Pyramix 6.2 SP2 Release Notes
Installation
Please consult the Installation Guide located on the Pyramix Installation Media (CD/DVD-ROM or USB
Memory card) for details of the hardware and software installation procedure and Authorization Key
registration process.
To install the Mykerinos board, TURN YOUR COMPUTER OFF (shut down then switch the power off).
Next plug the Mykerinos board into one of the PCI/PCI-Express bus slots on your computer and turn the
power back on.
Additional installation step for multi-board application
In order to enable multi-board operation, all Mykerinos cards in your PC have to be connected together
using a special HDTDM ribbon cable. This cable has to be plugged into the multi-pin connectors located
on the top edge of the I/O daughter cards. Please contact your Merging Technologies Sales Partner for
information on how to order this HDTDM ribbon cable.
To install the Pyramix Virtual Studio software insert the Pyramix Virtual Studio Installation Media -
•
the installation program should auto-start.
To install MassCore launch the MT Security Settings, go to the MassCore page and install the
•
MassCore RunTime (a MassCore base key is required).
Updates
Please check our Web site http://www.merging.com periodically for information, patches and updates.
www.merging.com/Pyramix
Merging Technologies
Le Verney 1070 Puidoux Switzerland
T : +41 21 946 04 44 • F : +41 21 946 04 45

Advertisement

loading
Need help?

Need help?

Do you have a question about the Pyramix 6.2 SP2 and is the answer not in the manual?

Questions and answers

Summary of Contents for Merging Technologies Pyramix 6.2 SP2

  • Page 1 I/O daughter cards. Please contact your Merging Technologies Sales Partner for information on how to order this HDTDM ribbon cable. To install the Pyramix Virtual Studio software insert the Pyramix Virtual Studio Installation Media - •...
  • Page 2 MT3675: Fixed. NLE machine (VCube) follows editing move when synchronized through SonyP2 MT3543: Fixed. Video detected text in the I/O Status window to clarified MT3669: Fixed. Mixer Configure page : Del with no strip or bus selected makes Pyramix freeze under Vista/Win7 MT3649: Fixed.
  • Page 3 A warning was added to inform users when the system is reaching Low Memory Conditions. In order to save a project under such conditions Pyramix will switch to Save to Disk mode as not enough memory might be available otherwise. This warning was added in order to prevent a Runtime Error on Save.
  • Page 4 “Windows has blocked some programs” message. You can then unblock it from there or deactivate UAC from the Windows Control Panel. No need to install the previous mp3 beta handler since it is by default part of the Pyramix V6.1 & V6.2 installers. Merging Technologies Le Verney 1070 Puidoux Switzerland www.merging.com/Pyramix...
  • Page 5 Create a new DWORD Value: No VS3 Keyboard Command and make sure that the Decimal DWord Value = 1 Relaunch Pyramix and Keyboard commands to mixer will be disabled (use DWORD value = 0 to re-enabled) New USB Sync card drivers...
  • Page 6 MT3598: Fixed. Changing certain VST order in Mix window may crash Pyramix MT3151: Fixed. Ramses faders above the latest Pyramix mixer channel to be positioned to mute, Must use the latest Ramses ConsoleSoft (v2.4.0.3082 or higher) in order to have the resolution.

  • Page 7: New Features

    Version Pyramix 6.2 NEW FEATURES New AAF Module: For better reliability and handling (see User Manual for all details) Automation additions (MT3460): New Filter Automation Tracks auto-select options: Select Last Used: Auto-select the previous automation tracks selected. Select Last Changed: Auto-select the last automation track written (the tracks having the last same date / time is the automation tracks version dialog) Select Displayed: Auto-select the tracks displayed in the timeline.
  • Page 8 MT USB Sync updates Added feature to be able to chase incoming biphase at 24 frm/s when Pyramix is set to 25 frm/s Supported only when the biphase pulse per frame count is greater or equal to 10 New Sony P2 synchronization mode (MT2890).
  • Page 9 0 dB for better visibility. It also allows “unmerging” static gain and envelope points that have been merged together by the Pyramix AAF Export function to retrieve the original settings as defined by Pyramix.
  • Page 10 Timecode display, cursor and other graphic refresh improvements (MT3275) Waveform generation optimization (MT3174) Pyramix: Recently opened Project file count increased (MT2897). Under Project>Open Recent Automation: snapshot view should display what is currently being displayed by the automation track (on the timeline, MT2697) Quick Export: Added check box “Generate New UID”...

  • Page 11: Bug Fixes

    MT3271: Fixed. Pyramix project is changes will now load back properly in VCube. MT3314: Fixed. Mykerinos-X30, DSP start fail error MT3448: Fixed. Sony communication overflow when a Sony controller controls a machine through Pyramix MT3452: Fixed. Strip Tools in DXD does not keep low pass filter over 20K MT3439: Fixed.
  • Page 12 MT3136: Fixed. Pyramix: When using Video (VT) the timeline is not updating correctly VT once doing a nudge clip. MT3074: Fixed. Track Monitoring will switch to input mode instead of repro under certain circumstances MT2848: Fixed. no "save" prompt on closing a project after some modifications MT3425: Fixed.
  • Page 13 MT3228: Fixed. Monitor Panel: Subgroup in the monitor panel is pre fader MT3184: Fixed. MT ASIO Bridge I/O names now start from 1 instead of 0 MT3172: Fixed. During Pyramix startup, some Message Box are displayed behind the splash screen and could be inaccessible MT3169: Fixed.
  • Page 14 A warning was added to inform users when the system is reaching Low Memory Conditions. In order to save a project under such conditions Pyramix will switch to Save to Disk mode as not enough memory might be available otherwise. This warning was added in order to prevent a Runtime Error on Save.
  • Page 15 “Windows has blocked some programs” message. You can then unblock it from there or deactivate UAC from the Windows Control Panel. No need to install the previous mp3 beta handler since it is by default part of the Pyramix V6.1 & V6.2 installers.
  • Page 16 A conflict has been reported and is under investigation (as of sept 2009) between motherboards using the latest Intel chipset X58 and Mykerinos PCIe cards (such as MYK-X30) under Windows Vista SP1 and SP2 versions. Pyramix users with such configurations should remain with the non-SP version of Vista for the time being.
