# Table of contents 1) Important information 2) Safety & Precautions - Do’s and Don’ts - Limitations and Usage Precautions 3) Features 4) Specifications 5) Front and Rear Panel 6) Remote Control 7) Hard disk insertion 8) Hard disk formatting and partition - Making partition and Formatting the HDDs under Windows 98SE/ME - Making partition and formatting the HDDs under Windows 2000/XP 9) Installation and Connection...
Important Information Congratulations for having bought this product. We are sure that you will be entirely satisfied with this multi-media player. Please take some time to read thoroughly this manual of Instruction so that you can use the unit to its best possibilities. Keep carefully this instruction manual and refer to it any time when you will need it.
Safety & Precautions ▣ Do’s and Don’ts Do’s ◈Unplug the player during lightning storms or when unused for long periods of time. ◈ Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. The wide blade is provided for your safety.
Safety & Precautions ▣ Limitations and Usage Precautions Please read the following Limitations and Usage Precautions before using your Mvix player. ◈ While Mvix players support dozens of file formats and codec, they are not intended to work with every codec-variation. Mvix players provide limited support to standardized versions of codec as stated in the Technical Specifications of this manual.
Features Enjoy your Movie and Video Files on TV ! Supports a variety of digital video files like DivX® 3/4/5, Xvid, MPEG1, MPEG2, MPEG4, DVD(IFO, VOB), VCD(DAT). Ideally suited for backing up all your DVD movies on a hard-Disk for easy access.
Front and Rear Panel Front Panel STOP SETUP ON/OFF IN BROWSER Rear Panel Audio out Component out Coaxial Video out S-Video Optical USB2.0 Slave Ext.IR Power Unicorn Information System...
Remote Control 1.Power 2. Setup 3. Change the VIDEO OUT mode 4. Mute 5. Number Keys 6. Function Key 7. Goto 8. Title for DVD 9. Show the info for file playing 10. Menu for DVD 11. Navigation – Arrow Keys 12.
Hard disk insertion 1. Slide the lock toward the “UNLOCK” 2. Once unlocked, slide the top-cover as direction shown above. 3. Open the top-cover. 4. Connect the 4-pin power cable using the white plug. Take note of the shape of the power cable plug.
Page 11
Hard disk insertion 5. Connect flat IDE cable. Again examine 6. Carefully insert the HDD inside the the socket of the IDE cable. The IDE MviX case as shown above. cables socket can only be inserted in one direction. 7. Once inserted, the HDD should snugly 8.
Page 12
Hard disk insertion 9. Once secured, slide the top-cover as 10. Slide and close the lock toward the shown above “LOCK” direction Unicorn Information System...
Hard disk formatting and partition Making partition and Formatting the HDDs under Windows 98SE/ME Click “Start” and select “Run” and the “Run” window will appear as shown below. Type “fdisk” in the text box of the “Run” window then click the “OK” button 1) Select “5.
Page 14
Hard disk formatting and partition Making partition and Formatting the HDDs under Windows 98SE/ME 3) Select “1. Create DOS partition or Logical DOS Drive” and press [Enter]. 4) Select “ 1. Create Primary DOS Partition ” and press [Enter] 5) Wait until finishing verifying the drive integrity.
Page 15
Hard disk formatting and partition Making partition and Formatting the HDDs under Windows 98SE/ME 6) After finishing drive integrity verification, type “Y” at “Do you wish to use the maximum available size for a Primary DOS Partition (Y/N)” 7) Type the capacity or % which you want to use and press [Enter].
Page 16
Hard disk formatting and partition Making partition and Formatting the HDDs under Windows 98SE/ME 11) Unplug the MviX and plug again. New volume will be appeared at [My Computer]. Click mouse right button at the new volume and select [Format] Unicorn Information System...
Hard disk formatting and partition Making partition and formatting the HDDs under Windows 2000/XP The drive is initially not visible in Windows Explorer. For the drive to been seen in Windows Explorer it needs to be configured via the disk management Utility.
