Flat Panel
LCD - TV
© 2005 All rights reserved.
Trademarks:
Manufactured under license by Dolby Laboratories.
'Dolby', 'Pro Logic' and the Double D symbol are trademarks of Dolby Laboratories.
The "HD ready" Logo is a trademark of EICTA.
Additional trademarks are the property of their respective owners.
We make no warranty of any kind with regard to this material, including, but
not limited to, the implied warranties of merchantability and fitness for a particular purpose.
We will not be liable for errors contained herein or for incidental or consequential damages in connection with the furnishing, per-
formance, or use of this material.
We assume no responsibility for the use or reliability of its software on equipment that is not furnished by our company.
This document contains proprietary information that is protected by copyright. All rights are reserved. No part of this document
may be photocopied, reproduced, or translated to another language without the prior written consent of our company.
The information in this document is subject to change without notice.
BDA00101000

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Flat Panel LCD - TV and is the answer not in the manual?

Questions and answers

Related Manuals for Dolby Laboratories Flat Panel LCD - TV

Summary of Contents for Dolby Laboratories Flat Panel LCD - TV

  • Page 1 © 2005 All rights reserved. Trademarks: Manufactured under license by Dolby Laboratories. ‘Dolby’, ‘Pro Logic’ and the Double D symbol are trademarks of Dolby Laboratories. The “HD ready” Logo is a trademark of EICTA. Additional trademarks are the property of their respective owners.

  • Page 2: Table Of Contents

    1. SAFETY AND PRECAUTIONS Operating Safety ....................1 Repair......................1 Notes for Service Engineers ................1 Point of use ....................2 Environmental conditions................. 2 Connecting ....................2 Standards/Electro-Magnetic Compatibility ............3 Precautions ......................3 Important Additional Safety Instructions..............3 Recycling and Disposal ..................4 2.
  • Page 3 9. TELETEXT To operate Teletext .................... 23 Teletext Page Selection ..................23 Select Teletext display functions ................23 Useful features for Teletext.................. 24 10. CONNECTING EXTERNAL DEVICES Connection of an external device to the Scart socket ..........25 Connecting a camera recorder................25 Connecting a video recorder to the aerial socket .............

  • Page 5: Safety And Precautions

    Please read through this section carefully and follow the instructions to maximize the reliable operation and lifetime of your LCD display. Always keep these instructions handy and close by your LCD display. Keep the instructions and the packaging so that if you sell or give away your LCD display you can supply them to the new owner.

  • Page 6: Point Of Use

    OINT OF USE • Keep your LCD display and all units connected to it away from moisture and avoid dust, heat and direct sunlight. Failure to observe these instructions can lead to malfunctions or damage to the LCD display. • Do not place any containers filled with liquid (vases or similar) on the LCD TV. The container could tip over and the liquid could impair electrical safety.

  • Page 7: Standards/Electro-Magnetic Compatibility

    TANDARDS LECTRO AGNETIC OMPATIBILITY Your display fulfils the requirements for electro-magnetic compatibility and electrical safety specified in the following standards: EN 55013, EN 55020, EN 60065 EN 61000-3-2, EN 61000-3-3 • When connecting ensure that Guidelines for Electro-Magnetic Compatibility (EMC) are observed.

  • Page 8: Recycling And Disposal

    ECYCLING AND ISPOSAL This device and its packaging have manufactured from materials that can be disposed of in an environmentally-friendly way and sent to correct recycling to a great extent. The device will be taken back after use, in order to send it to reutilization or exploitation of the materials, as far as is it is returned in a state that corresponds to use in accordance with regulations.

  • Page 9: Introduction

    Thank you for purchasing our LCD Multi-display. We thank you for your confidence in our products and are pleased to greet you as a new customer. We focused on great features, ease of use and reliability in manufacturing your LCD display. ERVICE Service and support will be available every time you use your new monitor.

  • Page 10: Control Elements And Front Connections

    The Buttons on the device control the basic functioning of the LCD TV, including the On- Screen Menu. You will reach the advanced functions through the remote. Operating display A yellow light indicates that the device is switched on but is in Readiness Mode.

  • Page 11: Back Of The Device And Connections

    Mains plug Aerial connection Scart/AV1 Mains switch DVI-I Scart/AV2 Service PC Audio IN Note: Please read chapter „10. Connecting External Devices“on page 25 for further infor- mation about operating external devices. 4 4 . . B B A A C C K K O O F F T T H H E E E E V V I I C C E E A A N N D D O O N N N N E E C C T T I I O O N N S S...

  • Page 12: Remote Control

    This is for a remote that is suitable for your LCD-TV; you will find the relevant Button identi- fication and arrangement on the following page: N N G G L L I I S S H H...

  • Page 13: Summary Of Control Buttons

    UMMARY OF ONTROL UTTONS Device on or switch to Readiness Mode POWER Switches the device on or into Operating Mode alternately Selecting the Signal Source Switch to the TV mode. Switches to PC mode (VGA or DVI) AV.SV Switches to video mode or S-video mode SCART 1 Switches to SCART 1.

