Summary of Contents for Revox Re:source
- Page 1 as82 CD Control Module E 2.02...
-
Page 3: Table Of Contents
Contents CD Control Module Installation Connection panel Cabling & Setup Blu-ray Player Cabling Volume control Setup Analogue inputs IN1 – IN3 Cabling Setup: Edit Name General operation 12-13 Multiroom operation Technical data Warranty... -
Page 4: Cd Control Module
CD Control Re:source CD Control Module The CD Control module is a universal Blu-ray player specifications audio interface with serial Company: Oppo / USA communication port. Model: BDP-93xx xx = Country code; e.g. EU, CH ... Unlike the Re:system M51 and M100, http://www.oppodigital.com/... -
Page 5: Installation
CD Control Re:source NSTALLATION Loosen the two screws with the TORX The CD-Control Module is equipped screwdriver supplied and remove the with the latest electronics and should blanking plate. be handled with care. Before removing the module from its Before you install the card, the... -
Page 6: Connection Panel
BDP-93 Blu-ray player. module and the BDP-93 player. Type: Plug-Plug You will find information about the corresponding cabling in the next For this reason, you should use the chapter. enclosed crossover adapter with the supplied Revox 1:1 cable. -
Page 7: Cabling & Setup
- see "Configuring the digital input". 2.) RS232 control connection with a serial null modem cable. The supplied crossover adapter must be used with the 1:1 cable from Revox. The cable length between the CD Control module and the receiver should not be more than 10 metres as otherwise you can expect to experience disturbances and reduced audio quality. -
Page 8: Volume Control
CD Control Re:source Volume control Compared with the internal Multiroom sources from the M series, the signal level on the audio output (cinch socket FL/FR) on the BDP-93 Blu-ray player, is too high. The output level of the Blu-ray player... - Page 9 CD Control Re:source Setup CD Control Configuring the digital input The basic settings for the CD Control When installing the CD Control module module are made in Setup. in a Re:system M51 or M10 with an installed 5.1 Decoder module, you have...
- Page 10 CD Control Re:source Configuring the digital input Hiding analogue inputs You can now select whether and which On the second page of the Setup (Menu of the 5.1 decoder digital inputs should softkey), the CD Control module offers receive the digital signal, using the Dig.
- Page 11 CD Control Re:source Defining switch-off behaviour Power Off: System Off After the CD has been paused or If required, the Blu-ray player can be stopped, the Blu-ray player stays in turned off completely through the this state. serial interface. You have 3 different...
-
Page 12: Cabling
CD Control Re:source Analogue input IN1 IN2 IN3 Connect the three analogue inputs IN1 – IN3 using a cinch stereo cable with your external device. The inputs are shown in the source menu as Aux-1 – Aux-3. The analogue inputs IN1 – IN3 are not suitable for connecting a record deck. -
Page 13: Setup
CD Control Re:source Setup Aux-1 / 2 / 3 Edit source name The Cursor softkeys move the [ ] The display names of the three inputs cursor left and right respectively. and the CD source can be freely defined. -
Page 14: General Operation
The picture below shows the M51 the CD had already been played, play Source menu. The display is designed in restarts from the position where it was a similar way for the various Revox Resume last stopped - function. Apps. The display and control options in... - Page 15 Revox through display The M208 Project Manager offers the operation: device control "Revox CD Oppo" in the • [Revox] database, which makes the Play • following CD play control commands Pause •...
-
Page 16: Multiroom Operation
You can operate the CD function of the Blu-ray player from each side room, Using the two buttons (shown with the Revox Multiroom System. If the with black/white squares) on the wall- M217 wall-mounted display is installed, mounted operating panel, you can... -
Page 17: Technical Data
CD Control Re:source Technical data Audio connections: Cinch stereo input Cinch stereo input Cinch stereo input Cinch stereo input Max. cable length 10 m * Digital data connections: RS 232 Sub-D 9-pin - crossover cabling Plug-Plug * Dependent on cable environment and quality E&OE... - Page 18 CD Control Re:source CD-Control module Operating manual / Part no.: 10.30.3126...
