OPERATING INSTRUCTIONS

MODEL : L-10 ELF

BEFORE USING TELEVISION RECEIVER,

READ AND OBSERVE ALL OF THIS OWNER'S MANUAL

This user's Guide identifies the features of the L-10 ELF television and describes how to program

the television using the infrared hand unit. "THESE INSTRUCTIONS ARE FOR L-10 ELF TV's

THAT ARE NOT COMPUTER CONTROLLED"

Programming is the process of selecting from among the many features of the L-10 ELF. It is

also the process of adding and removing channels from the six service levels this TV provides.

Please read through this guide carefully, with a L-10 ELF TV in front of you, as you begin the

process of learning how to program these televisions. Also keep the guide handy, so you can

refer to it, for future programming changes.

The information in this guide describes each of the main SETUP MENU items: Rental: (service

level), Picture, Sound, Channel Set up, Features, Blocking and Language. It also describes how

you can access and change the features within these menu options. To get ready, turn the TV on

and press the SETUP button on the infrared hand unit and the SETUP MENU will appear on the

TV.

Before installing TV's in the hospital, please obtain and read the instructions for attaching the TV

to the support arm. These instructions are not part of this guide and should be obtained from the

TV rental service provider.

Part No. 11906674

Owner's Manual

NSTALLATION PRECAUTIONS

Any changes or modifications in construction of this device which are not expressly

approved by the party responsible for compliance could avoid the user's authority to

operate the equipment.

GRAPHICAL SYMBOLS EXPLANATION

This lightning flash with arrowhead symbol, within an

CAUTION

equilateral triangle is intended to alert the user of the

RISK OF ELECTRIC SHOCK

presence of uninsulated "dangerous voltage" within

DO NOT OPEN.

the product's enclosure that may be of sufficient

magnitude to constitute a risk of electric shock to persons.

CAUTION : TO REDUCE THE RISK OF

ELECTRIC SHOCK, DO NOT

The exclamation point within an equilateral triangle is

REMOVE COVER(OR BACK)

intended to alert the user of the presence of important

NO PARTS INSIDE.

REFER SERVICING TO

operating and maintenance (Servicing) instructions in

QUALIFIED SERVICE PERSONNEL.

the literature accompanying the appliance.

Use only DC18 ~ 32V, AC 25 ~ 35V source from a CSA Certified / UL Approved Class 2

power Supply suitable for use in Healthcare Facilities.

INSTALLATION AND CONNECTION

Installation of the television receiver must be performed by the qualified service

personnel only. Mount the television receiver to the support arm and connect the external

coaxial cable to the coaxial cable of support arm for power source and TV signal.

CLEANING

Clean the exterior of your equipment by removing dust with lint-free cloth.

For the further cleaning, use soft cloth or paper towel dampened with water.

CAUTION: To avoid damage to the surface of the equipment, do not use abrasive or

chemical cleaning agents.

bout this user's guide

Table of Contents

Need help?

Do you have a question about the L-10 ELF and is the answer not in the manual?

