Thanks for purchasing our product

Please read this manual carefully before using

Statement:

· We strive to ensure the exactness and integrality of the manual in the process of preparation, but

still error or omission is inevitable.

· The copy, transmission, plagiary, storage in retrieval system, or translation into any language

without written authorization is prohibited.

CHAPTER I.

ABOUT THE PRODUCT .................................................................................................................................... 5

1.1

................................................................................................................................................................. 6

NTRODUCTION

PROSONIC

Table of Contents

Need help?

Do you have a question about the DVR and is the answer not in the manual?

Questions and answers

Summary of Contents for Prosonic DVR

Page 1 Thanks for purchasing our product PROSONIC Please read this manual carefully before using Statement: · We strive to ensure the exactness and integrality of the manual in the process of preparation, but still error or omission is inevitable. · The copy, transmission, plagiary, storage in retrieval system, or translation into any language without written authorization is prohibited.
Page 2: Table Of Contents
Digital Video Recorder ..............................6 UNCTIONS AND FEATURES CHAPTER II. INSTALLATION INSTRUCTION ........................10 ................................. 10 HECK THE DEVICE ..................................10 NSTALL CHAPTER III. OPERATION INSTRUCTION.......................... 13 ……………………………………………………………………………………………………………… .. 13 RONT PANEL ..............................14 EMOTE CONTROLLER ................................. 15 OUSE OPERATION ................................
Page 3 Digital Video Recorder 5.1.1 Password operation instruction ............................. 25 ................................26 MAGE SETTING 5.2.1 Area mask setting ............................... 26 5.2.2 Image mask setting ..............................27 5.2.3 Alarm processing setting ............................28 5.2.4 Video loss setting ................................ 30 5.2.5 Motion detection setting ............................. 31 ............................
Page 4 Digital Video Recorder CHAPTER VI. NETDVR OPERATION INSTRUCTION ......................55 ..................................55 EATURES ................................56 ONFIGURATION ................................56 TART SOFTWARE ..................................57 AIN MENU 6.4.1 Channel management ..............................58 6.4.2 User management............................... 60 6.4.3 Proxy management ..............................61 6.4.4 Channel number ................................ 62 6.4.5 Language ..................................
Page 5: Packing List
ETWORK PAN TILT CONTROL CHAPTER X. INTERNET EXPLORER SETTINGS ……………………………………………………………………...……. .75 ………………………………………………………………………………………….75 10.1 I NTERNET OPTIONS SETTINGS ON PC ………………………………………………………………………..…………………..…….….….76 10.2 V IEW DVR IMAGE BY IE ……………………………………………………………………………..…………………...…….79 10.3 V IEW DVR FIELD IMAGE …………………………………………………………………………………………………..……….79 10.4 A DJUST FRAME RATE …………………………………………………………………..……………………..……….80 10.5 P...
Page 6: Functions And Features
PSOS, it is independent of the PC platform, aviod computer virus attack and eliminates halt permanently, which enables the system to run faster and more stably. DVR is also integrated with the feature of digital A/V server and can be connected to Internet to build powerful safety monitoring network. It can be widely applied in different industries, e.g.
Page 7: Video Recording
Digital Video Recorder Compression method Compress/decompress in H264 algorithm and higher definition is ensured; The audio is compressed in G.729 algorithm, which will bring better audio effect; Synchronized A/V compression; CBR and VBR compression; Display 4-channel A/V input, BNC output; 25 F/S (PAL) or 30 F/S (NTSC) real-time compression in each channel without delay;...
Page 8: Ptz Control
Digital Video Recorder you have set; The system is integrated with sleep function to reduce heat radiation of the recorder and extend the service life of hard disk; Search Search by date/time, list or exact search; Common/alarm video recording searching; Log function;...
Page 9 Digital Video Recorder Customize time of alarm output; Customize alarm input type NC/NO; Clear alarm manually or by remote control/network; Open/Close buzzer in menu; Camera blank or video loss alarm; Support pre-alarm recording Network function Support 10/100MB self-adaptive network; Download backup with network control software; Control PTZ/lens, speed dome camera with network control software;...
