VES Andover Ltd Eagle Close Chandlers Ford Ind. Est Eastleigh Hampshire SO53 4NF
Tel: 08448 156060 Fax: 02380 261204 E-mail: vesltd@ves.co.uk Web: www.ves.co.uk
Installation, Operation and Maintenance Manual
Important
This manual must be read in full before Installation, Operation and Maintenance of the units supplied
Please ensure that this document is passed to the end user. This manual forms an integral part of the
product and should be kept for the working life of the product. Additional copies of this and supporting
documents are available by contacting VES or by visiting www.ves.co.uk and following the 'Download
O & M's' link.
The following symbols used within this document refer to potential dangers, advice for safe operation or
important points of reference
Warning
Indicates hazards associated with electric current and high voltages
Caution
Indicates hazards that require safety advice for personnel or potential unit/property damage
Important
Indicates important information
Contents
1
Introduction
2
Nomenclature
3
Receipt of Goods & Handling
4
Installation
5
Standard Wiring & Fan Installation
6
Maintenance
7
Declaration of Conformity
8
Extended Warranty
Introduction
1
The Ecovent® EVX series is a range of Heat Recovery units, with duties up to 2.5 m³/s. Suitable for
either plantroom, ceiling void or external locations. As standard, each unit will have been supplied
pre-wired to an isolator or fitted control panel, as specified at the time of order.
The standard operating temperature of these units is -20 to +35°C.
For further technical details regarding dimensions and weights, contact VES on 08448 15 60 60,
quoting the sales order (SO) number and the unit type as found on the unit nameplate, or
alternatively visit www.ves.co.uk.
®
Heat Recovery Unit
page
1
2
3
3
6
13
15
1
ORIGINAL INSTRUCTIONS
VES Ref. ID.986
Issue F
August 2014
