HomeLink 7510r Installation & Programming Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Homelink 75

Security System

Installation and
Programming
Guide
For DD243:2004 Compliant Installations

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 7510r and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for HomeLink 7510r

  • Page 1: Security System

    Homelink 75 Security System Installation and Programming Guide For DD243:2004 Compliant Installations...
  • Page 2 The contents of this book are subject to change without notice. Printed and published in the U.K. This manual applies to software used in the 7510r control unit with version 3.0x software.

  • Page 3: Table Of Contents

    7510r Contents Introduction..................1 Overview ..................... 1 A Tour of the Control Unit................2 Controls and Displays ..................... 2 Opening the Case ....................3 Controls and Connectors ..................4 Technical Specification................ 5 Specification ....................5 General ........................ 5 Security ........................ 5 Radio ........................
  • Page 4 7510r Strobe on Unset (770r only)................... 37 System Options ..................38 User Access ......................38 Remote Access..................... 39 Language ......................40 Restore Defaults....................40 Installer Code ...................... 41 Tcmd needs Entry....................41 PA Response ......................41 Auto Rearm ......................42 Siren Delay......................

  • Page 5: Introduction

    7510r Introduction Overview The 7510r is the control unit for a Homelink 75 security system. The 7510r provides the user with an array of features designed for domestic users. These include social alarm monitoring, activity alarm monitoring, direct communication to mobile telephones and voice messaging.

  • Page 6: A Tour Of The Control Unit

    Introduction 7510r A Tour of the Control Unit Controls and Displays Figure 1 shows the controls and displays available on the control unit. 1. LCD display (monochrome, 128x64 pixels). 2. Set key. 3. Navigation keys. 4. Numeric keypad. 5. Unset key.

  • Page 7: Opening The Case

    7510r Introduction Opening the Case To gain access to the interior of the control unit undo the two screws at the bottom of the case. Figure 2. Screw Locations Ease the body from the wall plate, see Figure 3. Caution! Disconnect the ribbon cable from the wall plate before opening the case completely.

  • Page 8: Controls And Connectors

    Introduction 7510r Controls and Connectors Figure 4 shows the connectors available in the body of the control unit. 1. Siren. 6. External loudspeaker and microphone connector. 2. Battery compartment. 7. Access to plug on modules. 3. Internal loudspeaker. 8. Back plate ribbon cable and connector.

  • Page 9: Technical Specification

    7510r Technical Specification Specification General Product name 7510r. Manufacturer Cooper Security Ltd. Environmental Class II. Operating temperature Tested -10 to +55°C. Dimensions 285mm W, 206mm H, 45mm D. Weight 1.060 kg (without stand-by battery). Case material ABS. Zones 2 wired, 32 radio.

  • Page 10: Communications

    Technical Specification 7510r Transmitter range The range of the transmitters compatible with this control unit depends on the environment in which they are installed. As a guideline, most transmitters will work up 200m range in free space conditions. Communications Speech messages can be configured to be up to 44s long (one 12s home message and four consecutive alarms messages of 8s each).

  • Page 11: Power Supply

    7510r Technical Specification Power Supply The internal power supply is an off-line switching type. This product complies with the requirements of EN50131- 6 Type A power supply at Grade 2 and environmental class 2. Mains power supply 230VAC, 80mA max, 40mA min, +10%/-15%, 50/60Hz ±5%.

  • Page 12: Compatible Equipment

    Technical Specification 7510r This product complies with the requirements of EN50131- 6:1997 at grade 2 and environmental class II. This equipment is compliant with EN 50136-2-1:1998 and EN 50136-2-3:1998. It allows the alarm transmission system to meet the performance requirements of EN...

  • Page 13: Installation

    7510r Installation Warning: Exposure to Radio Frequency Radiation The radiated output power of this device is below those levels considered safe by European exposure limits. Nevertheless, when fitting the product place it in such a manner as to minimise the potential for human contact during normal operation.

