Summary of Contents for Eddy Wireless SD Cards Series
- Page 1 IRELESS ® sales@eddywireless.com SD Cards Series MDVR USER'S MANUAL V1.07E V1.07E NO.:W2012K0101P002 W 2 0 1 2 P...
-
Page 2: Table Of Contents
Contents CHAPTER 1:PRODUCT APPLICATION AND PARAMETER-------------------------------------- CHAPTER 2:PRODUCT INTERFACE DEFINITION AND FUNCTION DESCRIPTION------- 2.1:MDVR Out-design and Dimension--------------------------------------------------------- 2.2:Definition of functional MDVR back panel interface----------------------------------- 2.3:Definition of simple type MDVR'S back panel interface------------------------------ 2.4:Brief instruction of commonly used interface cable---------------------------------- 2.5:USIM card installation------------------------------------------------------------------------ 2.6:Instructions of function keys on remote controller------------------------------------ CHAPTER 3:SYSTEM OPERATION MENU---------------------------------------------------------- 3.1:Demo working and user login---------------------------------------------------------------... -
Page 3: Chapter 1:Product Application And Parameter
SD Card Mobile DVR User Manual CHAPTER 1: PRODUCT APPLICATIONS AND PARAMETERS 1.1 MDVR is a cost-effective, function extensibile equipment which is designed for on-board video monitoring and remote monitoring, It uses the rapid handling device and embedded Linux platform, combined with the most advanced H.264 video compression / decompression technology , network technology and GPS technology . - Page 4 SD Card Mobile DVR User Manual FORM 2 : MDVR BASIC ELECTRICAL PARAMETERS LIST Parameters Items Specifications 36V, When long-term under 8V, or long-term over 36V, Power input DC8-36V auto power off, and enter protection mode. 12V +/-0.2V Max:2A. Power output Vehicle key signal Impedance 75Ù...
- Page 5 SD Card Mobile DVR User Manual 1.3: MDVR NOTICE: To make sure MDVR safety use, acquire satisfactory performance, and extend the service life of the equipments , please fully consider the following factors when install the equipment : 1.When install and operate the equipment , please obey all the electronic products guide, vehicles and other connection equipments requirements 2.Power supply and equipment grounded : Direct input range of the machine power supply is from...
-
Page 6: Chapter 2:Product Interface Definition And Function Description
SD Card Mobile DVR User Manual CHAPTER 2 : INTERFACE AND DESCRIPTION OF THE FUNCTIONS 2.1 MDVR OUT-DESIGN AND DIMENSION Figure 2-1 Unit mm Figure2-3 Panel Indicator Light Description V-OUT Video OUT SD1/SD2:Recording SD card indicator light ,Light will be on Function type MDVR dimension and installation hole site (double SD card when the SD card exists. -
Page 7: Definition Of Functional Mdvr Back Panel Interface
SD Card Mobile DVR User Manual 2.2: DEFINITION OF FUNCTIONAL MDVR BACK PANEL INTERFACE DEFINITION OF FUNCTIONAL MDVR BACK PANEL INTERFACE AS SHOWN IN FIGURE 2-8: POWER IN 4CH Audio/Video Input 4pin AUDIO/VIDEO OUTPUT AV-OUT CAM1 CAM2 CAM4 CAM4 POWER RS485 RS232 SENSORS SPEED Figure 2-8... -
Page 8: Definition Of Simple Type Mdvr's Back Panel Interface
SD Card Mobile DVR User Manual 2.3: DEFINITION OF SIMPLE TYPE MDVR'S BACK PANEL INTERFACE Figure 2-9 GPS Antenna AVIATION HEAD VIDEO & AUDIO INPUT 1--12VOUT 2--GND 3--A-IN 4--V-IN POWER INPUT VIDEO/AUDIO OUTPUT 1: Interface specifications, please refer to table 3, V-in & A-in with aviation head ; 2: 2 channel alarm input , 2 channel alarm output, a pair of school interface;... -
Page 9: Usim Card Installation
SD Card Mobile DVR User Manual 3.The yellow cable must be installed on the ignition line , or the equipment will not support the delay shut down , and the last video recording will be missed . 4.The installation of MDVR must get positive electrode directly from the battery. Please don't use iron wire as the ground line . -
Page 10: Instructions Of Function Keys On Remote Controller
SD Card Mobile DVR User Manual 2.6 INSTRUCTIONS OF FUNCTION KEYS ON REMOTE CONTROLLER Power on /off(not LOGIN used Temporarily) Number key area Picture adjustment PTZ control Direction key area Exit / return Delete/Cancel System information Play back operation key area 4 images segmentation PTZ control key area Shortcut key / test key... -
Page 11: Chapter 3:System Operation Menu
SD Card Mobile DVR User Manual CHAPTER 3 SYSTEM MENU SETTING INSTRUCTIONS 3.1: DEMO WORKING AND USER LOGIN. Trun on the device after power supply and other connecting successfully and according to installation guidance. Interface refer to Figure 3-1and there are four-image monitoring interface after the device start working.Press LOGIN button on the remote control ,then direct into login "... -
