Universal Device Controller User Guide Rev 1 Version 3.0 7/19/2010 High Resolution Systems Control Systems and Solutions 7111 Dixie Highway #151 Clarkston, MI 48346 www.HighResolutionSystems.com... - Page 2 The software can be used by itself or with the USB connected UDC-400 control panel which can be assigned any commands for any device. Each UDC-400 offers 40 physical buttons with three virtual pages of button layouts providing a total of 120 unique user defined buttons.
- Page 3 Universal Device Control Software Overview UDC-400 High Resolution Systems Control Systems and Solutions 7111 Dixie Highway #151 Clarkston, MI 48346 www.HighResolutionSystems.com...
-
Page 4: Descriptions Of Features
Descriptions of Features: Listen and Learn Technology Listen and Learn is used with unknown incoming commands and enables you to use your own controller as a Universal Device Controller. This feature gives you the ability to use your computer running UDC software as a listening device to record incoming commands. - Page 5 Device Control through different control surfaces and interfaces. To design your own web pages simply design a UDC Custom Controller, design and Listen & Learn Controller or use a UDC-400 controller. All button positions and images are displayed in web browsers just like in the UDC software.
- Page 6 meaning you can have one XY (RCP) panel for multiple routers simultaneously. The command is sent once you press a take button which specifies which router to send that switch to. Each different router would have its own Take or Auto take button but use the same XY (input/output) buttons.
- Page 7 Response Window Gives you real time feedback and responses from devices you are sending commands to. Soon you will be able to apply responses to buttons to perform a function when a response is seen. For example this will be used to send a query command to a router to get visual feedback on the current switched state of that router.