  • Page 14: Fix The Wall Plate

    Installation 7510r 2. Fix the Wall Plate Use at least three fixing holes when mounting the wall plate on a wall. Figure 7. Screw Wall Plate to Wall 3. Connect to Mains Figure 8 shows the mains connection. Connect to a suitable supply using a double pole disconnect device in accordance with EN60950-1.

  • Page 15: Connect Wired Detectors (Optional)

    Door Contact Figure 9. Connecting Detectors 5. Connect to Telephone Line (Optional) The person connecting the 7510r control unit to the PSTN must be suitably qualified. Connect the 7510r telephone connector (see Figure 10) ONLY to the PSTN or to other...

  • Page 16: Remote Loudspeaker/Microphone (Optional)

    Softer Note: This control changes the volume of non-alarm tones (for example Exit/Entry tone). To change the volume of voice announcements see “7510r User Guide”. The volume of alarm tones is fixed. Louder Figure 12. Adjusting Tones and Chime Volume.

  • Page 17: Fit Battery

    7510r Installation 7. Fit Battery Fit six AA 2100mAh NiMH batteries to the battery compartment in the back of the control unit, see Figure Figure 13. Fitting Batteries Make sure that you refit the battery compartment lid and secure it with the screw provided.

  • Page 18: Commissioning The System

    5. Program the system to suit user requirements. 6. Instruct the user in operation of the system. See the Homelink 75 User Guide. Page 14...

  • Page 19: Programming

    7510r Programming Entering Installer Menu 1. Make sure the system is unset and showing the standby screen (time and date). 2. Press Menu. 3. Key in your Installer access code. (When delivered from the factory the default Installer access code is “7890”).

  • Page 20: Restoring All Factory Default Programming

    Programming 7510r 5. Apply mains power if available. 6. Remove the short from the Reset pins. The control unit loads the factory default access codes: User 1: 1234, Installer: 7890. 7. Close the control unit. Restoring All Factory Default Programming If you wish to restore all factory default options then: 1.

  • Page 21: Detectors

    7510r Programming Reference - Detectors Detectors Add/Del Detector To use a radio zone the control unit must learn the identity of the radio detector. To learn radio detectors select Detectors, Add/Del Detector. If you want the control unit to select the first free zone for you then select Auto Learn.

  • Page 22: Deleting A Single Detector

    Not Used. Edit Zones The 7510r has two sorts of zones: radio and hardwired. The control unit allocates the radio zones to zones 1 to 32 and the two hardwired zones to zones 33 and 34. (To obtain access to the contacts for the hardwired zones see Figure 5 on page 4.)
  • Page 23 7510r Programming Reference - Detectors program for that zone. Select the item you wish to change. Changing Zone Names When changing the zone name, key in the letters from the keypad. Each number is associated with a range of letters in the same way as on many mobile phones.
  • Page 24 Programming Reference - Detectors 7510r Entry Route. Use this zone type for detectors sited between the Final Exit door/detector and the control unit. If an ‘Entry Route’ zone is violated when the system is set, an alarm will occur. If the entry/exit timer is running when an Entry Route zone is violated then no alarm occurs until the entry/exit timer expires.
  • Page 25 7510r Programming Reference - Detectors Technical Alarm. Use this zone type when you want to monitor equipment, for example a freezer, without causing a burglar alarm. If a technical alarm zone is activated while the system is set, the system makes no audible alarm.

  • Page 26: Zone Attributes

    Programming Reference - Detectors 7510r Exit Normal Alarm A zone programmed as ‘Exit Normal Alarm’ behaves similarly to a Normal Alarm zone. However, a zone of this type will start an alarm if the detector is triggered during the exit time.

  • Page 27: Outputs

    Outputs 3 to 34 are radio outputs. The control unit uses these outputs to command one or more of the radio output devices compatible with the 7510r. You can program the control unit to group outputs into different "types". For each type the control unit has a different pattern of activating or deactivating the output.