Page 12: System Menu Construction Chart
SD Card Mobile DVR User Manual 3.2 SYSTEM MENUS CONSTRUCTION CHART BASIC POWER SYSTEM NETWORK PASSWORD NORMAL RECORD CHANNEL TIME LIST SUB-STREAM SENSOR SPEED LOGIN VEHICLE G-SENSOR TEMPERATURE FORMAT CINFIGURE TOOLS UPGRADE PLAYBACK SHORTCUT Figure 3-5 DETECTION INFO WIRELESS MODULE WIFI SYSTEM SETUP Figure 3-6... -
Page 13: 2:Power Off/On Setup
SD Card Mobile DVR User Manual 06:00:00 30 ( 06:00:00 22:00:00 Figure 3-8 Figure 3-9 4."COMPANY NAME","VEHICLE NUM","DRIVER NAME""LINE NUM"Setting: Press "Enter" key to pop up keyboard window, then use left/right/up/down/enter key to setup. 5. When turn on automatic adjustment function, in the default time , the system will adjust the time via GPS automatically when it comes to the time for adjustment. -
Page 14: Recording Setup
SD Card Mobile DVR User Manual 3.4 RECORD SETUP Figure 3-13 Figure 3-12 It includes: Normal setting, Channel setting, timing setting and sub-stream setting. It can reach the highest quality recording after settings. With default settings, the device will start recording after powering on. -
Page 15: Channel Setup
SD Card Mobile DVR User Manual 3.4-2 CHANNELS SETUP 1 Set some properties of each channel,such as RES, QUAl MIC AUDIO,VOLUME etc . CH ENABLE RES. FPS QUAL MIC PREVIEW VOLUME FR: 1-25 optional,when reach 25 FR it is real-time recording. -
Page 16: Vehicle Information
SD Card Mobile DVR User Manual 3.5 VEHICLE INFORMATION Figure 3-19 Figure 3-18 It includes SENSOR, SPEED, G-SENSOR SETUP. SENSOR SETUP Figure 3-20 3.5-1 SENSOR SETUP- ALARM INPUT 1.When users install MDVRs, define the sensors according to different port settings, see the figures 3-20. -
Page 17: Speed Setup
SD Card Mobile DVR User Manual 3.5-3 SPEED SETUP VEHICLE Figure 3-22 1.When setting GPS /VECHILE to get the speed , please press ENTER to switch , if select GPS, " " so should require demo have GPS module and with signal, that can pass the speed to vehicle and the vehicle can get the speed from GPS. -
Page 18: 2:Configure Manage And Log Search
SD Card Mobile DVR User Manual 3.6-2 CONFIGURE MANAGE AND LOG SEARCH START TIME 2012-01-15 00:00:00 END TIME 2012-01-15 23:59:59 DATE TIME EVENT NAME 12/01/15 14:45:07 POWER ON 12/01/15 14:46:55 VIDEO LOST1 12/01/15 14:55:38 FILE PLAYBACK 12/01/15 14:56:25 REC NORMAL SET Figure 3-28 Figure 3-27 Configure manage mainly including import and outport system current... -
Page 19: 4:System Upgrade
SD Card Mobile DVR User Manual PROCEDURES OF SETTING DETECTION AREAS: Figure 3-30 Select Configure and press ENTER , enter into motion detection configurationinterface. " " " " (Figure 3-30). Step1 : Select the first Box , press Enter gets yellow , after move the arrow keys ,gets dark green ) "... -
Page 20: Module Manage
SD Card Mobile DVR User Manual 3.7 MODULE MANAGE 3.7-1 3G SETUP INSTRUCTIONS: When device need connect the network , must have setting in this menu . 1)Insert USIM card , which can support two options : China Telecom(WCDMA) and China Mobile (EVDO) USIM card slot is in the communications board , Remove the small plate which under the demo , then can see the USIM slot , detail installation information please refer to 2.5 section . -
Page 21: 2:Wifi Setup
SD Card Mobile DVR User Manual 3.7-2 WIFI SETUP WIFI SETUP IP ADDR ENABLE 192.168.001.012 NETMASK 255.255.255.000 ENCRYPT ENCRYPT TYPE:WEP GATEWAY 192.168.001.001 AUTH MODE OPEN ENCRYPT TYPE SSID PASSWORD WIFI SETUP SAVE Figure 3-36 INSTRUCTIONS: Insert WIFI antenna into the backside mount of the demo , Edith the following information at the interface as pictures (Figure 3-36) 1.Make enable and Encrypt status ON authentication mode including WPA , WPA-PSK,OPEN "... -
Page 22: System Information
SD Card Mobile DVR User Manual 8. Remote control opertation Setting " " on the manu . They are used for controlled up down ,left and right " ZOOM " " " " " + , - enlarge and narrow function "... - Page 23 SD Card Mobile DVR User Manual setup Record mode. Others manus such as sensor setting , speed alarm setting, Normal shock acceleration,motion detection set related parameters and also connect peripherals, when alarm signal occurs,system will record the video automatically.when playback the recording, resolution contains D1/HD1/CIF, Video s starting and ending timeis the file package time and it will show file s storage SEARCH RESULT...
