RotorSport MTOsport Maintenance Manual

Gyroplanes
Hide thumbs
Table of Contents

Advertisement

Quick Links

Copyright of RotorSport UK Ltd

Maintenance Manual

Gyroplane Type MTOsport (UK spec only)
RotorSport UK Ltd
Phone: +44 (0) 1588 650769
Fax: +44 (0) 1588 650769
Email:
STATEMENT OF INITIAL CERTIFICATION
This manual complies with British Civil Airworthiness Requirements,
CAP553 Section A, Chapter A5–3.
CAA Approval No: DAI/9917/06
Document number RSUK0044
Poplar Farm
Prolley Moor
Wentnor
Bishops Castle
SY9 5EJ
Company Reg No 5486550
info@rotorsport.org
Gerry Speich
Jun 6 2012 12:35 PM
Signed .................................
Page 1 of 80
Page issue 6, dated 20.03.12