Page 18
Hard disk formatting and partition Making partition and formatting the HDDs under Windows 2000/XP 4. Select the appropriate Partition Type. Choose Primary partition. Primary –Normal selection for less than 4 partitions. Extended – Used for 4 or more partitions. 5. Select the Partition Size. If you want one partition, simply click “Next”.
Page 19
Hard disk formatting and partition Making partition and formatting the HDDs under Windows 2000/XP 7. Select the Partition Format. NTFS is the default format type in Windows XP, but FAT32 is popular for users that dual boot between XP and 9X. There is a limit that Windows XP cannot create a partition larger than 32 GB using FAT32.If you want the FAT32, Partition Size is limited to 32GB.
Installation and Connection Video and Audio Connections Your MviX multimedia player supports Composite, S-Video or Component connections. Depending on the capabilities of your TV, you only need to make one video connection from these options. To hear sound through your TV, use audio connectors (RCA 2-CH) to connect the MviX multimedia player to the corresponding AUDIO-IN jacks on your TV or Hi-Fi Device.
Installation and Connection Connection to Component Output Connection to 2-CH (RCA) of normal TV White, Red Cable Green, Blue, Red Cable - Connect left (white), right (red) sound - Connect the MviX media player to your TV output to the appropriate terminal of your using a component cable as shown in the TV or Hi-Fi Device using the 2-CH RCA image above.
Installation and Connection Connection to Coaxial output Connection to Optical output Optical Cable Coaxial Cable When you have a multi channel When you have a multi channel decoder/amplifier with coaxial input, you can decoder/amplifier with optical input, you can enjoy 5.1CH high quality sound through coaxial enjoy 5.1CH high quality sound via optical cable.
Installation and Connection Connection to Computer To transfer data or files from pc to your Mvix Multimedia Player. Connect MviX Multimedia Player to your computer using the USB cable (cable supplied). Ensure that your MviX player is powered- Upon connection your PC (Win-ME/2000/XP) should recognize the new USB connected drive without installing driver.
MVIX Setup Menu Audio/Video Setup NTSC/S-Video YPbPr/480i YPbPr/480p YPbPr/720p YPbPr/1080i PAL/S-Video YPbPr/PAL 1) Video Out : Supports NTSC/S-Video, YPbPr/480i, YPbPr/480p, YPbPr/720p, YPbPr/1080i, PAL/S-Video, YPbPr/PAL 2) TV Type : Supports 4 X 3 Letter Box (Ordinary TV), 16:9 (HDTVs) 3) Audio Out : Supports Analog, or Digital Audio 4) Volume : You can control the volume in the range 0~100...
MVIX Setup Menu Setup/Various Middle Large 1) Subtitle Size : You can select the subtitle font size (Normal/Large) 2) Subtitle Color : You can change the color of the subtitle and its outline (Black/White, Black/Yellow, White/Yellow) 3) Slide Period : You can set the slide show time interval (3 ~100sec) 4) Bookmark : You can turn On/Off bookmark while you playback or load a file...
MVIX Setup Menu Firmware Setup 1) Connect your MVIX to your PC with the USB cable and turn it on. 2) Your PC recognizes your MVIX as an external hard disk. 3) Create a folder ‘UPGRAD’ at the root of the hard disk. 4) Download the new firmware (on www.mvixusa.com and www.mvix.co.kr) 5) Copy the new firmware that you just have downloaded in the ‘UPGRAD’...
MVIX Setup Menu Driver installation for Windows 98SE 1) Execute the run setup file located in the installation CD supplied with the MVIX. 2) Follow the instructions on the screen. 3) Reboot your PC at the end of the installation. 4) You should see the new Hard disk in Windows explorer.
MVIX Setup Menu Video Files Playback Press several times on “Media” key on the remote control to choose multimedia files According to the type of media (Video, Audio, Picture, Mix). On Video mode, only Video Files will be visible in the current directory. 1) Select “...
MVIX Setup Menu Audio Files Playback Press several times on “Media” key on the remote control to choose multimedia files According to the type of media (Video, Audio, Picture, Mix). On Audio mode, only Audio Files will be visible in the current directory. 1) Select “...
