- Page 1 G.SHDSL.bis Bridge Modem 5210D User Manual Version 0.01...
-
Page 2: Table Of Contents
STP ............................27 ............................28 TATUS 4.3.1 SHDSL.bis ..........................29 4.3.2 LAN ............................30 4.3.3 WAN ............................31 4.3.4 INTERFACE ..........................32 4.3.5 STP ............................33 ..........................35 DMINISTRATION 4.4.1 Security ..........................35 G.SHDSL.bis Bridge Modem 5210D User Manual V0.01... - Page 3 Wan ............................57 5.3.3 Interface ..........................58 5.3.4 STP ............................58 ............................59 5.4.1 System information........................ 59 5.4.2 Configuration information ..................... 59 5.4.3 Configuration with Script format ................... 60 ............................. 60 .............................. 60 G.SHDSL.bis Bridge Modem 5210D User Manual V0.01...
-
Page 4: Descriptions
1 Descriptions The Proscend 5210D is G.SHDSL.bis bridge modem with four Ethernet interfaces to a computer. It provides a very stable system installation with a simplified set of configuration options to ensure problem free operation. It complies with G.991.2 (2004) standard optimized for small to medium size business environment. - Page 5 Power: 100~240VAC (via power adapter) Power consumption: 9 watts maximum. Temperature: 0~45˚C Humidity: 0%~95%RH (non-condensing) Memory 2MB Flash Memory, 16MB SDRAM Products’ Information 5210D G.SHDSL.bis Bridge Modem with 4-ports LAN G.SHDSL.bis Bridge Modem 5210D User Manual V0.01...
-
Page 6: Applications
1.3 Applications G.SHDSL.bis Bridge Modem 5210D User Manual V0.01... -
Page 7: Getting To Know About The Modem
RS- 232 Console port for system configuration and maintenance (DB-9F) LINE SHDSL.bis interface for WAN port (RJ-45) Reset button to reboot or reset your modem to factory default setting (All customized settings that you have saved will be lost). G.SHDSL.bis Bridge Modem 5210D User Manual V0.01... -
Page 8: Shdsl.bis Line Connector
Below figure show the SHDSL.bis line cord plugs pin asignment: Console Cable Below figure show the cosole cable pins asignment: Pin Number Description Figure Receive Data Transmit date Signal Groung Front view of DB-9(F) of the Console Cable G.SHDSL.bis Bridge Modem 5210D User Manual V0.01... -
Page 9: Install To The Modem
Note: Suggest to use IE5.0, Netscape 6.0 or above and 800x600 resolutions or above. (3) Check the Terminal Access Program For Serial Console and Telnet Configuration, users need to setup the terminal access program with VT100 terminal emulation. G.SHDSL.bis Bridge Modem 5210D User Manual V0.01... -
Page 10: Install The Shdsl.bis Modem
Connect male end of RS-232 cable to the product and female end to any free COM port of Connect the power adapter by plugging power supply. Wire connection for SHDSL.bis modem G.SHDSL.bis Bridge Modem 5210D User Manual V0.01... -
Page 11: Configuration Via Web Browser
Choose IP address tab. Select Specify an IP address. Type IP Address and Subnet Mask items. Click OK button. Open IE or Netscape Browser to connect the modem. Type http://192.168.0.1 G.SHDSL.bis Bridge Modem 5210D User Manual V0.01... - Page 12 Note: After changing the User Name and Password, strongly recommend you to save them because another time when you login, the User Name and Password have to be used the new one you changed. G.SHDSL.bis Bridge Modem 5210D User Manual V0.01...
-
Page 13: Function Overview
Function overview Following is the function overview of G.SHDSL.bis modem. G.SHDSL.bis Bridge Modem 5210D User Manual V0.01... -
Page 14: Basic Setup
Click Basic for basic installation. 4.1.1 Bridge Mode Parameter Table: SHDSL.bis □CO side □CPE side IP address Subnet Mast Gateway Host Name WAN1 Encapsulation □VC-mux □LLC The flow chart of bridge mode setup: G.SHDSL.bis Bridge Modem 5210D User Manual V0.01... - Page 15 Some of the ISP requires the Host Name as identification. You may check with ISP to see if your Internet service has been configured with a host name. In most cases, this field can be ignored. (b) WAN1 VPI,VCI and Encapsulation WAN1: VPI: 0 VCI: 32 Encap: Click LLC G.SHDSL.bis Bridge Modem 5210D User Manual V0.01...
