Summary of Contents for Tsunami Slider D400S

  • Page 3: Trademarks

    Preface Notice The company reserves the right to revise this publication or to change its contents without notice. Infor- mation contained herein is for reference only and does not constitute a commitment on the part of the man- ufacturer or any subsequent vendor. They assume no responsibility or liability for any errors or inaccuracies that may appear in this publication nor are they in anyway responsible for any loss or damage resulting from the use (or misuse) of this publication.

  • Page 4: Fcc Statement

    Preface FCC Statement (Federal Communications Commission) This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 5: Important Safety Instructions

    Preface IMPORTANT SAFETY INSTRUCTIONS When using your telephone equipment, basic safety precautions should always be followed to reduce the risk of fire, electric shock and injury to persons, including the following: Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.

  • Page 6: Instructions For Care And Operation

    Preface Instructions for Care and Operation The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions: Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged.
  • Page 7 Preface Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong magnetic fields. These can hinder proper performance and damage your data. Follow the proper working procedures for the computer. Shut the computer down properly and don’t forget to save your work.

  • Page 8: Power Safety

    Preface Power Safety The computer has specific power requirements: • Only use a power adapter approved for use with this computer. • Your AC adapter may be designed for international travel but it still requires a steady, uninterrupted power supply. If you are unsure of your local power specifi- Power Safety cations, consult your service representative or local power company.

  • Page 9: Battery Precautions

    Preface Battery Precautions • Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the com- puter. • Recharge the batteries using the notebook’s system. Incorrect recharging may make the battery explode. • Do not try to repair a battery pack. Refer any battery pack repair or replacement to your service representative or qualified service personnel.

  • Page 10: Cleaning

    Preface Cleaning Do not apply cleaner directly to the computer, use a soft clean cloth. Do not use volatile (petroleum distillates) or abrasive cleaners on any part of the computer. Servicing Do not attempt to service the computer yourself. Doing so may violate your warranty and expose you and the computer to electric shock.

  • Page 11: Travel Considerations

    Preface Travel Considerations Packing As you get ready for your trip, run through this list to make sure the system is ready to go: Check that the battery pack and any spares are fully charged. Power off the computer and peripherals. Close the display panel and make sure it’s latched.
  • Page 12 Preface On the Road In addition to the general safety and maintenance suggestions in this preface, and Chapter 8: Troubleshoot- ing, keep these points in mind: Hand-carry the notebook - For security, don’t let it out of your sight. In some areas, computer theft is very common.
  • Page 13 Preface Developing Good Work Habits Developing good work habits is important if you need to work in front of the computer for long periods of time. Improper work habits can result in discomfort or serious injury from repetitive strain to your hands, wrists or other joints.
  • Page 14 Preface Lighting Proper lighting and comfortable display viewing angle can reduce eye strain and muscle fatigue in your neck and shoulders. • Position the display to avoid glare or reflections from overhead lighting or outside sources of light. • Keep the display screen clean and set the brightness and contrast to levels that allow you to see the screen clearly.

  • Page 15: Table Of Contents

    Preface Contents PC Camera ............. 1-8 LCD Panel ............1-8 Notice ................ I Microphone ............ 1-8 Trademarks ............I LED Power & Communication Indicators ..1-8 FCC Statement ..........II LED Status Indicators ........1-8 Instructions for Care and Operation ....IV Hot-Key Buttons ..........
  • Page 16 Preface Rear View ...............1-17 Turning on the Computer ......... 2-4 Vent ..............1-17 LED Indicators ............2-5 DC-In Jack ............1-17 LED Status Indicators ........2-5 2 * USB 2.0 Ports .........1-18 LED Power & Communication Indicators ..2-6 External Monitor (CRT) Port .......1-18 Auto Mail Checker ...........
  • Page 17 Preface USB Printer ............2-23 Mobile CPU SpeedStep ....... 3-20 Install Instructions: ........2-23 Enabling Power Options ........3-21 Parallel Printer ..........2-24 Conserving Power (Individual Components) ... 3-22 Install Instructions: ........2-24 Turn off Monitor .......... 3-22 Turn off Hard Disk ........3-22 Advanced Controls ......3-1 Conserving Power (System) ......
  • Page 18 Preface Windows 2000 Professional ........4-6 Wireless LAN (WinXP) ........4-15 New Hardware Found .........4-6 Bluetooth (WinXP) .......... 4-15 Audio (Win2000) ..........4-7 Auto Mail (WinXP) ......... 4-15 Modem (Win2000) ..........4-7 BIOS Utilities .......5-1 LAN (Win2000) ..........4-7 Overview ..............5-1 Video (Win2000) ..........4-7 Important BIOS Settings ..........
  • Page 19 Preface Battery Removal Process ........6-3 Overview ..............8-1 Upgrading the Hard Disk Drive .......6-4 Basic Hints and Tips ..........8-2 Hard Disk Upgrade Process ........6-4 Backup and General Maintenance ......8-3 Upgrading the System Memory (RAM) ....6-6 Viruses ..............8-4 Memory Upgrade Process ........6-7 Upgrading and Adding New Hardware/Software ..
  • Page 20 Preface LCD Options ............A-2 Display ..............A-2 Storage Devices ........... A-3 Audio ..............A-3 Interface ............... A-4 PC Card (Model A computers only) ....A-4 Communication ........... A-4 Power Management ..........A-4 Power ..............A-5 Indicators ............. A-5 Environmental Spec ..........A-5 Physical Dimensions ...........

  • Page 21: Introduction

    Introduction Chapter 1: Introduction Overview Notes Check the light colored This manual refers to the hardware and essential software required to run your boxes with the mark notebook computer. Depending on how your system is configured, some or all above to find detailed of the features described may already be set up.

  • Page 22: Warning Boxes

    Introduction Warning Boxes No matter what your level please pay careful attention to the warning and safe- ty information indicated by the symbol. Also please note the safety and handling instructions as indicated in the Preface . Not Included Operating Systems (e.g. Windows 2000 Professional, Windows XP etc.) have their own manuals, as do applications (e.g.

  • Page 23: Quick Start Guide

    Introduction Quick Start Guide This guide assumes that you are already familiar with computers and can tell at a glance what and where all the key components are. If you are not that com- Peripheral Devices fortable with this type of device, then please refer to the following pages, Please note that pe- which give an overview of the system.

  • Page 24: System Map

    Introduction System Map Your computer has a lot of built-in features. Most of these are enabled by your operating system. Further explanations of the various subsystems are covered in the chapter or pages indicated. Getting to Know Your Computer The graphics on the following pages will help you to become familiar with the basic functions, and to learn the location of the various ports and components of your computer.
  • Page 25 Introduction Table 1 - 1 Feature Model A Model B Model Differences Designs Supported Design I & II Design I & II Mobile CPU Supported Design Types IEEE 1394 Port This manual refers to PCMCIA (PC Card) the two notebook de- signs pictured on this Infrared Transceiver page.

  • Page 26: Top View

    Introduction Top View Figure 1 - 2 Top View with LCD Panel Closed LCD Latches LED Power & Communication Indicators To open the LCD display: Place the computer on a stable surface. Move the LCD latches in the direction of the arrows to release the top cover.

