Spyder Cam Spydercam User Manual

12.0 mp infrared digital spydercam
Hide thumbs
Table of Contents

Advertisement

Quick Links

12.0 MP Infrared Digital Spydercam

USER MANUAL

Thank you for purchasing the Spydercam.
In order to optimize the functionality of the Spydercam, please read this manual carefully
BEFORE operating the device. Also ensure that you keep it handy for future reference.
Ensure that you register your Spydercam at
www.spydercam.co.za

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Spydercam and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Spyder Cam Spydercam

  • Page 1: User Manual

    USER MANUAL Thank you for purchasing the Spydercam. In order to optimize the functionality of the Spydercam, please read this manual carefully BEFORE operating the device. Also ensure that you keep it handy for future reference. Ensure that you register your Spydercam at...

  • Page 2: Table Of Contents

    Contents Safety Warnings Precautions Key Features Description and Parts Additional Requirements Getting Started Advanced Operations Mounting the Spydercam Frequently Asked Questions/Troubleshooting Technical Specifications Included Parts List GPRS Notice...

  • Page 3: Safety Warnings

    Safety Warnings To reduce the risk of electric shock, do not remove the cover of the Spydercam at any time. While the Spydercam comes with a high waterproof rating (IP54), it should never be submersed in water. If the Spydercam is no longer within the service guarantee period, we are still able to provide services such as repairing and part replacements, at a cost.

  • Page 4: Key Features

    The design of the Spydercam allows it to be used in both in- and outdoors. While it is weather resistant, it should not be used close to heat sources and/or under water.

  • Page 5: Description And Parts

    Description and Parts The Spydercam provides the following connection ports for external devices: LCD, Keyboard, Speaker, SD Card slot, SIM Card port, Microphone port, USB port, TV out, AA port and External DC port.

  • Page 6: Additional Requirements

    The normal SD card size that is supported by the Spydercam is from 8MB to 32GB. In case the card cannot be read by the Spydercam it is advisable to format the card. This can be done via a computer (that has an SD slot) or with the Spydercam itself. For detailed instruction on how to format a SD card with the Spydercam, please refer to ADVANCED OPERATIONS (Point14).

  • Page 7: Getting Started

    Menu Settings and Test Mode Live Mode  In order to save battery power the Spydercam will automatically shut down after one minute if no key is pressed while the device is in Test Mode.  While in Test Mode the Red IR Light on the front of the device will remain on.

  • Page 8: Advanced Operations

    In order for you to change the category settings on the Spydercam, you are required to switch it into the Test mode. For your convenience it is also possible to set categories while the Spydercam is linked to the TV output if you find the LCD screen to be too small.
  • Page 9 Once you have switched the Spydercam into Test mode, the following screen will appear After the Spydercam has started, this screen will change to the following: Camera/Video Mode Image/Video size Number of Images/Videos taken and available space SD Card Status...
  • Page 10 With the Spydercam is in Test mode, press the Menu key to access the various setting options. No Category Sub Categories Recommended Setting Camera Mode Camera/Video/Playback Camera Digital Zoom 1X/2X/3X/4X Image Size 12MP/8MP/5MP 12MP Capture Number 1/2/3 Video Size 720X480/ 640 X480/QVGA 320X240...
  • Page 11 In order to navigate between video clips use the Left/Right button. The OK button to play the requested clip and the Up/Down keys to increase/decrease the playback volume. (If there is a power interruption during the capturing of a video clip, the file will show a ―file error‖...
  • Page 12 INTERVAL This setting determines how long the PIR of the camera will be disabled after each triggering in the ON/Live mode. During this time the Spydercam will therefore not take any pictures/videos. In order to change the interval period, in the Interval mode: Press Up/Down to select 0-60 minutes.
  • Page 13 VIDEO FRAMES In the Video Frames mode: Press Up/Down to select 30/15 frames per second. Press OK to save the selection Press Left to return to the previous screen without making a change to the existing setting. Press Menu to return to Test mode. TIME STAMP This functionality determines whether the date/time should be stamped onto the pictures and video clips.
  • Page 14 Press Menu to return to Test mode. IR LED The IR (Infrared) Led allows the Spydercam to operate effectively during night time or when there is insufficient natural light. In the IR LED mode: Press Up/Down to select ON/OFF.
  • Page 15 Press Left to return to the previous screen without making a change to the existing setting. Press Menu to return to Test mode. GPRS MODE This mode is to activate the Spydercam to send MMS/E-Mail Messages. In the GPRS Mode: Press Up/Down to select YES/NO. Press OK to save the selection Press Left to return to the previous screen without making a change to the existing setting.

  • Page 16: Mounting The Spydercam

     Using a lockable steel box Points to remember when setting up:  When the Spydercam is attached to a tree, please ensure that the diameter is at least 15 cm.  To achieve optimal results the Spydercam should be 3-6 meters away from the object and at a height of 1,5 to 2 meters.

  • Page 17: Frequently Asked Questions/Troubleshooting

     There will be a ―False Trigger‖ if the PIR sensor is activated by motion or heat in the activation zone.  To avoid this from happening try and move the Spydercam to an area where there is no interference.
  • Page 18  You will achieve the best results if the subject is within the ideal flash range. Anything closer than 3m (inside the 10º angle) will appear too light.  Ensure that you have not set the Spydercam up in such a way that light will reflect back from a painted wall.
  • Page 19 This is as a result of the Spydercam’s ability to automatically sense the brightness of the light.  If the problem persists, you just need to move the set up angle of the Spydercam slightly.  It is also recommended not to turn on the IR LED for indoor use during the day.
  • Page 20  When entering into the ON position, the device has a 15s waiting time, in the meantime the green indicated LED will blink.  As a solution you should mount the Spydercam while it is in the OFF position. Once finished affixing the camera, open the cover, switch to ON position, close the cover, and leave the area within 15 seconds.
  • Page 21 As an example you sometimes start to have conversation on a cell phone where the signal is very good, but it then varies between weak and strong as you talk.  As a result of this, the Spydercam cannot guarantee 100% success with the sending and receiving of MMS’s.

  • Page 22: Technical Specifications

    TV out (NTSC/PAL); USB; SD Card Operating Temperature -20º - 60 º Operating Humidity 5% - 90% Waterproof Specification IP54 Security Authentication CE FCC ROSH Included Parts List Part Name Quantity Spydercam USB Cable TV Out Cable Mounting Strap User Manual...

  • Page 23: Gprs Notice

    3. It is recommended to switch the GPRS mode to OFF, if you not using the MMS function since it will save the battery power. 4. The Spydercam sends MMS messages through GPRS network, so before using this function, you need to open GPRS service from your service provider. It supports four bands: 850MHz, 900MHz, 1800MHz, and 1900MHz.
