User Manual Contents Safety Instruction ................................1 Chapter 1: DVR Features .............................. 1 Chapter 2: Layout ................................2 2.1 Front Panel ................................2 2.2 Rear Panel ................................4 2.3 Remote Controller ..............................5 Chapter 3: DVR Installation ............................6 3.1 HDD Installation ..............................6 3.2 Camera and Monitor Connection .........................
Page 3
User Manual 8.2 Record Alarm setting ............................36 8.3 Mail box server List ............................37 8.4 Troubleshooting ..............................37 8.5 System Configuration ............................38 8.6 Accessory ................................38 ...
User Manual Safety Instruction 1. Read Instruction All the safety and operating instruction should be read before the equipment is operated. 2. Power sources This equipment should be operated only from the type of power source indicated on the marking label. If you are not sure of the type of power, please consult your equipment dealer.
User Manual Chapter 1: DVR Features Function Brief and Description Double video output; with monitor, VGA virtual output port or HDMI Output; Support Real time net-viewer and MP live surveillance, ZOOM IN/OUT, dwell time display and PIP monitoring display. H.264 video compression format; recording quality/resolution/frame rate adjustable, Record multiple record modes (Always, Scheduled, Manual, Alarm, Motion detection and remote record)
User Manual Chapter 2: Layout 2.1 Front Panel DVR is a short form of Digital Video Recorder. Front Panel 1 Key title Item Type Marks Function /Indicator When the “Red” indicator flashes it means the hard drive is HDD indicator being read or written to.
User Manual Front Panel 2 Key title Item Type Marks Function /Indicator When the “Red” indicator flashes it means the hard drive is being HDD indicator read or written to. Indicator If the “Green” indicator is on the system is getting power Power indicator normally.
User Manual 2.2 Rear Panel Physical port Connection method Video input Connect CH1-16 (Virtual) video input(BNC interface) Video output (UP) Main video output; (Down) Spot output (BNC interface) Audio input Connect CH1-4 audio signal input (BNC interface) Audio output Connect audio signal output, including spot main audio output and sequence audio output (BNC interface) Audio input Connect (CH5~CH16) Audio input...
User Manual 2.3 Remote Controller Key Title Key Function Press the button to enter into manual record. SEARCH Press the button to enter into record search menu 2×2 Enter into Quad display 3×3 Enter into 9-split display 4×4 Enter into 16-split display AUTO Enter into dwell time display Channel select;...
User Manual Mouse Operation Except using buttons of front panel or remote controller, you also can use mouse to perform system operation. TYPE Function In menu lock mode, Enter into pop-up menu and clicking any sub menu to pop up Log-in window; on menu unlock mode, enter into pop-up menu, and then clicking left key to enter into any sub menu directly.
User Manual Chapter 4: DVR Start up 4.1 System Initialization After connecting the Power cable of DVR to wall outlet and pressing the Power button on the front panel, you will enter into the system initializing screen shown as Picture 4-1 Picture 4-1 After finishing initialization the system will enter into Live screen.
User Manual 5.1 Main Menu Guide Color set Camera Dwell time display Recording Network Search Playback Rec. Search Detail File File Backup HDD Management Main Menu Alarm Setting Email Setting PTZ Setting Device Management 3G Network Area setting Motion Time Setting User password Video Setting System...
User Manual 5.2 Main menu After clicking right button of mouse, pop-up menu appears on the screen. You can click [main menu] option on pop-up menu mode to enter into Main menu interface (Shown as Picture 5-2). In Main Menu mode, you can control device management settings, such as Display, Record, Network, Search, Device and System setting etc.
User Manual [Mode] allow you select record modes, including Always and Scheduled. To record 24 hours a day set the [Mode] to Always. To record on motion or a set schedule, select the [Schedule] option When setting [Mode] to Schedule, the schedule screen will appear as shown in Picture 5-6. [Record CH] options include All, CH-1, CH-2, CH-3, CH-4, CH-5…CH-16 in turn.