  • Page 27: Top View With Lcd Panel Open

    Introduction Top View with LCD Panel Open Figure 1 - 3 Top View with LCD Panel Open Optional PC Camera Built-In Microphone LED Power & Communication Indicators LED Status Indicators Hot-Key buttons Close Cover Switch Power Button Keyboard 10. TouchPad and Buttons Top View 1 - 7...

  • Page 28: Pc Camera

    Introduction PC Camera If you have purchased the optional PC Camera, make sure to install the soft- ware application (see “PC Camera” on page 7 - 10). LCD Panel The computer comes with a 14.1" OR a 15.0" TFT (Liquid Crystal Display) screen, depending upon the configuration purchased.

  • Page 29: Hot-Key Buttons

    Introduction Hot-Key Buttons The three hot-keys allow you instant access to your default Internet browser, default e-mail program, and an application of your choice. To learn how to set the buttons, see “Hot-Keys” on page 2 - Close Cover Switch This switch acts as a sensor to tell when the LCD Panel is closed.

  • Page 30: Keyboard

    Introduction Keyboard The computer has a “Win Key” keyboard including a numeric keypad. It has the same features as a full-sized desktop keyboard and can easily be replaced Forced Off with a different language keyboard should you desire. If the system “hangs”, and the Ctrl + Alt + Del TouchPad &...

  • Page 31: Front View

    Introduction Front View Figure 1 - 4 Front View LCD Latches Mini-IEEE 1394 Model A Port S/PDIF Out Port Microphone-In Jack Headphone-Out Jack Infrared Transceiver Wireless Module Model B ON/OFF Switch Built-In Speakers Model B does not in- IEEE 1394 clude the IEEE 1394 port or Infrared Trans- The Mini-IEEE 1394 port only supports SELF POWERED IEEE 1394 devices.

  • Page 32: Mini-Ieee 1394 Port (Model A Only)

    Introduction Mini-IEEE 1394 Port (Model A only) This allows high-speed connection to various peripheral devices, e.g. external disk drives and digital cameras (see note above). S/PDIF Out Port This S/PDIF (Sony/Philips Digital Interface Format) Out Port allows you to connect your DVD-capable PC to a Dolby AC-3 compatible receiver for “5.1” or ‘dts’...

  • Page 33: Wireless Module On/Off Switch

    Introduction Wireless Module ON/OFF Switch If you have purchased the optional 802.11b Wireless LAN and/or Bluetooth module(s), you can use this switch to turn the module(s) ON or OFF. To en- able the module(s) you will need to install the drivers/software for it/them. You can use the key combination Fn + F12 to toggle through the options if you have two modules installed (see “Wireless LAN &...

  • Page 34: Left Side View

    Introduction Left Side View Figure 1 - 5 Model A Left Side View CD Device Bay USB 2.0 Port Model B Floppy Disk Drive PC Card Slot PC Card Slot Eject Button CD Device Bay A 5.25" CD-ROM drive, or DVD-ROM drive, or CD-RW, or Combination Model B does not in- CD-RW and DVD-ROM Drive (12.7mm height) is standard depending on the clude the Floppy Disk...

  • Page 35: Usb 2.0 Port

    Introduction USB 2.0 Port This USB 2.0 compatible port (USB 2.0 is fully USB 1.1 compliant) is for low-speed peripherals such as keyboards, mice or scanners, and for high- speed peripherals such as external HDDs, digital video cameras or high-speed scanners etc.

  • Page 36: Right Side View

    Introduction Right Side View Figure 1 - 6 Right Side View Security Lock Slot Security Lock Slot To prevent possible theft, a Kensington-type lock can be attached to this slot. Locks can be purchased at any computer store. 1 - 16 Right Side View...

  • Page 37: Rear View

    Introduction Rear View Figure 1 - 7 Rear View Vent DC-In Jack 8 9 10 2 * USB Ports External Monitor (CRT) Port Parallel Port Overheating Serial Port To prevent your com- S-Video-Out Port puter from overheating PS/2 Type Port make sure nothing...

  • Page 38: Usb 2.0 Ports

    Introduction 2 * USB 2.0 Ports These USB 2.0 compatible ports (USB 2.0 is fully USB 1.1 compliant) are for low-speed peripherals such as keyboards, mice or scanners, and for high- speed peripherals such as external HDDs, digital video cameras or high-speed scanners etc.

  • Page 39: S-Video-Out Port

    Introduction S-Video-Out Port Connect your television to your computer and view DVDs, VCDs or anything else your computer can display. You will need an S-Video cable to make the connection. Enable this port from the video driver controls (see “TV Display” on page 3 - 19).

  • Page 40: Bottom View

    Introduction Bottom View Figure 1 - 8 Bottom View Vent/Fan Outlets Battery Cover Hard Disk Cover Bluetooth Module The CPU is not a user Cover serviceable part. CPU & Memory Opening this compart- Socket Cover ment, or accessing the CPU in any way, may Note: The RAM and option- violate your warranty.

  • Page 41: Hard Disk Drive

    Introduction Hard Disk Drive The internal hard disk drive is used to store your data. See information on page 6 - 4 for information on upgrading/replacing your hard disk drive. Wireless LAN & Bluetooth Modules The Wireless LAN and Bluetooth modules Drive Warning may be enabled and...
  • Page 42 Introduction 1 - 22...

  • Page 43: Using The Computer

    Using The Computer Chapter 2: Using The Computer Overview To learn more about using your computer, please read this chapter. This chapter includes: • The Power Sources • Turning on the Computer • The LED Indicators • The Auto Mail Program •...

  • Page 44: The Power Sources

    Using The Computer The Power Sources The computer can be powered by either an AC adapter or a battery pack. Power Button as Standby or Hibernate AC Adapter Button Use only the AC adapter that comes with your computer. The wrong type of If you are using a fully AC adapter will damage the computer and its components.

  • Page 45: Recharging The Battery With The Ac Adapter

    Using The Computer Recharging the Battery with the AC Adapter The battery pack automatically recharges when the AC adapter is attached and plugged into an electrical outlet. If the computer is powered on, and in use, it Battery Removal will take several hours to fully recharge the battery. When the computer is We recommend that turned off but plugged into an electrical outlet, battery charge time is less.

  • Page 46: Turning On The Computer

    Using The Computer Turning on the Computer Now you are ready to begin using your computer. To turn it on simply press the power button on the front panel. Shutdown Note that you should When the computer is on, you can use the power button as a Standby/Hiber- always shut your com- nate/Shutdown hot-key button when it is pressed for less than 4 seconds puter down by choos-...

  • Page 47: Led Indicators

    Using The Computer LED Indicators There are two sets of LED indicators (LED Power & Communication Indi- cators and LED Status Indicators) on your computer that will display help- ful information about the current status of the computer. The LED Power & Communication Indicators are also visible when the top of your computer is closed.

  • Page 48: Led Power & Communication Indicators

    Using The Computer LED Power & Communication Indicators Icon Color Description Battery Problem Green The computer is on If the battery has a se- Blinking Green The computer is in standby mode rious problem contact Orange The battery is being charged your service represen- tative.

  • Page 49: Auto Mail Checker

    Using The Computer Auto Mail Checker After you have installed the driver for the Auto Mail program (see “What to Install” on page 4 - 2) you may then configure it to give you notification when you receive new mail. You must be online to receive this notification (note that this program only supports the POP3 protocol), and your default mail program does not need to be open.
  • Page 50 Using The Computer You may then configure the options for your mailserver, name, password, pro- gram and method(s) of notification. Note Check with your Inter- net Service Provider, network administrator or Mail Service provid- er for details on what to put on these pages.