MVIX Setup Menu Photo Files Playback Press several times on “Media” key on the remote control to choose multimedia files According to the type of media (Video, Audio, Picture, Mix). On Photo mode, only Photo Files will be visible in the current directory. 1) Select “Photo”...
MVIX Setup Menu All Files Playback Press several times on “Media” key on the remote control to choose multimedia files According to the type of media (Video, Audio, Picture, Mix). On Mix mode, only all Files will be visible in the current directory. 1) Select “Mix”...
MVIX Setup Menu Playlist With your MVIX, it is possible to create a playlist. Creation of your playlist 1) Press browser ◀ key on the remote control, so that you position yourself on the left menu. 2) Press twice on ▼ key on the remote control to select “...
Menu summary MEDIA Press several times on the “MEDIA” key on the remote control. MEDIA MEDIA MEDIA MEDIA AUTO PLAYBACK PLAYLIST Unicorn Information System...
Page 34
Menu summary SETUP AUDIO / VIDEO Video Output NTSC/S-Video YPbPr/480i YPbPr/480p YPbPr/720p YPbPr/1080i PAL/S-Video YPbPr/PAL TV Format 4 : 3 16 : 9 Audio Output Analog Digital Unicorn Information System...
Page 35
Menu summary SETUP AUDIO / VIDEO Volume Balance Unicorn Information System...
Page 36
Menu summary SETUP AUDIO / VIDEO Brightness Contrast Saturation Unicorn Information System...
Page 37
Menu summary SETUP VARIOUS SETTINGS Subtitle Size Middle Large LCD Bright Black/White Black/Yellow White/Black System Default System Default Unicorn Information System...
Page 38
Menu summary SETUP VARIOUS SETTINGS Subtitle Size English German French Spanish LCD Bright System Default Default Unicorn Information System...
Page 39
Menu summary SETUP UPGRADE 3 seconds Unicorn Information System...
Troubleshooting Under no circumstances should you try to repair the system yourself, as this will invalidate the warranty. Do not open the system as there is a risk of electric shock. If a fault occurs, first check the points listed below before taking the system for repair. 1.
Page 41
# Inhalt 1) Wichtige Hinweise 2) Wichtige Sicherheitshinweise 3) Features 4) Specifications 5) Gerätevorderseite 6) Fernbedienung 7) Installation der Festplatte 8) Festplatte formatieren und partitionieren - Festplatte unter Windows 98SE/ME formatieren und partitionieren - Festplatte unter Windows 2000/XP formatieren und partitionieren 9) Installation und Anschlüsse - Anschluss mit Composit Videokabel - Anschluss mit S-Videokabel...
Wichtige Hinweise Herzlichen Glückwunsch zum Kauf dieses Geräts. Wir versichern lhnen, dass Sie mit Diesem Multimedia-Player sehr zufrieden sein werden. Bitte lesen Sie die Bedienungsanleitung aufmerksam durch, um das Beste aus diesem Gerät heraus zu holen. Bewahren Sie die Bedienungsanleitung für späteres Nachschlagen auf. □...
Wichtige Sicherheitshinweise 1. Vergewissern Sie sich, dass das Gerät ausgeschaltet ist, wähernd Sie es an lhrem Fernseher anschließen. 2. MVIX ist so ausgelegt, dass sich das Gerät automatisch in Stand-by schaltet, während das USB-Kabel angeschlossen oder abgezogen wird. Das ist keine Fehlfunktion 3.
Features Sehen sie lhre Filme auf dem Fernseher an Sie können lhre Lieblingsfilme auf Fernseher oder Videoprojektor betrachten. MVIX kann die meisten gebräuchlichen Videoformate lesen, einschließlich MPEG1, MPEG2, AVI, DivX3.11, 4x, 5x, Xvid, DVD(IFO, VOB), VCD(DAT) nsw. Digitale Musicbox MVIX kann eine Vielzahl von Musikdateien wie AC3, MP2, MP3, DTS, WMA und OGG über Fernseher oder Audiosystem wiedergeben.
Gerätevorderseite Front Panel STOP SETUP ON/OFF IN BROWSER Rear Panel Audio out Component out Coaxial Video out S-Video Optical USB2.0 Slave Ext.IR Power Unicorn Information System...