  • Page 28: Teaching Radio Receivers

    Programming Reference - Outputs 7510r Teaching Radio Receivers To teach the control unit's identity to a radio receiver select Outputs, Add Output. The Add Output screen allows you to select the control unit output that you wish to make the receiver learn. Use u or n to select the desired output and press Select.
  • Page 29 7510r Programming Reference - Outputs Note: If you press DELETE until the current name has disappeared from the display, and then press DELETE once more, the display leaves the name change screen and restores the name of the output to its previous value.
  • Page 30 Programming Reference - Outputs 7510r operates when the system is in alarm, and remains active until the user disarms the system. Note: For best results use this output type on a strobe connected to a 770r Wireless Access Module. The strobe on a 750r cannot respond correctly because of the battery saving circuits within the radio siren.

  • Page 31: Other Devices

    Alarm Confirmation The panel activates this output during a confirmed alarm. Other Devices Use this menu to make the 7510r control unit learn a 750r external siren, 771r remote information display, 770r Wireless Accessory Module, or 7525r remote Arming Station.
  • Page 32 Programming Reference - Other Devices 7510r same time as the internal siren. The external siren runs for a fixed period of 90 seconds. By default, the control unit assigns a 750r external siren to all partitions. To program a 750r select Other Devices – External Siren .

  • Page 33: Info Module

    The Info Module is an external display module that can show the setting state of the system or one or more partitions. You must teach the identity of the 7510r control unit to each Info Module that you wish to use.

  • Page 34: Wam Module

    Mode 1 Repeater Module. The WAM repeats the signals from any detectors within its range, amplifying them to a level that the 7510r control unit can detect. This allows you to increase the area covered by detectors. Mode 2 Output Module. The WAM accepts commands from the 7510r control unit to operate wired outputs.
  • Page 35 The display asks you to activate the tamper switch on the WAM. 3. Activate the WAM tamper. The WAM signals its identity to the 7510r control unit. When the control unit learns the WAM’s identity it gives a double beep.
  • Page 36 Programming Reference - Other Devices 7510r Table 1. WAM Zones and OPs to Panel Zone and OPs Viewing a WAM To check the functions of the WAMs currently learned by the control unit: 1. Select Other Devices – WAM – View WAM.

  • Page 37: Arming Station

    The display asks you to activate the tamper switch on the Arming Station. 3. Activate the Arming Station tamper. The Arming Station signals its identity to the 7510r control unit. When the control unit learns the Arming Station’s identity it gives a double beep.
  • Page 38 Programming Reference - Other Devices 7510r Re-Programming Arming Station Buttons If you wish to re-program the buttons on an Arming Station. 1. Select Other Devices – Arming Station – Edit Arming Station. The display shows a list of the Arming Stations.

  • Page 39: Partitions

    3. Press YES. The control unit deletes the Arming Station’s identity and gives a double beep. Partitions The 7510r can provide up to four partitions. To program partitions select Partitions followed by the partition you wish to change. Partition Name You can assign a name up to 12 characters long to each partition.

  • Page 40: Exit Time/Entry Time

    Programming Reference - Partitions 7510r Final Door Set. Use this option to complete setting the partition by closing a door fitted with a Final Exit zone detector. Note that the exit time is infinite in this option. Note: Do not try to make a PIR zone act as a Final Exit for a partition.

  • Page 41: Part Set Exit Mode

    7510r Programming Reference - Partitions Siren + Comms Full alarm (communication and siren). Part Set Exit Mode You can select an exit mode for a part set partition that is different from that used when the same partition is full set.

  • Page 42: System Options

    Programming Reference - System Options 7510r sounder receiver (mode 4). The WAM operates its strobe output while the partition unsets. System Options This section of the Installer Menu contains a series of options that affect the working of the alarm system as a whole.

  • Page 43: Remote Access

    7510r Programming Reference - System Options Choose "N" to enforce Installer reset. The user can then silence the alarm, but the Installer must reset the system by entering the Installer access code. Omit All In some countries it is the custom to allow the user to omit all normal alarm zones that may be open (active) and preventing setting.