Questions and answers

Summary of Contents for Sumitomo L-10 ELF

Page 1: Operating Instructions
TV provides. Please read through this guide carefully, with a L-10 ELF TV in front of you, as you begin the process of learning how to program these televisions. Also keep the guide handy, so you can refer to it, for future programming changes.
Page 2: Table Of Contents
L-10 ELF television THE CONTENTS The L-10 ELF is a 10 inch, 125 channel, television, designed specifically for use in hospitals. It provides for six service levels: Free, Locked, Basic Unpaid, Basic Installation Precautions .
Page 3: About The L-10 Elf Television
L-10 ELF television bout service levels In the easy to clean, membrane control panel, on the lower front of the TV, there TV's are generally programmed for the required service levels before they are are 11 large, easy to read, buttons. Either the patient or the TV representative installed in a hospital.
Page 4: About The Infrared Hand Unit
4. Basic Paid Service Level change the special features that the L-10 ELF TV offers. When you collect the rental fee and press the PAID button on the infrared hand unit, the TV automatically changes to the Basic Paid Service Level.
Page 5: About Programming The L-10 Elf
Make these programming changes with the infrared hand unit . change programming on a nearby television. Make the selection on the infrared hand unit by pressing and releasing the How do I program the L-10 ELF? button(s) quickly. 1. Turn the TV on.
Page 6: How Do I Select A Tv Service Level
How do I select a TV service level? ow do I select a TV service level? 1. Press SETUP on the infrared hand unit. Locked - Choose VOL Locked Service SETUP MENU 2. Press CH to select Rental: service level Level or simply press the LOCKED button on Rental: Free For Additional Service...
Page 7 I select a TV service level? ow do I select a TV service level? "Self rent" is a valuable feature of the L-10 ELF television. Patients have the When a patient chooses to rent both the Basic and a Premium Service...
Page 8: How Do I Adjust The Quality Of The Tv Picture
ow do I adjust the quality of the TV picture? ow do I adjust the quality of the TV sound? Contrast - Select CH To adjust the quality of the TV sound ... Contrast to adjust the overall contrast of the picture. SETUP MENU Hold down the VOL+ button to increase or the VOL- button to reduce contrast.
Page 9: How Do I Change The Setup Of The Channels
W 30 W 31 W 32 W 33 W 34 W 35 W 36 W 37 W 38 W 39 W 40 W 41 W 42 W 43 W 44 W 45 W 46 W 47 W 48 If the L-10 ELF is set to STEREO and no stereo signal is being broadcast, a W 49 W 50 W 51 W 52 W 53 W 54 W 55 W 56 W 57 W 58 W 59 W 60 W 61 W 62 W 63 W 64 W 65 W 66 W 67 MONO signal will automatically be received.
Page 10 ow do I change the set up of the channels? ow do I change the set up of the channels? To assign a channel map ... To clear map ... Select CH Assign channel maps to program the channel selection with Select CH Clear map to automatically remove all channels from a map.
Page 11: How Do I Change The Features Of The Tv
ow do I change the features of the TV? ow do I change the features of the TV? To change the Features of the TV Speaker SETUP MENU 1. Press SETUP on the infrared hand unit. When the speaker is turned off, viewers can hear the TV only with an ear Rental: Free Picture 2.
Page 12: How Do I Operate The V-Chip
ow do I change the features of the TV? ow do I operate the V-chip? Rental CALLING UP THE BLOCKING MENU The Rental option, provides three ways to "self rent". If Rental: Menu is 1. Press SETUP on the infrared hand unit. selected, patients start the rental process by pressing the MENU button on the 2.
Page 13 ow do I operate the V-chip? ow do I operate the V-chip? MOTION PICTURE RATING. TV PARENTAL GUIDE RATING This procedure allows parents to block programs which contain TV Parental guide RATING REMARKS ratings that they consider inappropriate. Content labels are designed to indicate N/A (No rating) Not rated or not applicable program movie specific contents of TV programs within each TV Parental Guide rating.
Page 14 ow do I operate the V-chip? ow do I operate the V-chip? NONE: Not rated or not applicable program. TV-Y7 (FV;Directed to older children): This program is designed for children age 7 Important note: You have the ability to block all programs which and above.
Page 15 ow do I operate the V-chip? ow do I operate the V-chip? TV-G (General audience): Most parents would find this rating suitable for all ages. TV-14 (D/L/S/V: Parental caution recommended): This rating contains some Although this rating does not signify a program designed specifically for children, most material that many parents would find unsuitable for children under 14 years of parents may let younger children watch TV-G programs unattended.
Page 16 ow do I operate the V-chip? ow do I operate the V-chip? CONTENT LABELS CANADIAN ENGLISH RATING TV Parental Guidelines may have one or more letters added to the basic rating to let CANADIAN ENGLISH RATING parents know when a show contains higher levels of potentially, offensive material. RATING REMARKS Note that the content label should be considered in light of its associated rating.
Page 17 ow do I operate the V-chip? ow do I change the language? TO ACTIVATE V-CHIP FUNCTION To select either English, Spanish or French in the BLOCKING SETUP MENU programming screens and rental instructions ... MOTION PICTURE Rental: Free BLOCK Picture TV PARENTAL GUIDE 1.
Page 18: What If
hat if AFEGUARDS The "self rent" feature is not available . CAUTION Make sure that Rental: Free is the selected rental service level. PLEASE READ AND OBSERVE ALL WARNINGS AND INSTRUCTIONS CONTAINED The only channels being broadcast are 2-13. All other channels are snowy. IN THIS SAFEGUARDS AND THOSE ON YOUR TELEVISION.