Page 10: Chapter Ii. Installation Instruction
Digital Video Recorder Chapter II. Installation Instruction Check the device Before install the digital video recorder, please check whether the appearance of the device is damaged and whether the accessories are complete. Then, open the case, remove the protective film and begin to install the device. Prepare the devices (camera, power supply and monitor, etc) which will be connected to the digital video recorder and connect them.
Page 11: Rear Panel
Digital Video Recorder  Step 5: Connect SATA hard disk data cable. To connect two hard disks with one data cable, you need to set the master drive and slave drive. The data cable has three joints, which will be connected to the pin sockets on motherboard, master drive and slave drive respectively.
Page 12 Digital Video Recorder Connect to monitor and output video signals. 5. UTP network port Connect to Ethernet devices, e.g. Ethernet switch, Ethernet hub, etc. 6. Power supply Connect to DC12V/3A power supply. 7~9. Connection terminal of alarm input/output signal and RS485 signal Connect to peripheral equipment like alarm, decoder, pan/tilt, etc.
Page 13: Chapter Iii. Operation Instruction
Digital Video Recorder Chapter III. Operation Instruction Front panel Name Description Control power supply to the device. Power Switch The light of power indicator will be on after turn on the power Indicator Light and blink 1 cyle/s. It will be off after turn off the power. Input number 1 ~ 10 Number Key Indicate the work state of the device.
Page 14: Remote Controller
Digital Video Recorder Remote controller Name Remark Same as [Power] key on front panel; turn on/off the power Power Same as Alert, Cancel, Search, PTZ control, Exit, Info and VGA on Advance front panel Same as Play, FF and FR on front panel Playing Same as Record on front panel;...
Page 15: Mouse Operation
Digital Video Recorder Mouse operation Connect the mouse to the USB interface in front panel. Left click to confirm selection and right click to select menu. Right click menu is shown as below: Name Remark Set parameters of recorder Same as Menu key Recording data Same as Search key System information...
Page 16 Digital Video Recorder  Note: Password protection is divided into two levels: administrator (senior user) and operator (common user). (See Chapter 5.9.1: Authority setting on P.29.)  Prompt: Default password of administrator is 88888888; default password of operator is 66666666. If password protection is enabled, press [Menu] key and enter valid administrator password in the dialogue box "Input PSW", then, “System settings”...
Page 17: Input Method
Digital Video Recorder [↓], [←], [→] key to select items in main menu and press [Menu] key to enter the submenu and set the parameters. In the submenu, the operation will be canceled if you press “Cancel” button. Press “OK” and the setting will be saved. Return to main menu and move cursor to “Exit”, then, press [Menu] key and the following message box will popup: To save the setting, click “Yes”.
Page 18 Digital Video Recorder Video recording symbol: The yellow round icon indicates timing recording state. Video recording symbol: The red round icon indicates alarm recording state. Playing symbol: Indicates the recording is being played. FF symbol: Indicates fast forward. FR symbol: Indicates fast rewind. Single frame symbol: Indicates pause in single frame playing state.
Page 19: Chapter Iv. Basic Operation
Digital Video Recorder Chapter IIII. Basic Operation Turn on Check whether the current and voltage of power supply accord with the digital video recorder before turning it on. Check whether video recording device is connected and whether the connection is proper. Check whether monitor is connected to VOUT port or VGA port on rear panel.
Page 20: Recording Setting
Digital Video Recorder setting”, as shown below. Move cursor to “Time Zone” and press [Menu] key to select “Summer” or “Winter”. Press [←]/[→] to Time Zone select an option and press [Menu] to confirm. Move cursor to “Time Zone” and press [Menu] key to select “Y-M-D” or “M-D-Y”. Press [←]/[→] to Date Format select an option and press [Menu] to confirm.
Page 21: Secret Recording Setting
Digital Video Recorder Customize quality in “Quality” box. Move cursor to Quality and press [Menu] key to enter. Available options Step 2 include: Highest, High, Medium, Low and Customized. (Higher quality will occupy more space.) Press [←]/[→] to move cursor to desired option and press “OK” to save and exit. (Do not change this setting if not necessary) The “Audio”...
