter as follows 4.2.2.3. Port Statistics 1. The following information provides a view of the current status of the unit , A screen is displayed as shown in Figure 4.2.2.3.

  • Page 36: Administrator

    NH-800SP 8 PORTS Managed HPNA IP DSLAM USER’S MANUAL Ver_B2 4.2.2.4. Administrator Administrator Select the “ ”. The menu below will be used frequently. It includes the sub-menus as follows. IP address Switch setting Console port information Port controls Link aggregation...

  • Page 37: Ip Address

    NH-800SP 8 PORTS Managed HPNA IP DSLAM USER’S MANUAL Ver_B2 4.2.2.4.1. IP Address 1.User can configure the IP Settings and fill in the new value, than clicks apply button. 2.User must be reset IP Dslam and use new IP address to browser this web management.

  • Page 38: Switch Setting

    NH-800SP 8 PORTS Managed HPNA IP DSLAM USER’S MANUAL Ver_B2 4.2.2.4.2. Switch Setting Basic: Description: Display the device type of name. MAC Address: The unique hardware address assigned by manufacturer Firmware Version: Display the switch’s firmware version. Hardware Version: Display the switch’s Hardware version.
  • Page 39 NH-800SP 8 PORTS Managed HPNA IP DSLAM USER’S MANUAL Ver_B2 Advanced: Miscellaneous Setting : MAC Address Age-out Time: Type the number of seconds that an inactive MAC address remains in the switch's address table. The valid range is 300~765 seconds. Default is 300 seconds.
  • Page 40 NH-800SP 8 PORTS Managed HPNA IP DSLAM USER’S MANUAL Ver_B2 Priority Queue Service settings: First Come First Service: The sequence of packets sent is depend on arrive order. All High before Low: The high priority packets sent before low priority packets.

  • Page 41: Console Port Information

    NH-800SP 8 PORTS Managed HPNA IP DSLAM USER’S MANUAL Ver_B2 Protocol Enable Setting: Enable Spanning Tree Protocol : Default recommend to enable STP. Enable Internet Group Multicast Protocol: enable IGMP protocol. VLAN Protocol: 802.1Q(Port_Based) without GVRP VLAN mode. GVRP (GARP [Generic Attribute Registration Protocol] VLAN Registration Protocol) GVRP allows automatic VLAN configuration between the switch and nodes.

  • Page 42: Hpna Speed Control And Port Enable/Disable

    NH-800SP 8 PORTS Managed HPNA IP DSLAM USER’S MANUAL Ver_B2 4.2.2.4.4. HPNA Speed Control and port Enable/Disable This page can Change each port status and speed mode State: You can disable or enable HPNA port control Speed: You can change HPNA Speed modes by 0.7Mbps, 1Mbps Change Speed procedure: a.

  • Page 43: Filter Database

    NH-800SP 8 PORTS Managed HPNA IP DSLAM USER’S MANUAL Ver_B2 4.2.2.4.5. Filter Database IGMP Snooping: The HPNA IP DSLAM supports IP multicast , you can enable IGMP protocol on web management’s switch setting advanced page, then display the IGMP snooping information in this page, you can view difference multicast group ,VID and member port in here, IP multicast addresses range from 224.0.0.0 through 239.255.255.255.
  • Page 44 NH-800SP 8 PORTS Managed HPNA IP DSLAM USER’S MANUAL Ver_B2 IGMP have three fundamental types of message as follows: Message Description A message sent from the queries (IGMP router or switch) Query asking for a response from each host belonging to the multicast group.
  • Page 45 NH-800SP 8 PORTS Managed HPNA IP DSLAM USER’S MANUAL Ver_B2 Static MAC Address: When you add a static MAC address, it remains in the switch's address table, regardless of whether the device is physically connected to the switch. This saves the switch from having to re-learn a device's MAC address when the disconnected or powered-off device is active on the network again.
  • Page 46 NH-800SP 8 PORTS Managed HPNA IP DSLAM USER’S MANUAL Ver_B2 Port Security: A port in security mode will be “locked” without permission of address learning. Only the incoming packets with SMAC already existing in the address table can be forwarded normally. User can disable the port from learning any new MAC addresses, then use the static MAC addresses screen to define a list of MAC addresses that can use the secure port.enter the settings, then click Submit...
  • Page 47 NH-800SP 8 PORTS Managed HPNA IP DSLAM USER’S MANUAL Ver_B2 MAC filtering: MAC address filtering allows the switch to drop unwanted traffic. Traffic is filtered based on the destination addresses. For example, if your network is congested because of high utilization from one MAC address, you can filter all traffic...

