Page 1: Instruction Manual
Instruction Manual Falcon Eye KC-1100 Komamura Corporation... - Page 2 1．Names of Parts ④ ① ② ③ ⑤ ⑥ ⑬ ⑧ ⑫ ⑨ ⑩ ⑦ ⑪ ⑭ 字 ⑮ ⑯ ⑰ ⑱ ⑲ ⑳...
- Page 3 Names of parts Name ① CS Lens Mount Flange Back Adjuster ② Locking Screw for Flange Back Adjuster ③ Auto Iris Connector ④ Tripod Socket ⑤ ⑥ Guide Pin Socket ⑦～ Set up switch (Ref: 2. Operation) ⑪ Focus EZ Switch (Ref: 2-5 Special Menu) ⑫...
- Page 4 2．Operation 2－１ Set up menu Set up can be made on OSD. 2－２ Set up buttons Push switches are located on the camera back. Name Up Switch Down Switch Left Switch Right Switch Enter Switch 2－３ Set up mode Set up menu is consisted Main Menu (ref. page 5) and special Menu (ref.
- Page 5 2－４－１、SENSE (Sensitivity) UP （１）Setting it up something else rather than OFF or MANUAL, GAIN will be set automatically on AGC. It can also be switchable to HYP-AGC. ① OFF ② S/N Signal Noise priority mode For slow motion shooting. Max GAIN: +21dB on +15dB、HYP-AGC ③...
- Page 6 MANUAL setting COLOR⇒B/W B/W⇒COLOR ④ REMOTE Switchable to DAY/NIGHT mode through the optional remote control switch. Function: ⑬ RS４８５ /DAY/NIGHT switching terminal. Short circuit on １－２ or open on B/W COLOR. IR TRIG. POL setting on MAIN MENU (PAGE 4/5) RS485/DAY/NIGHT switch terminal １－２...
- Page 7 2－４－４、ALC LEVEL Auto Level Control 2－４－５、GAIN （１）LOW （２）MID 18dB （３）HIGH 36dB （４）AGC Auto Gain Control （５）HYP-AGC Hyper Auto Gain Control Compared with AGC, it increases the sensitivity by +6dB on S/N、 +6dB on STD and+18dB on MOVE. ＊In case of SENSE Up on either S/N、STD or MOVE and DAY/NIGHT on AUTO、the GAIN can be selected only on AGC or HYP AGC.
- Page 8 2－４－８、MENU LOCK （１）Locking MENU LOCK Push E button on ON （2） Unlocking MENU LOCK Push the button in order of U→L→D→R→U→D→E Start over again when mistake was made. 2－４－９、EXIT、CANCEL、RESET （１）EXIT （２）CANCEL （３）RESET MAIN MENU (PAGE 2/5) DETAIL L****I****H CHROMA L****I****H BLACK LEVEL L****I****H WDR MODE...
- Page 9 （４）AUTO B STR (Auto Black Stretch) Shadow zone adjustment 2－４－１５、FOG （１）OFF （２）ON 2－４－１６、GAMMA Gamma setting （ 0.45 / 0.75 / 1 ） 2－４－１7、COLOR MATRIX The adjustment of HUE and SATURATION can be made on R、G、B、Ye、 Cy and Mg. MAIN MENU (PAGE 3/5) FLIP/MIRROR NORMAL...
- Page 10 2－４－２０、CAMERA ID Camera ID setting EDIT CAMERA ID ABCDEFGHIJKLMNOPQRSTUV ① WXYZ : () _ /＋－. 1 2 3 4 5 6 7 8 9 ＋＋＋＋＋＋＋＋＋＋＋＋＋＋＋＋＋＋＋＋＋＋＋ ② ③ SPACE DELETE CLEAR ④ RETURN POSITION EXIT ⑤ ① Character selection by cursor ②...
- Page 11 The color of MASK can be chosen from gray, white or white . Setting ON and pushing E button, positioning and size of MASK can be selected. For re-positioning the MASK, push E button and the cursor will stop flashing. Then select the new position by using U, D, L and/or R buttons. 2－４－２３、RS485 BAUD BAUD rate can be selected from 9600 / 19200 / 38400 .