Page 22: Single Frame Playing
Digital Video Recorder Press  button to play fast reversely. Press  button to play fast forwardly. Press | button to play next track. Press | button to play previous track. Press Play button to resume normal playing and press it again to stop playback. Single frame playing In the playing process, press [] button on front panel to pause the recording.
Page 23: Turn Off
Digital Video Recorder Step 2: Select file type of recording to search. Common recording and alarm recording are available. Click [↑]/[↓] key to select recording. Click [←]/[→] key to select page. Press [Menu] key to select the recording (or multiple options) to play. The grounding of the item where cursor locates is yellow and the selected item is green.
Page 24: Chapter V Menu And Parameter Settings
Digital Video Recorder Chapter V Menu and Parameter Settings Local display Output system PAL and NTSC are available. The system should be same to that of the output device. It is PAL in Mainland China. Language Select menu language. Simplified Chinese, traditional Chinese, English, Hungarian, Spanish are available.
Page 25: Password Operation Instruction
Digital Video Recorder Password operation Press [Menu] key to select. If password protection is enabled, you can enter the password and then customize the menu. If password protection is disabled, press Menu key to enter menu setting interface directly. Panel lock Lock front panel.
Page 26: Area Mask Setting
Digital Video Recorder Select image Select video recording image. You can select up to 16 images or select single image to operate. Name Give name to the recording image for the convenience of operation and viewing. You can name every image here.
Page 27: Image Mask Setting
Digital Video Recorder Move cursor to “Select image” to select the image to set mask. Press [Menu] to confirm. Step 2: Set mask area Enter mask setting interface. Press [Menu] key to select “Mask alarm” to activate Area button. Move cursor to “Area” and press [Menu] to enter mask area setting interface, as shown below: In mask area setting interface, red line is used as the direction line of area selection.
Page 28: Alarm Processing Setting
Digital Video Recorder Step 1: Select image Enter “ImageSet” menu. Move cursor to “Select image” to select the image to set mask alarm. Press [Menu] to confirm. Step 2: Activate mask alarm Press [Menu] key to select “Mask alarm” to activate mask alarm. Step 3: Sensitivity setting Set “Sensitivity”.
Page 29: Alarm Processing Setting
Digital Video Recorder 5.2.3 Alarm processing setting Select triggering image Press [Menu] key to select among the 16 images. The selected image will record when alarm is triggered. Move cursor to select image and press [Menu] to activate channel image. Buzzer Press [Menu] to activate buzzer.
Page 30: Video Loss Setting
Digital Video Recorder Alarm output time Output time of alarm signals. Alarm should be connected to the recorder.  Note: You also need to set these three items (Recording time before alarm, recording time after alarm, alarm output time) in other options (e.g. video loss processing). Their values are interrelated, e.g. if the “Recording time before alarm” in “Mask alarm”...
Page 31: Motion Detection Setting
Digital Video Recorder “Input PSW” dialogue box will popup. (Default password: 88888888) Enter valid password to stop video loss alarm recording. The alerting symbol in the image will also disappear. 5.2.5 Motion detection setting Step 1: Select image Enter “ImageSet” interface. Move cursor to “Select image” to select the image to perform motion detection setting. Press [Menu] to confirm.
Page 32 Digital Video Recorder In the video scene of this channel, you need to define which area will be processed if motion detection occurs. The whole image is divided into 48 (6×8) panes. Three colors are available for cursor to set motion detection: yellow indicates moving cursor only;...
Page 33 Digital Video Recorder detection will be disabled. In alarm recording process, if buzzer is activated, the device will buzz. The time of alarm recording depends on recording time before and after alarm. Alarm recording will take effected only when alerted. Step 7: Timing motion detection Perform motion detection in preset time period.
Page 34: Video Recording Setting
Digital Video Recorder to give up the setting. Step 10: Activate/deactivate alerting Activate If alarm recording is enabled, you need to press [Alert] button on front panel to activate motion detection recording. Alerting symbol is displayed. If alarm occurs, the recorder will buzz. Press [Clear] on front panel to clear alarm output and press [Alert] button again to exit alerting state.
