Atop Fast Ethernet Media Converter series User Manual

Fast Ethernet Media Converter

1 UTP Port & 1 Optical Port
User's Manual
ATOP TECHNOLOGY
Tel: +86-755-86674946
Fax: +86-755-89314286
Email: sales@atoptechnology.com
Web: www.atoptechnology.com
FCC Warning
The 10/100M Fast Ethernet Media Converter series
have been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC
Rules. These standards are designed to provide
reasonable protection against harmful interference when
these devices are operated in a commercial environment.
These devices can generate, use, and radiate radio
frequency energy and may cause harmful interference to
radio communications unless installed in accordance with
this User's Guide. Operation of these devices in a
residential area is likely to cause harmful interference
which will make the user responsible for the appropriate
remedial action at his/her own expense.
CE Mark Warning
These are Class A products.
environment these products may
interference in which case the user will need to consider
adequate preventative methods.
1. Packing list
The box should contain the following items:
- The Media Converter
-
AC-DC Power Adapter
- The User's Manual
-
Warranty Card
Please notify your sales representative immediately if any
items are missing or damaged.
2. Overview
The 10/100M Fast Ethernet Media Converter series are
designed to meet the massive needs for network
deployment and able to extend a copper based fast
network via fiber cable to a maximum distance up to
120km.
Our 10/100M Fast Ethernet Media Converter series are
fully compliant
10/100Base-TX, 100Base-FX, standards. They can be
In a domestic installed into a Standard Converter Chassis. The
cause radio installation &
straightforward. Operation status can be locally monitored
through a set of Diagnostic LED located in the front panel.
Features:
10/100Base-TX to 100Base-FX Converter
Standards: IEEE802.3 10Base-T,
IEEE802.3u 100Base-TX/FX
Interface: 1 RJ-45 Port & 1 Optical Port (SFP or 1X9)
Flow Control: IEEE802.3x flow control for full duplex
mode. Back-pressure flow control for half duplex mode.
LED: Fiber-Link, Fiber-Duplex, Fiber-Fault, T.P.-Link,
T.P.-Duplex, T.P.-100/10M
with IEEE802.3, IEEE802.3U,
operation procedures are simple &