  • Page 44: Language

    Programming Reference - System Options 7510r Toggle output nn #9*nn* See “Homelink 75 User Guide” for more details. There are two options: Call-out control If you set this option to Y then the remote operator can control the system when they answer a call from the control unit.

  • Page 45: Installer Code

    7510r Programming Reference - System Options Note that Factory Defaults sets all reporting defaults to UK values, changes the language to English, and erases all names and stored texts. However, select Factory Defaults does not erase the log or stored voice memos.

  • Page 46: Auto Rearm

    Programming Reference - System Options 7510r Auto Rearm To change the number of times that the system will re- arm when the siren time expires select: System Options, Auto Rearm. Select NEVER to make the system never re-arm (the system will go into alarm once only). Select one of the other options to make the system re-arm once, twice, three, four or five times, or always.

  • Page 47: Stray On Entry Delay

    7510r Programming Reference - System Options Stray on Entry Delay To determine what the system will do if a user strays from an entry route zone during entry select System Options, Stray on ent Dly. (This option is available to provide compliance with EN 50131-1.)

  • Page 48: Jamming Detection

    Programming Reference - System Options 7510r Jamming Detection The control unit can detect interfering (or "jamming") radio signals. To enable jamming detection select System Options, Jamming. If the control unit detects jamming once you have enabled this option then the display shows an Alert message for the user.

  • Page 49: Rf Siren Options

    7510r Programming Reference - System Options There are three options available: The user cannot force set the system, even if you have applied the force set zone attribute to any zones. Confirm The user can force set the system. Users employing a...

  • Page 50: Alarm Confirmation

    Programming Reference - System Options 7510r Alarm Confirmation Note: This section of the manual describes the menus available for programming the system to meet DD243. For a description of how you may wish to apply these menus see Appendix A.

  • Page 51: Ip Network

    7510r Programming Reference - IP Network User/Installer: The user can reset after an unconfirmed alarm, but the Installer must reset after a confirmed alarm. User/User: The user can reset after both unconfirmed and confirmed alarms. Installer/Installer: The user cannot reset after an alarm, the installer must do it.

  • Page 52: Downloading

    Programming Reference - Downloading 7510r Note: If you leave this field blank then the control unit will use DHCP (Dynamic Host Control Protocol) to obtain an IP Address from a DHCP server. IP Sub-Net Mask If necessary, key in the sub-net mask, for example “255.255.255.000”.

  • Page 53: Connection Type

    7510r Programming Reference - Downloading display the account name from the keypad: Select Downloading, Account Name. Note that you cannot change the account name from the keypad. Connection Type To choose which physical connection you wish to use select Downloading, Connection Type. The options available...

  • Page 54: Access Mode

    "Rings to Answer" to a higher number than that used by the equipment sharing the telephone line with the control unit. If you do not, then the 7510r will answer before the other equipment. Access Mode This function allows you to provide extra security when a remote PC is dialling into the system.

  • Page 55: Phone Book

    7510r Programming Reference - Downloading first upload can be carried out either from User Menu, or from Installer Menu. Unattended. The control unit answers as soon as the number of rings set in "Rings to Answer" or "Answer on One Ring"...

  • Page 56: Secure Callback

    Programming Reference - Reporting 7510r IP Port 1 Key in the port number that Downloader “listens” to on the remote PC at IP address 1. IP Address 2 Key in an alternate IP Address used by Downloader. IP Port 2 Key in the port number used by the alternate IP address.

  • Page 57: Alarms (Arc Reporting)

    7510r Programming Reference - Reporting Speech Dialler Deals with recording speech messages, selecting the alarm types that will trigger them, and selecting destinations for the messages. Deals with creating text messages, selecting the alarm types that will trigger them and selecting destinations for the messages.
  • Page 58 Programming Reference - Reporting 7510r Single. The control unit reports to the first telephone number in the Phone Book, using a single account number (see "Account Numbers" on page 55). Operation: The control unit dials the number and attempts to connect with the ARC. If the call fails, the control unit ends the call and then re-attempts to connect up to a maximum of 15 times.

