A.C.Ryan Playon!HD Mini 3 User Manual page 15

No. Button Function
1 Power
2 Numeric buttons
3 Zoom
4 Red/Select
5 Green/Confirm
6 VOL+
7 VOL-
8 Home
9 OK/Enter
10 Navigational buttons
11 Menu
12 FRWD
13 Play
14 Slow
15 Pause
16 Repeat
17 Goto
18 A-B
19 Angle
20 TV SYS.
21 Eject
22 Files
23 Edit
24 Blue
25 Yellow
26 Prev
27 Info
28 Next
29 Mute
30 Return
31 Setup
32 FFWD
33 Stop
34 Audio
35 Subtitle
36 CM Skip
37 Replay
Press to enter standby mode or wake up.
Press to enter channel numbers or numeric input when changing settings.
Press to zoom the image (photo or video).
Press to select files in file selecting menu.
Function is available in virtual keyboard.
Press to increase the volume.
Press to decrease the volume.
Press to enter the home screen.
Press OK button to confirm.
Press the arrow buttons to select menu options, and the OK button to confirm.
Press to enable the option menu, where you can change the review mode of file manager and
media library; Press to display or hide the option menu during playback.
Press to fast rewind the current playback. Press repeatedly to select speeds.
Press to begin playback.
Press to play back in slow motion. Press the PLAY button to resume regular playback.
Press to pause playback or slideshow.
Press to set repeat option.
Press to jump to a specific point on a title. Specify the point using Title, Chapter and Time.
Press to set the beginning and end points of a section to repeat.
Press to change the view angle during DVD (with multi-angle) playback.
Press to switch between NTSC, PAL, 480P, 576P, 720P, 1080I, and 1080P.
Press to safely remove the USB device.
Press to enter file manager.
Press to enter file editing menu in file manager. Press to enter file selecting menu in media library.
Press to open/close USB DVD-ROM.
Display / close text console in the browser/internet media.
Press to view the previous file / page up.
Press to display current status. Press during playback, an on-screen display appears showing track
number and time elapsed/remaining.
Press to view the next file / page down.
Press to mute audio output, and press again to resume.
Press to return to the previous screen while navigating menus.
Press to enter the setup menu.
Press to fast forward the current playback. Press repeatedly to select speeds.
Press to stop playback.
Press to select an audio track.
Press to set subtitle options. You can change the color/size/offset/text encoding of subtitle.
Press to advance 30 seconds of the current playback.
Press to rewind 10 seconds of the current playback.
Product Introduction | 15
