Signal NVR 2708 User Manual

T series
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual

USER MANUAL

NVR 2708
NVR2716
- 1 -

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NVR 2708 and is the answer not in the manual?

Questions and answers

Summary of Contents for Signal NVR 2708

  • Page 1: User Manual

    USER MANUAL NVR 2708 NVR2716 - 1 -...
  • Page 2 Thank you for purchase our product. Please read this user manual carefully to ensure that you can use the device correctly and safely Important Safeguards and Warding: ◆ Do not place heavy objects on the NVR. ◆ Do not let any solid or liquid fall into or infiltrate the NVR. ◆...

  • Page 3: Table Of Contents

    CONTENT CONTENT .................................. 3 1 Open-package check and cable connections ....................4 1.1 Open-package check ............................. 4 1.2 Front panel ..............................4 1.3 Rear panel ..............................5 2 Basic operation ..............................5 2.1 Turn on ................................6 2.2 Turn off ................................. 6 2.3 System Login ..............................

  • Page 4: Open-Package Check And Cable Connections

    1 Open-package check and cable connections 1.1 Open-package check When you receive the NVR, please check first. First, please check whether there is any visible damage to the package appearance. The protective materials used for the package of the NVR can protect most accidental clashes during transportation. Then, please open the box and get rid off the plastic protective materials.

  • Page 5: Rear Panel

    press buttons 0~9 to input passwords and user IDs; during playback, press the following: : Increase reverse playback speed 1X, 2X, 4X : Press to freeze playback to one frame, then press again to advance frame-by-frame 7) : Press to start playback : Press to slow playback speed by 1/2, 1/4, 1/8 : Press to increase forward playback speed...

  • Page 6: Turn On

    2.1 Turn on Plug the power supply and turn on the power supply switch. Power supply indicator light shining indicates turning on the video recorder. After the startup you will hear a beep. The default setting of video output is multiple-window output mode. If the startup time is within the video setting time, the timing video recording function will start up automatically.

  • Page 7: Preview

    Picture 2.3 System Login Password protection: If the password is continuous wrong three times, the alarm will start. If the password is continuous wrong five times, the account will be locked. (Through reboot or after half an hour, the account will be unlocked automatically). For your system security, please modify your password after first login.

  • Page 8: Desktop Shortcut Menu

    Pic 2.4.1 Preview interface Channel name and status display,click Screen switch “channel” can pack up Full screen display on the next page turning,when choosing a non maximum number of channels,the operation can be carried out Note:It’s main stream’s resolution under single window,and it’s extra stream’s resolution under multi-screen.
  • Page 9 2.5.1 Main menu When you login, the system main menu is shown as below. Pic 2.5.1 Main menu 2.5.2 Playback There are two methods for you to play the video files in the hard disk 1.In the desktop shortcut menu 2.Main Menu>Record>playback Note: The hard disk which saves the video files must be set as read-write or read-only state.
  • Page 10 Pic 2.5.2.0 Video playback Playback control Operation hint Record mode Time interval choosing Switch by File searching Channel Date choosing time,file mode choosing Storage device File information Listed files Time searching choosing 【Listed files】Look up the listed files that accord with the searching criteria. 【File information】Look up the found file information.
  • Page 11 Special functions： ： ： ： Local zoom:When the system is in single-window full-screen playback mode, you can drag your mouse in the screen to select a section and then left click mouse to realize local zoom. You can right click mouse to exit.
  • Page 12 Pic 2.5.4 Alarm output 【Configuration】Alarm is on according to the configuration. 【Manual】Click the all button and the according channel is alarming no matter the channel in any state. 【Stop】 Click the stop button and the according channel stops alarming no matter the channel in any state.
  • Page 13 【Iris】Click button to adjust the iris of the camera. 【Hide】Current interface will be temporarily hidden after click it. 【Direction control】Control the PTZ rotation. 8 directions control is supportive.(4 directions in Front panel is supportive ) 【High speed PTZ】Full-screen show channel image. Left press mouse and control PTZ to rotate orientation.
  • Page 14 Value input blank Pic 2.5.5.2 PTZ control 2、 、 、 、 Tour Multiple preset points connected tour ,the PTZ run around on the line 1）Tour Settings Tour is connected by multiple preset points, setting procedure is as follows: Step1: In Picture 2.5.5.0, the Direction key will turn PTZ to designated location ,click Settings button to enter Picture 2.5.5.3.
  • Page 15 3、 、 、 、 Scan PTZ also can work on the preset scan line repeatedly. 。 1）Scan setup Setting steps: Step1: In Picture 2.5.5.0, click Setup button ，enter Picture 2.5.5.4； Step2: Click Scan button，the input proper value in the scan value blank; Step3:Click Start button, enter Picture2.5.5.0,here you can set the following items: Zoom,Focus,Aperture,Direction and so on.
  • Page 16 reverse direction to the right scan. When the left and right scan not in the same horizontal ,the PTZ will regard the end of horizontal line which connect to left scan as right scan,cycle rotate from left scan along the reverse direction to the right scan.
  • Page 17 【Direct Aux open】 choose auxiliary equipment, select Open or Close button, switch control； 【 Aux Num open 】 The operation of corresponding auxiliary switch according to PTZ agreement； 【Page Switch】In Picture 2.5.5.6，click Page Shift button enter the Picture 2.5.5.5 PTZ Main Menu , the menu itself can be control by the menu control buttons 2.5.6 Output Adjust Adjust TV output area parameters.

