Taillight Bulb Replacement

1. Remove (5) Phillips screws from taillight lens.
2. Working from front to back, carefully pry lens away from housind and
remove.
3. Pull bulb straight out from socket and insert new bulb.
4. Reinstall lens.

Handlebar Adjustment

1. Remove handlebar cover.
2. Using a 7/16² (11 mm) wrench, loosen four nuts on bottom of
adjuster block. NOTE: Turn handlebar to left or right for access
to back nuts.
3. Adjust handlebar to the desired height. Be sure that handlebars,
brake lever and throttle lever operate smoothly and do not hit the
gas tank, windshield or any other part of the machine when
turned fully to the left or right.
4. Torque the handlebar adjuster block bolts to specification.
Maintain an equal gap at front and rear of block.
5. Replace handlebar cover.
Handlebar Adjuster Block Bolt Torque -
11 - 13 ft. lbs. (15 - 18 Nm)
WARNING
Improper adjustment of the handlebars, or incorrect torquing of the
adjuster block tightening bolts can cause limited steering or loosen-
ing of the handlebars, resulting in loss of control.
MAINTENANCE / TUNE UP
Lens
Bulbs
2
3
Socket Screws
1
4
2.17
