Duratech DA05 WinCE Quick Start Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
HANDHELD COMPUTER
DA05 WinCE
Quick Start Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DA05 WinCE and is the answer not in the manual?

Questions and answers

Summary of Contents for Duratech DA05 WinCE

  • Page 1 HANDHELD COMPUTER DA05 WinCE Quick Start Guide...
  • Page 2 Copyright © 2007 All rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language, or computer language, in any form, or by any means, electronic, mechanical, magnetic, optical, chemical, or other, without the prior written permission of the manufacturer.
  • Page 3 Microsoft, Windows CE, Pocket PC, and Windows Mobile are registered trademarks of Microsoft Corp. Intel, Bulverde are the registered trademarks of Intel Corp. All product and company names are trademarks or registered trademarks of their respective holders.
  • Page 4 EMC and Safety Notice Federal Communications Commission Radio Frequency Interference Statement This equipment generates, uses, and can radiate radio frequency energy and if not installed and used in accordance with the instructions, may cause interference to radio communications. This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to part 15 of the FCC Rules.
  • Page 5 ---Consult the dealer or an experienced radio/TV technician for help. This Transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. Any changes or modifications (including the antennas) made to this device that are not expressly approved by the manufacturer may void the user’s authority to operate the equipment.
  • Page 6 3. Use an outlet that is far away from the interfered appliance. 4. Re-orient your computer in respect to the interfered appliance to see if there is improvement. If all of these failed, please call your dealer for help. This equipment complies with the requirements set out in the Council Direction on the Approximation of the laws of the Member States relating to Electromagnetic Compatibility (89/336/EEC).
  • Page 7 EN61000-4-8 Power-Frequency Magnetic Field EN61000-4-11 +A1:2001 Voltage Dips and Voltage Interruptions LVD EN60950-1 :2001 ETSI EN301 489-01 V1.4.1 EMC Standards for Radio Equipment ETSI EN 301 489-17 1.2.1 EMC Standards for 2.4GHz Wideband Transmission Systems) ETSI EN 300 328-2 V1.2.1 EMC Standards for Using Spread Spectrum Modulation Techniques UL, TÜV AC Adapter (EN60950 LVD is included in TÜV)
  • Page 8 Please recycle the packing materials, and at the end of the unit's life, all other materials in accordance with the local regulations. Please refer “Materials and Recycling” for the contents of the materials.

  • Page 9: Table Of Contents

    CONTENTS GETTING STARTED ....................1 ’ ....................1 S IN THE ......................2 UICK TART ..............3 ONTROLS NDICATORS ORTS ............10 PERATING NVIRONMENT AND UGGEDNESS COMPONENTS AND FUNCTIONS..............11 ......................11 ADAPTER ....................... 11 ATTERY ....................12 HARGE ATTERY .....................
  • Page 10 .......................20 PC................20 YNCHRONIZING DATA WITH DA05 ....................21 ESETTING THE USING WIRELESS LAN (OPTION) ..............24 USING BLUETOOTH (OPTION).................28 ....................31 NQUIRY DEVICES .....................33 EVICE PAIRING ................35 ROPERTIES AND CONFIGURATION Local services ....................35 Local device properties and configuration ............40 Distant device properties ...................45 ....................46 ISTANT SERVICES Services Inquiry ....................46...
  • Page 11 ................62 TOP THE LUETOOTH ANAGER SPECIFICATIONS....................63 CPU........................63 ........................ 63 EMORY ......................... 63 ISPLAY ...................... 63 OUCH CREEN ....................... 64 PORTS .............. 64 YSTEM IMENSIONS AND EIGHT AC A ......................64 DAPTER ....................... 65 ATTERY ................. 66 ATERIALS AND ECYCLING ..................