Fernbedienung 1.Power : On/Off 2. Setup : Aufrufen der Einstellungen 3. TV OUT : Modifieren der MVIX Einstellungen 4. MUTE : Adschalten des Tons 5. Ziffernasten 6. FUNC : Kontrollfunktionen 7. GOTO : Direktauswahl eines Programms 8. TITLE : Menüs des DVD oder VCD im häuptmenu 9.
Installation der Festplatte Vorsicht : Es ist wichtig, dass das Gerät während der installation vollkommen statisch entladen ist. 1. Schieben Sie den Schalter auf 2. Nach dem Entriegeln schieben Sie die UNLOCK. obere Abdeckung in Pfeilrichtung. 3. Öffnen Sie die obere Abdeckung. 4.
Page 49
Installation der Festplatte 5. Schließen Sie das flache IDE-Kabel an. 6. Setzen Sie die Festplatte versichtig in Es kann nur in einer Richtung lhre MVIX ein. angeschlossen werden. 7. Nach dem Einsetzen Festplatte in 8. Schrauben Sie die Festplatte mit den Führungsschiene befestigen.
Page 50
Installation der Festplatte 9. Schieben Sie die Abdeckung in 10. Schieben Sie die Verriegelung auf Pfeilrichtung. LOCK Unicorn Information System...
Festplatte formatieren und partitionieren Festplatte unter Windows 98SE/ME formatieren und partitionieren Warum muss eine Festplatte formatiert werden? Beim Kauf einer neuen Festplatte ist die magnetische Oberfläche frei von jeglichen Informationen. Die Formatierung schafft die Voraussetzungen zum Speichern WICHTIGER HINWEIS: Bei der Partitionierung und Formatierung müssen Sie besonders vorsichtig sein. Bei der Durchführung nachstehender Schritte auf der Festplatte mit dem System, läuft Ihr Computer möglicherweise nnicht an.
Page 52
Festplatte formatieren und partitionieren Festplatte unter Windows 98SE/ME formatieren und partitionieren Das linke DOS Fenster erscheint. Geben Sie die Nummer der letzten Disk ein (2 im linken Bild). Danach „Enter“ Das erste DOS Fenster erscheint erneut. Diesmal wählen Sie Zeile 1 „DOS oder logische Partition erstellen“.
Page 53
Festplatte formatieren und partitionieren Festplatte unter Windows 98SE/ME formatieren und partitionieren Warten Sie das Ende der Erstellung und Überprüfung der Partition ab. Nach der Erstellung und Überprüfung der Partition auf der Festplatte wird nebenstehendes Fenster angezeigt. Geben Sie „O“ als Bestätigung der maximalen Kapayität ein.
Page 54
Festplatte formatieren und partitionieren Festplatte unter Windows 98SE/ME formatieren und partitionieren Drücken Sie ESC; eine Nachricht yum Neustart von Windows wird angezeigt. Drücken Sie ESC erneut und schreiben EXIT zur Rückkehr zu Control Line Modus, danach Enter zur Bestätigung. Ziehen Sie lhre MVIX ab und schließen sie wieder an.
Festplatte formatieren und partitionieren Festplatte unter Windows 2000/XP formatieren und partitionieren 1) Unter Windows 2000 oder XP können Sie die Festplatte mit dem Steuerungsprogramm partitionieren und formatieren. 2) Rechtsklick auf das Workstation Icon und imm Menü bearbeiten wählen. 3) Nachstehendes Fenster wird angezeigt. 4) Klicken Sie auf Disk bearbeiten.
Page 56
Festplatte formatieren und partitionieren Festplatte unter Windows 2000/XP formatieren und partitionieren Wählen Sie die gewünschte Partition. Für mehrere Partitionen wählen Sie : „Erweiterte Partition“ Wählen Sie die gewünschte Partitionsgröße. Wollen Sie nur eine Partition, dann klicken Sie „Weiter“ Wählen Sie einen Buchstaben für die Festplatte (Windows weist Ihnen einen Default-Buchstaben zu).
