Polaris INDY TRAIL RMK Service Manual page 30

INDY 700 SKS / (EUROPEAN MODEL)
MODEL: . . . . . . . . . .
MODEL NUMBER: . S02SS7CS / (E02SS7CE)
ENGINE MODEL: . . S2189- -7070PL7C
ELECTRICAL
Flywheel I.D. . . . . . . 4010523
CDI Marking . . . . . . . 4010587
Alternator Output . . . 280 Watts
Ignition Timing . . . . . 18° @3000RPM±500
0.0815² BTDC
2.075mm BTDC
Spark Plug / Gap . . . Champion RN57YCC / 0.025² (0.64mm)
Voltage Regulator . . LR7
Electric Start . . . . . . . Option
LR7= Full wave voltage regulator
Magneto Pulses . . . . 6
SUSPENSION / CHASSIS
Body Style . . . . . . . . Gen II
Front Suspension . . Indy XC 10
Front Shocks . . . . . . Indy Select
IFS Spring Rate . . . . 100#/in.
Front Spring Preload 3/4² Thread Adjust
Front Vertical Travel 9.6² (24.4cm)
Rear Suspension . . . XTRA-10 136², (XTRA 10 European)
Rear Axle Travel . . . 9.5 in.(24.1cm)
Front Track Shock . . Nitrogen Cell
Spring Rate . . . . . . . . 200#/in. variable
Rear Track Shock . . Indy Select
Rear Springs . . . . . . .359² (sq.) / 77°
Track Type . . . . . . . . 15²x136²x1.25² (38.1x345.44x3.175cm)
Track Tension . . . . . . 3/8² - 1/2² (1-1.3 cm) slack with 10# (4.54kg) weight 16² (40.64cm) ahead of rear idler
shaft.
Overall Snowmobile Length
Overall Snowmobile Height
Maximum Snowmobile Width
OPTIONAL REAR TORSION SPRINGS (700 SKS)
SOFT
.347"(Sq.) Diameter x 77_ _ _ _
L.H. 7041627--067
R.H. 7041628--067
. . . . . . . . . . . . . . . . . 116² (295cm)
. . . . . . . . . . . . . . . . . 45² (114cm)
. . . . . . . . . . . . . . . 48² (122cm)
MEDIUM(STD)
.359²(Sq.) Diameter x 77_
L.H. 7041629--067
R.H. 7041630--067
GENERAL INFORMATION
CAPACITIES
Fuel Tank . . . . . . . . . . 11.8 gallons (44.7 liters)
Oil Tank . . . . . . . . . . . . 3 quarts (2.8 liters)
Coolant . . . . . . . . . . . . 5.5 / 6 quarts (5.2 / 5.7 liters)
Chaincase Oil . . . . . . . 9 / 11 fl. oz.(266 / 325cc)
CHAINCASE
Sprockets / Chain . . . 23-40-70P HYVO
Reverse . . . . . . . . . . . . Option
Brake Pads . . . . . . . . . Type 81, Large
Chaincase Center Dist.7.05² (17.91cm)
Driveshaft Sprockets . 2 Drivers Wide
Brake Type . . . . . . . . . Polaris HPB, Liquid Cooled
FIRM
.405"(Sq.) Diameter x 77_
L.H. 7041655--067
R.H. 7041656--067
1.23
