Cobra iRadar S120R User Manual

Thank you for purchasing the Cobra iRadar S120R
for iPhone, the world's first connected radar/laser
S120R
detector.
For iPhone
iRadar S120R uses Bluetooth® wireless
technology to connect your iPhone®/iPod Touch®
to display radar, laser and speed camera alerts.
Follow these simple steps to get your
iRadar S120R up and running.
Cobra iRadar is made for
iPod touch (4th Generation)
iPhone 4S
iPhone 4
iPhone 3GS
NOTE: Location-based alerts and GPS settings
available only with iPhone. Only radar/laser alerts
and settings will work with iPod touch.
Trademark Acknowledgement
User Guide
Cobra ® and the snake design are registered trademarks of Cobra Electronics
Corporation, USA.
iPhone ® and iPod ® touch are trademarks of Apple, Inc, registered with the U.S. and other countries.
The Bluetooth ® word mark is a registered trademark owned by Bluetooth SIG, Inc. and any use of such marks by Cobra
Electronics Corporation is under license. Other trademarks and trade names are those of their respective owners.
S120 User Guide iPhone.indd 1
What's in the box? Setting Up iRadar S120R
Cobra iRadar S120R The S120R has been designed to be mounted
Mounting bracket under the bonnet, behind the vehicle's grille or
Screw, nut & bolt pack within an air intake at the front of the vehicle if
Cable-tie fasteners appropriate using the 'L' shaped bracket and screw
pack provided.
Find a suitable mounting position for the detector,
ensuring that the front of the unit has a clear
view of the road ahead and is unobstructed by
any metallic objects and that there is a sufficient
mounting area to attach the 'L' shaped fixing
bracket. The S120R needs to be mounted in as
horizontal a position as possible so that it is looking
directly down the road ahead.
We recommend that you mount the detector either
behind the vehicle's grille (if the openings of the
grille are at least 10mm in diameter) or within an air
intake at the front of the vehicle. The S120R can be
mounted anywhere at the front of the vehicle, but
for optimum performance we suggest you mount
it as close to the number plate of the vehicle as
possible.
Typical Fitting Typical Fitting
Typical Fitting
10mm
Minimum
Typical Fitting
When you have found a suitable location, using
the 'L' shaped mounting bracket as a template,
Mounting Notes
drill between 2 and 4 pilot holes into the selected
When mounting and connecting the power cables
mounting surface for attaching the bracket using
of the S120R always ensure that you mount the
either the self-tapping screws or the nuts and bolts
unit and cables away from any moving parts
provided.
such as air-cooling fans or the fan belt. Always
You will need to attach the bracket using at least
position the unit so that device and power cables
2 screws or 2 nuts and bolts to ensure that the
do not interfere with any moving parts within the
bracket is well secured. Remember that there is a
engine compartment or interfer with any part
lot of vibration within the engine compartment
of the vehicle that could endanger you or your
so it is very important that the S120R mounting
Typical Fitting passengers. Please check that all surfaces are safe
bracket is secured correctly.
to drill through before beginning any work.
Connecting the iRadar S120R
The S120R is powered by wiring it directly to your
vehicles 12v electrical system using the cable
supplied Firstly connect the positive side of the
cable (Red) to a switched 12v ignition supply.
This is a live that is On when the ignition is
switched On and Off when the ignition is Off.
The negative side of the lead (black) should
be connected to a negative ground, so can be
attached to any metal portion of the vehicles
frame. The LED will blink red if the power
connection has been completed successfully. This
LED can be located near to the point where the
power cable enters the rear of the device.
It is not advisable to connect the S120R directly
to the vehicle battery as after long periods
of vehicle inactivity the vehicle battery may
become discharged.