Page 57
Festplatte formatieren und partitionieren Festplatte unter Windows 2000/XP formatieren und partitionieren Wählen Sie „FAT32” oder „NTFS” als Format, dann Klicken Sie „Weiter“ Anmerkungen : Partitionierung unter FAT32 ist auf 32GB begrenzt. NTFS hat keine Begrenzung. Zum Abschluss klicken Sie „Fertig“ Unicorn Information System...
Installation und Anschlüsse Video und Audio Anschlüsse lhre MVIX hat einen S-Video, Composite Video und Separatem Composit Video Ausgang. Anhängig von lhrem Fernseher können Sie beliebien der beiden Anschlüsse benutzen. Audiosignale können zum Fernseher miz RCA-Kabel oder lhrer Hi-Fi Anlage mit Koaxial Kabel und optischem kabel übertragen werden.
Installation und Anschlüsse Anschluss mit separatem composit Anschluss mit zwel RCA-Kabein videokabel RCA-Kabel Separatem Composit Videokabel -Schließen Sie das linke RCA-Kabel(weiß) -Schlie-en Sie lhre MVIX mit dem separaten an lhren Fernseher oder lhre Hi-Fi Anlage Componentkabel (nicht mitgeliefert) an lhrem an (mitgeliefert).
Installation und Anschlüsse Digitaler Audioanschluss mit Digitaler Audioanschluss mit Koaxialkabel optischem Kabel Optisches Kabel Koaxial- kabel Benutzen Sie einen Verstärker/Decoder mit Benutzen Sie einen Verstärker/Decoder mit digitalem koaxialem Eingang, dann können Sie digitalem optischem Eingang, dann können den 5,1-Kanal Sound voll ausschöpfen. Obige Sie den 5,1-Kanal Sound voll ausschöpfen.
Installation und Anschlüsse Anschluss am computer USB-Kabel Zur Übertragung von Informationen oder Dateien schließen Sie lhre MVIX mit USB-Kabel am Computer an. Vergewissern Sie sich, ob lhr MultimediaßPlayer eingeschaltet ist. Sobald der Anschluss hergestellt ist, registriert lhr Computer (unter Windows ME/2000/XP) MVIX als neuen Massenspeicher(Festplatte muss formatiert sein, Windows 98SE benötigt Treiber).
MVIX Menü Audio/Video Setup SETUP MENÜ: Rufen Sie die Funktion mit SETUP auf der Fernbedienung auf, hier können Sie alle Einstellungen lhrer MVIX vornehmen. Audio-und Video-Einstellungen. Die erste Optin im SETUP sind Audio und Video. NTSC/S-Video Video-Ausgabe PAL/S-Video YPbPr/480i TV-Format 4 : 3 YPbPr/480p YPbPr/720p...
MVIX Menü Setup/Sonstige SONSTIGE EINSTELLUNGEN : In SETUP navigieren Sie mit ▼ zu den Sonstigen Einstellungen. 1) Größe der Untertitel Hier können Sie die Größe der Untertitel einstellen (mittel, groß) Mittel Unterlitelgröße Mittel Groß Untertitelfarbe Schwary/Weiß Bildgeschwindigkeit Leseyerchen Sprache Deutsch LCD Helligkeit Werkseinstellung Werkseinstellung...
MVIX Menü Firmware Update Firmware-Info Version 3.28 Date Fri Nov 11 15:27:16 Firmware-Update Info Dateiname upgrade/uni_1_28.bin Dateistatus Mise jour dispolb Version 3.28 Date Fri Nov 11 15:27:17 Firmware upgraden Drucken Sie mindestens 3 Sekunden OK Firmware-Info Version Date Firmware wird aktualisiert... Warten Sie bis der Vorgang beendet is 1) Schließen Sie lhre MVIX über USB-Kabel an lhrem PC an und schalten sie ein.