  • Page 14: Apsas First Time Installation

    1. After removing the LCD display packaging, ensure the product is installed in a safe and well ventilated position. 2. Insert two AAA type batteries into battery compartment on the rear of the remote control. 3. Connect the external 75 Ohm aerial cable and the electricity cable to the rele- vant connections and make sure that the mains switch on the back is switched 4.
  • Page 15 9. Please go to the Start Menu Point with the assistance of the P+/P- setting But- tons, after you have selected your preferred language. The initial sound setting will be started automatically by selecting Continue by means of MENU and the P+/P- Buttons. The device will automatically search for, sort and store all the television channels receivable at your location.

  • Page 16: General Controls & Adjustment

    & & URNING THE DISPLAY N AND The mains switch of the LCD TV is located on the back of the device. The device moves to Readiness Mode if this switch is switched on. The operating display shines yellow in Readiness Mode. It is possible to switch the device to the normal Operating Mode by means of the POWER Button on the remote or on the de- vice.

  • Page 17: Continue Switching Channels

    ONTINUE SWITCHING CHANNELS You have three different possibilities to switch through the channels available: 1. Through direct entry of the channel number: You will call up the channel directly through the 0-9 Buttons. You can enter the following digit within 2 seconds after entering the first digit, in order to call up multi-digit channel numbers.
  • Page 18 Variation 1: Press the RED Button to reach the Picture Menu directly. Variation 2: Press the MENU Button to call up the Main Menu, set the cursor on PICTURE by means of the P+/P- Buttons and call up the appropriate Menu by means of the MENU Button.

  • Page 19: Additional Picture Settings

    DDITIONAL PICTURE SETTINGS Move the cursor to ADDITIONAL PICTURE SETTINGS with the P+/P- Buttons and press the MENU Button. Continue Picture 1. Noise reduction 2. Sharpness 3. Comb filter 4. Colour registration 5. Backlight 6. White balance 7. Perfect Clear Further fine adjustments in relation to the impression made by the picture can be carried out in this Menu.

  • Page 20: Sound (Balance, Equalizer, Etc.)

    OUND ALANCE QUALIZER Different settings in relation to the sound reproduction of your LCD TV can be made in this Menu. Variation 1: Press the BLUE Button to reach the Sound Menu directly. Variation 2: Press the MENU Button to call up the Main Menu, set the cursor on SOUND by means of the P+/P- Buttons and call up the associated Menu by means of the MENU Button.
  • Page 21 The different NORMAL/WIDE/CINEMA surround sound settings can be selected through a Menu by means of the VOL+/VOL- Buttons or by pressing the MENU Button. Note: Cinema Surround is a technology certified by Dolby Laboratories, which creates a virtual surround sound experience with only two loudspeakers through the use of Dolby Pro Logic.

  • Page 22: Tv Mode Adjustment

    DJUSTING SETTINGS 1. Select "TV" mode as signal source using the TV key on the remote control. 2. Press the Menu key and select TV on the screen menu. Main Menu Picture Sound Program table Installation Child lock Sleeptimer Swap function Games 3.

  • Page 23: Moving And Sorting Channels

    OVING AND SORTING CHANNELS 1. Go to the channel slot in the program table that you would like to move or sort with the assistance of the P+/P-/Vol+/Vol- Buttons. 2. Press the GREEN Button to call up the sorting function directly or call up an Edit Func- tions Menu with the MENU function and select MOVE.

  • Page 24: Setting Channels Manually

    ETTING CHANNELS MANUALLY 1. Go to the channel slot in the program table that you would like to edit with the assis- tance of the P+/P-/Vol+/Vol- Buttons. 2. Either press the YELLOW Button to call up the processing function directly or call up an Edit Functions Menu with the MENU function and select EDIT.
  • Page 25 9. Colour Standard: The colour standard can be changed with the MENU Button (menu) or the VOL+/VOL- Buttons. Changes to the colour norm of a station can be made here. 10. Audio channel: The preferred audio channel can be selected with the MENU Button (Menu) or the VOL+/VOL- Buttons.

  • Page 26: Manual Addition Of Channels

    ANUAL ADDITION OF CHANNELS 1. Go to the first empty channel slot following the channel slots already stored in the pro- gram table with the P+/P-/Vol+/Vol- Buttons. Press the MENU Button and select the NEW TV signal source. 2. Now enter the channel type and subsequently the channel number or the relevant fre- quency.

  • Page 27: Teletext

    Teletext is a free service that is broadcast by the majority of television stations and offers current information in relation to news, the weather, television programs, share prices, sub- titles and other subjects. Your LCD TV offers many useful functions for operating Teletext and multi-page text, storing sub-pages or fast navigation.