  • Page 13: Getting Started

    GETTING STARTED What’s in the Box The following components come with your handheld computer. If anything is missing or damaged please notify the dealer immediately. Handheld computer unit AC adapter AC power cord User's guide USB Data sync cable Spare stylus(with tether)

  • Page 14: Quick Start

    Quick Start • Attach the AC adapter to AC outlet. The adapter LED indicates the power is ready. • Insert the battery and then plug in the adapter to handheld computer. Orange charge LED will light up till the battery is full charged. Charging time will be , It’s recommended the battery is full charged about 4 hours.

  • Page 15: Controls, Indicators, And Ports

    Controls, Indicators, and Ports Front:...
  • Page 16 1. Wireless ON/OFF (Flight or button 3) Turn ON/OFF the wireless device (Option: WiFi, Bluetooth, GPS) Please turn it OFF at locations with wireless control (hospital, onboard airplane, etc.) 2. Button (User programmable) 3. Button (User programmable) 4. Navigator button [Left], [Right], [Up], [Down] 4 directions [Enter] at the center 5.
  • Page 17 Rear: 1. Speaker (under hand strap) 2. Stylus 3. Reset Button...
  • Page 18 4. Battery knob 5. Battery 6. Microphone Left: Wireless device antenna USB client port Data sync with the computer. USB Host port For Keyboard, USB Flash storage. Kensington lock slot...
  • Page 19 Right: Microphone/Earphone jack SD I/O slot (Secured Digital card and device) antenna (optional)
  • Page 20 Top: Serial port or GPS antenna...
  • Page 21 Bottom: DC jack PCMCIA slot One PCMCIA type II slot CF (Compact Flash card) will be available by PCMCIA-to-CF adapter Cradle docking connector Connection to cradle...

  • Page 22: Operating Environment And Ruggedness

    Operating Environment and Ruggedness A clean and moisture-free environment is preferred. If it is necessary to work in a hostile environment, please make sure all ports are well protected from dust, moisture, or water. Proper isolation from extreme hazardous exposure is recommended. The computer is designed with rugged features of vibration, shock, dust, and rain/water protection.

  • Page 23: Components And Functions

    COMPONENTS AND FUNCTIONS AC adapter When using the AC adapter: • Use a properly grounded AC outlet. • Use one AC outlet exclusively for the computer. Having other appliances on the same line may cause interference. • Use a power strip with built-in surge protection. The AC adapter automatically detects the AC line voltage (110V or 220V) and adjusts accordingly.

  • Page 24: Charge Battery

    • Shut down the computer when not to use for a longer time Battery Low When the battery is nearly exhausted, the computer prompts a window warning. Once the Battery Low warning occurs, please do either or all of the following: 1.
  • Page 25 To swap the battery: Turn power OFF Turn the battery knob counterclockwise to loose the battery Remove battery from compartment Insert a new battery Press the battery down and turn battery knob clockwise to lock it Press power button to turn ON the computer...

  • Page 26: Fix The Stylus With Tether

    Fix the stylus with tether...

  • Page 27: Optional Devices

    Optional Devices Cradle (optional) Cradle is the device for docking, port extension, and battery charging. AC adapter may attach directly to cradle and charges the computer battery as well as spare battery. There is a battery slot on the back of cradle to mount spare battery.
  • Page 28 Front: Right LAN/RJ45...
  • Page 29 Rear 1. Battery Lock 2. Spare battery charger 3. USB Client...
  • Page 30 4. USB Host 5. DC IN 6. COM port 7. Optional COM port Mount the cradle: 1. Computer should be power off before docking. 2. Open the rubber cap on the docking connector 3. Align the computer with cradle docking connector 4.

  • Page 31: Pcmcia Slot

    PCMCIA Slot The computer accepts one type-II PCMCIA card. Insert the card firmly into the slot and fix the rubber cover for water/dust protection. To remove the card, push the eject button to pop out the card. The eject button can hide into the compartment by pushing it inward gently.

  • Page 32: Basic Operation

    BASIC OPERATION Get Help Help or get it from companion CD Get the operation information from the list. Synchronizing data with PC Using ActiveSync, you can synchronize information on this device with information on the PC. ActiveSync is already installed on this device but you need to install it on your PC if your PC does not have it yet.