MVIX Menü Treiber-Installation für Windows 98SE 1) Starten Sie die mitgelieferte Installations - CD 2) Folgen Sie den Bildschirmanweisungen. 3) Am Ende der Installation starten Sie Ihren PC erneut. 4) In Windows Explorer wird Ihre neueFestplatte angezeigt. Treiber-Installation für Windows ME/XP/2000 1) Windows ME/XP/2000 hat den Treiber bereits installiert.
MVIX Menü Wiedergabe von Videodateien Wählen Sie eine Datei mit mehrfachem Tastendruck auf MEDIA auf Ihrer Fernbedienung Aus (Video, Audio, Bild, Mix). In Videomodus werden nur Videodateien im Verzeichnis angezeigt. Mes Films Le jour le plus long Les Bronzs Un coin perdu Midien Auto Wiedergabe Playlist...
MVIX Menü Wiedergabe von Audiodateien Wählen Sie eine Datei mit mehrfachem Tastendruck auf MEDIA auf Ihrer Fernbedienung Aus (Video, Audio, Bild, Mix). In Audiomodus werden nur Audiodateien im Verzeichnis angezeigt. Ma musique Just Want You To Know La isla bonita Ne me quitte pas These Hazel Eyes Midien...
MVIX Menü Wiedergabe von Bilddateien Wählen Sie eine Datei mit mehrfachem Tastendruck auf MEDIA auf Ihrer Fernbedienung Aus (Video, Audio, Bild, Mix). In Bildmodus werden nur Bilddateien im Verzeichnis angezeigt. Mes photos La Tour Eiffel Le Louvre Les Champs Elzsées Mon chien Midien Auto Wiedergabe...
MVIX Menü Wiedergabe aller Dateien Wählen Sie eine Datei mit mehrfachem Tastendruck auf MEDIA auf Ihrer Fernbedienung Aus (Video, Audio, Bild, Mix). In Mixmodus werden alle Dateien im Verzeichnis angezeigt. Le jour le plus long Les Bronzs Just Want You To Know La isla bonita Les Champs Elzsées Midien...
Page 70
MVIX Menü Playlist Mit Ihrer MVIX können Sie Playlisten selbst zusammenstellen. 1) Zum Aufrufen des linken Menüs drücken Sie ◀ Mes photos 2) Mit zweifachem Tastendruck auf ▼ La Tour Eiffel wählen Sie Plazliste und bestätigen Le Louvre mit OK Les Champs Elzsées Mon chien Midien...
Zusammenfassung Menü Media Mehrfacher Tastendruck auf MEDIA auf der Fernbedienung. Mes Films Ma musique Mes photos MEDIA MEDIA Just Want You To Know La Tour Eiffel Le jour le plus long La isla bonita Le Louvre Les Bronzs Un coin perdu Ne me quitte pas Les Champs Elzsées Midien...
Page 77
Zusammenfassung Menü SETUP UPGRADE Firmware-Info Version 3.28 Date Fri Nov 11 15:27:16 Firmware-Update Info Dateiname upgrade/uni_1_28.bin Dateistatus Mise jour dispolb Version 3.28 Date Fri Nov 11 15:27:17 Firmware upgraden Drucken Sie mindestens 3 Sekunden OK Für 3 Sekunden Firmware-Info Version Date Firmware wird aktualisiert...
Troubleshooting Problem Lösungsvorschlag 1. Richten Sie die Fernbedienung direkt auf den Empfangssensor vorn auf Ihrer MVIX aus. MVIX reagiert nicht auf 2. Gehen Sie dichter an Ihre MVIX heran. Die Fernbedienung 3. Tauschen Sie die Batterien der Fernbedienung aus. 4. Setzen Sie die Batterien mit der richtigen Polarität ein. Die Tasten arbeiten Stellen Sie das Gerät durch Ziehen des Netzsteckers für 10 Sekunden nicht korrekt...
※ Limited Warranty Your Mvix Wireless Hi-Definition Multimedia Player comes LIMITATION OF LIABILITY AND REMEDY... with a full 1-yr manufacturer’s warranty on parts and labor. UNICORN or ITS DISTRIBUTORS ARE NOT LIABLE The Warranty coverage on this player begins the day you buy UNDER ANY CIRCUMSTANCES FOR ANY DIRECT, your product.