- Page 16 Click Next to review the setting data: The screen will prompt the new configured parameters. Checking the parameters and Click Restart The modem will reboot with the new setting or Continue to configure another parameters. G.SHDSL.bis Bridge Modem 5210D User Manual V0.01...
-
Page 17: Reference Diagram
LAN. Bridged connections do not use the IP protocol. EoA can also be configured to provide a routed connection with the ISP, which uses the IP protocol to exchange data. G.SHDSL.bis Bridge Modem 5210D User Manual V0.01... -
Page 18: Advanced Setup
Advanced setup contains SHDSL.bis, LAN, WAN, Bridge, VLAN and STP parameters. 4.2.1 SHDSL.bis You can setup the Annex type, data rate and SNR margin for SHDSL.bis parameters in SHDSL.bis. Click SHDSL.bis Enter Parameters in SHDSL.bis 4.2.1.1 Annex Type G.SHDSL.bis Bridge Modem 5210D User Manual V0.01... -
Page 19: Data Rate (N*64Kbps)
ATM-based Access Network or Ethernet-based Access Network. 4.2.1.5 Rate Mode For adaptive mode, you have to configure in Rate Mode. It will adapt the optimal data rate according to the line status. G.SHDSL.bis Bridge Modem 5210D User Manual V0.01... -
Page 20: Wan
WAN under ADVANCED. On the other hand, you don’t need to setup WAN except you apply two or more Internet Services with ISPs. Enter the parameters: 4.2.2.1 Protocol, IP address and subnet Protocol: You can disable or enable this WAN ports. When enable, there have only one protocol G.SHDSL.bis Bridge Modem 5210D User Manual V0.01... -
Page 21: Vpi
QoS PCR (Peak Cell Rate) in kbps: The maximum rate at which you expect to transmit data, voice and video. Consider PCR and MBS as a menas of reducing lantency, not increasing bandwidth. The range of PCR is 64bps to 2400kbps. G.SHDSL.bis Bridge Modem 5210D User Manual V0.01... -
Page 22: Qos Scr
Press Restart to restart the modem working with new parameters or press continue to setup another parameter. 4.2.3 Bridge If you want to setup advanced filter function in bridge mode, you can use BRIDGE menu to setup the filter function, blocking function. Click Bridge to setup. G.SHDSL.bis Bridge Modem 5210D User Manual V0.01... - Page 23 Key the MAC address in MAC Address field and select Filter in WANs field. For example: if your VC is setup at WAN 1, select WAN 1 Filter. Press Finish in the bottom of web page to review the bridge parameters. G.SHDSL.bis Bridge Modem 5210D User Manual V0.01...
- Page 24 The screen will prompt the parameters that will be written in NVRAM. Check the parameters before writing in NVRAM. Press Restart to restart the modem working with new parameters or press Continue to setup another parameter. G.SHDSL.bis Bridge Modem 5210D User Manual V0.01...
-
Page 25: Vlan
The modem supports two types of VLAN: 802.1Q Tag-Based VLAN and Port-Based VLAN. User can configure one of them to the modem. 4.2.4.1 802.1Q Tag-Based VLAN For setting 802.1Q VLAN click the 802.1Q Tagt-Based VLAN. The screem will prompt as the following. G.SHDSL.bis Bridge Modem 5210D User Manual V0.01... -
Page 26: Port-Based Vlan
Port-Based VLANs are VLANs where the packet forwarding decision is based on the destination MAC address and its associated port. For setting Port-Based VLAN, Click Port-Based VLAN, The screem will prompt as follows: G.SHDSL.bis Bridge Modem 5210D User Manual V0.01... - Page 27 The default setting is all ports (LAN1 to LAN4 and WAN1 to WAN8) connected together which means all ports can communicate with each other. That is, there are no virtual LANs. The option is the most flexible but the least secure. G.SHDSL.bis Bridge Modem 5210D User Manual V0.01...
