Thank you for purchasing the Voltz Pedal Power Pack. Please read the entire manual
prior to setting up and using this device. If there are any questions about this product
that you might have that are not covered in this manual, please feel free to call Amperor
Voltz Tech Support at 281-807-3320 ext 106 or email
Features
• Included Voltz battery pack has self-contained charging system that can be
charged by 115V
10~32V
(plug it into your car).
DC
• Easy to read gas gauge for battery pack allows you to easily read how much
power is left in the battery.
• Included milliVoltz power adapter lets you power your 9V
effects with simple plug and play integration.
• Interchangeable tips allow you to power all of your pedals without the need to
buy extra input adapters.
• Available milliVoltz and Voltz accessories allow you to power the more exotic
effect pedals with input voltage requirements of 12.0V
24.0V
and 40.0V
DC
• Power as many effects pedals with one power supply because of the 90W power
output (that can power over 20 pedals twenty-four hours straight with a full
charge).
• Completely silent design. No connection to regular 115V
hum and all isolated outputs mean no cross talk or ground loops to deal with.
• Protection circuitry makes it safe to use with any effect pedal.
Inspection
Make sure your package includes the following items:
• Voltz integrated battery pack and charger.
• 3 each of the 9V
• 1 each of the 18V
• 12 inch Voltz to milliVoltz male-to-male tip cord.
• AC power cable
• Car Accessories power cable
• Compatibility guide
• Warranty Card
• Manual
or 230V
(plug it into the wall in the states or abroad) or
AC
AC
.
DC
milliVoltz power adapters with interchangeable tips.
DC
milliVoltz power adapter with interchangeable tips.
DC
support@amperordirect.com
and 18V
DC
, 15.0V
, 18.0V
DC
DC
means no 60cycle
AC
pedal
DC
,
DC

Advertisement

loading
Need help?

Need help?

Do you have a question about the Pedal Power Pack and is the answer not in the manual?

Questions and answers

Summary of Contents for Voltz Pedal Power Pack

  • Page 1 Thank you for purchasing the Voltz Pedal Power Pack. Please read the entire manual prior to setting up and using this device. If there are any questions about this product that you might have that are not covered in this manual, please feel free to call Amperor Voltz Tech Support at 281-807-3320 ext 106 or email support@amperordirect.com...

  • Page 2: Safety Precautions

    Getting Started ***Before initial use, fully charge the Voltz battery. • Plug Voltz unit into wall or car accessory voltage supply with provided AC cord or DC car accessories adapter. • Turn CHARGE / DISCHARGE switch on Voltz to CHARGE position.
  • Page 3 ***Only use patch and guitar instrument cables that are grounded to avoid loss of signal*** ***Be sure that the Voltz unit is switched to CHARGE if equipment is not in use to avoid the battery from being drained*** ***When charging in AC or DC mode, make sure that the Voltz unit is switched to the...
  • Page 4 DC outlet (car accessories outlet a.k.a. cigarette lighter). C. Output Jack – This is where you plug in the milliVoltz units into the Voltz to give you that complete hum-free setup. This is an 18VDC output so make sure you do not plug any effects directly into this output (unless you have a power hungry 18V Pedal).
  • Page 5 E. milliVoltz 18.5V input – Plug coming from either another milliVoltz DC/DC isolated converter or from the main Voltz Battery and Charger power source via the provided 12” male-to-male jack connector. F. 18.5VDC input – Power input jack for the plug connector coming from another milliVoltz DC/DC isolated converter or from the main Voltz Battery and Charger power source via the provided 12”...

  • Page 6: Battery Adapter

    DAISYCHAIN ADAPTER INSTRUCTIONS Make sure the pedals you are powering with the daisy chain have all the same polarities and voltage requirements. If your set-up requires less then five outputs, be sure to put electrical tape over the conductors of the remaining unused outputs so you don’t short anything out. If you are experienced enough with electrical and musical equipment, you could cut the remaining unused outputs off for a cleaner look.
  • Page 7 Voltz and milliVoltz illustrated set-up Plastic Insulator cap...
  • Page 8 Electrical Specifications ***all specifications are subject to change without notification*** Voltz Battery Pack Integrated AC/DC and DC/DC Charger AC Input Input AC Voltage Range 90 to 265Vac Frequency 47-63Hz Input Current 1.6A @ 90Vac; Full Load Power Rating <130 Watts.

  • Page 9: Electrical Specifications

    Electrical Specifications ***all specifications are subject to change without notification*** milliVoltz DC/DC Power Adapter DC Input Input DC Voltage 18.5V DC Output 9.6V Max Current 500mA 9.6V Max Power 4.8W Isolation 9.6V output isolated by transformer milliVoltz DC/DC Power Adapter DC Input Input DC Voltage Range 18.5V...
  • Page 10 Electrical Specifications ***all specifications are subject to change without notification*** milliVoltz DC/DC Power Adapter DC Input Input DC Voltage Range 18.5V DC Output 40.6V Max Current 200mA 40.6V Max Power 8.12W Isolation 40.6V output isolated by transformer 11320 Neeshaw Drive 281-807-3320 ext 106 Houston, Texas 77065...
