Server Racks Australia LKD-15X User Manual

1u 19” rack mount console
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
PACKING LIST
The complete LKD-151TP/ 151TB package consists of:
One 1U 19" rack mount console
Rear mounting kit
2 x short L brackets
2 x long L brackets
2 x short extending bracket
2 x long extending brackets
2 x supporting bracket
2 x PS/2 cables & 1 x VGA cable
1 x power cord
2 x Key to lock / screw pack
The complete LKD-158TP/ 158TB package consists of:
One 1U 19" rack mount console-
Rear mounting kit
2 x short L brackets
2 x long L brackets
2 x short extending bracket
2 x long extending brackets
2 x supporting bracket
1 x 1.8m KVM cable: 3 in 1 cable ---PS/2 mouse, PS/2 keyboard, DB 15 VGA;
DB25 VGA male to console.
1 x power cord
2 x Key to lock/ screw pack
Check to make sure that the unit was not damaged in shipping. If you encounter a
problem, contact your dealer.
Please read this manual thoroughly, and follow the installation and operation
procedures carefully to prevent any damage to the LKD-15X, and/or any of the
devices that connect to it.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LKD-15X and is the answer not in the manual?

Questions and answers

Summary of Contents for Server Racks Australia LKD-15X

  • Page 1 Check to make sure that the unit was not damaged in shipping. If you encounter a problem, contact your dealer. Please read this manual thoroughly, and follow the installation and operation procedures carefully to prevent any damage to the LKD-15X, and/or any of the devices that connect to it.

  • Page 2: Safety Instructions

    LKD-15X User Manual SAFETY INSTRUCTIONS Please read these safety instructions carefully. Please keep this User’s Manual for later reference. Please disconnect this equipment from AC outlet before cleaning. Don’t use liquid or sprayed detergent for cleaning. Use moisture sheet or clothe for cleaning.
  • Page 3 LKD-15X User Manual The Power Cord or plug is damaged. Liquid has penetrated into the equipment. The equipment has been exposed to moisture. The equipment has not worked well or you can not get it work according to User’s Manual.

  • Page 4: Table Of Contents

    1.2 Product Specification....................7 1.3 Hardware Requirement....................9 1.4 Mounting the unit to your cabinet ................10 1.4.1 Mounting the LKD-15X into 750 mm cabinets ............11 1.4.2 Mounting the LKD-15X into 900 mm cabinets ............12 CHAPTER 2 15” MATRIX LCD FLAT PANEL..................13 2.1 Introduction......................13 2.1.1 Specifications......................13...
  • Page 5 LKD-15X User Manual 2.2.10 OSD V-Position......................17 2.2.11 Switch Color......................17 2.2.12 Set User Color......................18 2.2.13 Memory Recall ......................18 2.2.14 Exit OSD........................19 CHAPTER 3 INSTALLATION.........................20 3.1 Installing the Video Card and Video Driver ............20 3.1.1 Configuring the Display Settings ................20 3.2 Connecting the Drawer ...................21 3.3 Turning On the Drawer...................21...
  • Page 6 LKD-15X User Manual 5.2.4 Front View........................30 5.3 Hot Plugging ......................30 5.3.1 Powering Off and Restarting..................31 5.3.2 Port Selection ......................31 5.4 Port ID Numbering ....................32 5.4.1 Overview ........................32 5.4.2 Port Key In Examples: ....................32 5.4.3 Hotkey Summary Table .....................32 5.5 OSD Operation .......................32 5.5.1 Overview ........................32...

  • Page 7: Chapter 1 General Information

    CHAPTER 1 GENERAL INFORMATION 1.1 Overview The LKD-15X is an ideal solution for network administration with multiple servers / platforms. Their 15-inch large size TFT LCD color display and ultra-low-profile compact industrial keyboard / trackball provide the user-friendliest and most reliable environment for network administrators.

  • Page 8: Product Specification

    LKD-15X User Manual 1.2 Product Specification Standard Meets EIA RS-310C 1U 19” rack mount standard Dimension (H x W x D) 44 x 440 x 492 (mm) LCD Panel 15” Active-Matrix TFT LCD Anti-reflection Glass for 2 x 249 x 333 (mm)
  • Page 9 LKD-15X User Manual AUTO MENU The LKD-151 Series Num Caps Scroll AUTO MENU The LKD-158 Series...

  • Page 10: Hardware Requirement

    LKD-15X User Manual 1.3 Hardware Requirement Computers Your PC must have a VGA, SVGA, or Multi sync video card and video driver already installed for the monitor. If you need to install a video card or a video driver, refer to your computer documentation for instructions.

  • Page 11: Mounting The Unit To Your Cabinet

    LKD-15X User Manual 1.4 Mounting the unit to your cabinet The unit is designed for standard 700mm ~900mm cabinets*. You may find the rear mounting kit in the carton. Please use the following combination (or more combination rather than below two) to fit in different cabinets.