-
Page 28: Stp
4.2.5 STP Click STP can disable or enable the bridge STP mode. The default is disable. G.SHDSL.bis Bridge Modem 5210D User Manual V0.01... -
Page 29: Status
IP type, MAC address, IP address and Subnet mask. WAN interface information. 8 WAN interface including IP address, Subnet Mask, VPI/VCI, Encapsulation, Protocol and Flag. INTERFACE LAN and WAN statistics information. STP information include Bridge parameter and Ports Parameter G.SHDSL.bis Bridge Modem 5210D User Manual V0.01... -
Page 30: Shdsl.bis
The status information shows the SHDSL.bis status and performance information. If the modem have connected to remote side, it can also show the performance information of remote side. Click Clear CRC Error can clear the CRC error count. G.SHDSL.bis Bridge Modem 5210D User Manual V0.01... -
Page 31: Lan
4.3.2 LAN This information shows the LAN interface status. G.SHDSL.bis Bridge Modem 5210D User Manual V0.01... -
Page 32: Wan
4.3.3 WAN This information shows all eight WAN interface. G.SHDSL.bis Bridge Modem 5210D User Manual V0.01... -
Page 33: Interface
The field shows the number of transmitted packets on this port InDiscards The field shows the discarded number of received packets on this port OutDiscards The field shows the discarded number of transmitted packets on this port G.SHDSL.bis Bridge Modem 5210D User Manual V0.01... -
Page 34: Stp
Root Path Cost: The Cost of the Path to the Root from this Bridge, this is equal to the sum of the values of the Designated Cost and Path Cost parameters held for the Root Port. When the Bridge is the Root, this parameter is zero. The ports parameters have: G.SHDSL.bis Bridge Modem 5210D User Manual V0.01... - Page 35 Forwarding: When a port receives or sends data. In other words, this is operating normally. Disabled: This is when the network administrator has disabled the port. Blocking: this means the port was blocked to stop a looping condition. G.SHDSL.bis Bridge Modem 5210D User Manual V0.01...
-
Page 36: Administration
Legal address pool will setup the legal IP addresses from which authorized person can configure the modem. This is the more secure function for network administrator to setup the legal address of configuration. G.SHDSL.bis Bridge Modem 5210D User Manual V0.01... - Page 37 The browser will prompt the all configured parameters and check it before writing into NVRAM. Press Restart to restart the gateway working with the new parameters and press Continue to setup other parameters. G.SHDSL.bis Bridge Modem 5210D User Manual V0.01...
- Page 38 Use ping test, view the status and configuration Exit Web Brower mode: Supervisor ID Supervisor Password All function can use Logout Factory default User name admin Password admin Supervisor ID root Supervisor Password root G.SHDSL.bis Bridge Modem 5210D User Manual V0.01...
-
Page 39: Snmp
SNMP security. This modem support both MIB I and MIB II. Click SNMP to configure the parameters. 4.4.2.1 Community pool Press Modify to modify the community pool. You can setup the access authority. G.SHDSL.bis Bridge Modem 5210D User Manual V0.01... -
Page 40: Trap Host Pool
Press OK to finish the setup. The browser will prompt the configured parameters and check it before writing into NVRAM. Press Restart to restart the gateway working with the new parameters and press Continue to setup other parameters. G.SHDSL.bis Bridge Modem 5210D User Manual V0.01... -
Page 41: Syslog
4. Specify a UDP port number to which the syslog server is listening. The default value is 514. Make sure this is not blocked from your firewall. Press Finish to finish the setup. The browser will prompt the configured parameters and check it G.SHDSL.bis Bridge Modem 5210D User Manual V0.01... -
Page 42: Time Sync
Synchronization with PC SNTP v4.0. Simple Network Time Protocol with Version 4 4.4.4.1 Synchronization with PC For synchronization with PC, select Sync with PC. The modem will synchronize the time with the connecting PC. G.SHDSL.bis Bridge Modem 5210D User Manual V0.01... -
Page 43: Sntp V4.0
Update Period: How many times the modem can resynchronize to time server. The unit is second. Press Finish to finish the setup. The browser will prompt the configured parameters and check it before writing into NVRAM. G.SHDSL.bis Bridge Modem 5210D User Manual V0.01... -
Page 44: Utility
CONFIG TOOL Load the factory default configuration, restore configuration and backup configuration UPGRADE Upgrade the firmware LOGOUT Logout the system RESTART Restart the modem 4.5.1 System Info Click System Info for review the information. G.SHDSL.bis Bridge Modem 5210D User Manual V0.01... -
Page 45: Syslog
SHDSL.bis modem support detailed logging via Syslog function. The syslog protocol allows devices to send event notification messages across an IP network to syslog servers that collect the event message. The modem can generate a syslog message and send it to a syslog server. G.SHDSL.bis Bridge Modem 5210D User Manual V0.01... -
