Warning
– If the information in these instructions is not followed exactly, a fire or explosion could happen causing
property damage, personal injury or loss of life.
Do not store flammable materials, vapors or liquids in vicinity of this or any other appliance.
WHAT TO DO IF YOU SMELL GAS:
Do not try to light appliance and make sure all valves are in the off position.
Do not touch any electrical switch
Immediately call your gas supplier using a phone from a safe distance
If you cannot contact gas supplier call the fire department
Fire is hot and so are the objects containing fire do not touch fire pit or fire pit media!
We highly recommend that our products be installed and serviced by professionals who are certified in the U.S. by
DCI LLC All Rights Reserved: For technical support call 951-805-0314
F
P
T
IRE
IT
ABLE
NFI (National Fireplace Institute).
A
I
SSEMBLY
NSTRUCTIONS
1
Advertisement
Table of Contents
Related Manuals for DCI LLC So Cal Fire Pits
Summary of Contents for DCI LLC So Cal Fire Pits
- Page 1 Fire is hot and so are the objects containing fire do not touch fire pit or fire pit media! We highly recommend that our products be installed and serviced by professionals who are certified in the U.S. by NFI (National Fireplace Institute). DCI LLC All Rights Reserved: For technical support call 951-805-0314...
-
Page 2: Safety First
Supply Pressure: Minimum: 3.5” W.C.; Maximum: 7.0” W.C. Outlet Pressure: 3.5” to 5.0” W.C. ● LP Gas: Supply Pressure: Minimum: 8.0” W.C.; Maximum: 15.0” W.C. Outlet Pressure: 10.0” to 12.0” W.C DCI LLC All Rights Reserved: For technical support call 951-805-0314... - Page 3 • Choose a location that allows easy access for installation and maintenance of the fire pit. • Pick a location that allows sufficient horizontal room to enjoy the fire pit while allowing a safe distance from the heat and flame. DCI LLC All Rights Reserved: For technical support call 951-805-0314...
- Page 4 Screw 2. Attach (1) leg to side panel using (3) screws and nuts. Screw 3. Slide rear panel into position and attach using (3) screws and nuts. Back Panel Screw DCI LLC All Rights Reserved: For technical support call 951-805-0314...
- Page 5 (3) screws and nuts. Screw 5. Attach (1) side panel using (3) screws and nuts. Side Panel Screw 6. Attach (1) leg to side panel using (3) screws and nuts. Screw DCI LLC All Rights Reserved: For technical support call 951-805-0314...
- Page 6 Gas Knob 9. Attach (1) Propane regulator hose to top (shorter) stem of flow control valve. For Natural gas specific unit connect 1/2 psi. gas source Propane regulator with attached hose DCI LLC All Rights Reserved: For technical support call 951-805-0314...
- Page 7 Attach inlet of (1) burner entire unit. to SS flex hose and tighten fitting. Table Top Nuts Burner DCI LLC All Rights Reserved: For technical support call 951-805-0314...
- Page 8 If you smell gas DO NOT use, turn off tank then call a professional! DCI LLC All Rights Reserved: For technical support call 951-805-0314...