  • Page 48: Vlan Configuration

    NH-800SP 8 PORTS Managed HPNA IP DSLAM USER’S MANUAL Ver_B2 4.2.2.4.6. VLAN configuration A Virtual LAN (VLAN) is a logical network grouping that limits the broadcast domain. It allows you to isolate network traffic so only members of the VLAN receive traffic from the same VLAN members. Basically, creating a VLAN from a switch is logically equivalent of reconnecting a group of network devices to another Layer 2 switch.
  • Page 49 NH-800SP 8 PORTS Managed HPNA IP DSLAM USER’S MANUAL Ver_B2 Figure 4.2.2.4.7 VLAN application diagram...
  • Page 50 NH-800SP 8 PORTS Managed HPNA IP DSLAM USER’S MANUAL Ver_B2 Basic Create a VLAN and add tagged member ports to it. 1. From the main menu, click administrator -- VLAN configuration. 2. Click Add 3. Type a name for the new VLAN.
  • Page 51 NH-800SP 8 PORTS Managed HPNA IP DSLAM USER’S MANUAL Ver_B2 Port VID Configure port VID settings From the main Tag-based (IEEE 802.1Q) VLAN page, click Port VID Settings. Port VID (PVID) Sets the Port VLAN ID that will be assigned to untagged traffic on a given port. For example, if port 10's Default PVID is 100, all untagged packets on port 10 will belong to VLAN 100.
  • Page 52 NH-800SP 8 PORTS Managed HPNA IP DSLAM USER’S MANUAL Ver_B2 HPNA SWITCH have two ingress filtering rule as follows : Ingress Filtering Rule 1 :Forward only packets with VID matching this port's configured VID Ingress Filtering Rule 2 :Drop Untagged Frame...

  • Page 53: Spanning Tree

    NH-800SP 8 PORTS Managed HPNA IP DSLAM USER’S MANUAL Ver_B2 4.2.2.4.7. Spanning Tree The Spanning-Tree Protocol (STP) is a standardized method (IEEE 802.1d ) for avoiding loops in switched networks. When STP enabled, to ensure that only one path at a time is active between any two nodes on the network.
  • Page 54 NH-800SP 8 PORTS Managed HPNA IP DSLAM USER’S MANUAL Ver_B2 3. Please setting new value for STP parameters , and click Apply button. Parameter Description You can change priority value, A value used to identify the root bridge. The bridge with the lowest value has the highest priority and Priority is selected as the root.
  • Page 55 NH-800SP 8 PORTS Managed HPNA IP DSLAM USER’S MANUAL Ver_B2 4.The following parameter can be configured on each port , click set Apply button to modify . Parameter Description You can make it more or less likely to become the root port, the...

  • Page 56: Port Sniffer

    NH-800SP 8 PORTS Managed HPNA IP DSLAM USER’S MANUAL Ver_B2 4.2.2.4.8. Port Sniffer The Port Sniffer is a method for monitor traffic in switched networks. Traffic through ports can be monitored by one specific port. That is, traffic goes in or out monitored ports will be duplicated into sniffer port.

  • Page 57: Snmp

    NH-800SP 8 PORTS Managed HPNA IP DSLAM USER’S MANUAL Ver_B2 4.2.2.4.9. SNMP Any Network Management running the simple Network Management Protocol (SNMP) can management the switch, Provided the Management Information Base (MIB) is installed correctly on the management station. The SNMP is a Protocol that governs the transfer of information between management and agent.
  • Page 58 NH-800SP 8 PORTS Managed HPNA IP DSLAM USER’S MANUAL Ver_B2 Read only: Enables requests accompanied by this string to display MIB-object information. Read write: Enables requests accompanied by this string to display MIB-object information and to set MIB objects. 3. Trap Manager A trap manager is a management station that receives traps, the system alerts generated by the switch.

