Summary of Contents for NETWORKSOUND Mamba
- Page 1 NETWORKSOUND HDTV Control Audio Data Video Intercom 5.1/7.1 Surround MediaNet Mamba Product Manual Copyright NetworkSound, Inc 2003-2008...
- Page 2 Mamba Digital Snake Manual Thank You for purchasing Mamba Digital Snake System. We hope this product manual covers setup, operation and maintenance of Mamba Digital Snake System as well as answer to any of your technical questions. Index: 1. Mamba Digital Snake Features 2.
- Page 3 Mamba Digital Snake Manual NetworkSound digital snake use our patent pending MediaNet protocol to deliver high quality synchronized audio over a standard CAT-5/6 cable. MediaNet features include synchronous uncompressed audio delivery, built in CAT-5/6 cable redundancy, and latency less than 200 microsecond (I2S to I2S) over 450 feet / 140 meter CAT-5/6 cable. Our digital audio snakes offer added flexibility by supporting multiple configurations, including point to point, split and daisy chain.
- Page 4 Mamba units. The Sync LED indicates that the Mamba units are in sync. If there is a problem, the Sync LED would either blink or OFF. In such case, power on reset to all units should resolve the...
- Page 5 RS232 :- Connect any RS232 terminal or device in to this port. The RS232 is pass thru, which means data sent from one Mamba unit e.g stage box will be available on other unit e.g FoH unit. The RS232 is set to 19200 bps, 8 data bits, no stop bits and no flow control. The RS232 is bi-directional so you can send and receive data on each side simultaneously.
- Page 6 Splitter: The Mamba LLS (Line Level Splitter) system is comprised of one “Stage” unit , one “FoH” unit and one “Monitor Mix” unit. The split system is available in 16X8X8, 32X16X16 , 48X24X24X24 and 64X32X32 configuration. For example, a 32X16X16 configuration allows you to split 32 inputs at the stage to FoH and Mon mix and able to receive 16 return channels from FoH and Mon Mix units.
- Page 7 From the back side of the micpre, connect a DB25 - TRS breakout cable (for PR8E) or DB25 - XLR F (for EP84) from the outputs (channels 1-8) to Mamba stage box inputs. The 8 channel DB25 breakout cable is ideal for each micpre box to Inputs on Mamba stage box.
-
Page 8: Front View
Mamba Pre Digital Snake Manual PR8E Micpre Technical Specifications PR8E - Multichannel Microphone Preamplifier The new PR8-E multi-channel mic/line preamp is the vanguard of the 'next-generation' in the SMPRO range. Using the latest components available and redesigned from the ground up, the PR8-E's carefully structured single circuit board design results is an exceptionally low noise pre-amp boasting a very high gain structure. - Page 9 Mamba Pre Digital Snake Manual EP84 Micpre Technical Specifications EP84 - Multichannel Microphone Preamplifier The EP84 is the latest multi-channel microphone preamplifier from SM Pro Audio. Packed with quality features and connectivity options, this sturdy 2RU rack-mountable unit is designed to provide studio users with 8 channels of pristine microphone preamplification.
- Page 10 The RS232 feature in Mamba Digital Snake is a pass thru communication. This means, any device that supports RS232 can plug in on one side of the Mamba Digital snake (e.g FoH) and communicate to other side of snake (e.g Stage). The information sent by the FoH side will be available on the Stage Box RS232 port.
- Page 11 Mamba Digital Snake Technical Specification Analog Output: Analog Input: Maximum output level = +22 dBu Maximum input level = +22 dBu SNR = 114.6 dB SNR=101 dB THD+N (1kHz @ -1dBFS) =0.0043% THD+N (1kHz @ -1dBFS) = 0.0026% Operating Temperature: Latency: -0°...
- Page 12 > If still no power to Mamba system, you can check the external fuse on the power connector on the Mamba. Make sure that you remove the power cord and disconnect any cables to the Mamba system.
- Page 13 If a defect is discovered, first write or call [408 434 9393] NetworkSound, Inc. to obtain a Return Authorization number. No service will be performed on any product returned without prior authorization.
-
Page 14: Safety Instructions
Do not insert any sharp or foreign object to heat dissipation cutout on the side. There are no serviceable parts on the Mamba Digital Snake System. Please call NetworkSound for any problems or service requests.