Page 35 Digital Video Recorder  Prompt: Higher quality image will occupy more space. Frame rate The number of images that will be recorded in one second. E.g. 25f/s indicates recording 25 images in one second. Audio Whether audio will be recorded in monitoring state. Channels 1-16 are available. Secret recording In monitoring state, the video won’t be displayed on the monitor but it will be recorded.
Page 36: Network Setting
Digital Video Recorder The recorder is activated in specified time period only. Date Ten options are available. Beginning time The time to start recording. The recording will be started at specified time. The format is 24-hour. Press numerical keys on front panel to input time. End time The time to stop recording.
Page 37 Digital Video Recorder Type Available modes to get IP: Auto and Static. DHCP protocol is used to get IP automatically. The LAN must have DHCP server, otherwise the recorder can’t get IP. This IP address is unique. The recorder can’t detect whether there IP address conflict automatically. Please IP address specify valid IP address.
Page 38: Alarm Setting
Digital Video Recorder PPPOE With PPPOE, you may connect the PC to remote access device with simple bridging access device. Enter account and password to transfer information through network. DDNS Dynamic domain name service. Map user's dynamic IP address to a static DNS. When user accesses network, the client will send the dynamic IP of host to the server application in server host.
Page 39: Abnormity Processing
Hard Disk Error, in each option, user can select Buzzer, Alarm Upload and Alarm Output for reminders. Note: Alarm Upload and Alarm Output are only available when alarming device is equipped; the Buzzer is built in the DVR host. Serial port device...
Page 40: Serial Port Device
Digital Video Recorder Set the channel number of decoder, including velocity, data bit, stop bit, checkout and stream control, in serial port device menu. The values of these items must match the connected serial device. The default values are: 8 data bits, 1 stop bit, none checkout bit and hardware stream control.
Page 41 Note: the above parameters are for settings of all decoders, same parameters must be selected. Equipment: select decoder Channel selection: select the corresponding channel of the DVR controlled by the decoder, or it will lead to failure of control.
Page 42 Digital Video Recorder Decoder protocol: select type of decoder protocol. The following decoder protocols are preset in the program, including “PANNSONIC”,“LLW”, “PELCO-D”, “PELCO-P”, “LILIN”, “NEON”, “PELCO-D YA”, “PELCO-D SFD”, “PELCO-P MK”, “PELCO-D ZT”, “PELCO-P ZT”, “ZHIMIN”. Note: different protocols can be used for different channels. Address ID: Input the address of the decoder connected to the selected screen.
Page 43 Digital Video Recorder Copy: to copy the set parameters of the channel to other channels to save time. Auto Cruise: auto cruise is to set the cruising path. The cruising path is a path on which the camera moves at a certain speed, passing through different cruising points with numbers. Each cruising point includes the preset point and time for stay.
Page 44 Digital Video Recorder ○ 3 To set the “step length”, i.e. the moving speed from preset point to another; ○ 4 Click “Auto Cruise” to set cruising path; ○ 5 Select “Cruising Point” and check “Enable cruising function of the screen” and “Enable this cruising point”;...
Page 45 Digital Video Recorder PTZ Lens Control  Select PTZ lens control: press the PTZ control button, the PTZ icon will display at the lower left corner of the monitor, or the indicator will light to show that it is under PTZ control status. (PTZ status indicator in the gray blank) ...
Page 46 Digital Video Recorder ZOOM -: Next Auto on: Alerting Auto off: Timing Supplementary 1 on: Search (for example wiper or heating, etc) Supplementary 1off: Information Supplementary 2 on: Quit Supplementary 2 off: Clear  Note: Decoder control buttons of different types may correspond to different buttons on the front-panel. Speed dome camera and preset points control ...
Page 47: Preview Setting
Digital Video Recorder point into the system.  Load preset location of the dome Press the [Menu] button to enter system menu; select “Serial Device” and “Set Preset Point” in order and input the number of a preset point saved in the system (00 to 63) in the “Preset Point Number” dialog box and then select “Load”...
Page 48: Authority Setting