  • Page 59: 4.10.Security Manager

    NH-800SP 8 PORTS Managed HPNA IP DSLAM USER’S MANUAL Ver_B2 4.2.2.4.10.Security Manager 1. Use this page; user can change web management user name and password. User name: Admin Password: 123 4.2.2.4.11. TFTP Update Firmware 1. The following menu options provide some system control functions to allow a user to update firmware and remote boot switch system: Install TFTP program and execution.
  • Page 60 NH-800SP 8 PORTS Managed HPNA IP DSLAM USER’S MANUAL Ver_B2...

  • Page 61: Configuration Backup

    NH-800SP 8 PORTS Managed HPNA IP DSLAM USER’S MANUAL Ver_B2 4.2.2.4.12. Configuration Backup TFTP Restore Configuration Use this page to set TFTP server address. You can restore EEPROM value from here, but you must put back image in TFTP server, switch will download back flash image.

  • Page 62: Reset System

    NH-800SP 8 PORTS Managed HPNA IP DSLAM USER’S MANUAL Ver_B2 4.2.2.4.13. Reset System Reset HPNA IP DSLAM to default configuration 4.2.2.4.14. Reboot Reboot the HPNA IP DSLAM in software reset...

  • Page 63: Chapter 5. Applications

    NH-800SP 8 PORTS Managed HPNA IP DSLAM USER’S MANUAL Ver_B2 Chapter 5. Applications The HPNA provides home network architecture. Transforming an apartment into a Multiple-Family Home network area, sharing a single internet account for multiple users via Router & Cable Modem, it can provide unlimited access time in the internet at a reasonable low price.
  • Page 64 NH-800SP 8 PORTS Managed HPNA IP DSLAM USER’S MANUAL Ver_B2 Used as apartment for Internet access The HPNA IP DSLAM provides a high speed, 1Mbps transmission over existing home telephone wiring over a single Internet account to provide simultaneous independent Internet access to multiple users.
  • Page 65 NH-800SP 8 PORTS Managed HPNA IP DSLAM USER’S MANUAL Ver_B2 Note: For network applications that actually require Router (e.g., Interconnecting dissimilar network types), attaching the HPNA IP DSLAM directly to a router can significantly improve overall home networking performance. High bandwidth backbone ready The IP DSLAM provides 10/100Mbps auto sensing for external trunk device (Fiber optics, Wireless Bridge, xDSL &...

  • Page 66: Appendix A: Cable Requirements

    NH-800SP 8 PORTS Managed HPNA IP DSLAM USER’S MANUAL Ver_B2 Appendix A: Cable Requirements A CAT 3, 4 or 5 UTP (unshielded twisted pair) cable is typically used to connect the Ethernet device to the modem. A 10Base-T cable often consists of four pairs of wires, two of which are used for transmission. The connector at the end of the 10Base-T cable is referred to as an RJ-45 connector and it consists of eight pins.
  • Page 67 NH-800SP 8 PORTS Managed HPNA IP DSLAM USER’S MANUAL Ver_B2 Figure A-2 Pin Assignments and Wiring for an RJ-45 Straight-Through Cable Figure A-3 Pin Assignments and Wiring for an RJ-45 Crossover Cable...
  • Page 68 NH-800SP 8 PORTS Managed HPNA IP DSLAM USER’S MANUAL Ver_B2 TIP: 1. Verify that the cable type is correct. Be sure RJ-45 cable connectors are securely seated in the required ports. Use 100Ω straight-through cables for all standard connections. Use Category 5 cable for 100Mbps Fast Ethernet connections, or Category 3, 4 or 5 cables for standard 10Mbps Ethernet connections.
  • Page 69 NH-800SP 8 PORTS Managed HPNA IP DSLAM USER’S MANUAL Ver_B2 Serial Console Interface Connector Pin Assignments The serial console interface connector is a 9-pin, RS-232 D-type, DTE connector. A null modem cable is required to connect a workstation running the Linux or Windows operating system.

