2U Server Barebone Quick Start Guide www.enlightcorp.com... -
Page 2: Table Of Contents
Index System Overview ...................3 Front View..................... 3 Back View ..................... 3 Hardware Installation ................4 Remove Chassis Cover ................4 Server System Layout................... 4 Install Processor and Heat sink..............5 2.3.1 To install the processor...................... 5 2.3.2 To install the heat sink ....................... 6 Install System Memory.................. -
Page 3: System Overview
Figure 1-1 Front View HDD Trays Floppy Disk Drive HDD LEDs CD-ROM Drive LEDs and Button Panel Figure 1-2 Back View Dual USB Port NIC1 Connector (RJ45) PS/2 Mouse Port Serial Port NIC2 Connector (RJ45) VGA Port PS/2 Keyboard Port AC Power Connector... -
Page 4: Hardware Installation
To remove the top cover: Loosen the screw on the top of the cover. Press down the button as the arrow shows. Slide the cover toward the rear of side horizontally as the arrow shows to the back panel. Figure 2-1 Lifting the cover from the chassis Figure 2-2 System Top View... -
Page 5: Install Processor And Heat Sink
DIMM slots CD-ROM(Option) Processors HDD Trays System Fans Power Supply Floppy Disk Expansion Slots 2.3.1 To install the processor The location of the processor on the motherboard is shown as below: Figure 2-3 Processor Location Processor 1 Processor 2 If SINGLE processor is intended, always install the processor on the processor 1 socket and for the location of processor 1 and processor 2, please refer to the above figure. -
Page 6: To Install The Heat Sink
Carefully insert the processor into the socket until it fits in place with the marked corner matches the socket corner near the end of the lever, while making sure that the processor is parallel to the socket. Lock the socket by pushing down the lever. -
Page 7: Install System Memory
When you insert the DIMM(s), you have to always start with DIMM B3, A3. Please refer to the following table: DIMM Table 2-1 DIMM Installation Option Unlock a DIMM socket by pressing the retaining clips outward. Figure 2-8 Pressing the retaining clips outward Carefully insert the DIMM into the socket until the retaining clips snap back in place. -
Page 8: Install Hdd
To open the HDD tray: Turn the lock counterclockwise to release the lever from the HDD. Slide the released button to the direction of the arrow, and the lever will be lifted automatically. Figure 2-10 Pressing the released button Slide the HDD assembly out of the drive bay. -
Page 9: Install Power Supply(Option)
Push the levers back in place. Turn the lock on the lever clockwise to secure the HDD. Figure 2-14 Pushing the levers back in place To install the power supply: Push the power supply right into the tray until it completely enters the tray. Figure 2-15 Putting the power supply into the tray 3.1.1 Setup Step 1¡... - Page 10 Turn on your computer to start booting. When prompted, type <CTRL+R> to access the RAIDCore BIOS Array Configuration Utility. Step 2¡ G To initialize disks from the BIOS: Use the arrow keys to select Initialize Disk(s) from the Main menu. Press Enter.
- Page 11 From the main menu of the Array Configuration screen, select Create Array using the arrow keys, and then press Enter. Select the disks on which to create the array by doing the following: Highlight the disk using the arrow keys. For each disk, press the Insert key to select the disk.
- Page 12 To select an array size, do one of the following: Press PAGE UP or the up arrow to increase the array size. You are asked if you want to limit the size of the array to the 2 TB maximum. Press ESC to create a larger array.
-
Page 13: To Install The Bc4000 Series Raid Controller Drivers In Windows 2003
You can now install the RAIDCore Management Suite for administering the controller, arrays, and disks Storage management software that provides all of the creation, management, and data logging needed to manage arrays. You can find it on Enlight’s support WEB or Speedy-In CD-Title. -
Page 14: Scsi
3.2.1 Setup Turn on your computer to start booting. When prompted, type <CTRL+R> to access the RAIDCore BIOS Array Configuration Utility. From the ARC menu, select Array Configuration Utility. If Configuration change has been detected in the system. Please Press Accept update to the current configuration. - Page 15 From the main menu of the Array Configuration screen, select Create Array using the arrow keys, and then press Enter. Select the disks for the new array, then press Insert. To deselect a disk, highlight the disk, then press Delete. When you are finished selecting disks, press Enter.
