H-Series VO Gas Fireplaces
H38DFO Outdoor Shown
Warning:
Improper installation, adjustment, alteration, service or maintenance can cause
injury or property damage. Refer to this manual. For assistance or additional
information consult a qualified installer, service agency or the gas supplier.
Safety Notice:
Glass doors on gas fireplaces are extremely hot while the fireplace is on and remain
hot even after the fireplace has been turned off. Safety screens are available and
can reduce the risks of severe burns.
For Your Safety:
Do not store or use gasoline or other flammable vapors and liquids in the
vicinity of this or any other appliance.
Canadian Heating Products Inc. Langley, BC V4W 4A
XG0150
Installation Operation & Maintenance Manual
Check local codes and read all instructions prior to installation.
®
C
US
www.montigo.com
H34VO
H38VO
H42VO
Installation and service
must be performed by a
qualified installer, service
agency, or the gas supplier.
WARNING:
FOR OUTDOOR
USE ONLY
What to do if you smell gas
•
Do not try to light any appliance.
•
Do not touch any electrical
switch; do not use any phone in
your building.
•
Immediately call your gas
supplier from a neighbor's
phone. Follow the gas supplier's
instructions.
•
If you cannot reach your gas
supplier, call the fire department.
Montigo Del Ray Corp. Ferndale, WA 98248
Outdoor
Outdoor
Outdoor
Warning:
•
Installer: Leave this manual
with the appliance.
•
Consumer: Leave this
manual for future reference.
081009
Advertisement
Table of Contents
Summary of Contents for DelRay H34VO Outdoor
-
Page 1: Safety Notice
www.montigo.com Installation Operation & Maintenance Manual Check local codes and read all instructions prior to installation. H-Series VO Gas Fireplaces H34VO Outdoor H38VO Outdoor H42VO Outdoor Installation and service must be performed by a qualified installer, service agency, or the gas supplier. WARNING: FOR OUTDOOR USE ONLY... -
Page 2: Table Of Contents
Installation, Your new DelRay gas fireplace will give you years of durable, Operations and Maintenance manual. Pay special attention to all reliable use. Welcome to the Montigo family of gas fireplace cautions, warnings, and Important warnings. -
Page 3: Introduction
H-SeriesVO Outdoor Gas Fireplace Introduction Thank You for choosing a Montigo Gas Fireplace. CAUTIONS About this Fireplace: Due to its high operating temperatures, the appliance should The H-SeriesVO is an outdoor fireplace with a pan-style burner and be located out of traffic & away from furniture. glowing embers. Children and adults should be alerted to the hazards of ... -
Page 4: Installation
H-SeriesVO Outdoor Gas Fireplace Installation Choosing The Fireplace Location Clearances The H-SeriesVO clearances to combustible materials are listed The H-SeriesVO may be installed in an outdoor setting such as a below and are the minimum clearances to combustibles that apply patio or balcony. -
Page 5: Installing The Gasline
H-SeriesVO Outdoor Gas Fireplace Installation 6” clearance • Flexible gas connectors must not exceed 3 feet in length, unless it is t o corners only allowable within applicable installation codes. The appliance and its individual shutoff valve must be disconnected from the gas supply piping system during any pressure testing of that system at test pressures in excess of 1/2 psig (3.5 kPa). The appliance must be isolated from the gas supply piping system by closing its individual manual shutoff valve during any pressure testing * Shaded framing must... -
Page 6: Mantels And Surrounds
H-SeriesVO Outdoor Gas Fireplace Installation Mantels & Surrounds NOTE: National Canadian Gas Association mantel test requirements are for fire hazard prevention to combustible materials. New technology, to meet consumer and government demands for the wise use of energy, has prompted us to manufacture many models of fireplaces which are hot, fuel and energy efficient. Warning: When covering the upper metal portion of the fireplace with a non- combustible material Please Note: The decorative facing materials... -
Page 7: Removing And Installing The Door
H-SeriesVO Outdoor Gas Fireplace Installation Removing and Installing the Door Step 5: Ensure the tool is firmly Removing the door: in the lower end of the The doors are removed in a few simple steps. Follow the Steps shown to slot, (as shown), Then pull remove the Horizontal access panel, unlatch the door buckles, remove toward you (Caution: hold the door, then replace in reverse order. -
Page 8: Installing The Log Set
H-SeriesVO Outdoor Gas Fireplace Installation H38VO H42VO the underside of the logs, as shown above, figure 30c insets. Installing the Log Set Installing the Logs: Step 5. Place the Centre Front log , Figure 30d below, as shown using The H38VO & H42VO is supplied with a seven ceramic fibre log logset. the notch cast in the Bottom Rear log as shown in figure 30c above. - Page 9 H-SeriesVO Outdoor Gas Fireplace Installation H34VO Installing the Log Set Installing the Logs: The H34VO is supplied with a seven ceramic fibre log logset. Unpack Log A the logs and handle them very carefully. Formed Log B Log D Angles Log C Log Base Step 5. Place Log "D" as shown. Place the Log on the Right-hand bracket (pointing inward toward the burners) and press onto the (2) Log Base formed pins, shown.
-
Page 10: Lighting Instructions
H-SeriesVO Outdoor Gas Fireplace Operation - Model H-SeriesVO with Continuous Pilot For Your Safety - READ BEFORE LIGHTING: WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. A. -
Page 11: Operation
H-SeriesVO Outdoor Gas Fireplace Operation Maintenance Lighting Instructions General The lighting instructions are outlined on page 9. Note that it is impor- Have the fireplace installation inspected yearly, including a visual tant to inspect the burner before each use of the appliance. check of the fireplace system, the burner and the pilot flame. For your convenience a 1/8" manifold pressure tap is supplied on the Burner Adjustment gas valve for a test gauge connection. -
Page 12: Gas Control Valve
H-SeriesVO Outdoor Gas Fireplace Maintenance Gas Control Valve Spare Parts - H-SeriesVO H34VO H38VO H42VO NG Gas Valve RGC1006 RGC1006 RGC1006 LP Gas Valve RGC1005 RGC1005 RGC1005 NG Pilot RPA020 RPA020 RPA020 LP Pilot RPA021 RPA021 RPA021 Burner NG RBH3401 RBH3801 RBH4201 Burner LPG... -
Page 13: Warranty
The Companies as stated above refer to - Canadian Heating Products Inc. and/or Montigo Del Ray Corp. NOTE: Canadian Heating Products Inc. and/or Montigo DelRay Corp. reserves the right to make changes at any time, without notice, in design, materials, specifications, prices and also to discontinue colors, styles and products. -
Page 14: State Of Massachusetts / Amendment
H-SeriesVO Outdoor Gas Fireplace Appendix A - State of Massachusetts Amendment (Gas Fireplace / Equipment sold in the State of Massachusetts) 5.08: Modifications to NFPA-54, Chapter 10 (1) Revise NFPA-54 section 10.5.4.2 by adding a second exception as follows: Existing chimneys shall be permitted to have their use continued when a gas conversion burner is installed, and shall be equipped with a manually reset device that will automatically shut off the gas to the burner in the event of a sustained back-draft (2) Revise 10.8.3 by adding the following additional requirements:... -
Page 15: Notes
H-SeriesVO Outdoor Gas Fireplace Notes Page 15 Part No. XG0150 - 081009... - Page 16 XG0150 - 081009 Montigo Del Ray Corp. Canadian Heating Products Inc. Ferndale, WA 98248 Langley, BC V4W 4A1...
