SALEEN SERIES VI SUPERCHARGER FOR 2005-07 MUSTANG
MAINTENANCE SCHEDULE
Very little maintenance is required for your Series VI supercharger. There are two key
fluids involved in the kit which you should pay attention to. Please hold on to the
installation manual for the supercharger kit to aid in the location and identification of the
components
1. The oil in the front (gear case) of the supercharger is refilled via a brass plug on the
driver's side. The plug is underneath the water crossover of a completely installed kit. The
supercharger takes a full pint of oil. The oil that the supercharger is delivered with will last
50,000 miles. A 5W-50 oil may be substituted but will need to be changed every 5000
miles. When changing the oil, be sure to completely siphon all of the oil out of the gear
case.
2. The supercharger kit comes complete with an independent coolant system. Regularly
check the fluid level of the intercooler system. The fluid should reach the bottom of the
neck of the recovery tank when the system is cold. With the water pump on (key on or car
on), check as often as every couple of oil changes that the fluid is circulating. If it is not,
purge the system per the instructions in the supercharger installation manual.
Change the fluid in the intercooler system as often as the radiator fluid is changed, using a
50/50 mix of antifreeze and water.
If you have any questions, please call Saleen at 248-743-4800.
*note: there is no warranty on the supercharger in the aftermarket unless supplied by the
installer.
Advertisement
Table of Contents
Related Manuals for Saleen VI Series
Summary of Contents for Saleen VI Series
-
Page 1: Maintenance Schedule
Change the fluid in the intercooler system as often as the radiator fluid is changed, using a 50/50 mix of antifreeze and water. If you have any questions, please call Saleen at 248-743-4800. *note: there is no warranty on the supercharger in the aftermarket unless supplied by the... - Page 2 • Saleen-programmed PCMs have a unique “PCM ID” number. This number can be found on the Saleen label affixed to the PCM or it can be looked up using a diagnostic tool (IDS, WDS, or NGS; for 2005 and newer vehicles [except S7] always use IDS if available).
- Page 3 An easy field test for a supercharged vehicle is to compare it to an equivalent Saleen supercharged vehicle. If you have any questions, please feel free to contact us at 248-743-4800.
- Page 4 SERVICE FOR WARRANTY Remove only the complete manifold assembly as shown below for warranty returns and repairs. Fuel rails and injectors need not be completed. NEVER DISASSEMBLE ANY PART OF THE CORE SUPERCHARGER UNIT AS THIS WILL VOID ANY EXPLICIT OR IMPLIED WARRANTY. Check supercharger oil level here...
- Page 5 Check supercharger oil level here 1. Belt routing diagram, 2005-07 S281 SC. (Figure 1) 2. S331 SC belt routing, Figure 2. 3. Tamper-proof pulley seal; DO NOT REMOVE UNDER ANY CIRCUMSTANCE! Figure 1...
- Page 6 Figure 2 1. The coolant for the supercharger’s intercooler system should reach the bottom of the neck for the recovery tank. S281 recovery tank (Figure XX) S331 recovery tank (Figure XY) 2. The water pump on the S281 will operate with the key in the accessory position (Position II).
- Page 7 115.Remove the pressure test tool, and refill the recovery tank to the cold fill range with the 50/50 water/anti- freeze mix. (FIGURE 98) 116.Install the radiator recovery tank cap. 117.Cap off the inlet to the intercooler recovery tank using a short piece of ¾”...
- Page 8 Figure 100 Figure 101 123.Remove pressure tool from the tank and fill tank with an 80/20 water/anti- freeze mix, to 1” from the top. 124.Install the intercooler tank cap 00- 2001-C09994* onto the tank. (Topmost arrow in FIGURE 104) 125.Attach the water pump timer 178-372 to the inside of the passenger side front fender with two strips of double sided tape.
- Page 9 w.p. timer Figure 105 Figure 104...
