SMSC MediaLB Analyzer Hardware Manual

Medialb analyzer

Advertisement

Quick Links

Multimedia and Control
Networking Technology
MediaLB Analyzer
Hardware Manual
MediaLB Monitor USB V1.0.1
3-pin Active-Pod Low Speed V1.0.1
6-pin Active-Pod High Speed V1.0.0
Document Information
Version: V2.0.X-2
Date: 2008-12-17
®
MOST
Media Oriented Systems Transport
*X13186*
Copyright © 2008 SMSC

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MediaLB Analyzer and is the answer not in the manual?

Questions and answers

Summary of Contents for SMSC MediaLB Analyzer

  • Page 1 Multimedia and Control Networking Technology MediaLB Analyzer Hardware Manual MediaLB Monitor USB V1.0.1 3-pin Active-Pod Low Speed V1.0.1 6-pin Active-Pod High Speed V1.0.0 Document Information Version: V2.0.X-2 Date: 2008-12-17 ® MOST Media Oriented Systems Transport *X13186* Copyright © 2008 SMSC...
  • Page 2: Further Information

    In no event shall SMSC be liable for any direct, incidental, indirect, special, punitive, or consequential damages; or for lost data, profits, savings or revenues of any kind;...
  • Page 3 MediaLB Analyzer Hardware Manual MediaLB Analyzer Hardware Manual Copyright © 2008 SMSC All rights reserved Copyright © 2008 SMSC Hardware Manual Page 3 Document Version: V2.0.X-2 Date: 2008-12-17...
  • Page 4 Hardware Manual Document History Version Date Section Comment on changes V2.0.X-2 2008-12-17 Totally revised New: 6-pin Active-Pod for High Speed MediaLB Debug Header V1.0.X-1 2008-07-16 First version Hardware Manual Copyright © 2008 SMSC Page 4 Document Version: V2.0.X-2 Date: 2008-12-17...
  • Page 5: Table Of Contents

    Pin-Out MediaLB Connectors for 6-pin High Speed MediaLB Debug Header....22 4.2.2 Specifications........................22 APPENDIX A: LIST OF FIGURES ....................... 24 APPENDIX B: LIST OF TABLES ......................25 APPENDIX D: INDEX ........................... 26 Copyright © 2008 SMSC Hardware Manual Page 5 Document Version: V2.0.X-2 Date: 2008-12-17...
  • Page 6 MediaLB Analyzer Hardware Manual Hardware Manual Copyright © 2008 SMSC Page 6 Document Version: V2.0.X-2 Date: 2008-12-17...
  • Page 7: Preface

    Hardware Manual 1 Preface 1.1 Intended Use This SMSC product is intended to be used for developing, testing or analyzing MediaLB and MOST based multimedia products and systems by persons with experience in developing multimedia devices. The operation of this SMSC product is only admitted with original SMSC devices, e.g., provided power supply.
  • Page 8: Term Definitions

    Definitions Active-Pod Part of the MediaLB Analyzer. It is a small housing that is directly connected to the MediaLB Debug Header of the DUT. It buffers the MediaLB signals and transfers them to the MediaLB Monitor without compromising the signal integrity.
  • Page 9: Introduction

    Hardware Manual 2 Introduction The MediaLB Analyzer is a tool defined by a combination of hardware and software components designed to allow observation and visualization of MediaLB data in a comfortable way. The MediaLB Analyzer consists of the following main modules: Hardware Modules •...
  • Page 10: Features

    MediaLB Analyzer Hardware Manual 2.1 Features The MediaLB Analyzer hardware modules provide the following features: • MediaLB Monitor Streaming capable USB2.0 High Speed interface MediaLB Clock-Activity, Speed, and Lock Detection 256 MByte RAM for data buffering Compact housing High Speed Trigger Input •...
  • Page 11: Medialb Monitor

    The trigger event is generated upon the transition of logical low level to logical high level. For details about characteristic values refer to section 3.3.3 on page 16. Figure 3-2: High Speed Trigger Characteristic Copyright © 2008 SMSC Hardware Manual Page 11...
  • Page 12: Trigger

    MediaLB Monitor device OptoLyzer Suite. MediaLB Monitor USB driver is not Consider reinstallation of the OptoLyzer Suite. installed or not loaded properly. Table 3-3: Red Ready LED Hardware Manual Copyright © 2008 SMSC Page 12 Document Version: V2.0.X-2 Date: 2008-12-17...
  • Page 13: Lock Led

    3072 4096 6144 8192 Table 3-5: MediaLB Speed 3.1.6 Active-Pod Connector The Active-Pod connector has to be connected with the respective Active-Pod via the delivered Active-Pod cable. Copyright © 2008 SMSC Hardware Manual Page 13 Document Version: V2.0.X-2 Date: 2008-12-17...
  • Page 14: Rear Panel

    It is mandatory to connect this connector with a USB 2.0 High Speed connector on the Notice PC! Check it in the Device Manager. If the Device Manager shows an Enhanced USB Host Controller, the connector has USB 2.0 High Speed capability. Hardware Manual Copyright © 2008 SMSC Page 14 Document Version: V2.0.X-2 Date: 2008-12-17...
  • Page 15: Power Supply

