Fellowes Powershred C-320 Instructions page 2

Card/CD entry
CD flap
Shredder head
Paper entry
Door
Casters
Pocket for manual and oil
CAPABILITIES
Will shred: Paper, credit cards, CD/DVDs, staples and small
paper clips
Will not shred: Adhesive labels, transparencies, newspaper,
cardboard, large paper clips, laminates or plastic other than
noted above
Paper shred size:
Strip-Cut.................................................................................5.8mm
Strip-Cut.................................................................................3.9mm
Cross-Cut....................................................................... 3.9 x 30mm
IMPORTANT SAFETY INSTRUCTIONS — Read Before Using!
• Keep away from children and pets. Always set to
Off (O) or unplug when not in use.
• Keep foreign objects – gloves, jewelry, clothing, hair,
etc. – away from shredder openings. If object enters top
opening, switch to Reverse (R) to back out object.
• Avoid touching exposed blades under Cross-Cut shredder head.
2
ENGLISH
Models C-320/C-320C
Control panel
Paper jam Bin full Door open
(red) (red) (red)
Turbo Jam Release Button
Auto-On (I) Off (O) Reverse (R)
Standby (green)
Bin
Maximum:
Sheets per pass (Strip-Cut 5.8mm).......................................... 28-30*
Sheets per pass (Strip-Cut 3.9mm).......................................... 22-24*
Sheets per day (Strip-Cut).......................................................14,000
Sheets per pass (Cross-Cut) ..................................................... 16-18*
Sheets per day (Cross-Cut)........................................................7,000
Cards/CDs per pass .........................................................................1
Cards/CDs per day ........................................................................10
Paper width........................................................................... 254mm
*A4 (70g) paper at 220-240v, 6Amps; heavier paper, humidity
or other than rated voltage may reduce capacity.
• Never use aerosol, petroleum based or other flammable
products on or near shredder. Do not use canned air
on shredder.
• Do not use if damaged or defective. Do not open
shredder head. Do not place near or over heat or
water source.
• Use only designated entry for cards/CDs. Keep finger away from
CD hole.
OPERATION
Shredder comes ready to use. Insert waste bag (Fellowes #36056) for easy disposal.
PAPER
Set to Off (O)
and plug in
Press Auto-On (I) Feed into paper entry
and release
TROUBLESHOOTING
Paper jam: Set to Off (O) and empty bin. Replace bin, close door, and follow any or all of the below procedures.
Strip Cut:
Press and hold
Press and hold Open CD flap
Reverse (R) for
Turbo Jam
1 second
Release Button
Cross-Cut:
Remove all uncut
Press and hold Press and hold
Turbo Jam Reverse (R) for 1 paper from entry
Release Button second
MAINTENANCE
Cross-Cut and Strip-Cut: Follow oiling procedure below and repeat twice.
Run regularly in reverse for
one minute
Cross-Cut only:
Lubricate when bin is full, or
immediately, if:
• Capacity decreases Press and hold *Apply oil
• Motor sounds different, or across entry
shredder stops running
*Only use a non-aerosol vegetable oil in long nozzle container such as Fellowes #35250
SUPPLIES
To purchase supplies, contact Fellowes at the appropriate location listed on the back page of this instruction manual, or visit us at
www.fellowes.com.
WARRANTY
LIMITED WARRANTY Fellowes, Inc. ("Fellowes") warrants the cutting blades of the
machine to be free from defects in material and workmanship for 20 years from
the date of purchase by the original consumer. Fellowes warrants all other parts of
the machine to be free of defects in material and workmanship for 2 years from
the date of purchase by the original consumer. If any part is found to be defective
during the warranty period, your sole and exclusive remedy will be repair or
replacement, at Fellowes' option and expense, of the defective part.
This warranty does not apply in cases of abuse, mishandling, or unauthorized
repair. ANY IMPLIED WARRANTY, INCLUDING THAT OF MERCHANTABILITY OR
CARD/CD
Feed into card/CD
Press Auto-On (I) Hold card/CD
at edge entry and release
Pull several sheets
Press and hold Turbo Jam
of uncut paper
Release Button. Repeat
from entry procedure if still in jam mode.
Indicator lights:
Make sure door is
tightly closed
Paper Jam
Press and hold Turbo
Jam Release Button
Remove and
empty bin
Press Auto-On (I) Shred one sheet Press and hold
Reverse (R)
2-3 seconds
FITNESS FOR A PARTICULAR PURPOSE, IS HEREBY LIMITED IN DURATION TO THE
APPROPRIATE WARRANTY PERIOD SET FORTH ABOVE. In no event shall Fellowes be
liable for any consequential or incidental damages attributable to this product.
This warranty gives you specific legal rights. The duration, terms, and conditions of
this warranty are valid worldwide, except where different limitations, restrictions,
or conditions may be required by local law.
For more details or to obtain service under this warranty, please contact us or
your dealer.
Set to Off (O)
3