  • Page 33: Resetting The Da05

    Resetting the DA05 Soft Reset To do a soft reset will delete any data that has not been saved in the ROM. But your Try a soft reset if the device does saved files and programs are not deleted. not respond when you tap the display or press a button. To do a soft reset, use the stylus to press the reset button on the rear.
  • Page 34 Do a hard reset if You want to restore the device to factory default settings. You forget the password and need to reset it. Your device is experiencing severe operational problems and you have attempted a soft reset. To do a hard reset Press and Hold Key4 and use stylus to tape reset button (on the rear).System will enter Eboot mode.
  • Page 35 Use stylus to tape rest button(on the rear) to reboot System...

  • Page 36: Using Wireless Lan (Option)

    Using Wireless LAN (option) Connect to Internet Turn on the Wireless Signals. 1.1 Press “Wireless” button on the DA05 keypad and screen will pop up a “Wireless Manager” dialog. (Figure 1-2) 1.2 Tap “On” button to enable wireless function and screen will pop up a “WLAN11G1”...
  • Page 37 function available. (Figure 1-5) 1.7 If you enter “Network key” is correctly then you can see “CreTE_WL300” icon shown connected status. ( Figure 1-6) 1.8 Now you can use “Internet Explorer” to surfer World Wide Web that for you want. ( Figure 1-7 & Figure 1-8)

  • Page 40: Using Bluetooth (Option)

    Using Bluetooth (option) Turn on the Wireless Signals. 1.1 Press “Wireless” button on the DA05 keypad and screen will pop up a “Wireless Manager” dialog. 1.2 Tap “On” button to enable Bluetooth function 1.3 When the bluetooth manager is run, a new window appears and a bluetooth icon appears in the task bar.
  • Page 41 Tool Bar List Window Status Bar...
  • Page 42 The toolbar Stop the current action Refresh Parent Folder(FTP) Show favorite list Show distant devices Show the about box Configure the application Show local service Shut down...

  • Page 43: Inquiry Devices

    The status bar Working indicator Distant Deivce State State : What the bluetooth manager is doing Working indicator : For long task (Inquiry, Connection) Distant device : With which device the bluetooth manager is currently connected Inquiry devices When the application is started, you need to click on to start inquiry remote Bluetooth devices.
  • Page 44 represented by an icon (showing what class of device they are: computer, laptop, pda, audio device) and the name of the device. Once you have clicked one time on all futures clicks will show devices without inquirying (to decrease search time). To inquiry again remote bluetooth devices you must refresh the list by clicking on .

  • Page 45: Device Pairing

    During an inquiry, you can stop it by clicking on the the icon. Device pairing The device pairing can be done in three ways : • We want to be paired with another distant device For that the distant device must be in the list window to be paired with the current device.
  • Page 46 • A distant device try to pair with the current device (with no Auto Pin Code) When a device try to pair with the current device, a new window appear to enter the pin code selected by the distant device. •...

  • Page 47: Properties And Configuration

    Properties and configuration Local services General In the Bluetooth Manager v1.5, there are three local services proposed to distant devices: SPP (Serial Port): A distant device wants to establish a serial connection with the local device OPP (Object Push): To receive files and contact information card FTP (File Transfer): To access to local directories, files and upload files and create directories Note : the OPP and FTP profil cannot be separated : You cannot deactivate one...
  • Page 48 You can activate or deactivate a local service by double-clicking it or by right clicking it and selecting the Start or stop item from the contextual menu. The local service is not The local service is activated activated You can also configure the service by selecting the Properties Item when you right click him.
  • Page 49 Application properties) • The application shows a dialog box with all the available port COM • Select the COM Port to be mapped with the SPP Server • The Serial Port profile is activated If the Auto Server COM Port is checked, the serial Port profile is activated with the last used COM Port for the SPP Server profile.
  • Page 50 If the service is connected you can know the COM port assigned by selecting “Properties” in the contextual menu of the service. FTP Profile...
  • Page 51 You can change the directory of the FTP server (directory seen by distant device) in the service properties (Contextual menu) OPP Profile You can change the directory where the File sent by distant device will be put.