  • Page 51: Special Group

    Using The Computer Special Group You may add the e-mail addresses of those you wish to assign to your special group here. The Mail LED will then blink fast when mail is received from members of this group, if LED notification is enabled in the control panel (Figure 2 - Figure 2 - 4 Special Group Setup...

  • Page 52: Hard Disk Drive

    Using The Computer Hard Disk Drive The hard disk drive is used to store your data in the notebook computer. The hard disk can be taken out to accommodate other 2.5" IDE hard disk drives Power Safety with a height of 9.5 mm. Before attempting to access any of the inter- The hard disk...

  • Page 53: Floppy Disk Drive (Fdd) - Model A Only

    Using The Computer Floppy Disk Drive (FDD) - Model A Only The computer (Model A only - see “Model Differences” on page 1 - 4) is equipped with a fixed 1.44 MB, 3.5" floppy disk drive module. By default it Media Warning is labeled “Drive A:”, and can be used as a boot device if properly set in the Don’t try to remove a...

  • Page 54: Cd/Dvd Device

    Using The Computer CD/DVD Device There is a bay for either a CD-ROM, or DVD-ROM, or CD-RW, or Combi- nation CD-RW and DVD-ROM drive, depending on the model you pur- Sound Volume Adjustment chased. The CD Device is usually labeled “Drive D:”, and may be used as a boot device if properly set in the BIOS (“Boot Menu”...

  • Page 55: Handling Cds Or Dvds

    Using The Computer Handling CDs or DVDs Proper handling of your CDs/DVDs will prevent them from being damaged. Please follow the advice below to make sure that the data stored on your CD- CD Emergency Eject ROMs/DVD-ROMs can be accessed. If you need to manually Remember to: eject a CD (e.g.

  • Page 56: Dvd Regional Codes

    Using The Computer DVD Regional Codes DVD region detection is device dependent, not OS-dependent. You can select your module’s region code 5 times. The fifth selection is permanent. This can- not be altered even if you change your operating system or you use the module in another computer.

  • Page 57: Changing Dvd Regional Codes

    Using The Computer Changing DVD Regional Codes Go to the Control Panel in WindowsXP/Windows 2000 and double-click Sys- tem > Hardware (tab), click Device Manager, then click the + next to DVD/ CD-ROM drives. Double-click on the DVD-ROM device to bring up the Properties menu, and select the DVD Region (tab) to bring up the control panel as seen in “DVD Regional Codes (Windows XP)”...

  • Page 58: Pc Card Slot - Model A Only

    Using The Computer PC Card Slot - Model A Only The computer (Model A only - see “Model Differences” on page 1 - 4) is equipped with a PCMCIA 3.3V/5V slot for one type II PC Card. Make sure you install the driver for the PC Card (see “What to Install”...

  • Page 59: Hot-Keys

    Using The Computer Hot-Keys The computer has two sets of Hot-Keys, three Hot-Key buttons on the com- puter, and the function key combinations on the keyboard. Non-Default E-Mail and Browser Programs Hot-Key Buttons It is possible to config- These keys access the internet, e-mail or a user-defined application with one ure both the e-mail and quick button press.
  • Page 60 Using The Computer To configure and specify an application for Application 1 (the default Hot- Key setting is for the CD Player/Media Player application), you must follow the instructions below. Application.exe Right click the Hot-Key driver icon on the taskbar and the following You will need to locate menu will appear.

  • Page 61: Function Keys And Numeric Keypad

    Using The Computer Function Keys and Numeric Keypad Function Keys Other Keyboards On the bottom-left of the keyboard is the Fn key or Function key. The Fn key If your keyboard is allows you to change operational features instantly. To use the functions press damaged or you just and hold the Fn key, then press the appropriate function key (F3 - F9 etc.) lo- want...

  • Page 62: Numeric Keypad

    Using The Computer Numeric Keypad The keyboard has an embedded numerical keypad for easy numeric data input. The numeric keys are highlighted by a yellow typeface. Special Characters Some software appli- Activate the Number Lock feature by pressing and holding the Fn key, then cations allow press the NumLk key at the top right of the keyboard.

  • Page 63: Touchpad And Buttons/Mouse

    Using The Computer TouchPad and Buttons/Mouse The TouchPad is a device for pointing (controlling input positioning) on the computer’s display screen by sensing finger movement, and downward pres- Mouse Driver sure. It is an alternative to the mouse, however, you can also add a mouse to If you are using an ex- your computer either through the PS/2 interface, or one of the USB ports.
  • Page 64 Using The Computer Easy Launcher You can add programs to the menu from the Others Mouse control panel. Click on Settings for Easy Launcher to get the settings options. Click the New button and browse to any pro- grams you wish to add to the menu.

  • Page 65: Adding A Printer

    Using The Computer Adding a Printer The most commonly used peripheral is a printer. The following conventions will help you to add a printer, however it is always best to refer to the printer manual for specific instructions and configuration options. USB Printer Most new printers have a USB interface connection.

  • Page 66: Parallel Printer

    Using The Computer Parallel Printer This is still the most common type of printer. Install Instructions: Set up the printer according to its instructions (unpacking, paper tray, toner/ ink cartridge etc.). Attach the parallel cable to the printer. Connect the printer’s parallel cable to the parallel port at the rear of the computer (see “Rear View”...

  • Page 67: Advanced Controls

    Advanced Controls Chapter 3: Advanced Controls Overview This chapter covers: Drivers • Advanced video controls • Power and battery management features You are unable to use most advanced con- trols until the neces- sary drivers utilities are properly in- stalled. If your system hasn’t been properly configured (your serv- ice representative may...

  • Page 68: Advanced Video Controls

    Advanced Controls Advanced Video Controls This section is about making adjustments for the LCD, and switching display devices. Protecting the LCD Do not allow any for- Opening the LCD eign objects (i.e. paper As you open the lid, adjust it so you can look at the screen straight on, without or plastic) to get be- tween the lid/LCD and any glare.

  • Page 69: Video Driver Controls

    Advanced Controls Video Driver Controls The video interface lets you change the screen resolution and color output to whatever is most comfortable/efficient for you. This is a matter of hardware, Screen Resolution/ Screen Area Note video memory and the driver for your operating system. The driver interface shows the available options (see “LCD Options”...

  • Page 70: Display Properties

    Advanced Controls Display Properties Figure 3 - 2 Advanced Display Properties When the Display Properties control panel is open, click the Advanced (button) to bring up the options tabs. Clicking through these tabs allows you to make any video adjustments you require. 3 - 4 Video Driver Controls...

  • Page 71: Sis Utility Tray/Manager

    Advanced Controls SiS Utility Tray/Manager With the video driver installed additional control panels are available. To get to the control panels do the following: Click Start, point to Settings and click Control Panel (if you are in Cate- gory View choose Appearance and Themes). Double-click Display (icon).
  • Page 72 Advanced Controls You may make changes to the Driver Mode Settings, Video Settings, Gamma Correction Settings, and view General Information, by clicking the appropri- ate tab and adjusting the setting. Some screen examples are shown below. Figure 3 - 4 SiS Utility Tray/ Manager Setting Tabs 3 - 6 Video Driver Controls...