    Type: Binder, serial 718 Figure 3-4: Power Connector (Rear Panel) The table shows the pin assignment of the power connector. Description Power Reserved Table 3-6: Power Supply Connector Copyright © 2008 SMSC Hardware Manual Page 15 Document Version: V2.0.X-2 Date: 2008-12-17...
  • Page 16: Specifications

    Will be activated in a later version of MediaLB Monitor. Trigger output voltage (high/low level) Will be activated in a later version of MediaLB Monitor. Table 3-9: DC Characteristics Hardware Manual Copyright © 2008 SMSC Page 16 Document Version: V2.0.X-2 Date: 2008-12-17...
  • Page 17: Mechanical Characteristics

    3.3.4 Mechanical Characteristics • Protection Rating: IP 42 • Dimensions: MediaLB Monitor: 113 / 82 / 32 mm (L / W / H) USB cable: Active-Pod cable: 40 cm Copyright © 2008 SMSC Hardware Manual Page 17 Document Version: V2.0.X-2 Date: 2008-12-17...
  • Page 18: Active-Pods

    Pin 1 Front View Rear View MediaLB Connector B Pin 1 MediaLB Connector A Bottom View Figure 4-1: 3-pin Active-Pod Low Speed - Connectors and Status LED Hardware Manual Copyright © 2008 SMSC Page 18 Document Version: V2.0.X-2 Date: 2008-12-17...
  • Page 19: Pin-Out Medialb Connectors A And B For 3-Pin Low Speed Medialb Debug Header

    Table 4-2: 3-pin Active-Pod Low Speed – Status LED Interpretation Since the DUT detection pin detects the connection to MediaLB, it is important that the pin 5 on DUT is connected to ground. Copyright © 2008 SMSC Hardware Manual Page 19...
  • Page 20: Specifications

    Table 4-5: 3-pin Active-Pod for Low Speed MediaLB Debug Header DC Characteristics 4.1.3.4 Mechanical Characteristics • Protection Rating: IP 42 • Dimensions: Active-Pod: 56 / 37 / 25 mm (L / W / H) Active-Pod cable: 40 cm Hardware Manual Copyright © 2008 SMSC Page 20 Document Version: V2.0.X-2 Date: 2008-12-17...
  • Page 21: 6-Pin Active-Pod For High Speed Medialb Debug Header

    MediaLB Monitor USB delivery! Figure 4-2: 6-pin Active-Pod High Speed – Active-Pod Connector Figure 4-3: 6-pin Active-Pod High Speed - MediaLB Connector Copyright © 2008 SMSC Hardware Manual Page 21 Document Version: V2.0.X-2 Date: 2008-12-17...
  • Page 22: Pin-Out Medialb Connectors For 6-Pin High Speed Medialb Debug Header

    On DUT this pin has to be connected to 3.3 VCC. 4.2.2 Specifications 4.2.2.1 Absolute Maximum Ratings Parameter Unit MediaLB signal voltage -0.4 Operating (ambient) temperature °C Storage temperature °C Table 4-7: Absolute Maximum Ratings Hardware Manual Copyright © 2008 SMSC Page 22 Document Version: V2.0.X-2 Date: 2008-12-17...
  • Page 23 4.2.2.4 Mechanical Characteristics • Protection Rating: IP 42 • Dimensions: Active-Pod (High Speed): 35 / 22 / 8 mm (L / W / H) Active-Pod cable: 40 cm Copyright © 2008 SMSC Hardware Manual Page 23 Document Version: V2.0.X-2 Date: 2008-12-17...
  • Page 24: Appendix A: List Of Figures

    MediaLB Analyzer Hardware Manual Appendix A: List of Figures Figure 2-1: MediaLB Analyzer Overview....................9 Figure 3-1: MediaLB Monitor - Front Panel ................... 11 Figure 3-2: High Speed Trigger Characteristic..................11 Figure 3-3: MediaLB Monitor - Rear Panel.................... 14 Figure 3-4: Power Connector (Rear Panel)................... 15 Figure 4-1: 3-pin Active-Pod Low Speed - Connectors and Status LED ..........
  • Page 25: Appendix B: List Of Tables

    Table 4-7: Absolute Maximum Ratings ....................22 Table 4-8: Recommended Operating Conditions .................. 23 Table 4-9: 3-pin Active-Pod for High Speed MediaLB Debug Header DC Characteristics....23 Copyright © 2008 SMSC Hardware Manual Page 25 Document Version: V2.0.X-2 Date: 2008-12-17...
  • Page 26: Appendix D: Index

    Trigger..............8, 12 Lock............... 13 MediaLB Speed ..........13 USB 2.0 High Speed Connector....... 14 Ready............12 USB Host Controller ..........14 Status ............19 Legend ............... 2 Hardware Manual Copyright © 2008 SMSC Page 26 Document Version: V2.0.X-2 Date: 2008-12-17...
  • Page 27 MediaLB Analyzer Hardware Manual Notes: Copyright © 2008 SMSC Hardware Manual Page 27 Document Version: V2.0.X-2 Date: 2008-12-17...
