UPA 200Mbps 4 ports Ethernet Switch Power
Strip
-
One Powerline port
-
Four
Ethernet ports
10/100Mbps
-
Four power outlets
Description
The PLS342P provides convenient powerline access
to office/family users by sharing a simple AC power
line network. Embedded In-Home AV(200Mbps)
interface enables you to connect 4 PC ethernet ports
to another PC's at other end of power line, and not
limited by the wall or layer that block RF wireless
communication. Built in 4 surge protection power
plugs for electric apparatus extension
(Patent # US 6,956,464 B2, Taiwan 216,848 )
Features
One Powerline port
Four 10/100Mbps Ethernet ports
Four Power outlets
Model type : US, EU, UK
High surge protect capability (1400 Joules)
10A Over Current / Circuit Short Protection
Page 1/2
Advertisement
Related Manuals for Abocom PLS342P
Summary of Contents for Abocom PLS342P
- Page 1 Ethernet ports 10/100Mbps Four power outlets Description The PLS342P provides convenient powerline access to office/family users by sharing a simple AC power line network. Embedded In-Home AV(200Mbps) interface enables you to connect 4 PC ethernet ports to another PC’s at other end of power line, and not limited by the wall or layer that block RF wireless communication.
- Page 2 Specification Main Chipset DS2 DSS9010+ DSS7800 + Realtek RTL8306 Standard support UPA DHS (200 Mbps) PLC, IEEE 802.3 & 802.3u. Interface One Powerline port, four power outlets, four 10/100Mbps Ethernet ports Power AC 100~240V/ 50~60Hz/ 10A Dimension (W x D x L) US type: 141.9mm (W) x 280mm(L) x 48.8mm(H), EU/UK type: 141.9mm (W) x 280mm(L) x 47.6mm(H).