  • Page 18: Main Menu

    【logout】Quit the menu. Offer password next entrance. 【shut down】Quit the system. Turn off the power supply. When press the shut down button, there is schedule hint. After three seconds, the system is shut down. Cancel midway is of no effect. 【reboot】Quit the system.
  • Page 19 “detection recording” state is on. The video file type is “M”. Alarm: Trigger the external alarm signal in the set time section. When above alarm is set as opening recording, the “detection recording” state is on. The video file type is “A”.
  • Page 20 Picture 3.1.3 detect storage device 【Detect】Detect the storage connected with the NVR such as hard disk or universal disk. 【Backup】Click backup button and the dialog box is popped up. You can choose the backup file according to the type, channel and time. Picture 3.1.3.1 Backup Remove：...

  • Page 21: Alarm Function

    Alarm functions include: motion detect,video blind, video loss, alarm input and alarm output, abnormality. 3.2.1 Motion Detect When system detects the motion signal that reaches the set sensitivity, the motion detect alarm is on and the linkage function is turned on. Note: "Advanced" button is the same as right click.
  • Page 22 Pic 3.2.1.1 set the time section 【Interval】Only one alarm signal is turned on even there are several motion detect signals in the set interval. 【Alarm output】 Start the external equipment of corresponding linkage alarm when the motion detect alarm is turned on.
  • Page 23 Set method: refer to chapter 3.3.1. Motion detect. 3.2.3 Video Loss When the equipment can not obtain the channel video signal, the video loss alarm is turned on and the linkage function is turned on. Note:Both the NVR and the connected device need to enable this function ,then it can works.
  • Page 24 Pic 3.2.3 Video loss Set method: refer to chapter 3.3.1. Motion detect 3.2.4 Alarm input When the equipment obtains the external alarm signal, the alarm function is turned on. Note: "Advanced" button is the same as right click. Pic 3.2.4 Alarm input Set method: refer to chapter 3.3.1.

