WALL AND
CEILING MOUNT
BRACKET
INSTALLATION
GUIDE
NETWORK EXTENDER
FOR BUSINESS

Advertisement

loading
Need help?

Need help?

Do you have a question about the Network_Extender_Business and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Verizon Wireless Network_Extender_Business

  • Page 1 WALL AND CEILING MOUNT BRACKET INSTALLATION GUIDE NETWORK EXTENDER FOR BUSINESS...
  • Page 2 CONTENTS BASICS Provides a description of what is in the installation box, an overview of your installation components, and a brief overview of the differences between the various installation and mounting options. INSTALLATIONS Describe the setup and installation procedures for all three available mounting options including: Floating Ceiling, Fixed Ceiling, and Wall Mounting.
  • Page 3 WARNING The Network Extender for Business should not be installed near fire or smoke sensors or detectors, or installed so as to block exit or other safety signs, fire or other emergency or warning lights, and the power cord cannot be tucked up into a floating ceiling.

  • Page 4: Bracket Features

    BASICS BRACKET FEATURES 1. RAIL BRACKET 2. POE SPLITTER ENCLOSURE 3.  NETWORK EXTENDER FOR BUSINESS (SCS-2U3100) 4. FIXED BUTTONS (TWO PER SIDE) VZW_BCNE8_NEBracket_Mounting_ISG_WB_100511_F8.indd 3 10/24/2011 12:54:17 PM...
  • Page 5 1. RAIL BRACKET 2. SPLITTER ENCLOSURE - TOP COVER 3. SPLITTER ENCLOSURE - BODY 4. ETHERNET PORT 5. LAN PORT (NETWORK) 6. POWER PORT VZW_BCNE8_NEBracket_Mounting_ISG_WB_100511_F8.indd 4 10/24/2011 12:54:26 PM...
  • Page 6 WHAT’S IN THE BOX 1. Confirm the box contents: (1) Enclosure ISG (Installation Guide) ≠ (1) Rail Bracket ≠ (1) POE Splitter Enclosure (Top Cover, ≠ and Housing) (9) Securing screws ≠ (2) Drywall screws ≠ (2) Drywall anchors ≠ 2. Remove them from the packaging and place them carefully nearby.
  • Page 7 NOTE: The POE Splitter is not included in this installation kit and must be purchased separately. For more information, visit: http://global.level1.com/Home-Products/ PoE-Powered-Device/PoE-Splitters/POS- 4000/1165.html http://cptechusa.com/cpt/index. php?option=com_content&view=article&i d=53&Itemid=58 VZW_BCNE8_NEBracket_Mounting_ISG_WB_100511_F8.indd 6 10/24/2011 12:54:28 PM...