  • Page 73: Video Memory

    Advanced Controls Video Memory The computer does not have dedicated video memory. It makes use of a por- tion of system memory as video memory. By default, the video memory is set Video Memory Usage to 32MB, and you may change the setting in the BIOS (see “Embedded Share 3D Applications, such Memory (Advanced Menu>Advanced Chipset Control)”...

  • Page 74: Display Devices

    Advanced Controls Display Devices Besides the built-in LCD, you can also use an external VGA monitor (CRT) or TV as your display device. A VGA monitor connects to the external mon- VGA Monitor and TV Display Setting itor (CRT) port a TV to the S-Video-Out port , as illustrated in Figure...

  • Page 75: Display Options

    Advanced Controls Display Options Multiple Display Modes & DVD Display Mode Windows XP Windows 2000 Playback In Mirror mode DVD Single movies must be dis- played in the primary Mirror device - “Switch- ing/Enabling Dis- Multimonitor Not Available plays (Driver)” page 3 - Single - Either the LCD, VGA monitor or TV as a display device.

  • Page 76: Switching/Enabling Displays (Keyboard)

    Advanced Controls Switching/Enabling Displays (Keyboard) To simply switch display devices, or enable other devices, with the Fn + Display (F7) toggle do the following: 1. Plug the VGA monitor or TV into the appropriate port. 2. Press and hold the Fn key, while simultaneously pressing the F7 key. 3.

  • Page 77: Switching/Enabling Displays (Driver)

    Advanced Controls Switching/Enabling Displays (Driver) With the video driver installed (see “What to Install” on page 4 - 2), you can use its built-in controls to switch between the displays as follows: 1. Plug the VGA monitor or TV into the appropriate port. 2.

  • Page 78: Mirror Mode

    Advanced Controls Mirror Mode In this mode the display of the two devices is the same. Mirror mode simply shows an exact copy of the Primary display desktop on the Secondary dis- Switching Display play(s). This mode will drive multiple displays with the same content. Use this Modes feature to display the screen through a projector for a presentation etc.

  • Page 79: Multimonitor

    Advanced Controls Multimonitor This mode allows a desktop to span the displays to act as a large work area, thus creating a lot more screen area for display. Figure 3 - 8 Multimonitor Setting Setting Multimonitor Mode 1. Follow the instructions in “Switching/Enabling Displays (Driver)”...
  • Page 80 Advanced Controls Configuring Multimonitor Displays You can reconfigure the displays in Multimonitor mode from the Display Properties > Settings control panel (see “Multimonitor Setting” on page 3 - 13). Make sure you have checked the “Extend my Windows desktop onto this monitor.”...

  • Page 81: Adjusting Monitor Settings

    Advanced Controls Adjusting Monitor Settings If you prefer to use a VGA monitor (CRT) you may change its vertical refresh Vertical Refresh Rate rate, color depth and resolution. The vertical refresh rate In Multimonitor Mode of your CRT is impor- Follow the instructions in “Setting Multimonitor Mode”...
  • Page 82 Advanced Controls You may also adjust the refresh rate from the Display Properties control panel after Multimonitor mode has been enabled: Double-click on the VGA monitor icon (in the example below it is the icon as the VGA monitor is set for Display_2). Click the Monitor tab, then select the refresh rate.
  • Page 83 Advanced Controls In Mirror or Single Mode To change the refresh rate in Single or Mirror mode you will need to do the following: Setting Changes Follow the instructions in “Switching/Enabling Displays (Driver)” on Some setting changes page 3 - may require you to re- Choose the Mirror or Single option from the Driver mode drop box.
  • Page 84 Advanced Controls You can also adjust the refresh rate from the Display Properties control panel (click Advanced button and choose the Monitor tab): Once the VGA monitor is confirmed as the Primary device, close the Dis- play Properties control panel. Open the Display Properties >...

  • Page 85: Tv Display

    Advanced Controls TV Display To display desktop images on a TV display, connect the TV to your com- VGA Monitor and TV puter by using an S-Video cable from the TV to the S-Video-Out port at Display Setting the rear of the computer. Follow the instructions in “Switching/Enabling Displays (Driver)”...

  • Page 86: Power Management Features

    Advanced Controls Power Management Features To conserve power, especially when using the battery, your notebook comput- er uses the ACPI power management system. Power management conserves OS Note power by controlling individual components of the computer (the monitor and Power management hard disk drive) or the whole system.

  • Page 87: Enabling Power Options

    Advanced Controls Enabling Power Options Power Options are enabled through the control panel in your Windows sys- tem (Power Options). With other operating systems you may have power management available, so check your documentation. Figure 3 - 15 Power Options Control Panel You may conserve power through individual components or throughout the whole system.

  • Page 88: Conserving Power (Individual Components)

    Advanced Controls Conserving Power (Individual Components) Turn off Monitor Resuming Operation To conserve power, you can set the monitor to turn off after a specified time. system resume from Monitor Turn off Hard Disk or Hard Disk Standby by pressing a key on The computer's hard disk motor will be turned off if the hard disk drive has the keyboard.

  • Page 89: Conserving Power (System)

    Advanced Controls Conserving Power (System) With this function you can stop the notebook’s operation and restart where you left off. This system features Standby and Hibernate sleep mode levels (Hibernate mode will need to be enabled by clicking the option in the Hiber- nate tab in the Power Options control panel - Figure 3 - 17 on page 3-24).

  • Page 90: Standby

    Advanced Controls Standby Standby saves the least amount of power, but takes the shortest time to return to full operation. During Standby the hard disk is turned off, and the CPU is System Resume made to idle at its slowest speed. All open applications are retained in memo- system ry.

  • Page 91: Configuring The Power Button

    Advanced Controls Configuring the Power Button The power button may be set to send the computer in to either Standby or Hi- bernate mode (Figure 3 - 18). In Standby mode, the LED will flash Sleep Button green, and in Hibernate mode the LED will be off. If you are in a power sav- ing mode set to save power through individual components (e.g.

  • Page 92: Battery Information

    Advanced Controls Battery Information Please follow these simple guidelines to get the best use out of your battery. Caution New Battery Danger of explosion if Always completely discharge, then fully charge, a new battery before using it battery is incorrectly (see “Battery FAQ”...

  • Page 93: Battery Faq

    Advanced Controls Battery FAQ How do I completely discharge the battery? Use the computer with battery power until it shuts down due to a low battery. Conserving Battery Don’t turn off the computer by yourself even when you see a message that in- Power dicates the battery is critically low, just let the computer use up all of the bat- To conserve battery...

  • Page 94: Configuring The Infrared Settings For Fir

    Advanced Controls Configuring the Infrared Settings for FIR You will need to change the settings for the infrared device in the BIOS (see “I/O Device Configuration (Advanced Menu)” on page 5 - 11) to enable the Infrared Communication FIR setting support. The infrared transceiv- To configure your computer for Fast Infrared (FIR) communication follow er operates on a “Line...

  • Page 95: Drivers & Utilities

    Drivers & Utilities Chapter 4: Drivers & Utilities Overview This chapter deals with installing the drivers and utilities essential to the operation or improvement Assumption of some of the computer’s subsystems. The system takes advantage of some newer hardware compo- We assume that you will install all drivers and utilities nents for which the latest versions of most available from the built-in CD device and it is assigned to “Drive...