  • Page 28: Useful Features For Teletext

    2. Split Screen: Press the PIP ON/OFF Button (= divided screen), to display the current television pic- ture as split screen, in addition to Teletext. 3. Television picture in Multi-Page Text: The television picture in the upper field of the two small Teletext pictures will be pre- sented in Multi-Page Mode by pressing the PIP ON/OFF Button again.

  • Page 29: Connecting External Devices

    ONNECTION OF AN EXTERNAL DEVICE TO THE CART SOCKET Please connect the SCART/AV1 or the SCART/AV2 socket of the LCD TV to the device to be connected with a EURO AV cable (Scart cable), to connect a video recorder, a DVD player, a SAT receiver or similar to one of the two Scart sockets of your LCD TV, for example.

  • Page 30: Settings For External Devices (Picture, Sound, Name, Etc.)

    ETTINGS FOR EXTERNAL DEVICES ICTURE OUND Please refer to the Chapters „Picture (Contrast, Colour, Brightness, etc.)“ on Page 13 and „Additional picture settings“ on Page 15, to change the picture for AV settings. The functions described in these Chapters also apply to the AV positions. You will find more precise descriptions in chapter „Sound (Balance, Equalizer, etc.)“...
  • Page 31 YCrCb: A YcrCb signal that is the output of a many DVD players can be represented at this setting. It will be recognized automatically whether the pictures are transmitted in the line interlaced or full picture (progressive) process. YPrPb: A YprPb signal that is the output of a many DVD players can be represented at this setting.

  • Page 32: Pc Mode

    ONNECTION Your LCD TV offers you the possibility of connecting a PC or a video source with a DVI out- put (a DVD player for example) to it. Your LCD TV is able to reproduce both analog and digi- tal input signals. Connect the DVI-I socket of the LCD TV to the video adapter of your PC or to your video source.
  • Page 33 3. Input: With the VOL+/VOL Buttons or by means of a list of selections that can be reached by pressing the MENU Button; it is possible to choose between the AUTO/ANALOG PC/ANALOG VIDEO/DVI PC/DVI VIDEO Settings. AUTO: Your LCD-TV will recognize the type of signal (analog or digital) at the DVI-I socket automatically.

  • Page 34: Picture In Picture (Pip)

    You can use the PIP function to display two programs at the same time. 1. Press the PIP ON/OFF Button on the remote. Channel slot 1 will be displayed as a small picture when you call up the PIP function for the first time, after switching the LCD TV on. 2.

  • Page 35: Comfort Functions

    HILD LOCK You can block all the functions of the device with the Child Lock. The entry of a PIN will be required automatically when the device is switched on again, if the Child Lock has been ac- tivated and the device has been switched off. The picture and the sound will not be switched on and the operation of the device will not be permitted until a PIN number has been entered.

  • Page 36: Swap Function

    You can set the switching off time in steps of 5 MIN./10 MIN./15 MIN./30 MIN./1 HOUR/2 HOURS/OFF by operating the SLEEP Button or the VOL+/VOL- Buttons, or call up this Menu by pressing the MENU Button. The OFF setting means that the Sleep Timer is switched off.

  • Page 37: Switching On Mode

    WITCHING You can establish your preferred Operating Mode of the LCD TV after switching it on with this setting. 1. Press the MENU Button to reach the Main Menu. 2. Select the INSTALLATION Menu Point with the P+/P- Buttons and press the MENU But- ton again.

  • Page 38: Time Display Time

    TIME IME DISPLAY In TV Mode, the time will be displayed by pressing this Button. Press the TIME Button while your LCD TV is transmitting a television channel with Teletext transmission. The current time will be displayed in the form of a digital clock in the right upper corner of the screen.

  • Page 39: Games

    Your LCD TV is equipped with four games and an associated high score list. Games Highscores Brixx Anaconda Scramble Outer Space Move to the game that you would like to play with the aid of the P+/P- Buttons and press the MENU Button to call up the game.

  • Page 40: Troubleshooting

    Many times, problems have simple causes. We would like to give you some tips to solve some common problems. Should these tips not help, please call us! There is no picture or sound. Make sure the AC adapter is properly inserted in the power outlet. Make sure the input mode is set to correctly.

  • Page 41: Other Questions

    O YOU REQUIRE ADDITIONAL UPPORT If the suggestions in the above section have not solved your problem, please contact the hotline. We will try and help you over the telephone. However, before you contact your Technology Center, please keep the following information available: What additional peripheral devices are you using? What messages are appearing on the screen? During which operational step did the problem arise?

  • Page 42: Warranty

    ARRANTY We warrant to our customers that this product is free from defects in materials and workmanship as follows: for a determined period from the date of original purchase, defective parts or a defective product returned to a repair facility or an Authorized Service Facility ("ASF") for such product, as applicable, and proven to be defective upon inspection, will be exchanged for new or comparable rebuilt parts, or a refurbished product, as determined by the repair facility or the ASF.