  • Page 12: Mounting The Lkd-15X Into 750 Mm Cabinets

    LKD-15X User Manual 1.4.1 Mounting the LKD-15X into 750 mm cabinets 1. Fasten the supporting brackets with the chassis. 2. Fasten the extended brackets with the supporting brackets and the chassis. 3. Screw the L brackets with the extended brackets. Adjust the length of L brackets according to your needs.

  • Page 13: Mounting The Lkd-15X Into 900 Mm Cabinets

    5. Fasten the front screws and the rear ones. 1.4.2 Mounting the LKD-15X into 900 mm cabinets Follow the same procedure as mounting the LKD-15X into the 900 mm cabinet, but exchange the short L-brackets with the long L-brackets.

  • Page 14: Chapter 2 15" Matrix Lcd Flat Panel

    LKD-15X User Manual CHAPTER 2 15” MATRIX LCD FLAT PANEL 2.1 Introduction 2.1.1 Specifications Screen Type TFT LCD Display Area 304.128mm(H) 228.096mm(V) Contrast Ratio 350:1 Viewing Angle Up/down: 100 degree Left/right:120 degree Number of pixels 1024 Pixel pitch (H x W) 0.297mm...

  • Page 15: Factory Preset Timing For Reference

    LKD-15X User Manual 2.1.2 Factory Preset Timing for Reference VGA 640 350 @ 70Hz Preset mode VGA 640X400@70Hz VGA 720 400 @ 70Hz VGA 640 480 @ 60/ 72/ 75Hz SVGA 800 600 @ 56/ 60/ 72/ 75Hz XGA 1024 768 @ 60/ 70/ 72/ 75Hz 2.2 Panel Controls and OSD Functions...

  • Page 16: Contrast

    LKD-15X User Manual 2.2.3 Contrast Press the “menu” bottom. Use the bottom to scroll. Press the “menu” bottom to enter. Use the bottom to adjust the contrast of the display. Press the “auto” button to exit. 2.2.4 Clock Press the “menu” bottom.

  • Page 17: Horizontal Position

    LKD-15X User Manual Press the “auto” button to exit. 2.2.6 Horizontal Position Press the “menu” bottom. Use the bottom to scroll. Press the “menu” bottom to enter. Use the bottom to move the display picture left or right. Press the “auto” button to exit.

  • Page 18: Osd H-Position

    LKD-15X User Manual 2.2.9 OSD H-Position 1. Press the “menu” bottom. 2. Use the bottom to scroll. Press the “menu” bottom to enter. Use the bottom to move the OSD position left or right. Press the “auto” button to exit.

  • Page 19: Set User Color

    LKD-15X User Manual 4. Use the bottom to choose the color temperature mode. 5. Press the “auto” button to exit. 2.2.12 Set User Color 1. Press the “menu” bottom. 2. Use the bottom to scroll. 3. Press the “menu” bottom to enter.

  • Page 20: Exit Osd

    LKD-15X User Manual 4. Restore the default value (factory mode). Press ‘’ Menu’’ to executing. 5. Press the “auto” button to exit. 2.2.14 Exit OSD 1. Press the “menu” bottom. 2. Use the bottom to scroll. 3. Press the “menu” bottom to enter.

  • Page 21: Chapter 3 Installation

    LKD-15X User Manual CHAPTER 3 INSTALLATION 3.1 Installing the Video Card and Video Driver Before connecting the LKD-151 and LKD-158, make sure your computer has a video card already installed for the monitor. After you connect the drawer, install the video software driver.

  • Page 22: Connecting The Drawer

    LKD-15X User Manual 3.2 Connecting the Drawer To connect an LKD-151 and LKD-158 monitor/keyboard drawer to a computer, perform the following steps: AC/IN 90V~264V POWER ON/OFF TOUCH PANEL MOUSE KEYBOARD The rear view of the LKD-151 Turn off your computer. You should always turn off your computer before connecting or disconnecting a device.

  • Page 23: Testing The Drawer

    LKD-15X User Manual 3.4 Testing the Drawer To test that the drawer is working properly, perform the following steps: Power up the monitor/keyboard drawer, and then turn on your computer. Make sure the video image is centered within the screen area. Use the OSD controls to adjust the image (see note below) or press the Auto button on the right hand side of the monitor.

  • Page 24: Chapter 4 Touch Screen (Lkd-151T)

    LKD-15X User Manual CHAPTER 4 TOUCH SCREEN (LKD-151T) 4.1 Installation of LKD-151T 4.1.1 Software installation for Win95/98 Insert the Onetouch utility diskette (described in the packing list) into your floppy disk drive. Choose [Run] from the [Start] menu iii. Type [A:\win98\setup].
  • Page 25 LKD-15X User Manual responds correctly then your touch panel is accurately aligned to your monitor. 12. Touch [OK] button to exit and the [Reboot Message Dialog Box] will appear. 13. Remove the setup diskette from the floppy disk and click [Reboot] button after [Installation Driver OK] appear.