  • Page 96: What To Install

    Drivers & Utilities What to Install The Device Drivers & Utilities + User’s Manual CD-ROM contains the drivers and utilities neces- Wireless Module ON/OFF Switch sary for the proper operation of the computer. While installing the drivers make sure that the Table 4 - 1 on page 4-5 lists what you need to in- Wireless Module ON/OFF switch is turned OFF,...

  • Page 97: Authorized Driver Message

    Drivers & Utilities Authorized Driver Message If you receive a message telling you that the driver you are installing is not authorized (Digital Signa- ture Not Found), just click Yes or Continue Any- Navigate (Browse...) to D: way to ignore the message and continue the You will notice that many of the instructions for driver installation procedure.

  • Page 98: Updating/Reinstalling Individual Drivers

    Drivers & Utilities Updating/Reinstalling Individual If the driver is not listed in the Add/Remove Pro- grams item: Drivers If you wish to update/reinstall individual drivers it 1. Click Start (menu), point to Settings and click may be necessary to uninstall the original driver. Control Panel.
  • Page 99 Drivers & Utilities Feature Windows 2000 Windows XP Audio page 4 - 7 page 4 - 12 Modem page 4 - 7 page 4 - 12 Network (LAN) page 4 - 7 page 4 - 12 Video page 4 - 7 page 4 - 12 Install Windows XP Service Pack 1, after USB 2.0...

  • Page 100: Windows 2000 Professional

    Drivers & Utilities Windows 2000 Professional This section covers driver and utility installation in- structions for Windows 2000 Professional. New Hardware Found Windows 2000 Service Pack 3 If you see the message “New Hardware Found” (Found New Hardware Wizard) during the Make sure that you install Windows 2000 Service Pack 3 after installing all the drivers.

  • Page 101: Audio (Win2000)

    Drivers & Utilities Audio (Win2000) LAN (Win2000) 1. Click Start (menu) > Run ... 1. Click Start (menu) > Run ... 2. Navigate (Browse...) to 2. Navigate (Browse... to D:\Drivers\Audio\Setup.exe and click OK > D:\Drivers\lan\Setup.exe and click OK. Next. 3. To continue click Next. 3.

  • Page 102: Usb 2.0 (Win2000)

    Drivers & Utilities USB 2.0 (Win2000) PC Card/PCMCIA (Win2000) 1. Click Start (menu) > Run ... Driver installation required for Model A computers 2. Navigate (Browse...) to only. D:\Drivers\Usb2.0\USB20.exe (or 1. Click Start (menu), point to Settings and click D:\Drivers\Usb2.0\win2000\USB20.exe) and Control Panel.

  • Page 103: Pc Camera (Win2000)

    Drivers & Utilities PC Camera (Win2000) TouchPad (Win2000) See install procedure in “PC Camera Driver In- 1. Click Start (menu), point to Settings and click Control Panel. Double-click System (icon) stallation (Win2000)” on page 7 - and then click Hardware (tab) > Device Man- ager (button).

  • Page 104: Wireless Lan (Win2000)

    Drivers & Utilities Wireless LAN (Win2000) Auto Mail (Win2000) See install procedure in “Wireless LAN Driver In- 1. Click Start (menu) > Run ... 2. Navigate (Browse...) to stallation (Win2000)” on page 7 - D:\Drivers\AutoMail\SETUP.EXE and click Bluetooth (Win2000) 3. To continue click Next > Next. See install procedure in “Bluetooth Driver Instal- 4.

  • Page 105: Windows Xp

    Drivers & Utilities Windows XP This section covers driver and utility installation in- structions for Windows XP. New Hardware Found Windows XP Service Pack 1 If you see the message “New Hardware Found” Make sure that you install Windows XP Service (Found New Hardware Wizard) for the Univer- Pack 1 after installing all the drivers (if your Win- dows XP version includes Service Pack 1 you can...

  • Page 106: Audio (Winxp)

    Drivers & Utilities Audio (WinXP) LAN (WinXP) 1. Click Start (menu) > Run ... 1. Click Start (menu) > Run ... 2. Navigate (Browse...) to 2. Navigate (Browse...) to D:\Drivers\Audio\Setup.exe and click OK > D:\Drivers\lan\Setup.exe and click OK. Next. 3. To continue click Next. 3.

  • Page 107: Usb 2.0 (Winxp)

    Drivers & Utilities USB 2.0 (WinXP) 3. Click the Hardware (tab), then click Device Manager (button). 4. Click “+” next to PCMCIA Adapters (if its sub-items are not shown). 5. Double-click Generic Cardbus Controller Install Windows XP Service Pack 1 and click Driver (tab).

  • Page 108: Hot-Key (Winxp)

    Drivers & Utilities Hot-Key (WinXP) 4. Click “+” next to Mice and other pointing devices (if its sub-items are not shown). 1. Click Start (menu) > Run ... 5. Double-click PS/2 Compatible Mouse and 2. Navigate (Browse...) to click Driver (tab). D:\Drivers\Hotkey\Setup.exe and click OK.

  • Page 109: Wireless Lan (Winxp)

    Drivers & Utilities Wireless LAN (WinXP) Auto Mail (WinXP) See install procedure in “Wireless LAN Driver In- 1. Click Start (menu) > Run ... 2. Navigate (Browse...) to stallation (WinXP)” on page 7 - D:\Drivers\AutoMail\SETUP.EXE and click Bluetooth (WinXP) 3. To continue click Next > Next. See install procedure in “Bluetooth Driver Instal- 4.
  • Page 110 Drivers & Utilities 4 - 16...

  • Page 111: Bios Utilities

    BIOS Utilities Chapter 5: BIOS Utilities Overview BIOS Settings Warning This chapter gives a brief introduction to the computer’s built-in software: Incorrect settings can cause your system to Diagnostics: The POST (Power-On Self Test) malfunction. To correct mistakes, return Configuration: The Setup utility Setup and restore the If your computer has never been set up, or you are making important changes Setup Defaults with...

  • Page 112: Important Bios Settings

    BIOS Utilities Important BIOS Settings Generally speaking you should not have to adjust any of the BIOS settings, as they will already be set for your computer. However the following is a quick reference to the most important settings you may need to change at some point.

  • Page 113: The Power-On Self Test (Post)

    BIOS Utilities The Power-On Self Test (POST) Each time you turn on the computer, the system takes a few seconds to con- duct a POST, including a quick test of the on-board RAM (memory). POST Screen 1.BIOS information As the POST proceeds, the computer will tell you if there is anything wrong. 2.CPU type If there is a problem that prevents the system from booting, it will display a 3.Memory status...

  • Page 114: Failing The Post

    BIOS Utilities Failing the POST Errors can be detected during the POST. There are two categories, “fatal” and “non-fatal”. QuickBoot Mode choose Fatal Errors QuickBoot Mode (not These stop the boot process and usually indicate there is something seriously available for all mod- wrong with your system.

  • Page 115: The Setup Program

    BIOS Utilities The Setup Program The Phoenix Setup program tells the system how to configure itself and man- age basic features and subsystems (e.g. port configuration). Entering Setup To enter Setup, turn on the computer and press F2 during the POST. The prompt (“Press F2 to Enter Setup”) seen in Figure 5 - 1 is usually present...