Digital Video Recorder Protect the setting and using of digital video recorder through authority setting. Set the management and operation authority in system settings. The levels of authority are: Administrator, Operator 1, 2 and 3. Administrator is enabled with the highest authority.
Page 49: Play Backup
Digital Video Recorder you didn’t input same password. Authority setting Only selected authority may be set. Press [Menu] button to activate selected option. Step 3: Save setting Move cursor to select “OK” to save and exit.  Note: If you access the menu with administrator, the “Input PSW” dialogue box will popup when you press [Menu] button. Input the administrator password and then set the menus.
Page 50: Playback By Time Search
Digital Video Recorder Input time Set the backup time. Backup will be performed in specified time period. Select channel Select recording image. Only selected images will be backup. Recording type Select the type of video recording. Common, alarm and all are available. Searching mode Set the accuracy of recording searching.
Page 51: Tools
Digital Video Recorder Common, alarm and all are available. Select Common to operate common video recording. Select Alarm to operate alarm video recording. (Alarm video recording includes timing recording and detection recording.) Select All to operate all video recordings. Step 4: Select searching mode Quick search and exact search are available.
Page 52: Factory Settings
Digital Video Recorder 5.12 Factory settings Restore default settings. It will take effect when the device is restarted. (IP and gateway are also reset.) 5.13 Upgrade Upgrade the software. Check whether the language of original software is congruent with update. The update will fail if they don’t have same language.
Page 53: Hdd Management
Digital Video Recorder been copied into root directory of USB device. And the file name must be upcmsdvr.bin Restart the recorder after update.  Note: Do not interrupt the upgrading process. Cutting off power supply or pressing the power button is prohibited; otherwise, the recorder can’t be run in order.
Page 54: Recover Data
Digital Video Recorder new password. When password is confirmed, click “Back” to cancel format; or click “Execute” to format. When the hard disk is formatted, all files will be deleted. You need to input valid password to format the hard disk. 5.14.1 Recover data Click “Recover data”...
Page 55: Chapter Vi Netdvr Operation Instruction
Digital Video Recorder Chapter VI NETDVR Operation Instruction Netdvr is the new generation network video monitoring software developed by us. It is integrated with powerful channel management function. You can monitor the audio/video through network. It supports network searching and playing, network backup and TCP/Multicast protocol, and may build perfect monitor center system with Managecenter.
Page 56: Configuration
Digital Video Recorder channel; click multi-image full screen in monitoring menu. In multi-image full screen, you click a window to display it in full screen;  Support synchronized local A/V recording and shooting (support pause shooting); circle playing and progress bar playing of local recordings.
Page 57: Main Menu
Digital Video Recorder This dialogue box will initialize Administrator account. Please input and repeat the administrator password and then click “OK”. The system is in English interface by default when you use the software for the first time. Main menu When the account is initialized, enter the main interface as shown in the picture below: The interface is in English by default.
Page 58: Channel Management
Digital Video Recorder  Note: The software is in single channel when it is initialized, however, you may select multi channels. 6.4.1 Channel management After the settings of language and skin, enter “Channel management” to input IP address of video recorder and customize the parameters, as shown below: ...
Page 59 The status bar on the left displays the three added video recorders and their parameters. All the three added recorders are set as default DVR. When you view the scene, the software will connect to the first DVR in the list directly, e.g. “226” in the picture above.
Page 60: User Management
Default mode: Monitor and Patrol are available. Patrol time: 5 sec by default. Move to: In multi-channel control, you can move any DVR from one channel to another. 6.4.2 User management User management includes three items: Account, Authority and Log.
Page 61: Proxy Management
To use this function, another proxy software is needed. If this function is enabled, it will connect to the IP of proxy server instead of DVR when you view the scene. When proxy server is started, up to 20 users may access a same proxy server to view...