- Page 12 2－４－２５、SDI FORMAT Signal format for HD output can be selected. 2－４－２６、SDTV FORMAT （１） NTSC-J For Japan PEDESTAL：0 IRE （２） NTSC-M For USA and other NTSC areas. PEDESTAL：7.5 IRE 2－４－２７、SDTV ASPECT （１） LETTER BOX （２） SIDE CUT （３） SQUEEZE 2－４－２８、SDTV C.BURST （１）OFF （２）ON 2－４－２９、IR TRIG POL...
- Page 13 2－４－３１、MODEL NAME & VERSION (1) MODEL NAME (2) MAIN VERSION (3) FIRM VERSION (4) FPGA VERSION 2－５、SPECIAL MENU On PAGE 1/5 of MAIN MENU, go to EXIT and push L and R buttons simultaneously to bring SPECIAL MENU. SPECIAL MENU (PAGE 1/1) WHITE DEFECT ADJAST...
- Page 14 3．FOCUS EZ This is to support focusing. The focusing status can be observed on the focus indicator as shown below. When using auto iris lens, it will keep the iris fully opened for easy focusing. The sensitivity will be automatically corrected. The focus adjustment window will FOCUS EZ 60S appear by pushing U button more...
- Page 15 4．MENU 4－１ MAIN MENU PAGE SENSE UP MANUAL DAY / NIGHT COLOR B / W Ｓ/Ｎ AUTO MOVE REMOTE FLICKER LESS SWITCHI LEVEL DARK BRIGHT MANUAL COLOR⇒B/W B/W⇒COLOR SHUTTER OFF, 1/100, 1/125, 1/250, 1/500,1/1,000, 1/2000,1/4000, 1/10000 x1, x2, x4, x6, x8, x12 x16, x24, x32, x64 BLC MODE SPOT...
- Page 16 WHITE BAL. ATW1 ATW2 PUSH MANUAL RED GAIN BLUE GAIN HIGH MENU LOCK PAGE DETAIL L****I****H CHROMA L****I****H BLACK LEVEL L****I****H WDR MODE AUTO KNEE AUTO B.STR GAMMA 0.45 0.75 COLOR MATRIX SETUP L****I****H SATURATION L****I****H GREEN L****I****H SATURATION L****I****H BLUE SATURATION L****I****H...
-
Page 17: Video Test
CYAN L****I****H SATURATION L****I****H MAGENTA L****I****H SATURATION L****I****H L****I****H PAGE FLIP/MIRROR NORMAL FLIP MIRRAR FLIP&MIRROR ZOOM x1, x2, x3, x4, x5, x6, x7, x8, x9, x10 CAMERA ID ABCD…….STV WXYZ…….789 RS485 ID 1,2,…..207 P. MASK MASK1 MASK2 MASK3 MASK4 MASK5 MASK6 MASK7 MASK8... - Page 18 COLOR BAR CROSS LINE PAGE SDI FORMAT 1080I/59.94 （1080P/30.00） 1080P/29.97 （）: Tentative （720P/60.00） 720P/59.94 （720P/30.00） 720P/29.97 1080I/50.00 1080P/25.00 720P/50.00 720P/25.00 SDTV FORMAT NTSC-J NTSC-M SDTV ASPECT LETTER BOX SIDE CUT SQUEEZE SDTV C. BURST IR TRIG POL BRAKE MAKE GENLOCK L****I****H PAGE MODEL NAME...
-
Page 19: Specification
5．Specification ■Camera Sensor Single Panel CMOS/ RGB Bayer Array Total Pixel Approx.2,600,000pixels 2270(H)x1144(V) Efficient Pixel Approx.2,200,000pixels 1974(H)x1100(V) Pixel Size 5.0μm(H)x5.0μm(V) Sensor Size 2/3” Scanning Type Progressive Sensitivity F11 2000lx Min. Lux at subject 0.005lx（1/30、50IRE、+66dB） Horizontal Resolution Over 900TV lines S/N ratio Over 50dB (γ=1、DETAIL mode OFF）... - Page 20 ■Interface Image Output HD-SDI (BNC)×1 Composite Video (VBS) (BNC)×1 Sync Signal Input External Sync Input (VBS／2 sync) BNC×1 Serial Port RS-485 Contact Input IR cut filter switch Video Output HD-SDI 1080I/59.94 、 1080P/29.97 、 720P/59.94 、 720P/29.97 、 1080I/50.00 、 1080P/25.00 、 720P/50.00、720P/25.00 Composite Video NTSC、PAL Down Convert...
- Page 21 １ unit：mm...