  • Page 70: Appendix B: Troubleshooting

    NH-800SP 8 PORTS Managed HPNA IP DSLAM USER’S MANUAL Ver_B2 Appendix B: Troubleshooting Diagnosing HPNA Indicators The HPNA can be easily monitored through its comprehensive panel indicators. These indicators assist the network manager in identifying problems the 8 ports HPNA IP DSLAM may encounter. This section describes common problems you may encounter and possible solutions.
  • Page 71 NH-800SP 8 PORTS Managed HPNA IP DSLAM USER’S MANUAL Ver_B2 Check the adapter on the attached device and cable connections for possible defects. Replace the defective adapter or cable if necessary. I had a HPNA link and the data transmission was OK. After disconnection & change another port, I got link 3.

  • Page 72: System Diagnostics

    NH-800SP 8 PORTS Managed HPNA IP DSLAM USER’S MANUAL Ver_B2 enjoy internet service, you must change a Router with higher session numbers to overcome that. System Diagnostics Power and Cooling Problems If the POWER indicator does not turn on when the power cord is plugged in, you may have a problem with the power outlet, power cord, or internal power supply as explained in the previous section.
  • Page 73 NH-800SP 8 PORTS Managed HPNA IP DSLAM USER’S MANUAL Ver_B2 that will support auto-negotiation. Physical Configuration If problems occur after altering the network configuration, restore the original connections, and try to track the problem down by implementing the new changes, one step at a time. Ensure that cable distances and other physical aspects of...

  • Page 74: Appendix C: V-Lan Set Up Example

    NH-800SP 8 PORTS Managed HPNA IP DSLAM USER’S MANUAL Ver_B2 Appendix C: V-LAN Set up example Web management Administrator Switch settings Advanced: protocol setting VLAN Operation Mode: Select “Port_Based”...
  • Page 75 NH-800SP 8 PORTS Managed HPNA IP DSLAM USER’S MANUAL Ver_B2 Web management Administrator Switch settings Vlan Configuration:...
  • Page 76 NH-800SP 8 PORTS Managed HPNA IP DSLAM USER’S MANUAL Ver_B2 Add VLAN Group 1, member: port 1 and port 9...

  • Page 77: Appendix D: Compliance And Safety Information

    NH-800SP 8 PORTS Managed HPNA IP DSLAM USER’S MANUAL Ver_B2 Appendix D: Compliance and Safety Information FCC Radio Frequency Interference Statement This equipment has been tested and found to comply with the limits for a computing device, pursuant to Part 15 of FCC class B rules.
  • Page 78 NH-800SP 8 PORTS Managed HPNA IP DSLAM USER’S MANUAL Ver_B2 proper functioning of your equipment. If they do, you will be notified in advance in order for you to make necessary modifications to maintain uninterrupted service. This equipment may not be used on coin service provided by the telephone company. Connection to party lines is subject to state tariffs.
  • Page 79 NH-800SP 8 PORTS Managed HPNA IP DSLAM USER’S MANUAL Ver_B2 CE Mark Warning This is a class A product. In a domestic environment, this product may cause radio interference in which case the user may be required to take adequate measures.

  • Page 80: Warranty

    NH-800SP 8 PORTS Managed HPNA IP DSLAM USER’S MANUAL Ver_B2 Warranty The original owner that the product delivered in this package will be free from defects in material and workmanship for one year parts after purchase. There will be a minimal charge to replace consumable components, such as fuses, power transformers, and mechanical cooling devices.

  • Page 81: Chinese Sj/T 11364-2006

    NH-800SP 8 PORTS Managed HPNA IP DSLAM USER’S MANUAL Ver_B2 Chinese SJ/T 11364-2006 有 毒 有 害 物 质 或 元 素 部件名称 铅(Pb) 汞(Hg) 镉(Cd) 六价铬[Cr(VI)] 多溴联苯(PBB) 多溴二苯醚(PBDE) 结构壳体 ○ ○ ○ ○ ○ ○ 电路组 ○ ○ ○...