  • Page 52: Local Device Properties And Configuration

    Local device properties and configuration Click on , to see: • the local device properties (MAC address, name and device type) • application option (start minimized, Auto assigned COM port number for client SPP and server). • security options of the bluetooth manager...
  • Page 53 Security properties Distant devices must be paired to access local service Don’t show a window when a distant device wants to be The current paired. Auto type device is visible the PIN code or not from other number devices...
  • Page 54 General properties Name for distant device of the current device MAC address of the current device devices Class of device of the current device...
  • Page 55 Application properties Check this if you want the Bluetooth manager starts minimized Check this if you want to affect the first available COM port to a Check this if you don’t SPP client connection want a dialog appears when you start the SPP server(to select the COM port)
  • Page 56 About Box Click on the icon if you want some general information about the bluetooth manager: • Version • License information...

  • Page 57: Distant Device Properties

    Distant device properties You can have general information on a distant device (like the General tab of the Local device properties) by selecting “properties” in the contextual menu of the distant device.

  • Page 58: Distant Services

    Distant services Services Inquiry To inquiry the services available on a distant device, you have to double click on this one. After that, the bluetooth manager inquiries (it indicates this in the status bar) for all the services (among SPP/FTP/OPP/DUN) of the distant device. You can stop the inquiry with the icon.

  • Page 59: File Transfer

    File Transfer To use this service, double click on the icon or choose connect on the contextual menu (right click). Then, the bluetooth Manager tries to connect to the distant service. If the connection is successful, the root directory shared by the distant will be shown in the list view.
  • Page 60 The file is downloaded by default to the “\My Documents\Bluetooth\Ftp” directory. You can change this one with the FTP properties (contextual menu of the File Transfer service). You can upload a file to the distant device by right-clicking on a whitespace of the listview and select Add file.

  • Page 61: Object Push

    You can also delete a file by selecting delete on his contextual menu. Object Push To use this service, double-click on the distant service or select “Push file” on the contextual menu. Then you can choose the file to transfer.

  • Page 62: Serial Port

    Serial Port To use this serial service, double-click on the icon or choose “Connect” from the contextual menu. If the Auto Client COM Port is not checked (cf. 0.
  • Page 63 Application properties) • The application shows a dialog box with all the available COM If the Auto Client COM Port is checked (cf. 0.
  • Page 64 Application properties) • The Application selects automatically the first avalaible COM port in the system. If the connection is successful a messagebox appears: else an error message appears The status of the service (connected or not) is displayed as shown below: Service not connected Service connected...
  • Page 65 When the service is on, all applications could use the virtual COM port. To know the COM port setting, select properties in the contextual menu. When connected, the Manager can still be used as usual.

  • Page 66: Dial-Up Networking

    Dial-Up Networking To use the Dial-up Networking service, double click on the icon or choose "Connect" in the contextual menu. The first avalaible COM port in the system is assigned to the DUN profil on the selected device. The status of the service (connected or not) is displayed as shown below: Service connected Service not connected When connected, the Manager can still be used as usual.
  • Page 67 The modem created by the Manager is displayed in the list of available modems for Dial-Up connection when making a new connection ("Make New Connection" icon in the "Network and Dial-Up Connection" system window).

  • Page 68: Distant Disconnection Management

    Distant disconnection management When a connection, previously established, is shut down by the distant host (manual disconnection or connection loss due to distant device shutting down or due to a weak signal), the user is notified of the disconnection and the Manager attempts to reconnect during a time t (by default, 1min30).