Page 15
User Manual At the bottom of the NETWORK SETUP window there is an option to setup a DDNS service of the DVR shown as Picture 5-10.You can access the DVR through a static or dynamic IP address; however a dynamic address can change from time to time.
User Manual Friendly Reminder: The router’s port forwarding interface may be different, however, when entering into virtual server, user will need forward port 0080 and port 9000 of router to IP address of DVR allocated or automatically captured, and select [All] or [Both] in corresponding protocol column and save the above setting. Above steps may differ from the router device depending on the manufacturer.
Page 17
User Manual If you want to backup one history record from the file list, you just select the record and backup device, and then click [Ok] button. Picture 5-14 If you select embedded DVD recorder, backup will be started after clicking [OK] button (shown as below Picture 5-15) When backup processing ends, system will prompt you “Backup success!”...
User Manual 5.2.6 Device Management Options in device management include HDD, Alarm, PTZ, Mobile, Motion and Serial set. Click [Main Menu Device Management] option to enter into the window shown as Picture 5-20. Picture 5-20 5.2.6.1 HDD Management In the [Device Management] screen, highlight and click [HDD] icon to enter into the window shown as Picture 5-21.
Page 19
User Manual Picture 5-23 Picture 5-23(A) Click [Alarm Config] on the bottom of the [Alarm set] window to enter into the interface shown as Picture 5-23(a).Now you are allowed to set detailed alarm parameters. Channel select: the option allows you select one channel you want. I/O Status: allows you select the three options –...
Page 20
User Manual On the [EMAIL] screen, when Enabling [Email] option, you can set its parameters shown as Picture 5-25. Picture 5-25 is a security link transport protocol. You can encrypt your communication info (including your email) SSL: using SSL to prevent hackers from monitoring your email or communication info and even your password. Generally Gmail.com server set SSL to [On] shown as Picture 5-25, and other mail server to [Off].
User Manual Picture 5-27 5.2.6.3 PTZ Setup Enter into [Main menu Device PTZ Setup] to select the channel you want to control and set PTZ protocol (Pelco-D or Pelco-P), Baud Rate (1200, 2400, 4800, 9600), Stop bit (1, 2), Parity Check (None, Odd, Even Mark Space), Address Code and Cruise status respectively.
User Manual The channel is separated into a 13X10 area. When any object moves into the motion detection area, and the area where the object is located is displayed in red recording will be triggered. In the semi-transparent area the motion detection is off. Picture 5-32 5.2.6.6 Set Serial When Multiple DVRs are controlled by keyboard, user needs to set...
User Manual When you set Password Enabled to “ON” firstly (shown as Picture 5-37), you can setup a user password and administrator password respectively. The password is consist of digital number 0~9 and supports up to 6 characters. Picture 5-37 5.2.7.3 Video/Audio Setup Click [Main Menu System Video/Audio] to enter into Video/Audio setup screen shown as Picture 5-38.
User Manual Default: Click the [Default] button to reset the DVR parameters to factory default settings. Reboot: Click the [Reboot] button to restart the device manually. Safe power off: the button allows you cut the power after making sure the DVR shutdown. Note: 1、...
User Manual If you clicking the right key in 9-split mode: Channel (CH1~9) Channel (CH10~16) If in the 16-split mode, the display show as below: Channel (CH1~16) 5.5 PTZ Control We introduced setting PTZ parameters previously in chapter 5.2.6.3. Here we will discuss how to operate PTZ controls. Pop up the Pop-up Menu to highlight and enter into [PTZ control] menu (shown as Picture 5-44).
User Manual 5.6 PIP Mode PIP display is one kind of live display mode, including 1x1 display modes and 1x2 display modes. 1x1 display mode 1x2 display mode 5.7 Video Search Click Pop-up Menu to quickly enter into [Video Search] Menu. We have introduced how to search and playback video record in previous section.
Page 27
User Manual Picture 6-3 Picture 5-47 3、 Select the playback file you desired from the file shown as Picture 5-48. Picture 5-48 Note: Please select the file with *.264 format or *.nvr. The record file backed-up by U flash disk or removable disk is with *.264 format, and DVD Recorder with *.nvr format.