  • Page 116: Setup Screens

    BIOS Utilities Setup Screens The following pages contain additional advice on portions of the Setup. Setup Menus Along the top of the screen is a menu bar with five (5) menu headings. When Setup menus you select a heading, a new screen appears. Scroll through the features listed shown in this section on each screen to make changes to Setup.

  • Page 117: Main Menu

    BIOS Utilities Main Menu Figure 5 - 2 Main Menu PhoenixBIOS Setup Utility Main Main Advanced Security Boot Exit Item Specific Help System Time: [22:11:05] System Date: [11/26/2002] <Tab>, <Shift Tab>, or Legacy Diskette A: [1.44 MB 3½"] <Enter> selects field. Primary Master [TOSHIBA MK3018GAP-(PM)] Secondary Master...
  • Page 118 BIOS Utilities Primary Master (Main Menu) Pressing Enter under opens the sub-menu to show the configuration of the HDD that fits into the computer’s HDD bay. These items are configured au- Switching Hard Disks tomatically for you. Every time you install a Secondary Master (Main Menu) different hard disk in the computer, it will be...

  • Page 119: Advanced Menu

    BIOS Utilities Advanced Menu Figure 5 - 3 Advanced Menu PhoenixBIOS Setup Utility Main Advanced Advanced Security Boot Exit Item Specific Help Setup Warning Setting itmes on this menu to incorrect values may cause your system to malfunction. Select the operating system installed Installed O/S: [Win2000/XP]...
  • Page 120 BIOS Utilities Embedded Share Memory (Advanced Menu>Advanced Chipset Control) This item tells the computer how much system memory (RAM) can be shared to become available as video memory. By default, the video memory is set to 32MB. The more system memory used as video memory, the less is available as system memory (e.g.
  • Page 121 BIOS Utilities Embedded Modem Device/Audio Device/1394 Device (Advanced Menu >Advanced Chipset Control) These items allow you to disable these devices, should you need to do so. I/O Device Configuration (Advanced Menu) The sub-menus under this item include options to configure the Serial port A (Serial Mouse), Serial port B (Infrared) and Parallel (Printer) port.
  • Page 122 BIOS Utilities USB Host Controller (Advanced Menu) This item allows you to enable or disable support for USB hardware. Reset Configuration Data (Advanced Menu) This item is set to No as default. You can change the setting to Yes if you have installed a new add-on which has reconfigured the system, resulting in such a serious system conflict that the operating system is unable to boot.

  • Page 123: Security Menu

    BIOS Utilities Security Menu Figure 5 - 4 Security Menu PhoenixBIOS Setup Utility Security Main Advanced Security Boot Exit Item Specific Help Supervisor Password Is: Clear Supervisor Password Set Supervisor Password [E E nter] controls access to the setup utility. Fixed disk boot sector: [Normal] Password on boot:...
  • Page 124 BIOS Utilities Set Supervisor Password: (Security Menu) Set a password for access to the Setup utility (this will not affect access to the computer OS, only the Setup utility). Password Warning Fixed disk boot sector: (Security Menu) If you choose to set a Choose Write Protect to protect the area of the hard disk containing informa- boot password, NEV- ER forget your pass-...

  • Page 125: Boot Menu

    BIOS Utilities Boot Menu Figure 5 - 5 Boot Menu PhoenixBIOS Setup Utility Boot Main Advanced Security Boot Exit Item Specific Help Removable Devices Keys used to view or CD-ROM Drive configure devices: Hard Drive <Enter> expands or collapses devices with Network Boot a + or - Model Differences...
  • Page 126 BIOS Utilities Boot devices usually are hard drives, floppy drives (Model A only - see “Model Differences” on page 1 - 4), CD-ROMs and LANs (Local Area Net- works). When you specify a device as a boot device on the Boot Menu, it requires the availability of an operating system on that device.

  • Page 127: Configuring The Network Boot Protocol

    BIOS Utilities Configuring the Network Boot Protocol The system supports booting from FDD, HDD, CD or LAN (network). To boot from a network, set Network Boot as the first item in the boot order. Fol- Enabling Network low the full instructions in the sidebar to configure the network boot protocol. Boot Go to the Boot Menu.

  • Page 128: Exit Menu

    BIOS Utilities Exit Menu Figure 5 - 7 Exit Menu PhoenixBIOS Setup Utility Exit Main Advanced Security Boot Exit Item Specific Help Exit Saving Changes Exit Discarding Changes Exit System Setup and Load Setup Defaults save your changes to CMOS. Discard Changes Save Changes Help...

  • Page 129: Upgrading The Computer

    Upgrading The Computer Chapter 6: Upgrading The Computer Overview This chapter contains information on upgrading the computer. Follow the steps outlined to make the desired upgrades. If you have any trouble or prob- Warranty Warning lems you can contact your service representative for further help. Before you Please check with your begin you will need: service representative...

  • Page 130: When Not To Upgrade

    Upgrading The Computer When Not to Upgrade These procedures involve opening the system’s case, adding and sometimes replacing parts. Power Safety Warning You should not perform any of these upgrades if: Before you undertake any upgrade proce- • Your system is still under warranty or a service contract dures, make sure that •...

  • Page 131: Removing The Battery

    Upgrading The Computer Removing the Battery If you are confident in undertaking upgrade procedures yourself, for safety reasons it is best to remove the battery. Under normal circumstances we rec- Warranty Warning ommend that you do not remove the battery. Please check with your Battery Removal Process service representative...

  • Page 132: Upgrading The Hard Disk Drive

    Upgrading The Computer Upgrading the Hard Disk Drive The hard disk drive can be taken out to accommodate other 2.5" IDE hard disk drives with a height of 9.5mm (h) (see “Storage Devices” on page A - 3). Fol- HDD System low your operating system’s installation instructions, and install all necessary Warning drivers and utilities as outlined in...
  • Page 133 Upgrading The Computer Carefully disconnect the hard disk cable from the rear of the hard disk assembly, and pay careful attention to which end of the cable connects to the hard disk (see sidebar). Remove screws from the hard disk assembly. HDD Cable Take the HDD out of the case, and pay careful attention to the orientation of The hard disk cable...

  • Page 134: Upgrading The System Memory (Ram)

    Upgrading The Computer Upgrading the System Memory (RAM) The computer has two memory sockets for 200 pin Small Outline Dual In-line (SO-DIMM) type memory modules: Desktop CPU’s • Support DDR SDRAM SODIMM (2.5V) - DDR 200/ DDR 266 Mobile CPU’s •...

  • Page 135: Memory Upgrade Process

    Upgrading The Computer Memory Upgrade Process Turn the computer off, and turn it over. Remove screws from the memory socket cover Carefully lift up the memory socket cover (a fan cable is still attached to the mainboard and there is no need to disconnect it) and set it on the computer. Remove any currently installed module(s), if it/they need to be upgraded or Figure 6 - 4 replaced.
  • Page 136 Upgrading The Computer Figure 6 - Gently pull the two release latches ( & on the sides of the memory socket toward the sides of the computer. Contact Warning Be careful not to touch the metal pins on the module’s connecting edge.
  • Page 137 Upgrading The Computer The module’s pin alignment will allow it to only fit one way. Make sure the module is seated as far into the slot as it will go. DO NOT FORCE the module; it should fit without much pressure. Figure 6 - 6 Memory Sockets One &...