-
Page 24: Chapter 4: Common Shortcut Setup
SD Card Mobile DVR User Manual CHAPTER 4: COMMON SHORTCUT SETUP 4.1 CABLES TESTING AND POWER ON The host power cable has three wires red, black and yellow. Red and black wires connect to the car battery directly,red wire to positive pole and black to negative pole.The yellow wire directly connects to the ignition wire (namely the gear before the start-up motor). - Page 25 SD Card Mobile DVR User Manual alarm preparation record time (range 0-60s) and the alarm record delay time (range 30-900s); the alarm output time (range 5-240s), the alarm output setting can be dependent on the actual external alarm equipment. Second, the installation of corresponding external alarm input devices is needed, like emergency switch button, switch door magnetic door, sudden braking sensor and other sensors.
-
Page 26: Ptz Connection And Setup
SD Card Mobile DVR User Manual 4.3 PTZ CONNECTION AND SETUP Setup steps: Step 1, Choose PTZ protocol, includes PELCO-D and PELCO-P, mostly choose PELCO-D. Step 2, Setup baudrate from 1200/2400/4800/9600, which has to correspond to that on PTZ. Step 3, Setup PTZ address, which should match the set address on PTZ, Normally the default PTZ address is 1. -
Page 27: Playback Recorded Files On Pc
SD Card Mobile DVR User Manual PLAYBACK RECORDED FILES ON PC Recorded files can not only playback on the device itself,but also can transfer to the PC player to play.Install the player: Double-click the CD-ROM installation files MDVR PLayer V1.0.1.30_111221.exe , and select the "... -
Page 28: Vehicle Fast Connecting To Cms
SD Card Mobile DVR User Manual 4.5 VEHICLE FAST CONNECTING TO CMS NOTE: For the Simply MDVR which without WIFI and 3G modules, the below instructions is not compatible to them Install SIM card which support WCDMA/EVDO. Please refer to Section 2.6 for detailed Step 1: installation steps reference, as shown in Figure 2-15. -
Page 29: Appendix1 : Cms Platform Interface
SD Card Mobile DVR User Manual Mode is workable without authentication,For encryption type, need to choose WEP, then insert SSID and password (wireless network's name and password). Also need to set the host IP address, mask, gateway and etc. With settings finished, press the F1 button on the remote control, Check "... -
Page 30: Appendix2 : Faq
SD Card Mobile DVR User Manual APPENDIX 2: FAQ Q: What should I do if problems occur when I can not solve myself? A: Please write down the units number, software version number and describe theproblems in details, then submit to our technical support for analysis. Please kindly note that the more detailed descriptions that you offer will make our analysis more convenient. - Page 31 SD Card Mobile DVR User Manual FAQ ABOUT 3G (Basic SD card MDVR without 3G/WIFI modules ,Please notice the bellowing points: ) Q: What need I pay attention on using 3G wireless module to dial? A: 1.Built-in wireless module is different between WCDMA and EVDO, also different devices support different modules.
-
Page 32: Appendix3 : Corresponding Table Of Storage Space
SD Card Mobile DVR User Manual APPENDIX 3: CORRESPONDING TABLE OF STORAGE SPACE Corresponding table between image quality and recording space Quality Resolution Storage Space The storage space for one channel per hour is as showing as the above table for reference. The actual recording file size is depending on the current channel, illumination variant, object movement and many other factors.