  • Page 25: System Setup

    Pic 3.2.6 Abnormal handing 【Event Type】 selecting abnormity you want to inspect 【Enable】 Select it to make sure abnormal function workable 【Show message】 Automatically alarm cue dialog box come out of the main screen 【Buzzer】 Device will have one long nosie “di” while alarm is happening 3.3 System setup Set the system parameters such as:General,Network, Net service,GUI display,PTZ configuration/RS485 ,RS232,Tour and digital。...
  • Page 26 【Date Separator】Choose list separator of the data format. 【Time Format】Choose time format: 24-hour or 12-hour. 【Language】Support 29 language at present:S- Chinese,T-Chinese,English,Farsi,Finnish,French, Greek,Hungarian, Italian, Japanese, German, polish, Portuguese, Russian, Spanish, Thai, Turkish, Vietnamese, Romania, Brazil,Indonesia, Swedish, Arabic, Bulgarian, Czech, Hebrew, etc. 【HDD full】Choose stop record: Stop recording when the hard disk is full.
  • Page 27 3.3.2 Network setup Pic 3.3.2 Network setup 【Net Card】You can choose cable network card or wireless network card. 【DHCP Enable】Obtain IP address automatically(not suggested) Note： ： ： ： DHCP server is pre-installed. 【IP address】Set the IP address. Default: 192.168.1.10. 【Subnet mask】Set the subnet mask code. Default: 255.255.255.0. 【Gateway】Set the default gateway.
  • Page 28 Pic 3.3.3.0 Netservice 【PPPoE setup】 Pic 3.3.3.1 PPPOE Enable：Reverse■ means choose,setting can become effective. Input the user name and password that ISP（Internet service provider）provides. After saving it reboot up your system. Then the NVR will build a network connection based on PPPoE. The IP address will change into dynamic IP address after above operation is well done.
  • Page 29 Enable：Reverse■mean choose，setting can become effective. Host computer IP:Input the IP address installed NTP server. Port:Default: 123. You can set the port according to NTP server. Time zone:London GMT+0 Berlin GMT +1 Cairo GMT +2 Moscow GMT +3 New Delhi GMT +5 Bangkok GMT +7 Hongkong Beijing GMT +8 Tokyo GMT +9 Sydney GMT +10 Hawaii GMT-10 Alaska GMT-9 Pacific time GMT-8 American mountain time GMT-7 American mid time...
  • Page 30 Pic 3.3.3.4 IP filter setup 【DDNS】 Pic 3.3.3.5 DDNS setup It is the abbreviation of dynamic domain name server. Local domain name：Provide the domain name registered by DDNS. User name： ： ： ： Provide the account registered by DDNS. Password： ： ： ： Provide the password registered by DDNS. When the DDNS is successfully configured and start, you can connect the domain name in the IE address column to visit.
  • Page 31 Pic 3.3.3.6 FTP setup 【Enable】Click Enable,then all settings will be available 【Server IP】 IP address for FTP server 【Port】 Domain Port of FTP,default 21 【User Name】User name of FTP 【Password】Password of user 【Anonymous】 ：enable anonymous,no need setting user name and password 【Max File Length】Max length for upload files at every packed,default 128M 【Dir Name】...
  • Page 32 【Enable】■ means it is chosen 【Sever IP】IP address of DDNS server 【Port】: Port No. of device, related DDNS server listen port 【User name】the user name that device can log in DDNS server 【Password】the password related to the user name. 【Refresh cycle】Time interval between device and DDNS when chynchronously. Note: Please set up server before using DDNS.
  • Page 33 Pic 3.3.3.9 Wireless setup 【Enable】Choose Enable to make all settings available 【Type】Dial type,default AUTO 【Wireless AP】3G access point 【Dial Number】3G Dial Number 【User Name】User name of 3G 【Password】Password of dial user 【IP Address】IP address,got from dial 【Mobile Monitor Setup】 To visit the device by mobile,please make a router mapping of this port and use mobile software to monitor and operate it by protocol.
  • Page 34 Pic 3.3.3.11 UPNP setup 【Enable】Choose Enable to make sure all UPNP settings available 【HTTP】Route will automatically distribute HTTP port for the device,when IE viewing,it need this port 【TCP】 Router will automatically distribute TCP port for the device,when monitoring via CMS,it need this port.
  • Page 35 Pic 3.3.3.14 cloud 3.3.4 GUI Display Configure the parameters of video output signal. In the local preview mode include:time display, channel title, record status, alarm status,deflick, transparency and region cover. - 35 -...
  • Page 36 Pic 3.3.4 GUI display 【Time Display】Display the system data and time in the surveillance window. 【Channel title】Display the system channel number in the surveillance window. 【Record Status】Don’t support. 【Alarm Status】Display the system alarm status in the surveillance window. 【Transparency】Choose the background image transparency. The range is 128~255. 【Resolution】set display resolution.
  • Page 37 【Data bits】including 5-8 options，default is 8； 【Stop bits】including 2 options, default is 1； 【Parity】Include odd check, even check, sign check, blank check. Default: void. 3.3.6 RS232 Pic 3.3.6 RS232 setup 【Serial Port Function】Common serial port is used to debug and update program or set up specific serial port.
  • Page 38 Pic 3.3.7 tour setup 【Interval】Set the tour switch interval time. The range is 5-120 seconds. 【Alarm tour】set the interval time to shift alarm tour, range is 5-120 seconds, choose return when alarm ends, when alarm link to tour, system will auto shift to six-view after alarm finished. Note：at preview mode, click upper right icon can turn on / off tour（...
  • Page 39 Pic 3.3.8.1 Single link page of digital channel Multi-linkage page of Digital channel Pic 3.3.8.2 digital channel interface 【Channel】select channel number. 【Enable】Open digital channel, tick enable, then can do related settings 【Time Synchronization】Tick it means the time of this channel and device is the same. 【Connection Mode】can be singe connect or multi-ink, multi-link modes can connect to several devices, device will be tour displayed one by one, tour interval can be set, no less then 10s;...
  • Page 40 Pic 3.3.8.3 remote channel configure page 【Configure Name】device is with default configure name, user can revise it if necessary； 【Device Type】3 types: IPC、DVR、HVR，user can choose as what you like, default is IPC； 【Protocol】Default is NETIP,can choose ONVIF. 【Remote channel】User can input remote channel title from the device that you want to connect remotely 【Stream】Default is main stream, do not support extra-stream at present；...
  • Page 41 Pic 3.3.8.4 the device list searched under remote channel setting Channel Status: Channel status is to show the status of all the digital channel When there is what existing, status Including Max Resolution, this Resolution, Connection Status. See as follow pictture: Pic 3.3.8.5 When a channel is added with device but it is not enable, you will see as below: - 41 -...
  • Page 42 Pic 3.3.8.6 Note: when under multi-screen,display extra stream’s resolution,when under single screen,display main stream’s resolution. when the current resolution is over the max resolution that the channel supported, then a red “X” will be shown on the preview image, for example: Under full digital channel mode, Max resolution of channel 3 is D1, if it was connected to a device with resolution over D1 ( such as 960H), you will see below pic: 3.3.8.7...