  • Page 26: Software Installation For Dos And Win 3.1

    LKD-15X User Manual 4.1.2 Software installation for DOS and Win 3.1 1. Insert the utility diskette (described in the packing list) into your floppy disk drive. 2. At the DOS prompt [C:>], type [A: INSTALL] then press [Enter]. 3. Type in the [Source Disk Driver] (type A if it’s in A drive) 4.
  • Page 27 LKD-15X User Manual Note: 640 x 480 (step 12) refers to your monitor screen resolution. If you change these settings you will have to run the position alignment program again. You can change the COM Port or Mouse Device Driver in the Autoexec.bat file with the DOS Edit program.

  • Page 28: Basic Touchscreen Operation

    LKD-15X User Manual 4.2 Basic Touchscreen Operation 4.2.1 Opening menu To open a menue, such as the Start menue on the Windows desktop touch the Start button once, lightly and rapidly. Other menus are opened in the same way. 4.2.2 Single tapping This technique is used to select an object or item from a menu, or to open a menu, as described above.

  • Page 29: Chapter 5 Kvm Switch (Lkd-158 Only)

    LKD-15X User Manual CHAPTER 5 KVM Switch (LKD-158 only) 5.1 Features Cascadable To Three Levels - Control Up to 512 Computers from a Single Console No Software Required - Computer Selection via Front Panel Switches, Hot Keys, or OSD (On Screen Display)

  • Page 30: Single Station Installation

    LKD-15X User Manual 5.2.2 Single Station Installation In a Single Stage installation, there are no additional KVM switch daisy chained down from the LKD-158. To set up a single stage installation, do the following: 1. Use connector cable sets (as described in the Hardware Requirements section), to connect any available monitor, keyboard and mouse ports of the computer you are installing.

  • Page 31: Front View

    LKD-15X User Manual 5.2.4 Front View 1. Port LEDs On Line Connected :Lights ORANGE to indicate that the computer attached to the corresponding port is up and running. If the LED is flashing, it indicates that the Port is being used for Cascading to another Master View switch.

  • Page 32: Powering Off And Restarting

    LKD-15X User Manual 5.3.1 Powering Off and Restarting If it becomes necessary to Power Off one of the LKD-158 units, before starting it back up you must do the following: 1. Shut down all the computers that are attached to it.

  • Page 33: Port Id Numbering

    LKD-15X User Manual On Screen Display (OSD), provides a menu driven interface to handle the computer switching procedure. OSD operation is discussed in detail beginning on page 15 5.4 Port ID Numbering 5.4.1 Overview Each CPU Port on a LKD-158 installation is assigned a unique Port ID. You can...

  • Page 34: Osd Navigation

    LKD-15X User Manual Note: 1. The keys must be on the same side (both left, or both right) 2. You can optionally change the hotkey to LIST:ALL the Scroll Lock key (see F6, NAME below), in which case you would press [Scroll Lock] twice.

  • Page 35: Osd Main Menu Headings

    LKD-15X User Manual Number keys must be pressed from the regular keyboard; not from the numeric keypad. If you submit an incorrect Port ID, an error message displays, and you are returned to the OSD Main Menu. 5.5.4 OSD Main Menu Headings: This column lists the Port ID numbers (Station Number - Port Number) for all the CPU Ports on the installation.
  • Page 36 LKD-15X User Manual Note: 1. If the scanning stops on an empty port, or one where the computer is attached but is powered Off, the monitor screen will be blank, and the mouse and keyboard will have no effect. To recover, key in the Hotkey sequence (see Hotkey Selection, above), for any Port ID that has an active computer attached.
  • Page 37 LKD-15X User Manual When a port has been selected, an arrowhead displays in the QV column to indicate so. The arrowhead disappears when a port is deselected. F5 Edit: ♦ To help remember which computer is attached to a particular port, every port can be given a name.
  • Page 38 LKD-15X User Manual F6 Set ♦ Pressing [F6] brings up an OSD configuration menu. To change a setting: 1. Move the highlight bar to the choice you want, then press [Enter]. 2. On the submenu that appears next, move the highlight bar to the choice you want and press [Enter].

  • Page 39: Factory Default Settings

    LKD-15X User Manual Setting Function DEFAULT factory defaults. You are asked to confirm before the VALUES* procedure goes on. Key in Y, then press [Enter] to confirm. While the settings are being cleared, a message appears on the display to indicate so. After the settings have been cleared, another message appears to indicate that the procedure completed successfully.
  • Page 40 LKD-15X User Manual If the two entries match, the new password is accepted and the screen displays the following message: SET PASSWORD OK If the entries do not match, the screen displays the message: PASSWORD NOT MATCH in which case you must start again from the beginning.

  • Page 41: Trouble Shooting

    LKD-15X User Manual 5.6 Trouble Shooting Symptom Possible Cause Action Erratic Behavior Unit not receiving Use the Power Adapter that was supplied enough power under with the unit to provide external power. self-powered operation. Pressing Hot Keys The connection from...
  • Page 42 LKD-15X User Manual 2. Check the connector from mouse module to PCBA, it’s so fragile that the soldering is easy to be broken by intensive force; PLEASE DO NOT OPEN THE UP COVER OF THE KEYBOARD WITHOUT INSTRUCTION OF ORIGINAL MAKER...
