NETWORKS
For advanced settings and more detailed information, download the user
manual from www.shyamnetworks.com.
Falcon SM200
Series Camera
Quick Start Guide
Package Contents
Camera with Mount Base
Flexible Clamp with Fixing Screws 1
Power Adapter
Wall Mounting Screws
Terminal Block for Alarm I/O
Quick Start Guide
www.shyamnetworks.com
1
1
1
1
1
Advertisement
Table of Contents
Summary of Contents for Shyam Falcon SM200 Series
-
Page 1: Series Camera
NETWORKS Falcon SM200 Series Camera Quick Start Guide Package Contents Camera with Mount Base Flexible Clamp with Fixing Screws 1 Power Adapter Wall Mounting Screws Terminal Block for Alarm I/O Quick Start Guide For advanced settings and more detailed information, download the user manual from www.shyamnetworks.com. -
Page 3: Hardware Overview
SM200 NETWORKS 1. Hardware Overview Front View SM201 SM241W SM202 SM242W Figure 1 Rear View Figure 2... -
Page 4: Available Models
SM200 NETWORKS Available Models MODEL DESCRIPTION SM201 CS mount wired (PoE) and HD camera SM241W CS mount wired (PoE) and wireless HD camera SM202 4x Zoom wired (PoE) and HD camera SM242 W 4x Zoom wired (PoE) and wireless HD camera Interface Description LABEL NO. - Page 5 SM200 NETWORKS Interface Description LABEL NO. INTERFACE DESCRIPTION Y (CVBS) Y in component video mode and CVBS in composite video mode. Pb in component video mode. Pr in component video mode. SD Card Slot For inserting the SD card to store data directly in to the card. User Input Boots the camera with default IP configuration.
-
Page 6: Led Behavior
SM200 NETWORKS LED Behavior COLOR STATUS DESCRIPTION Top Left on The network to which the camera is Green LAN Port connected is up. Top Right on Indicates network activity and that Yellow LAN Port data is being transferred. Indicates camera is booting up. Indicates failed firmware upgrade or Blinking no valid firmware in camera. -
Page 7: Wall Mounting
Connect the power adaptor cord into the back of the camera and then plug it into a power source. On powering-up the camera the Sts. LED glows green. In case any LED does not operate, then refer to the “Quick Troubleshooting” section. Congratulations! The installation of the Falcon SM200 series camera is complete. - Page 8 STEP 3 Type the http://192.168.1.168 URL in the Internet Explorer 6.0 or above version to access the web interface. STEP 4 Provide username as admin and password as password to view the Live View page. Figure 5 Please refer to “Falcon SM200 Series Camera Configuration and User Guide” for more details.
- Page 9 SM200 NETWORKS Accessing Falcon by UPnP WINDOWS VERSION PROCEDURE ME or XP When enabled on your computer, Falcon is automatically detected and added to ‘My Network Places’. Vista or Windows 7 When enabled on your computer, Falcon is automatically detected and added to ‘Network’. The camera icon as it appears in Windows 7: Figure 6...
- Page 10 SM200 NETWORKS 4. Adding Falcon in Shyam Dicortex VMS STEP 1 Open the Dicortex Configuration Client interface. STEP 2 Click the Settings tab. STEP 3 Click the Add button to view the Add New Devices window. Figure 7 After 5 to 10 seconds, the list of devices appears in the Add New Devices window.
-
Page 11: Quick Troubleshooting
SM200 NETWORKS 5. Quick Troubleshooting PROBLEM PROBABLE REASON RESOLUTION The Sts. LED is ‘Off’. No power is supplied. Ensure that the power adapter is plugged in properly. The Sts. LED blinks Ethernet link is not Check if the Ethernet cable is plugged amber. -
Page 12: Warranty
Product ______________________________________________________________________ Model No. _______________________________ Serial No. ___________________________ Dealer’s Stamp & Signature Customer Care, Shyam Networks (A Division of Vihaan Networks Ltd.) 21-B, Sec-18, Udyog Vihar, Gurgaon-122015 Haryana, India Email: customer.care@vnl.in All India Helpline No. - +91 124 309 2000 Ext. 2009, +91 9873573710 Manufactured by Vihaan Networks Ltd.