  • Page 69: Connection Shortcuts Management

    Connection shortcuts management Shortcuts associated to defined services on defined devices make establishing connections with distant devices easier. A shortcut can be created by selecting the...
  • Page 70 "Create Shortcut" item in the contextual menu of a connected service. If the shortcut already exists, a notification is displayed. If the shortcut is successfully created, a notification is also displayed. button in the tool bar displays the connection shortcuts list. The service, the device and, eventually, the COM port are used in the shortcut name.
  • Page 71 To establish a connection from the shortcut, double-click on the icon or select "Connect" in the contextual menu. Once the connection is established (even if the connection is not successfully established), the display is switched to the services list associated to device linked to the shortcut. The connection status of the service (connected or not) is displayed not only on the service icon but also on the associated shortcut icon.
  • Page 72 Shortcuts can be deleted by using the "Delete" item of the contextual menu. The user must confirm the deletion.
  • Page 73 The content of the shortcut list is saved between executions of the Manager.

  • Page 74: Stop The Bluetooth Manager

    Stop the Bluetooth Manager When the BlueTooth Manager window is closed (by the close button X), the application is still running in the background. To display or stop it, click on the BlueTooth icon on the Windows bar and select: “Show” or “Exit” . You can also display it by starting again the application...

  • Page 75: Specifications

    SPECIFICATIONS Intel Bulverde PXA270 CPU speed 624MHz Memory 128MB 128MB Display Type: 4” Active TFT Transflective Color LCD Resolution: 480 x 640 pixels Color: Backlight: Touch Screen Type: Resistive...

  • Page 76: I/Oports

    Interface: Serial I/O ports USB 2.0 port USB client port Serial port Audio ports (Microphone/Earphone) PCMCIA slot (type II x 1) SD slot System Unit Dimensions and Weight Width: 90mm (W 3.5”) Depth: 150mm (H 5.9”) Height: 33mm (D 1.3”) Weight: 450g (15 oz.) AC Adapter...

  • Page 77: Battery

    Frequency: 50/60 Hz Output Voltage: DC 12V 3.75A Maximum Power: 45 Watts Dimension: 108mm (4.2” W) x 56mm (2.2” D) x 34mm (1.3” H) Weight: 270 g (9.5 oz.) Battery Type: Lithium Ion Capacity: 3.7V 3900mAH Dimension: 71mm (W 2.8”) x 64mm (D 2.5”) x 12.3mm (H 0.5”) Weight: 108 g (3.8 oz.)

  • Page 78: Materials And Recycling

    Materials and Recycling Materials of the computer are as follows: Cabinet: Aluminum alloy ADC-12 or A380, Magnesium alloy AZ91D, UL grade PC+ABS GE C6200 or TN-3813BW Bracket: Aluminum 5052 Steel with Nickel plating Stainless Steel S304 Cushion pad: Nature rubber PCB: FR-4, UL 94V0 Battery:...

  • Page 79: Environmental Ratings

    Environmental Ratings Temperature: DA05I: 0ºC ~ 45ºC (32ºF ~ 113ºF) operating -20ºC ~ 60ºC (-4ºF ~ 140ºF) storage DA05M: -20ºC ~ 50ºC (-4ºF ~ 140ºF) operating -40ºC ~ 70ºC (-40ºF ~ 158ºF) storage Humidity: 5 ~ 95% Non-condensing operating 95% maximum storage Altitude: 0 ~ 12,180 meters (0 ~ 40,000 feet) operating and storage...

  • Page 80: Maintenance / Service

    MAINTENANCE / SERVICE Cleaning Always turn OFF the power, unplug the power cord and remove the battery before cleaning. The exterior of the system and display may be wiped with a clean, soft, and lint-free cloth. If there is difficulty removing dirt, apply non-ammonia, non-alcohol based glass cleaner to the cloth and wipe.

  • Page 81: Rma Service

    • Remove the software suspected. RMA Service If troubleshooting is unsuccessful, please consult your dealer for service If it is necessary to send in the computer for repairs, please follow the dealer’s instructions for RMA# procedure. Shipping instructions: 1. Use the original shipping container and packing materials, if possible. 2.
  • Page 82 • A DETAILED description of the problems you have encountered • A list of the hardware/software configuration, if applicable. 4. Clearly mark the outside of the shipping box with the RMA number. This will facilitate faster processing and avoid faulty return. 5.
