Summary of Contents for SnapTV Inteno box
-
Page 1: Installation Guide
Installation guide for SIO © SnapTV AS 2010... - Page 2 Motorola box, a PC and an IP telephone. You can also have multiple PCs connected to this switch simultaneously. The Motorola box is to be connected between the TV and the Inteno box supplying the TV with channels and other services via the Internet.
- Page 3 FOLLOW THESE STEPS TO GET STARTED: Unpack the boxes and place the Motorola box and the Inteno box close to the data socket in the wall. Also be sure to have two available power outlets nearby. Use a data cable to connect the Inteno box to the data socket in the wall.
- Page 4 Connect the power adapter that came with the Inteno box first into the back of the box, then into a wall outlet. The connection on the back of the Inteno box is labeled PWR. The power supply that came with the Motorola box connects to the back of the Motorola box to the far right and then to a wall outlet.
- Page 5 SCART If you have an IP phone, connect this to the Inteno box by using the connection point marked with the green color. If you have an analog phone, it must be connected to the Inteno box via an ATA.
- Page 6 If you have another PC which you want to connect to the internet, you must use the connection on the back of the Inteno box marked with the blue color. IP-Network IP-Datanett INTENO Power Outlet Vegguttak strøm PC 2 PC 1...
- Page 7 OVERVIEW OF COLOR CIPHERS ON THE INTENO BOX: Red: Connects to PC Yellow: Connects to the Motorola box Green: Connects to IP phone Blue: Connects to PC...
- Page 8 CONTACT OUR SUPPORT SERVICES FOR ANY QUESTIONS: Telephone: +47 93 20 02 22 e-mail: support@snap.tv...
