Texsport 14204 Operating Manual

Thank you for buying a Texsport uthentic
hope you enjoy your new stove and that it will serve you for many years to
come. We encourage you to read and understand each step of the set-up
and safety operation instructions prior to working with this stove.
FOR OUTDOOR USE ONLY
GENERAL SAFETY INFORMATION
• NEVER use in an enclosed area.
• DO NOT expose the propane cylinder to excessive heat.
• Never operate stove with missing or damaged parts.
• lways check burner holes prior to each operation. If blockage
is found DO NOT use stove.
• lways inspect stove, propane cylinder and regulator and
tube assembly for damage, debris or dirt before attaching the
stove to the propane cylinder.
• If any damaged is discovered, DO NOT USE.
• DO NOT USE S SP CE HE TER OR FOR ILLUMIN TION.
• lways attach/detach propane cylinder outdoors away from
any open flame or pilot lights and only when the stove is cool.
• When storing or transporting stove always disconnect the
propane cylinder and store it in a cool, well ventilated loca-
tion, in an upright position.
• Be sure connection to propane cylinder is tightly secure (hand
tighten only) prior to each use.
• Never operate the stove near any flammable liquid or vapors.
Keep all flammable or combustible materials beyond the clear-
ance zone as indicated on page 4 of this manual.
• Discontinue operation of the stove and close valve if:
– ambient temperature drops below -10˚ F.
– there is no fuel remaining in the propane cylinder
– combustion becomes unstable
– lighting cannot be performed quickly and easily
– you experience repeated flame outs
• Should blockage occur in the fuel jet do not attempt to clear
with a metal object. Call Texsport Customer Service at
800-231-1402 8 M – 5PM CST Mon-Fri.
Never leave stove unattended when hot or in use.
• KEEP OUT OF RE CH OF CHILDREN.
2
dventure Gear product. We
CONNECTING THE FUEL SOURCE
Step 1......Use only the approved 16.4 oz/465 g disposable
Step 2......Make sure that the burner control valve knobs is turned
Step 3......Make sure regulator assembly rubber seal is clean and
Step 4...... ttach the propane cylinder onto the regulator assembly
Step5 ......Please check all connections for leaks using soapy
Step 6......When you are sure there are no leaks, you may pro-
SETUP/LIGHTING YOUR STOVE
Step 1......The wind baffle packed on the bottom of the stove must
Step 2......Place a flame source near the face of the burner and at
Step 3......If stove fails to light, turn off the valve. llow any gas to
If stove still does not light – call Texsport Customer Service at
800-231-1402 8 M – 5PM CST Mon-Fri.
USING YOUR STOVE
Step 1...... fter burner has ignited, adjust to desired heat level.
Step 2......Keep children, pets and flammable materials well away
INSTRUCTIONS FOR USE
propane cylinder approved for use by the United States
Department of Transportation DOT-NRC 232/290
M1110.
off. Twist in a clockwise direction
undamaged and in its proper centered position.
(hand tighten only). Insert tube into the inlet housing on
the right side of the stove. Insert the tube fully into the
inlet and turn the collar clockwise to tighten.
(When installed correctly the propane cylinder and reg-
ulator and tube assembly will slant slightly toward you.
The propane cylinder does not rest flat on the surface).
water. Bubbles will form if there is a leak present.
ceed to setup/lighting your stove.
be removed and placed over the burner and locked into
place.
the same time open the control valve to a low or medi-
um setting. Gas will begin to flow and the burner will
ignite.
dissipate and repeat step 2.
from ignited burner.
3
Step 3......While ignited DO NOT touch the cooking area. Only
the control knob should be touched during operation.
Step 4......Stove surface is very hot and should not be handled or
moved, except after being shut down.
Step 5...... llow stove to cool for 15 minutes before moving or
storage.
MAINTENANCE
Be sure to keep equipment clean and make sure burners are
always unobstructed. Propane appliances seldom require service as
long as you keep valves and orifices away from dirt and dust.
lways blow the valve clean before connecting it to a cylinder. If
damaged DO NOT use the appliance and contact Texsport
Customer Service at 800-231-1402 8 M – 5PM CST Mon-Fri.
DO NOT PERFORM MAINTENANCE WHILE
THE STOVE IS STILL HOT.
PLEASE ALLOW ADEQUATE TIME TO COOL.
MINIMUM CLEARANCE TO
FLAMMABLES OR COMBUSTIBLES
Please keep stove away from any flammable or combustible materi-
als or objects. DO NOT allow any fabric, clothing or any flamma-
ble or combustible material to come within the following distance
restrictions.
12" from all sides of stove
Keep objects 48" above stove burner.
48" 48"
12"
12"
12"
4
12"
