Summary of Contents for ENERGY SISTEM T5650

  • Page 1 User Manual...

  • Page 3: Safety Considerations

    1. INTRODUCTION To ensure your safety and the safety of others, please ensure that you read all the safety information before operating this product. Keep this information in a safe place for future reference. This symbol indicates that this product incorporates double insulation between hazardous mains voltage and user accessible parts.
  • Page 4 Do not use liquid or aerosol cleaners. Clean the set top box with a soft, damp (not wet) cloth. T5650 handling and care Place the product in a well-ventilated area Don’t install it in the cold or under direct sunlight...

  • Page 5: Front Panel

    2. FRONT PANEL POWER: Used to switch the set top box ON or OFF. Standby Indicator: Used to visually show the power state of the set top box: green LED will show if is turned on the set top box red LED will be light if the set top box entered standby mode.

  • Page 6: Remote Control

    4. REMOTE CONTROL 4.1. BUTTON DESCRIPTIONS STANDBY: Switch the set top box between on and standby mode. MUTE: Mute/unmute the sound. MENU: Open the main menu window. CH+/-: Move around the menu screens or change the channels in normal play mode. VOL+/-: Move around the menu screens or change the volume in normal play mode.

  • Page 7: Installing The Batteries

    4.2. INSTALLING THE BATTERIES Remove the battery cover from the remote control and put 2xAAA size batteries inside the compartment. The diagram inside the battery compartment shows the correct way to install the batteries. 1. Open the cover 2. Install the batteries 3.

  • Page 8: Connecting To A Tv Set

    5. CONNECTIONS Caution: Make sure to check that the voltage of the wall outlet has the same rating than the receiver. To prevent the risk of electric shock, do not open the cover or the back of the receiver. When connecting the receiver to other equipment (e.g. TV, VCR and amplifier) make sure to refer to relevant user manual for instruction.

  • Page 9: Connecting To Tv And Vcr

    5.2. CONNECTING TO TV AND VCR TV aerial RF IN SCART HDMI 100-240V~ 50/60Hz Digital Audio LOOP Coaxial HDMI OUT THROUGH...

  • Page 10: Connecting To An A/V Receiver With Digital Audio Input

    5.3. CONNECTING TO AN A/V RECEIVER WITH DIGITAL AUDIO INPUT 100-240V~ 50/60Hz Digital Audio LOOP Coaxial HDMI OUT THROUGH A/V Receiver...

  • Page 11: User Interface - Main Menu

    6. USER INTERFACE - MAIN MENU Note that the first time you use T5650 it will automaticaly show the Setup->Installation screen in order to scan for TV and radio channels. Please refer to Setup->Instalation in page 11. Once the channel scan is finished and all the channels are stored into the database, you can start to watch the digital terrestrial TV channel or listen to the radio broadcast, some typical operations are given in this chapter.
  • Page 12 Set the antenna power on or off to supply +5V power to antenna or not. Note: The default is OFF, set this option to ON only if T5650 is connected to an active antenna which amplifies the received RF signal, otherwise please set it to OFF.

  • Page 13: Manual Scan

    Figure 4. Clear database message Figure 5. AutoScan Finished Manual Scan Press <GREEN> button to start Manual Scan. Manual Scan adds the scanning results into database, it doesn’t erase the database. But you have to indicate the Frequency and Bandwidth for scanning. If you scan the same Frequency and Bandwidth more than once, the previous programs will be overwritten.

  • Page 14: Video Output

    Figure 8. TV Setup TV Format ≥ 4:3LB(LetterBox): Typically for wide screen content on conventional 4:3 TV with black bars above and below the picture. ≥ 4:3PS(PanScan): Typically for wide screen content on conventional 4:3 TV with left and right edges cropped.

  • Page 15: Advance Timer

    Guide(see section “Guide” on page 17). When scheduled date/time arrives, T5650 will automatically switch to the scheduled program. Press any key except <Vol-/Vol+/Mute> button, T5650 will ask you to abort it or not when watching booked program. You can delete the event while it is not running.