  • Page 59: Account Numbers

    7510r Programming Reference - Reporting If you have fitted an 8750 Ethernet module then the control unit can report alarm events over the Internet to a suitable receiver. There are two types of receiver: an IRIS polling engine, or a specialised application running on an ARC’s PCs. You must store separate IP addresses for each type of receiver.
  • Page 60 Programming Reference - Reporting 7510r With CID the control unit sends only the last four digits of the account code. With Fast Format you can use four-, five- or six-digit codes. The control unit pads five-digit codes to six digits using a leading zero.
  • Page 61 7510r Programming Reference - Reporting Close (see note 1) Zone Omitted (Channel 5. see note 2) Burg Partition 1 Burg Partition 2 Burg Partition 3 Burg Partition 4 Alarm Confirmation (required for DD243) Alarm Abort Notes:1. Open and Close provide the same functions as Open/Close, but on two separate channels.
  • Page 62 Programming Reference - Reporting 7510r mode above it.) Use the table to decide which mode is appropriate for the installation. Note: The control unit delays reporting/logging either mains loss, or leaving Installer Menu with mains loss, by 15-22 minutes (chosen randomly). The control...
  • Page 63 7510r Programming Reference - Reporting Table 1. SIA Telegram Reports (cont’d) INTERMEDIATE (BASIC and SUMMARY plus: ) Event SIA Code Code BURG RESTORE 130‡ DOWNLOAD SUCCESS EXTERNAL SIREN TAMPER EXTERNAL SIREN TAMPER RESTORE JAMMING KEYBOX CLOSED KEYBOX OPEN LID TAMPER RESTORE 137‡...
  • Page 64 Programming Reference - Reporting 7510r SIA Report Restorals If you have selected a SIA report mode in Reporting, Alarms then you can enable or disable restoral reporting by selecting Reporting, Alarms, SIA Report Restore. The options available are: Disabled Restore off. The system does not communicate restorals.
  • Page 65 7510r Programming Reference - Reporting control unit to make a static test call at 6:00pm every day. To make test calls on one day every month select Reporting, Alarms, Static Test Call, Monthly. From the display select a number between 1 and 31 to specify the day of the month on which the call should take place.

  • Page 66: Social Care Reporting

    Programming Reference - Reporting 7510r If you select Enabled the for full alarm response the control unit sends tampers as burglary (BA) and sends Contact ID 130 in place of Contact ID 137. Social Care Reporting The control unit sends a social care alarm message for...
  • Page 67 7510r Programming Reference - Reporting Function SCANCOM SCAN FAST STALL Talk DTMF ‘2’ DTMF ‘C’ Listen DTMF ‘1’ DTMF ‘*’ Toggle DTMF ‘*’ End this call DTMF ‘5’ DTMF‘#’ Play ‘Home’ DTMF ‘3’ message. 2. The control unit sends the “Home” speech message (see “Speech Dialler”...
  • Page 68 Programming Reference - Reporting 7510r Alternate. Reports to one of the two telephone numbers in the Phone Book. Operation: The control unit dials the first telephone number and attempts to connect to the receiving centre. If call fails, the control unit ends the call, dials the second telephone number and attempts to connect to the receiving centre.

  • Page 69: Speech Dialler

    The called party can use DTMF ‘5’ to close the call down. Speech Dialler The 7510r has a built-in speech dialler. The control unit can record five speech messages using its internal microphone and replay them to a pre-programmed telephone number to report an alarm.
  • Page 70 Programming Reference - Reporting 7510r emergency”. The control unit plays these messages after the home message. The control unit can record up to 12 seconds of speech for the Home message, and up to eight seconds of speech for each of the alarm messages.
  • Page 71 7510r Programming Reference - Reporting Call Mode This option enables or disables the speech dialler feature. To employ speech dialling set the call mode to “Enabled”. Messages To record the speech messages you wish the speech dialler to use enter Installer mode and select Reporting, Speech Dialler, Messages.
  • Page 72 This allows the user to re-direct any speech message programmed for this slot. Report Triggers In the 7510r you can link up to five different trigger events to each speech message. A trigger event is one item selected from a list of alarm types.