Page 62: Channel Number
Channel number item is controlled through multi-channel. Take 9 channels as an example: If user selects 9-channel centralized control, the Netdvr software will be displayed in 9 channels (9 video windows). Then, enter “Channel management” to add DVR and customize the each channel, as shown in the picture below:...
Page 63: Language
Different from single channel, you need to customize Channel 0, Channel 1, Channel 2…Channel 8 separately.  Note: The number of DVR in each channel is unlimited. After setting, the operation of each channel is independent. 6.4.5 Language Three languages are available: Simplified Chinese, Traditional Chinese and English (default).
Page 64 Digital Video Recorder Storage path: The storage path of backup files and recording files. You can use default path (select “Default path”) or customize the path. You can select o overwrite the backup or recording files or not. If the size of recording file is too big, you can split the file into different segments.
Page 65: Exit
View mode: Common and Multicast are available. Their difference is: only one user may view the DVR if Common is selected, while multiple users may view the DVR at the same time if Multicast is selected. If there is a user viewing the image in multicast mode, all users will access the DVR in multicast mode.
Page 66: Chapter Vii Specific Operation Of Netdvr
View Click “View” and the following two modes are available to connect: 1. If you have customized “Default DVR” in “Channel management”, it will connect to the IP of default DVR and display the scene video; 2. If you haven’t customized “Default DVR”, the following dialogue box will popup:...
Page 67: Patrol
When you are viewing the scene, you can zoom or switch the video windows, take pictures, record video and control PTZ. Patrol If you added multiple DVR to a channel and select “Yes” in “Patrol”, you need to input time in “Patrol time” (default: 5 sec).
Page 68: Take Picture
Digital Video Recorder As shown in the picture above, select “Yes” for DVR 227 and 228 in Channel 0 and set the “Patrol time” as 5 sec. After setting, right click in channel 0 and select “Patrol”, then, the software will connect to the IP of DVR 227 and 228 in channel 0 in sequence and patrol the images of each DVR according to the preset time.
Page 69: Adjust Image Quality And Frame Rate
25F/S in Frame rate. When you view the scene, change the frame rate into 12.5F/S, then, the frame rates of scene and the recording files of DVR are both 12.5F/S. Stop viewing or recording, then, perform the operation again, and the frame rate will turn into 25F/S.
Page 70: Keys Definition
You can press the following keys when you view the scene, play local files or operate the DVR. Stop: Press this key to cancel the monitoring. Pause: When you play local files, operate DVR files (list playing) or operate local DVR HDD, you can press this key hold the playing and press “Play” to resume the playing.
Page 71 When audio is enabled, select “Channel 1” to play the audio of channel 1; select “Channel 2” to play the audio of channel 2; and so on. Talk: Press this key to realize talk function. The network end and front DVR scene may talk to each other. Press “Stop” to end talk function.
Page 72 Status: Display current playing status, e.g. fast/slow, etc. Read data: The data that have been read (count in 8MB). When front DVR is connected, if the data packet is empty, it indicates that the network or the DVR is abnormal. Please wait for a moment and connect again later.
Page 73: Pan/Tilt Control
Digital Video Recorder Chapter VIIII Pan/tilt Control Pan/tilt control Correspond the address setting of decoders to the images and press the PTZ key on front panel to control the pan/tilt. The numerical keys on front panel correspond to the addresses of decoders and you need to press the numerical key that accords with decoder address to control the pan/tilt.
Page 74 DVR isn’t enabled with this function. When you control the pan/tilt with DVRPLAY, if the command is invalid, please check whether the “PTZ” key on DVR has been reset (i.e. the “PTZ” symbol on LCD is...
Page 75: Chapter X Internet Explorer Settings
Digital Video Recorder Chapter X Internet Explorer Settings  Note: set the firewall level to low or middle. Disable or uninstall “Internet Assistant” and similar software first or the software may not run. Please make sure DirectX 9.0 issued by Microsoft is installed in your PC and that the version of your Internet Explorer is 6.0 or above.
Page 76: View Dvr Image By Ie