  • Page 16: Set Default

    6.1.5. Set Default Restore T5650 to factory default settings. All user settings will be restored to factory default values and the TV/radio channel database will be erased together. 6.1.6. SW Update Updates T5650 firmware by USB. 6.2. TV/RADIO There are two types of programs: TV and Radio.
  • Page 17 You can edit the program name, maximum length is 20 characters. Press <Left/Right> button to select Edit option and <Up/Down> button to select the program. Press <OK> button to display program info and press it again to edit program name. Press <Up/Down/Left/Right/0~9/RED/GREEN>...
  • Page 18 Press <Exit> button to exit to previous menu. Press <RED> button to enter Book page and <YELLOW> button to save after edition. If it’s in conflict with itself or other event, a conflict message will be displayed. The successful booking will be added to Main Menu->...
  • Page 19 Figure 14. My Album - Thumbnails Figure 15. My Album - Folder Use <Up/Down/Right/OK> to browse folders or files. Press <OK> to view the selected photo and press again to start slide show. Press <Info> to view the available functions. Zoom Press <RED>...
  • Page 20 Press <Up/Down/Left/Right/OK> to browse folders and files. Press <RED> to play or pause. Press <GREEN> to stop. Press <YELLOW> to set play mode as Repeat All / Repeat Random / Repeat Off. Press <BLUE> to set fast forward speed as x2 / x3 / x4 / normal. Press <Left/Right/Mute>...
  • Page 21 Auto: Timeshift is continuously active. Off: Timeshift disabled One Button recording On: T5650 starts recording with a simple <Record> button press. Off: After pushing <Record> you have to specify the lenght of the recording. Default recording period Specify the default recording period from 15 minutes to 8 hours in 15-minutes steps.
  • Page 22 Figure 20. My Record Figure 21.Recorded list Figure 22. Recording Device Figure 23. Recording Preferences 6.4. ACCESSORY There are three options: Gomoku, Calendar, Calculator. 6.4.1. Gomoku Press <Up/Down/Left/Right> button to set play mode and difficulty. Press <OK> button to start play Gomoku.

  • Page 23: Normal Play

    7. NORMAL PLAY Normal Play means T5650 under watching TV or listening to the Radio. See Figure 24, Figure 25, . Figure 24. Normal Play - TV Figure 25. Normal Play - Radio 7.1. INFORMATION Press <Info> button once to display info banner. Banner displays the program No., favorite setting, current time, program name, now and next event, lock, scramble, subtitle and teletext info.

  • Page 24: Program List

    7.4. PROGRAM LIST Press <OK> button to display Program List with No., name and lock/scramble/skip status. See Figure Press <Up/Down/Left/Right> to change the channel. Press <OK/Exit> to return to the normal play mode. Figure 28. Program List Figure 29. Audio Channels 7.5.

  • Page 25: Teletext Subtitle

    Press <Up/Down> button to select the teletext language if the program has teletext (availability depends on channel broadcaster). Press <OK/Exit> button to exit the teletext setting page. Press <0~9/Up/Down/Left/Right> button to change teletext page (if available). Figure 30. Teletext settings Figure 31.
  • Page 26 Press <Text/Subtitle> button to display teletext or subtitle setting page. Press <Left/Right> button to select “TTX Subtitle”. Press <Up/Down> button to select teletext subtitle language. Press <OK/Exit> button to exit the setting page. Figure 34. Teletext language Figure 35. Teletext subtitles 7.11.
  • Page 27 There are some messages to inform user the current status of the T5650. ≥ No Signal If T5650 can’t get the signal, for example if the antenna cable is disconnected. ≥ No Service Program doesn’t have any contents to play.

  • Page 28: Troubleshooting

    8. TROUBLESHOOTING If you experience problems with this receiver or its installation, in the first instance please read carefully the relevant sections of this User Manual and this Troubleshooting section. Problem Possible cause What to do Standby LED not lit Mains lead unplugged Check mains lead No signal found...

  • Page 29: Specifications

    9. SPECIFICATIONS Item Specification Tuner Frequency range VHF: 174 — 230 MHz / UHF: 470 — 862 MHz Input Impedance 75 Ohms unbalanced Signal input level -78 — -25 dbm Bandwidth 7/8 MHz Modulation Demodulator COFDM OFDM Modulation 2k, 8k FFT, SFN and MFN Connectors RF in IEC 169-2 female connector...

  • Page 30: Warranty Procedure

    WARRANTY Energy Sistem Soyntec S.A. warrants its products to be free from defects in materials and workman- ship at the time of purchase. The warranty period is 36 months from the date of purchase for DVB-T STB receivers. WARRANTY PROCEDURE ≥...
