Step 1.
PLANNING FOR THE INSTALLATION
In planning for the installation of a new Trilogy Pool, there are
many important considerations that must be evaluated in order to
achieve a functional, long-lasting and aesthetic addition to a home.
When choosing a location, consider the following:
1.
Grade: Pools and decks are normally constructed on level ground.
Extreme variations in grade should be resolved before the excavation of
the pool begins. A relatively level and flat location is preferred so time
and effort is not wasted on radical fluctuations in grade.
2.
Excavation Equipment Access and Pool Delivery: Determine the
most efficient route for equipment to enter and access the site. Also keep in mind that a well planned route can save
time and money by enabling multiple pieces of equipment to work in unison. For example: Coordinate the delivery of the
pool with the completion of the excavation and prepping of the hole. If a track excavator was used to prepare the site, it
may also be utilized to unload and set the pool. Finally, consider the placement of the equipment. If possible, position
the equipment so the pool can be unloaded and placed directly into the excavation.
3.
Underground Utilities: Check with local authorities for the locations of underground water, gas, power and sewer lines.
4.
Overhead Power Lines.
5.
Local Building Codes: Determine the setbacks from property lines, easements, house footings, etc.
6.
Water Drainage: Water should always drain away from the pool. Failure to keep ground water away from the exterior
of the pool may result in damage to the pool that is not covered under warranty.
7.
Local Fencing Codes.
8.
Location of Pool Equipment: Locate to within 20' of pool.
9.
Electrical Run for Pool Equipment.
10.
Underground Water Conditions.
11.
Exposure to Sunlight.
12.
Surrounding Foliage.
13.
View from Residence.
Notice: Failure to read and follow specific instructions contained in this manual will void your pool warranty.
TOOLS REQUIRED
A. Transit Level
B. Shovel
C. Pick
D. Rake
E. Stakes and nails
F. Spray paint for outlining pool
G. String
H. Hammer
I. (7) 2"x 4" x 16'
J. Tape Measures: 25' and 50' lengths
Nebula
Advertisement
Summary of Contents for Trilogy Nebula
- Page 1 Step 1. TOOLS REQUIRED PLANNING FOR THE INSTALLATION A. Transit Level In planning for the installation of a new Trilogy Pool, there are B. Shovel many important considerations that must be evaluated in order to C. Pick achieve a functional, long-lasting and aesthetic addition to a home.
- Page 2 When laying out the pool, note that the dimensions are to the outside edge of the pool coping. Most permit plans are measured to the waters edge. The coping of a Trilogy Pool is approximately 6” on all sides. There is a differ- ence of 12”...
- Page 4 (see Cross Section A-A) must be installed to alleviate the excess water and the associated hydro- static pressure accompanying it. Trilogy suggests digging an 18” x 8’ x 18” trench across the deep end of the excava- tion.
- Page 5 Step 5. PREPARATION OF THE BOTTOM SURFACE OF THE EXCAVATION The preparation of the excavation bottom is critical so the pool will fi t properly. Thorough prepara- tion will eliminate settling, stress cracks and a mini- mum of time will be spent setting the pool. First, install 2”...
-
Page 6: Setting The Pool
A crane or excavator will lower the pool into the excavation. Please note that Trilogy recommends lifting all pool models over 12’ wide with a spreader bar and 20’ lifting straps. Once the pool is set in the excavation, the pool should be checked for level and the bottom should be walked over to detect any voids in the sand that might be present. - Page 7 Figure 5 for a basic fi ltering system diagram. See your contractor for more advanced fi ltering systems that may include sanitizers, jets, blowers, automatic pool cleaners, etc. Trilogy recommends the use of schedule 40, 2” plumbing on most pools. Visually inspect all plumbing installed at the factory upon the delivery of the pool and during the backfi ll process.
-
Page 8: Installation
No. 3 rebar on 2’ centers (Fig 6-7). Trilogy Pools recommends concrete decking. Concrete should be poured at least 3’ around the perimeter of the pool and at least 4” deep. Trilogy Pools will not be held responsible for any concrete work or cracks that may result from its use.