  • Page 43: Advanced

    3.4 Advanced Manage tools menu including: HDD Manage,Account,Online User, Output Adjust, Auto Maintain, Restore,Upgrade,Device Info,Import/Export. 3.4.1 HDD Manage Configure and manage the hard disk. The menu displays current hard disk information: hard disk number, input port, type, status and overall capability. The operation include: setup the write-read disk,snapshot,read-only disk, redundant disk,format disk,recover disk,partition.Choose the hard disk and click the right function button to execute.
  • Page 44 Pic 3.4.2.0 Account 【Modify User】Modify the existed user attribute. 【Modify Group】Modify the existed team attribute. 【Modify Password】Modify the user password. You can set 1-6 bit password. The blank ahead or behind the char string is invalid. The middle blank in the char string is valid. Note：...
  • Page 45 Pic 3.4.2.2 add user 【Add Group】Add a user group and set the purview. There are 33 different purviews: shut down the equipment, real time surveillance, playback, record setting, video backup and so on. Pic 3.4.2.3 add group 【Delete User】Delete the current user. Choose the user and click delete user button. 【Delete Group】Delete the current group.
  • Page 46 3.4.3 Online user To check the information of network user that connected with local device, also can tick the selected user to break up connection,（make √ at the box） ，then the user will be frozen after connection stopped, and will not log in until device reboot. Pic 3.4.3 online user 3.4.4 Output adjust Refer to chapter 2.5.7 .
  • Page 47 Pic 3.4.6 restore 3.4.7 Upgrade Pic 3.4.7 upgrade 【Upgrade】 】 】 】 choose USB interface. 【 【 【 【 Upgrade file】 】 】 】 choose the upgrade file. 3.4.8 Device Info Provide device interface info like audio in,alarm in/out to be conveniently used for user. Pic 3.4.8 device info 3.4.9 Import / Export Users can export the log info and the configure file from device to connected flash stick, and also can...

  • Page 48: Info

    import related configure file from flash stick to settings, which greatly bring convenience to the customers. Pic 3.4.9 import/export interface 3.5 Info Display the hard disk information, including HDD info, BPS, log,version info. 3.5.1 HDD info Display the hard disk state: hard disk type, overall capability, residual capability, the recording time and so on.
  • Page 49 3.5.2 BPS Display the code stream （Kb/S） and hard disk capability （MB/H） in real time. It displays as the wave sketch map. Pic 3.5.2 BPS 3.5.3 Log To search log information base on the set search mode. Log information include: system operation, configuration operation, data management, alarm affair, recording operation, account management, file management and so on.

  • Page 50: Appendix 1.Remote Controller Operation

    Pic 3.5.4 version info Appendix 1.Remote controller operation The remote control is the secondary input device For navigating the system’s interface. To use the remote control: 1.STANDBY:Press to turn standby mode ON/OFF. 2. LOGIN/LOCK: If "Security" has been enabled in the Setup menu, press to open the user password login screen.
  • Page 51 10. MENU: Opens the main menu. 11. EXIT: Close menu windows 12. EXTRA: For the future use. 13. Navigation/Enter: • : Move cursor in menus up; • : Move cursor in menus right; • : Move cursor in menus left; TIP: When using the remote •...
