Eagle Vision EV-VS
Search & Rescue Camera
Quick Start Guide
Thank you for purchasing the Eagle Vision EV-VS. Feel free to contact us 24 hours a day/ 7 days
a week if we can help:
United Vision Solutions, Co.
47 Stearns Terr,
47 Chicopee, MA 01013 USA.
(413) 592-8477
www.unitedvisionsolutions.com
info@unitedvisionsolutions.com
Advertisement
Summary of Contents for United Vision Solutions Eagle Vision EV-VS
-
Page 1: Quick Start Guide
Eagle Vision EV-VS Search & Rescue Camera Quick Start Guide Thank you for purchasing the Eagle Vision EV-VS. Feel free to contact us 24 hours a day/ 7 days a week if we can help: United Vision Solutions, Co. 47 Stearns Terr, 47 Chicopee, MA 01013 USA. - Page 2 Eagle Vision EV-VS® Rechargeable NiMH Battery Pack To Charge: Connect the battery pack to the charger then plug the charger • into the wall outlet. (The charger can use and will auto-detect either 110 Vac or 220 Vac.) The red LED will be on during charging.
- Page 3 We also include a AA battery holder for back-up power if you aren’t able to recharge your NiMH rechargeable battery. AA Lithium batteries last much longer than Alkaline Batteries. Firmly insert eight (8) Lithium batteries (included) into the battery holder according to the diagram on the battery holder.
- Page 4 EV-VS on and off. (We keep it simple!) The 24 built-in infrared diodes turn on automatically at night. Note: People cannot see IR light. The Eagle Vision EV-VS camera and monitor can see Loosen the black tightening ring and pull on the pole to ex- tend it.
- Page 5 FOR BETTER STABILITY USING THE CHEST MOUNT, CLIP ONE STRAP TO THE TOP “D” RINGS AND ONE STRAP THE BOTTOM “D” RINGS AND ADJUST ACCORDINGLY FOR MOUNTING THE MONITOR ON YOUR BACK, CROSS THE STRAPS. EACH STRAP WILL HOOK TO AN OPPOSING TOP AND BOTTOM “D”...
- Page 6 Here is a SWAT team using a EV-VS Pole Camera to maintain surveillance behind cover. Gooseneck and Shield Mount Use the gooseneck or shield mount to fasten the camera head to the top of a shield. Gooseneck Shield Mount Here is the “Shield Mount” holding the camera head to the top of a shield.
- Page 7 50 foot E x te nsion Cable Monitor Suspect Be 100 feet Away! Camera Is Here 100 Feet of Extension Cable Use the gooseneck and the extension cable to monitor activities up to 100 feet away! Keep both ends of the cable out of the stuff sack for rapid deployment.
- Page 8 Attach the extension pole if you want to look into 2nd story windows or onto one story roof tops. The connectors can only fit together one way. Use our Bore-Scope to look under doors. It even has a pushbutton switch to illuminate objects that are close to the lens that could be hidden inside containers.
- Page 9 Computer monitors and the Sun do not mix well. Use the sun shade to help you see the picture in the sunlight or to keep the light from the monitor from spreading at night. Keep the monitor above – 4 degrees Fahrenheit while in use.
- Page 10 REMOTE CONTROL USE THE REMOTE CONTROL IF YOU WANT TO ADJUST OR DIM THE PICTURE SEE THE INSTRUCTIONS INCLUDED WITH THE REMOTE FOR ITS NOTE: IF THE BATTERY IN THE MONITOR RUNS ALL THE WAY DOWN, USE THE REMOTE TO TURN IT BACK ON AND RESTORE THE SETTINGS.
- Page 11 If needed, will repair or replace any part of Eagle Vision EV-VS within a period of one year from the date of purchase provided that the damage was not caused by negligence or unreasonable behavior. United Vision Solutions, Co. 47 Stearns Terr, 47 Chicopee, MA 01013 USA. (413) 592-8477 www.unitedvisionsolutions.com...