Digital Video Recorder 10.2 View DVR Image by IE Enter the DVR address you want to visit in IE and press Enter to start connecting. After connection success, select the user level in the login box and enter password. Username: admin...
Page 77 Digital Video Recorder  Select the DVR video channel that you want to view in . The default is all channels. This number button can control audio channels in the process of viewing video;  is the button for switching video channels. You can switch among Single Channel, 4-Channel, 9-Channel and 16-Channel;...
Page 78 Digital Video Recorder  Press Search button ( ) to load video in DVR;  Press Play button ( ) to play local video;  You can record video or capture image and enable or disable volume while playing video;...
Page 79: View Dvr Field Image
Digital Video Recorder 10.3 View DVR Field Image Enter IE player. The default play channel is the first channel, which means if no play channel is selected, only the image of the first channel of the field will display by pressing view field button ( ).
Page 80: Play/Backup Video On Dvr
10.5 Play/backup Video on DVR When logon success, click Search button ( ) in the interface. For multi-channel device, e.g. 16-channel DVR, if the bandwidth is not enough for transferring images of 16 channels at the same time, images of any...
Page 81 Digital Video Recorder one or several channels can be selected. Before playing the video, select the channel numbers that you want to view (icon is in red) and do not select the channel numbers that you will not view (icon is in yellow), and then play the video.
Page 82: Capture Video
Digital Video Recorder 10.6 Capture Video When playing video stream, click the Capture button ( ) to capture an image of the video. Upon clicking for the first time, an interface will pop-up for users to select a path to save the files, and the software will automatically create a folder CapFiles in the selected path.
Page 83: Achieve Control Over Ptz
PTZ will move to location 6. For other settings of the PTZ please refer to the text reminders in the interface. 10.11 Operate Remote Menu Click the “Setting” button at the right side of the IE player interface and the remote menu will be pop-up. This menu is the same with the menu appearing when operating the DVR.
Page 84: Chapter Xi Troubleshooting
Check whether the HDD is connected properly and whether the HDD and cable are in good condition. To check the HDD, remove it and turn on the DVR. The DVR may be turned on normally even without the HDD and displays “No HDD, continue?”.
Page 85 4. Why the DVR restarts repeatedly after self detection? ① Check the HDD. If the HDD hasn’t been formatted or the HDD has fault, the DVR will be restarted; ② Check the power supply of DVR; ③ Pull out the network cable and restart the DVR. Serious network fault may cause the DVR to restart repeatedly.
Page 86 2. Why the monitor doesn’t display anything? ① There is a black screen process (about 30 seconds) when the DVR is starting; ② If there is no image displayed when the DVR is started for a long time (more than 60 seconds), please check whether the monitor is turned on and whether the video cable is connected properly.
Page 87 Digital Video Recorder (III) Video recording/playing, recording data, backup 1. Why the recording has no audio? ① Check whether “Mute” is activated; ② Check whether “Audio” is selected in the settings of video recording; ③ Check the audio input cable. 2.
Page 88 8. Why the image playing is slow? ① Check whether slow playing is enabled. The DVR supports 1/2, 1/4, 1/8 and 1/16 speed slow playing; ② Check whether the HDD is connected properly and whether the HDD has bad sectors. The bad sectors of HDD may cause image...
Page 89: Appendix 1 Specifications And Parameters
Digital Video Recorder Appendix 1: Specifications and Parameters Item Specifications and parameters Compression standard H.264 Video signal PAL (625 lines, 50f/s); NTSC (525lines, 60f/s) Video input Composite video: 1.0V p-p/75Ω, BNC connector ×4 Composite video: 1.0V p-p/75Ω, BNC connector ×2 ， VGA x 1 Video output Audio output RCA connector ×...
Page 90 Digital Video Recorder Backup mode Network backup; external CD-R; USB interface Display: 704×576 Resolution Image: CIF 352×288 2 SATA Hard Disk （ Capacity can support to 2000GB(2T)） Hard disk E-clock Y/M/D; h/m/s Encryption Data encryption + secondary password management Power 20W (exclude hard disk) Environmental Working temperature: +5℃~+50℃;...
Page 91: Appendix 2 Packing List
Digital Video Recorder Appendix 2: Packing List Name Quantity 1 Set Power Cord 1 Piece Power Adapter 1 Piece IR Remote Controller 1 Piece...
Page 92 Digital Video Recorder 1 Piece Manual 1 Piece Screws 1 Pack Quality Certificate 1 Piece...