  • Page 73: Sms Reporting

    7510r Programming Reference - Reporting Note: There are a total of five voice messages available. The control unit always sends the Home Message at the beginning of every speech report. The control unit then sends messages 1, 2, 3 or 4 to the telephone numbers you selected.
  • Page 74 Programming Reference - Reporting 7510r The control unit sends the text in the Home Message to every telephone number you have programmed for SMS messages. The control unit also sends message 1 to telephone number 1, message 2 to telephone number 2, message 3 to telephone number 3 and message 4 to telephone number 4.
  • Page 75 7510r Programming Reference - Reporting SMS Triggers You can link a set of alarm events to each message. To link an event select Reporting, SMS, SMS Triggers. Select a message from the list displayed on the screen. The control unit shows the phone number (or name) of the message destination, and a list of events.

  • Page 76: Line Fail Reporting

    Programming Reference - Reporting 7510r telephone number before accepting a request to process a SMS message. Line Fail Reporting This menu lets you program the system to respond with either audible or silent alarms when the control unit detects a fault on one of its communication lines. To program Line Fail Reporting select Reporting, Line Fail Reporting.

  • Page 77: Primary Telecoms

    7510r Programming Reference - Social Care Primary Telecoms This option allows you to choose which communication link the control unit will use first. If you select PSTN the control unit will always try to report on the PSTN line first, followed by any plug on module if the PSTN line fails.

  • Page 78: Testing

    Programming Reference - Testing 7510r control unit’s microphone. If necessary you can change the volume of sound from the loudspeaker by selecting Social Care Alarms, Set Volume (see also “Controls and Connectors” Figure 4 item 9 on page 4 and “Remote Loudspeaker/Microphone on page 12).
  • Page 79 7510r Programming Reference - Testing Press BACK to end the test. Detector Signals The display shows the current and lowest value of the received signal strengths from each learned radio transmitter. Ext Siren Signals The display shows a list of the received signal strengths from each 750r siren.

  • Page 80: View Log

    Programming Reference - View Log 7510r Present the tag to the top left hand corner of the front of the control unit. The display shows the user assigned to the tag. View Log The control unit keeps a log of the last 350 events (for example, alarms and setting/unsetting).

  • Page 81: Appendix A: Dd243 Compliance

    7510r Appendix A: DD243 Compliance Applicability Please study this section if the following applies: 1. You are installing an alarm system in the United Kingdom. 2. The system has remote signalling and requires the local Police Authority to issue a URN (Unique Reference Number).

  • Page 82: Unsetting (Clause 6.4)

    Two zones Note: When you enable Alarm Confirmation the control unit sets the confirm time to 30 minutes. Homelink 75 cannot comply with DD243: 2004 paragraphs 6.4.3 or 6.4.6. Sounders and Status Indication Once you have enabled alarm confirmation, then the following menu options provide further facilities that may be useful in a DD243:2004 installation.

  • Page 83: Bs 8473: 2006

    7510r Appendix A BS 8473: 2006 In addition, if you wish the installation to comply with BS 8473 : 2006 then use the following commands: Command Name Value Notes System Options, Reset After Engineer Reset. User Access Alarm System Options,...

  • Page 84: Appendix B: Glossary

    7510r Appendix B: Glossary Alert An icon ( ) shown on the display to draw the user’s attention to a change in the system status that may require some user action. Alarm Receiving Centre. Groupe Spécial Mobile. The mobile phone standard used throughout Europe and many other parts of the world.
