Connection Options

Connection Options
DIGITAL AUDIO OPTICAL
OUTPUT
Used to connect either an exter-
nal amplifier, or add a sub-
woofer to your surround sound
system if it has a digital
audio optical input.
(Refer to )
1
DIGITAL AUDIO OPTI-
CAL INPUT1(COMPO-
NENT2)
Connect digital audio
from the equipment
whose video is connect-
ed to COMPONENT 2.
DIGITAL AUDIO OPTI-
CAL INPUT2(DVI)
Connect digital audio
from the equipment
whose video is connect-
ed to
HDMI/DVI(VIDEO).
(Refer to )
2
CableCARD™
Used for CableCARD™
received Cable Service
Provider.
IEEE1394
Connect DVHS or
MicroMV to IEEE1394
Connector.
HDMI1/DVI, HDMI 2
Connect a HDMI signal
to HDMI1/DVI or
COMPONENT INPUT 1-2
HDMI2. Or connect a
Connect a component
DVI(Video) signal to
video/audio
HDMI1/DVI.
these jacks. Refer to your
DVD manual for further
information.
Notes: In standby mode, these port will not work.
1
2 If the video is connected through HDMI-TO-HDMI cable, you don't need to connect digital audio. This port
is used only when the video connected through DVI-TO-HDMI cable.
DESCRIPTION OF CONTROLS
Back Connection Panel
Back Connection Panel
G-LINK CABLE Inputs
Connect a G-
Connect cable signals to
LINK Cable to
the TV, either directly or
this jack.
through your cable box.
ANTENNA
G-LINK
DIGITAL AUDIO
OPTICAL OUTPUT
C DIGITAL AUDIO
OPTICAL INPUT1
a (COMPONENT2)
b
l CABLE
e
DIGITAL AUDIO
C
OPTICAL INPUT2
(DVI)
A COMPONENT
R
INPUT2 INPUT1
D
Y
IEEE-1394
P
B
HDMI1
/DVI
P
R
(L)
HDMI2
AUDIO
(R)
DTV/DVD INPUT
RGB/DVI INPUT
Connect the monitor
device to
output connector from
a PC to the appropri-
ate input port.
UPGRADE PORT
RGB
PC/DTV (XGA/
480p/
720p
1080i)
RGB/DVI
Y
B P
R P
PC/DTV
(XGA/
480p/ 720p /
1080i)
DVI DTV/DVD
ANTENNA Inputs
Connect antenna sig-
nals to the TV directly.
UPGRADE
PORT
RGB INPUT
PC/DTV
S-VIDEO
(XGA
/480p
/720p
/1080i)
MONITOR VIDEO VIDEO
RGB/DVI INPUT
OUTPUT INPUT2 INPUT1
VIDEO
(L)
AUDIO
(R)
(L)
AUDIO
MONO
(R)
(L)
VARIABLE
AUDIO
AUDIO OUT
(R)
VARIABLE AUDIO OUT
Used to connect either
an external amplifier,
or add a sub-woofer to
your surround sound
system.
- 5 -
RGB Input
Connect the TV output
connector from a PC/DTV
to the appropriate input
port.
S-VIDEO In
A connection available
with some high-end
equipment that provides
even better picture qual-
ity for Video 2.
VIDEO 1 or 2
Connects the video sig-
nals from various types
of equipment.
Left/Right AUDIO
Used for stereo sound
from various types of
equipment.
MONITOR OUTPUT
Connect a second TV or
Monitor.