  • Page 8: Installation

    INSTALLATION This section covers the installation procedures for all three available mounting scenarios: Floating Ceiling Bracket Mounting ≠ Fixed Ceiling Bracket Mounting ≠ Wall Bracket Mounting ≠ FLOATING CEILING BRACKET MOUNTING Confirm you have the following items: Rail Bracket ≠ Splitter - Top Cover ≠...
  • Page 9 In environments where there are ceiling tiles (Floating ceilings) being supported by rails, use the rail bracket to support the installation of the POE Splitter Enclosure. RAIL AND BRACKET INSTALLATION 1. Locate the rail bracket. 2. Remove the four silver bracket securing screws from the areas above and below the measurement tongs.
  • Page 10 4. With the bracket placed securely on the rail, pull the bracket measurement tongs outwards to close the bracket onto the rail. 5. Tighten the rail screws (shown above) to fasten the bracket to the rail. 6. Align the rail bracket to the POE Splitter’s top cover (orient the cable opening as shown).
  • Page 11 RAIL BRACKET using a 90� Rotation TOP COVER using a 90� Rotation 8. Insert and tighten the previously removed screws to fasten the bracket to the top cover. VZW_BCNE8_NEBracket_Mounting_ISG_WB_100511_F8.indd 10 10/24/2011 12:54:34 PM...
  • Page 12 SECURING SCREWS 9. Thread the LAN Ethernet cable (from your local network) through the cable opening on the top cover. VZW_BCNE8_NEBracket_Mounting_ISG_WB_100511_F8.indd 11 10/24/2011 12:54:36 PM...
  • Page 13 ENCLOSURE AND CABLE INSTALLATION 1. Connect all three cables to their corresponding port locations on the POE Splitter as shown. LAN CABLE (POE SWITCH - NETWORK) ETHERNET CABLE TO NETWORK EXTENDER POWER CABLE TO NETWORK EXTENDER POWER PORT NOTE: The LAN cable must originate from a PoE port on a PoE - compatible switch that can pass both power and data through the CAT cable.
  • Page 14 2. Thread the Ethernet cable and Power cable through the housing and out the bottom cable opening. 3. Insert the splitter component into the housing. VZW_BCNE8_NEBracket_Mounting_ISG_WB_100511_F8.indd 13 10/24/2011 12:54:51 PM...
  • Page 15 4. Assemble the POE Splitter to the top cover as shown. VZW_BCNE8_NEBracket_Mounting_ISG_WB_100511_F8.indd 14 10/24/2011 12:55:23 PM...
  • Page 16 5. Secure the top cover to the enclosure using the three securing screws. SECURING SCREWS (3) VZW_BCNE8_NEBracket_Mounting_ISG_WB_100511_F8.indd 15 10/24/2011 12:55:24 PM...
  • Page 17 6. Slide the Network Extender into the bottom of the POE Enclosure as shown. NETWORK EXTENDER FOR BUSINESS (SCS-2U3100) VZW_BCNE8_NEBracket_Mounting_ISG_WB_100511_F8.indd 16 10/24/2011 12:56:42 PM...
  • Page 18 7. Align the Fixed Buttons to their corresponding opening alongside the Network Extender. FIXED BUTTONS 8. Press each Fixed Button until they snap into their secured position. UNSECURED SECURED VZW_BCNE8_NEBracket_Mounting_ISG_WB_100511_F8.indd 17 10/24/2011 12:58:06 PM...
  • Page 19 9. Connect the Power and Ethernet cable connectors (previously threaded through the side opening) to their corresponding ports on the attached Network Extender. Ethernet Cable Connector Power Port Power cable Connector VZW_BCNE8_NEBracket_Mounting_ISG_WB_100511_F8.indd 18 10/24/2011 12:58:08 PM...
  • Page 20 10. Confirm the proper installation of both cables to the attached Network Extender. Power Cable Ethernet Cable VZW_BCNE8_NEBracket_Mounting_ISG_WB_100511_F8.indd 19 10/24/2011 12:58:22 PM...
  • Page 21 FIXED CEILING BRACKET MOUNTING Confirm you have the following items: Drywall screws (2) ≠ Drywall anchors (2) ≠ Splitter - Top Cover (1) ≠ POE Splitter (not included) ≠ Splitter - Enclosure (1) ≠ Securing screws (3) ≠ Cables: LAN, Ethernet, and Power ≠...
  • Page 22 3. Position the opening in the ceiling to match the opening on the top of the cover. 4. Locate and install the drywall anchors into the ceiling surface. 5. Align the screw holes between the drywall anchors and top cover. DRYWALL ANCHORS (2) DRYWALL SCREWS (2) NOTE: The drywall anchors are inserted after drilling of a fixed ceiling or drywall.
  • Page 23 ENCLOSURE AND CABLE INSTALLATION 1. Connect all three cables to their corresponding port locations on the POE Splitter as shown. LAN CABLE (POE SWITCH - NETWORK) ETHERNET CABLE TO NETWORK EXTENDER POWER CABLE TO NETWORK EXTENDER POWER PORT NOTE: The LAN cable must originate from a PoE port on a PoE - compatible switch that can pass both power and data through the CAT cable.
  • Page 24 2. Thread the Ethernet cable and Power cable through the housing and out the bottom cable opening. 3. Insert the splitter component into the housing. VZW_BCNE8_NEBracket_Mounting_ISG_WB_100511_F8.indd 23 10/24/2011 12:58:25 PM...
  • Page 25 4. Assemble the POE Splitter to the top cover as shown. VZW_BCNE8_NEBracket_Mounting_ISG_WB_100511_F8.indd 24 10/24/2011 12:58:43 PM...
  • Page 26 5. Secure the top cover to the enclosure using the three securing screws. SECURING SCREWS (3) VZW_BCNE8_NEBracket_Mounting_ISG_WB_100511_F8.indd 25 10/24/2011 12:58:44 PM...
  • Page 27 6. Slide the Network Extender into the bottom of the POE Enclosure as shown. NETWORK EXTENDER FOR BUSINESS (SCS-2U3100) VZW_BCNE8_NEBracket_Mounting_ISG_WB_100511_F8.indd 26 10/24/2011 12:58:45 PM...
  • Page 28 7. Align the Fixed Buttons to their corresponding opening alongside the Network Extender. FIXED BUTTONS 8. Press each Fixed Button until they snap into their secured position. UNSECURED SECURED VZW_BCNE8_NEBracket_Mounting_ISG_WB_100511_F8.indd 27 10/24/2011 12:58:46 PM...
  • Page 29 9. Connect the Power and Ethernet cable connectors (previously threaded through the side opening) to their corresponding ports on the attached Network Extender. Ethernet Cable Connector Power Port Power cable Connector VZW_BCNE8_NEBracket_Mounting_ISG_WB_100511_F8.indd 28 10/24/2011 12:58:46 PM...
  • Page 30 10. Confirm the proper installation of both cables to the attached Network Extender. Power Cable Ethernet Cable VZW_BCNE8_NEBracket_Mounting_ISG_WB_100511_F8.indd 29 10/24/2011 12:58:47 PM...