  • Page 138: Upgrading The Cd Device

    Upgrading The Computer Upgrading the CD Device The easy changeable CD device may be upgraded or changed. CD Device Upgrade Process Turn the computer off, and turn it over. Remove screws from the memory socket cover Carefully lift up the memory socket cover (a fan cable is still attached to the mainboard and there is no need to disconnect it) and set it on the computer.
  • Page 139 Upgrading The Computer Use a screwdriver to carefully push the CD device assembly out of the computer at point Figure 6 - 8 CD Device Removal Insert the new device and carefully slide it into the computer (the device only fits one way).

  • Page 140: Upgrading The Processor

    Upgrading The Computer Upgrading the Processor If you want to upgrade your computer by replacing the existing processor with a faster/new one you will need to contact your customer service representa- Warranty tive. We recommend that you do not do this yourself, since if it is done incor- The CPU is not a user rectly you may damage the processor or mainboard.

  • Page 141: Optional Modules

    Optional Modules Chapter 7: Optional Modules Overview This chapter contains the information on the various optional modules which may come with your computer, depending on the configuration pur- chased. If you are unsure please contact your service representative. The chapter includes information on the following: •...

  • Page 142: Wireless Lan & Bluetooth Modules

    Optional Modules Wireless LAN & Bluetooth Modules If your purchase includes the optional 802.11b Wireless LAN module and/or Bluetooth module, make sure you install the supplied device driver(s) for it/ Communication Conflict them as indicated in the following pages (only install the drivers for the op- tional modules you have purchased).

  • Page 143: Wireless Lan Driver Installation (Win2000)

    Optional Modules Wireless LAN Driver Installation (Win2000) 1. Turn the Wireless Module ON/OFF switch ON. 2. If you have two wireless modules, you may need to use the key combina- Network Protocols tion Fn + F12 to enable the Wireless LAN module (the Mail LED indi- cator will be green - see “LED Power &...

  • Page 144: Wireless Lan Driver Installation (Winxp)

    Optional Modules Wireless LAN Driver Installation (WinXP) 1. Turn the Wireless Module ON/OFF switch ON. 2. If you have two wireless modules, you may need to use the key combina- tion Fn + F12 to enable the Wireless LAN module (the Mail LED indi- cator will be green - see “LED Power &...

  • Page 145: Bluetooth Driver Installation (Win2000)

    Optional Modules Bluetooth Driver Installation (Win2000) 1. Turn the Wireless Module ON/OFF switch ON. 2. If you have two wireless modules, you may need to use the key combina- tion Fn + F12 to enable the Bluetooth module (the Mail LED indicator will be orange - see “LED Power &...

  • Page 146: Bluetooth Driver Audio Setup (Win2000)

    Optional Modules Bluetooth Driver Audio Setup (Win2000) After installing the Bluetooth driver in Windows 2000 you may no longer hear any sound, nor see the Volume icon in the taskbar. If this is the case then fol- low this procedure: Go to the Sounds &...

  • Page 147: Bluetooth Driver Installation (Winxp)

    Optional Modules Bluetooth Driver Installation (WinXP) 1. Turn the Wireless Module ON/OFF switch ON. 2. If you have two wireless modules, you may need to use the key combina- tion Fn + F12 to enable the Bluetooth module (the Mail LED indicator will be orange - see “LED Power &...

  • Page 148: Control Panel Options (Bluetooth)

    Optional Modules Control Panel Options (Bluetooth) You may need to change some control panel options after installing the Blue- tooth driver: Audio Go to the Start menu and point to Settings and click Control Panel, then double-click the Sounds & Audio Devices/Sounds & Multimedia icon (Category View >...
  • Page 149 Optional Modules FAX (Win2000) Go to the Start menu and point to Settings and click Control Panel, then double-click the Fax icon. Click Advanced Options (tab) and click the Open Fax Service Management Console (button). Click Devices in the Tree window on the left. The fax devices will be displayed in the right window, with the device with the highest priority displayed at the top.

  • Page 150: Pc Camera

    Optional Modules PC Camera If you have purchased the optional PC Camera you will need to install the de- vice driver for it as indicated in the following pages (only install the drivers for the optional modules you have purchased). After installing the driver you can run the application software by going to the PC Camera 301P item in the Start >...

  • Page 151: Pc Camera Driver Installation (Win2000)

    Optional Modules PC Camera Driver Installation (Win2000) 1. Insert the PC Camera CD-ROM into the CD Drive. 2. Click Start (menu) > Run ... 3. Navigate (Browse...) to D:\Default setting_60Hz\Setup.exe and click 4. Click Next (click Yes if asked if you want to continue at any time). 5.

  • Page 152: Pc Camera Driver Installation (Winxp)

    Optional Modules PC Camera Driver Installation (WinXP) 1. Insert the PC Camera CD-ROM into the CD Drive. 2. Click Start (menu) > Run ... 3. Navigate (Browse...) to D:\Default setting_60Hz\Setup.exe and click 4. Click Next ( click Continue Anyway if asked if you want to continue at any time).

  • Page 153: Audio Setup

    Optional Modules Audio Setup If you wish to capture video & audio with your camera, it is necessary to setup the audio recording options in Windows. To do this in Windows XP (for Win- Windows 2000 Audio dows 2000 see sidebar): Setup Go to the Start menu and point to Settings and click Control Panel, then Go to the Start menu...
  • Page 154 Optional Modules Windows 2000 Audio Setup (continued) Make sure the Select (check box) in the Mi- crophone section is checked, and boost the volume as high as it will go. Close the windows. Figure 7 - 1 Audio Setup (Windows XP) 7 - 14 PC Camera...

  • Page 155: Amcap

    Optional Modules AMCAP AMCAP is a video viewer useful for general purpose video viewing and test- ing, and can capture video files to .avi format. Pre-Allocating File To capture video: Space Run the AMCAP program from the Start > Programs menu (it is recom- You may pre-allocate mended that you set the capture file before the capture process - see Set the file size for the cap-...
  • Page 156 Optional Modules Eliminating Screen Flicker If you find that the video screen in the AMCAP program is flickering, you can try to adjust the option from the Video Capture Filter options. Run the AMCAP program from the Start > Programs menu. Go to Options and scroll down to select “Video Capture Filter...”.

  • Page 157: Troubleshooting

    Troubleshooting Chapter 8: Troubleshooting Overview Should you have any problems with your computer, before consulting your service representative, you may want to try to solve the problem yourself. This chapter lists some common problems and their possible solutions. This can’t anticipate every problem, but you should check here before you panic. If you don’t find the answer in these pages, make sure you have followed the instructions carefully and observed the safety precautions in the preface.

  • Page 158: Basic Hints And Tips

    Troubleshooting Basic Hints and Tips Many of the following may seem obvious but they are often the solution to a problem when your computer appears not to be working. • Power - Is the computer actually plugged into a working electrical outlet? If plugged into a power strip, make sure it is actually working.

  • Page 159: Backup And General Maintenance

    Troubleshooting Backup and General Maintenance • Always backup your important data, and keep copies of your OS and programs safe, but close to hand. Don’t forget to note the serial numbers if you are storing them out of their original cases, e.g.

