Read all information and instructions, including Gaslight Warning Tag attached to light,
Model 9T must be used for recreational vehicles (tie-on mantle)
The design of Model 9 and 9T is C.S.A. certified. Installation must
conform with local codes or, in the absence of local codes, with the
National Fuel Gas Code, ANSI Z223.1 (latest edition), and/or with
CAN1-B149.2 (latest edition) installation code for propane and butane
burning appliances and equipment, and local codes.
IMPORTANT INFORMATION FOR USING PAULIN INDOOR GASLIGHTS
Use Gaslights only for purposes of illumination. Installation and repair of equipment that operates on
propane or butane gas is a job for experts. Do not attempt to install or repair your gaslight unless you
have been thoroughly trained and are experienced in such matters. If your gaslight appears to be mal-
functioning, turn it to the "OFF" position and immediately contact your local dealer or the Paulin factory.
After installation and before use, have qualified gas personnel
approve your installation and check for gas leaks using a leak
detector. Tubing, fittings, gaslight valve, and any other gas
transporting component should be checked. Subjecting
valve assembly to testing pressures in excess of 6 PSI
can damage sealing grease which can cause leaks and
voids warranty.
Use your gaslight in vented rooms only.
Carbon monoxide is produced by the incomplete
combustion of fuel.
Attention Installer:
C.S.A. requires that you leave these instructions
with the appliance for the consumer.
Owners Guide
before installation or use. Retain this guide for future reference.
Information and Instructions
Model 9 for homes, cottages, and cabins (pre-formed mantle).
Indoor Gaslights
Caution
If you smell gas:
1. Shut off gas to appliance.
2. Open windows
3. Don't touch electrical switches
4. Extinguish any open flame.
5. Immediately call your gas supplier.
DO NOT STORE OR USE GASOLINE
OR OTHER FLAMMABLE VAPORS
AND LIQUIDS IN THE VICINITY OF
THIS OR ANY OTHER APPLIANCE.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Model 9 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Paulin Model 9

  • Page 1 If your gaslight appears to be mal- functioning, turn it to the “OFF” position and immediately contact your local dealer or the Paulin factory. After installation and before use, have qualified gas personnel...
  • Page 2 Flow of combustion air and ventilation air must not be obstructed. Use propane gas only for Model 9 and 9T. Propane gas must be to this rating: 2500 to 2530 B.T.U per cubic foot. Paulin propane gas nozzles are drilled to this rating only. They will not function properly if used otherwise.
  • Page 3 RECOMMENDED MAINTENANCE CONTINUED Mantles. Use Paulin mantles which are designed for use with propane and butane gas only. Never use broken mantles. Inspect for carbon deposits each time gaslight is used. Clean or replace defective mantles immediately. Use proper ceramic burner nose and mantle combination. (Example: “Tie-On” type burner nose, #L12-11A, with tie-on mantles, #L13-6.
  • Page 4 Straight Fitting is required, Paulin #L22-12A (included). If Gaslight is to be connected from behind (through wall), a 1/8 NPT Street Elbow (Male- Female), Paulin #L22-23A (included) must be used in addition to the Straight Fitting. Permanent screws that attach valve assembly to wallplate SHOULD NEVER BE LOOSENED OR REMOVED.
  • Page 5 Instructions”) by engaging Tabs (H) and inserting Globe so that Globe Lock Screw can be tight- ened into the neck of the Globe. Do not overtighten. Replacement parts and accessories are available from your local gas dealer or from Paulin Products, Inc.
  • Page 6 MANTLE INSTALLATION & LIGHTING INSTRUCTIONS Do not use defective mantles (holes, etc.) Replace defective mantles immediately. After installation and before use have qualified gas personnel approve your installation and check for gas leaks using a leak detector. Tubing, fittings, gas- light valve, and any other gas transporting component should be checked.
  • Page 8 The unit is used in an unaltered form and assembly and only indoors and only for appropriate illumination purposes. b. The unit is used with propane gas (model 9 or 9T) or butane gas (model 9B or 9BT) only in a well ventilated area.