  • Page 31: Wall Bracket Mounting

    WALL BRACKET MOUNTING Confirm you have the following items: Drywall screws (2) ≠ Drywall anchors (2) ≠ Splitter - Top Cover (1) ≠ POE Splitter (not included) ≠ Splitter - Enclosure (1) ≠ Securing screws (3) ≠ Cables: LAN, Ethernet, and Power ≠...
  • Page 32 2. Thread the LAN Ethernet cable (from your local network) through the opening in the wall and into the cable opening on the top cover. 3. Locate and install the drywall anchors into the wall surface. 4. Align the screw holes between the drywall anchors and top cover.
  • Page 33 ENCLOSURE AND CABLE INSTALLATION 1. Connect all three cables to their corresponding port locations on the POE Splitter as shown. LAN CABLE (POE SWITCH - NETWORK) ETHERNET CABLE TO NETWORK EXTENDER POWER CABLE TO NETWORK EXTENDER POWER PORT NOTE: The LAN cable must originate from a PoE port on a PoE - compatible switch that can pass both power and data through the CAT cable.
  • Page 34 2. Thread the Ethernet cable and Power cable through the housing and out the bottom cable opening. 3. Insert the splitter component into the housing. VZW_BCNE8_NEBracket_Mounting_ISG_WB_100511_F8.indd 33 10/24/2011 12:58:50 PM...
  • Page 35 4. Assemble the POE Splitter to the top cover as shown. VZW_BCNE8_NEBracket_Mounting_ISG_WB_100511_F8.indd 34 10/24/2011 12:59:09 PM...
  • Page 36 5. Secure the top cover to the enclosure using the three securing screws. SECURING SCREWS (3) VZW_BCNE8_NEBracket_Mounting_ISG_WB_100511_F8.indd 35 10/24/2011 12:59:09 PM...
  • Page 37 6. Slide the Network Extender into the bottom of the POE Enclosure as shown. NETWORK EXTENDER FOR BUSINESS (SCS-2U3100) VZW_BCNE8_NEBracket_Mounting_ISG_WB_100511_F8.indd 36 10/24/2011 12:59:09 PM...
  • Page 38 7. Align the Fixed Buttons to their corresponding opening alongside the Network Extender. FIXED BUTTONS 8. Press each Fixed Button until they snap into their secured position. UNSECURED SECURED VZW_BCNE8_NEBracket_Mounting_ISG_WB_100511_F8.indd 37 10/24/2011 12:59:11 PM...
  • Page 39 9. Connect the Power and Ethernet cable connectors (previously threaded through the side opening) to their corresponding ports on the attached Network Extender. Ethernet Cable Connector Power Port Power cable Connector VZW_BCNE8_NEBracket_Mounting_ISG_WB_100511_F8.indd 38 10/24/2011 12:59:11 PM...
  • Page 40 10. Confirm the proper installation of both cables to the attached Network Extender. Power Cable Ethernet Cable VZW_BCNE8_NEBracket_Mounting_ISG_WB_100511_F8.indd 39 10/24/2011 12:59:11 PM...
  • Page 41 GPS CABLE INSTALLATION 1. Remove the GPS Extension Cable cover. 2. Install the connector to the available port. 3. Re-install the cover back onto the Network Extender. NOTE: For more detailed installation instructions, refer to the External GPS antenna section of the online User Manual. Extension Cable VZW_BCNE8_NEBracket_Mounting_ISG_WB_100511_F8.indd 40...
  • Page 42 NOTES VZW_BCNE8_NEBracket_Mounting_ISG_WB_100511_F8.indd 41 10/24/2011 12:59:35 PM...