  • Page 160: Viruses

    Troubleshooting Viruses • Install an Anti-Virus program and keep the definitions file (the file which tells your program which viruses to look for) up to date. New computer viruses are discovered daily, and some of them may seriously harm your computer and cause you to lose data. Anti-Virus programs are commercially available and the definitions file updates are usually downloadable directly from the internet.

  • Page 161: Upgrading And Adding New Hardware/Software

    Troubleshooting Upgrading and Adding New Hardware/Software • Do not be tempted to make changes to your Windows Registry unless you are very sure of what you are doing, otherwise you will risk severely damaging your system. • Don’t open your computer or undertake any repair or upgrade work if you are not comfortable with what you are doing.
  • Page 162 Troubleshooting • Thoroughly check any recent changes you made to your system as these changes may affect one or more system components, or software programs. If possible, go back and undo the change you just made and see if the problem still occurs. •...

  • Page 163: Power

    Troubleshooting Power Problem Possible Cause - Solution You turned on the power Battery missing / incorrectly installed. Check the battery bay, make sure the battery is but it doesn’t work. present and seated properly (the design of the battery only allows it to go in one way). Make sure there’s nothing interfering with the battery contacts.
  • Page 164 Troubleshooting Problem Possible Cause - Solution A beeping sound is heard The battery power is nearly used up. Connect the AC adapter to your computer. and the low-battery indicator is on. A beep isn’t heard when The battery power is nearly used up and the volume control may be turned down. Adjust the low-battery indicator the volume control and connect the computer with the AC adapter.

  • Page 165: Display

    Troubleshooting Display Problem Possible Cause - Solution Nothing appears on The screen saver is activated. Press any key or touch the TouchPad. screen. The system is in a power saving mode. Toggle the sleep/resume key combination, Fn + F4 (see “Function Keys and Numeric Keypad”...
  • Page 166 Troubleshooting Problem Possible Cause - Solution The screen is flickering, The vertical refresh rate is insufficient on your external monitor. Avoid using the or the images aren’t Simultaneous display mode. Use LCD only or CRT only. Switch to a lower resolution and/ clear.

  • Page 167: Hard Disk & Boot Password

    Troubleshooting Hard Disk & Boot Password Problem Possible Cause - Solution The computer takes Data saved on the hard disk drive may be lost or damaged. Operate the scan disk or disk longer during Startup. defragmenter to check for any lost or damaged data. The computer is waking up from the Hibernate mode.

  • Page 168: Floppy Disk Drive

    Troubleshooting Floppy Disk Drive Problem Possible Cause - Solution The floppy disk drive will The floppy disk is not formatted. Format the disk (you may do this by right-clicking the disk not write data to disk. icon in My Computer in Windows and choosing Format from the menu). Bear in mind that this will erase all data contained on the floppy disk.

  • Page 169: Audio

    Troubleshooting Audio Problem Possible Cause - Solution The sound cannot be The volume might be set too low. Check the volume control in the Volume Control Panel heard or the volume is in the Windows taskbar, or use the key combination Fn + F5 and F6 (see “Function Keys very low.

  • Page 170: Cd Device

    Troubleshooting CD Device Problem Possible Cause - Solution The compact disc cannot The compact disc is dirty. Clean it with a CD-ROM cleaner kit. be read. The compact disc tray The compact disc is not correctly placed in the tray. Gently try to remove the disc using the will not open when there eject hole (see “Loading Discs”...

  • Page 171: Pc Card

    Troubleshooting PC Card Problem Possible Cause - Solution The system cannot The PC Card is not inserted into the socket or inserted incorrectly. Remove the card and recognize the PC Card. re-insert it aligning the PC Card with the slot. Push the card in until it locks into place. The PC Card or card driver is not compatible with the computer.

  • Page 172: Keyboard And Mouse

    Troubleshooting Keyboard and Mouse Problem Possible Cause - Solution Unwelcome numbers If the LED is lit, then Number Lock is turned ON. Press and release the Fn + NumLk appear when typing. key combination. I have installed a new You have not installed the driver to enable any extra functions. Make sure you read the external keyboard or documentation which comes with any new external device, and make sure you install the mouse but cannot use all...

  • Page 173: Printer

    Troubleshooting Printer Problem Possible Cause - Solution The printer cannot be The printer is not turned on, is not correctly connected to the computer, or has an internal added to the system or problem. Make sure the printer is on. Check all connections and cables and then try to will not work.

  • Page 174: Operation

    Troubleshooting Operation Problem Possible Cause - Solution The system freezes or The system’s power saving features have timed-out. Use the AC adapter, press the sleep the screen goes dark. (Fn + F4) key combination, or press the power button if no LEDs are lit. A software conflict made the system “crash”.

  • Page 175: Wireless Lan & Bluetooth Modules

    Troubleshooting Wireless LAN & Bluetooth Modules Problem Possible Cause - Solution The Wireless LAN or The ON/OFF switch has not been switched ON. Make sure you have set the ON/OFF Bluetooth module cannot switch to ON in order to enable the module (see “Wireless LAN &...

  • Page 176: Driver Installation

    Troubleshooting Driver Installation Problem Possible Cause - Solution There is a problem You have enabled Windows XP Multi Language Options. Make sure that you do not installing the Audio enable any Multi Language Options when installing the drivers in Windows XP. drivers in Windows XP.

  • Page 177: Appendix A. Specifications

    Appendix A. Specifications Processor • Intel Mobile Pentium 4 Processor - (478-pin) Micro FCPGA package (Model A computers • Intel Pentium 4 Processor - (478-pin) FC-PGA2 only) package µ 0.13) 0.13 Micron Process Technology, 512KB µ 0.13) 0.13 Micron Process Technology, 512KB L2 Cache &...

  • Page 178: Security

    Security BIOS • Security (Kensington® Type) Lock • One 512KB Flash ROM • BIOS Password • Phoenix BIOS Memory LCD Options For Desktop CPU’s • 14.1" XGA TFT (1024*768) • 15.0" XGA TFT (1024*768) • Two 200-pin DDR SODIMM sockets, support- •...

  • Page 179: Storage Devices

    Storage Devices Audio • 3.5" 3-mode Floppy Disk Drive (Model A com- • AC'97 2.1 compliant interface puters only) • 3D stereo enhanced sound system • Compatible with Sound-Blaster PRO™ • Easy changeable 2.5" 9.5 mm (h) Hard Disk • S/PDIF Digital output (5.1 CH) for DVD content Drive and stereo audio Supports Master mode IDE...

  • Page 180: Interface

    Interface PC Card (Model A computers only) • Built-in TouchPad (scrolling key functionality • One type II PCMCIA 3.3V/5V socket supporting integrated) CardBus • Three USB 2.0 ports Communication • One Mini-IEEE 1394 port (Model A computers only) • Wireless Infrared transfer IrDA 1.1 compliant, •...

  • Page 181: Power

    Power Physical Dimensions • Full range AC adapter • 329 (w) x 275 (d) x 36.5 (h) mm AC-Input 100~240V, 50~60Hz Weight DC Output 20V, 4.5A (90w) • 3.0 kg w/o battery (Model A computers) • Supports one removable Smart Li-Ion battery •...
  • Page 182 A - 6...

Table of Contents