- Page 16 Type an optional label for the array, then press Enter. Enter the desired array size. Select the desired stripe size.
- Page 17 Specify whether you want to enable read and write caching for the array. Specify whether you want to enable read caching for the array. Specify whether you want to enable write caching for the array.
-
Page 18: Install The Driver When You Install Windows
4. When the Adaptec driver is found, press Enter. Respond to the on-screen instructions to complete the installation. Storage management software that provides all of the creation, management, and data logging needed to manage arrays. You can find it on Enlight’s support WEB or Speedy-In... -
Page 19: Os Pre Installation Steps
® Speedy-In! ,"Install OS with EASE and SPEED", is an intelligent and essential deployment tool that simplifies server's setup. It provides an easy-to-use, intuitive graphical interface to guide you installing operating system, reviewing documentation of hardware and software, upgrading or installing drivers and utilities. - Page 20 Figure 4-1. Install OS - Windows Family Summary Information Panel In the Summary Panel, you are required to type a 25-digit product key, or just ignore it to finish in Detail Panel. The summary panel is display as Figure 4-2. Figure 4-2.
- Page 21 Licensing Modes Per Server/5 Client Licenses User Name / Organization Your Name/Your organization Computer Name / Password Empty Domain and Workgroup Default is workgroup with name is workgroup also Network Setting Default is DHCP Time Zone Setting GMT-05:00/Eastern Time (US & Canada) You can click Install after type in product key.
- Page 22 ® The Speedy-In! automatically detects hard disks attached to your server and displays detailed information in list box. • Select first bootable HDD device in list box • Define boot partition size by inputting a certain space value or percentage value in the two text boxes below percentage bar •...
- Page 23 User Name and Organization In this area you can input following names, • User Full Name (less than 50 chars) • Organization Name (less than 50 chars.) Computer Name and Administrator Password You can type computer name (less than 15 chars.) and set administrator password (<128 chars.) here.
- Page 24 You can input group name for the computer, set the domain name, and create a new account in this area. • Click on the radio button beside Workgroup to enter group name (less than 15 chars.) • Click on the radio button beside Windows Server Domain to enter domain name (less than 50 chars.) •...
- Page 25 o Primary DNS Server o Secondary DNS Server o IP Address o Subnet Mask o Default gateway Time Zone Setting You can set time zone here. • Select a time zone from drop-down list box. • In the second box select your region. Install Progress After an OS has been selected and all configurations are ready, you can click Install either in Summary or Detail Panel to start up installation, a panel is display to show the progress.
- Page 26 Figure 4-3. Windows Install Progress There are four steps for Windows install that are Creating Partition, Formatting Partition, ® Transferring Image and Copying Windows Files. After transferred Image File, Speedy-In! ejects from CD-ROM and a dialog pops up to prompt you change Disc. After you insert Windows Setup Disc and click OK, the progress will continue until all the Windows files are copied to hard drive.
-
Page 27: Troubleshooting
The location of the power supply on the server chassis is shown as below: Figure 5-1 Power Supply Location Note: When the server is equipped with DUAL power supplies, the hot-swappablefunction is provided. Otherwise, you need to power off the server. To remove the power supply: Press the retaining clip along the direction of the... -
Page 28: System Fans
To install the power supply: Push the power supply right into the tray until it completely enters the tray. The system fan locates beside the power supply and maintains the ideal temperature for themotherboard, backplane and disk drives.The location of the system fan is shown as below: Figure 5-2 System Fan Cage Location Important: Before you install or remove the system fan, make sure the power is off. - Page 29 To remove the system fans: Remove the system fan from the system fan cage. To install the system fans: Put the system fan right into the system fan cage.