Page 46: Config Tool
Press SYSLOG, it sends the syslog messages shown as follows: 4.5.3 Config Tool This configuration tool has three functions: load Factory Default, Restore Configuration, and Backup Configuration. Press CONFIG TOOL. G.SHDSL.bis Bridge Modem 5210D User Manual V0.01... -
Page 47: Load Factory Default
Select the Backup Configuration and then press Finish. Browse the place of backup file name or put the name. Then press OK. The modem will automatically backup the configuration. If you don’t put the file name, the system will use the default: config1.log G.SHDSL.bis Bridge Modem 5210D User Manual V0.01... -
Page 48: Upgrade
Press Upgrade in UTILITY. Select the firmware file name by click Browse on your PC or NB and press OK button to upgrade. The system will reboot automatically after finish the firmware upgrade operation. G.SHDSL.bis Bridge Modem 5210D User Manual V0.01... -
Page 49: Logout
To logout the modem, press LOGOUT in UTILITY. For logout system and close window, click the LOGOUT in UTILITY When click the Yes button, the modem will logout and browser window will be closed. G.SHDSL.bis Bridge Modem 5210D User Manual V0.01... -
Page 50: Restart
When the restart button been clicked, the modem will restarting and the browser session will be disconnected. This may appear as if your browser session is hung up. After the modem restarts, you may either click the browser’s reload button or close the browser and re-open it later. G.SHDSL.bis Bridge Modem 5210D User Manual V0.01... -
Page 51: Example
Click Bridge and CO Side to setup the modem and then click Next. Enter LAN Parameters IP: 192.168.0.1 Subnet Mask: 255.255.255.0 Gateway: 192.168.0.1 Host Name: SOHO Enter WAN1 Parameters VPI: 0 VCI: 32 G.SHDSL.bis Bridge Modem 5210D User Manual V0.01... -
Page 52: Cpe Side
Enter WAN1 Parameters VPI: 0 VCI: 32 Click LLC Click Next The screen will prompt the new configured parameters. Check the parameters and Click Restart The modem will reboot with the new setting. G.SHDSL.bis Bridge Modem 5210D User Manual V0.01... -
Page 53: Configuration Via Serial Console Or Telnet With Menu Driven Interface
VT100 terminal emulation and connecting to the management IP of modem. Type the command line on DOS mode: telnet 192.168.0.1 Note: The default IP address is 192.168.0.1. Wait for the login prompt appears. Input User and Password after login screen pop up: G.SHDSL.bis Bridge Modem 5210D User Manual V0.01... -
Page 54: Operation Interface
For example, to show the system information, just logon to the modem, move down the cursor by pressing key K twice and select “show” command by key L, you shall see a submenu and select “system” command in this submenu, then the system will show you the general information. G.SHDSL.bis Bridge Modem 5210D User Manual V0.01... -
Page 55: Window Structure
5.1.5 Menu Driven Interface Commands Before changing the configuration, familiarize yourself with the operations list in the following table. The operation list will be shown on the bottom field of the window. G.SHDSL.bis Bridge Modem 5210D User Manual V0.01... - Page 56 Move forward to submenu [TAB] To choose another parameters Ctrl + C To quit the configuring item Ctrl + D Disconnection Ctrl + U Hot-key switch to command line interface Ctrl + Q Display help menu G.SHDSL.bis Bridge Modem 5210D User Manual V0.01...
-
Page 57: Main Menu
The statistic status of WANs and LAN interface can be monitor by interface command. Show the STP status on all LANs and WANs clear Clear and rest all statistics data G.SHDSL.bis Bridge Modem 5210D User Manual V0.01... -
Page 58: Shdsl.bis
WAN7 192.168. 7. 1/255.255.255. 0 38 LLC Ethernet WAN8 192.168. 8. 1/255.255.255. 0 39 LLC Ethernet ------------------------------------------------------------------------ Show WAN status include IP address, Net Mask, VPI/VCI, encapsulation type, protocol on each WAN ports G.SHDSL.bis Bridge Modem 5210D User Manual V0.01... -
Page 59: Interface
Learning - While the port does not yet forward frames (packets) it does learn source addresses from frames received and adds them to the filtering database (switching database) G.SHDSL.bis Bridge Modem 5210D User Manual V0.01... -
Page 60: Show
From this screen, you can know more about the general information of this modem. 5.4.2 Configuration information Move cursor to “ >> “ to config and press enter. You can view all setting using table format. G.SHDSL.bis Bridge Modem 5210D User Manual V0.01... -
Page 61: Configuration With Script Format
If you want to exit the system without saving, use exit command to quit system. ------------------------------------------------------------------------ Command: exit <CR> Message: Please input the following information. Do you want to disconnect? (y/n): ------------------------------------------------------------------------ Press “y” to confirm the exit operation. G.SHDSL.bis Bridge Modem 5210D User Manual V0.01...
