PrimeDTV Technologies PHD-HM5 Product Manual

HD Media Player Product Manual
Model: PHD-HM5
Thank you for using PrimeDTV high-definition media player PHD-HM5.
Be careful before you use the player.
1. After opening the package, please check the parts item list, please contact us if you find any item missing.
2. Please place PHD-HM5 flat and in a dry cool environment. Make sure nothing to block the air net and nothing sitting on the top.
3. Please power off PHD-HM5 before connecting it to TV
Packing list
Product introduction
Front Panel:
STANDBY/ON
Rear Panel:
HDMI LAN Y Pb Pr
HD player
HD Media Player Product Manual
Model: PHD-HM5
PrimeDTV Technologies, Inc. © 2009
HD player manual
PHD-HM5
OPTICAL L AUDIO R DC 12V
USB
PrimeDTV Technologies, Inc. © 2009
POWER
PAGE UP MENU
OK
PAGE DOWN BACK
IMAGE AUDIO VOL+
CHANGE SELECT
SUBTITLE TIME VOL-
Remote control
Power adapter
Power Button
Power light
(at the middle left)
Remote Control
IR Receiver
(at the middle left)
High Definition Multimedia Interface
HDMI
Recommend the use of this interface to connect TV
LAN 100M Local Area Network
HD YPbPr Output (Default Output)
YPbPr
Optical Audio (Toslink) Output
OP
Analog Audio Output
L/R
USB Input to connect USB device
DC12V
Power Interface
Set unit Standby or On
Blue: working mode
Red: Standby mode
Please make sure nothing
block the Front Panel IR
Receiver