Page 28
User Manual The button functions from left to right in turn are as follows: [Play] button: start playing record file [Pause] button: pause the record file playback [Stop] button: stop the record file playback [Rewind] button: rewind playing the record file at X2, X4, X8 and X16 speeds. [Forward] button: forward playing the record file at X2, X4, X8 and X16 speeds.
User M Manual Chapte er 6: W Web App plicatio on Man nager 6.1 Plu g-ins d ownloa ad and in nstallat tion 1. Open yo our web brow wser and inpu t the IP addre ess and web p port of DVR;...
User M Manual Picture 6 6.3 We b Client t Interfa After s successful lo ogging-in we eb client, yo ou will ente er into the Live interfa ace shown a as Picture 6- -3 and simultaneou usly Audio / V Video will be automatically y connected w...
Page 31
User M Manual Picture 6 Back-up Highlight th he backup file e you desired and click [Do ownload] but tton. The backup file will be d defaulted to sa ave as AVI fo ormat. While doubl le-clicking th he record file or highlight the record fi ile and click [...
Page 32
User M Manual Picture 6 Click [Motio on] option, yo ou are allowe ed to set Mot tion channel, its sensitivity y and MD Ar rea, and also copy the sett tings to other channe els. Picture 6 arm Param meters Click [ [Alarm Param...
Page 33
User M Manual Picture 6 Clicking [O utput] option n allows you set alarm ou utput paramet ters, includin ng buzzer tim me, Post Reco ord time, Ala arm out time, and op pen Pre-record d function Picture 6 6-10 Z Param meters Click [...
Page 34
User M Manual twork Para ameters Click [ [Network Pa arameters] op ption to ent er into [Net twork setting g] menu sho own as Pictu ure 6-12. Re elevant parameters s setting please e refer to secti ion 5.2.3 – [N Network Setti ing].
Page 35
User M Manual vice Mana Extend d [Device Ma anage] option n to enter int o sub menus s – System se etting, Autho ority and DST T shown as P Picture 6-15. After en ntering into S System settin g, you can fre eely set syste em Language,...
User M Manual 6.3.1.4 L Local sett ting The option a allows you se et [Record Sav ve Path], [Fra ame Save Pat th] and [File Save Path]. Picture 6 6-18 6.3.1.4 L Log out Click [Log gout] option to o return back k Log-in Inter rface shown a...
User Manual 6. Load: allow you load the last preset point you set. 7. Save: allow you save the preset point you set. 8. Cruise: allow you enable/disenable the [Cruise] function. 9. Clean: allow you delete the current preset point. 6.3.3 Play Control Picture 6-20 1.
User Manual Chapter 8: Appendix 8.1 Operation Function Table Type Title Description Page Time Set system date/time, display format and day-light saving setting time Language Set system language select Set CH title and position; adjust image color parameter Channel value; set CH display to ON / Off and time display/recording setting time overlaying to On/Off.
User Manual Remote Set record mode and status of DVR remotely record Remote Check local record history via network playback PTZ control Remotely control PTZ camera, position, focus, zoom and iris etc. parameter Set local CH display, record, alarm, PTZ control parameter value set of DVR via network remotely...
User Manual the screen that means a motion alarm is triggered. When [ ] icon appears on the screen, that means HDD alarm has occurred. 8.3 Mail box server List Web site Mail box Sender server(25) Receiver server(110) @163.com smtp.163.com pop3.163.com @vip.163.com smtp.vip.163.com...
User Manual Q: “Record” Can not work normally, how to deal with? A: Check if the current screen is in Play mode, pressing [Stop] button to exit the Play mode and then you can enter into the [Record] function. Q: Why the Remote Controller can’t work normally? A: Check if the battery is power off;...
Page 43
The material in this document is the intellectual property of our department . No part of this manual be reproduced, copied, translated, transmitted, or published in any form or by any means without our department prior written permission. Our products are under continual improvement and we reserve the right to make changes without noti ce.
