Earth Stove ES2100 Installation And Operation Instructions Manual

Earth Stove ES2100 Installation And Operation Instructions Manual

Free-standing epa certified wood-burning stove

Advertisement

THE ONE AND ONLY
Free-Standing
EPA Certified
Wood-Burning Stove
P/N 507108-01, Rev. NC, 08/2012
A French manual is available upon
request. Order P/N 506223-52.
Ce manuel d'installation est disponible en
francais, simplement en faire la demande.
Numéro de la pièce 506223-52.
Save These Instructions
For Future Reference
Report # 100854192PRT-001

Installation and Operation

ES2100
MODEL
• Hot! Do not touch! The glass and surfaces of this appli-
ance will be hot during operation and will retain heat
for a while after shutting off the appliance. Severe
burns may result.
• Carefully supervise children in the same room as
appliance.
Instructions
WARNINGS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ES2100 and is the answer not in the manual?

Questions and answers

Summary of Contents for Earth Stove ES2100

  • Page 1: Installation And Operation

    A French manual is available upon request. Order P/N 506223-52. Ce manuel d’installation est disponible en francais, simplement en faire la demande. Numéro de la pièce 506223-52. ES2100 MODEL Save These Instructions For Future Reference WARNINGS • Hot! Do not touch! The glass and surfaces of this appli- ance will be hot during operation and will retain heat for a while after shutting off the appliance.
  • Page 2: Table Of Contents

    Paint Curing ................. 15 Burn-In Period ................15 Thank you for selecting an Earth Stove™ as the answer to your home Operating Hints ................15 supplemental heating needs. Door Operation ................15 Starting and Maintaining a Fire ............
  • Page 3: Important Safety Information

    IMPORTANT SAFETY AND WARNING ing season to check for soot and creosote accumulations. Any accumulations over 1/8” thick should be removed by INFORMATION a professional chimney sweep. Do not attempt to burn out heavy creosote accumulations with a hot fire. If large ac- cumulations are occurring, review your burning procedures.
  • Page 4: Testing Information

    TESTING INFORMATION SELECTING THE PROPER VENTING SYSTEM This manual describes the installation and operation of these non-catalytic The appliance is merely one component of a larger system. The other wood heaters. These heaters meet the U.S. Environmental Protection equally important component is the venting system. This is necessary for Agency’s emissions limits for wood heaters sold on or after July 1, 1990.
  • Page 5: Negative Pressure Warning

    NEGATIVE PRESSURE WARNING Chimney Height Requirements The chimney must extend 3’ (.92m) above the level of roof penetration This appliance is not designed to be operated in a negative pressure. and a minimum of 2’ (.61m) higher than any roof surface within 10’ (3m) In very airtight homes with large kitchen exhaust fans, furnace cold air (see Figure 1).
  • Page 6: Clearances To Combustibles

    CLEARANCES TO COMBUSTIBLES CHIMNEY AND CONNECTOR Minimum 6" diameter, minimum 24 MSG black steel connector pipe with WARNING: BE ABSOLUTELY SURE THE DISTANCE BETWEEN THE UL103HT listed factory-built chimney suitable for use with solid fuels HEATER AND THE SURFACE OF ANY COMBUSTIBLE CONSTRUC- or masonry chimney.
  • Page 7: Installation Clearances

    INSTALLATION CLEARANCES - REFER TO FIGURES 2, 3 AND 4 Parallel Installation Corner Installation Parallel Installation Combustible Wall Combustible Wall Stove 6” Ø Flue Floor Collar Floor Protection Protection Stove Stove Floor Protection Top View Canada Top View Side View See note 8 Figure 2 Figure 4...
  • Page 8: Specifications

    Approved for residential and manufactured home installations. • Optional Kits Available: Blower The ES2100 woodstove is safety listed with Outside Air Kit the following agency: Square-foot heating capacities and burn times are approximations only. • Intertek, Tested to UL 1482, ULC S627...
  • Page 9: Typical Installation Figures

    TYPICAL INSTALLATIONS Single Wall Pipe Using 6” Diameter Single Wall Connector Pipe INSTALL VENTING SYSTEM PER VENT MANUFACTURERS INSTRUCTIONS! Chimney Termination Storm Collar Roof Flashing Ceiling Support Assembly Slip Adaptor Single wall stove pipe must not pass through attics, closets, walls or ceilings.
  • Page 10: Chimney Installation

    CHIMNEY INSTALLATION Double Wall Pipe • Install chimney as per manufacturer’s instructions. Some brands of Using 6” Diameter Type L-Vent Connector Pipe pipe may require removal of the spacer ring in the flue collar. Manufactured (Mobile) Home Installation Shown • All horizontal runs of pipe should be as short as possible and are INSTALL VENTING SYSTEM PER VENT MANUFACTURERS required by NFPA No.
  • Page 11: Chimney - Wall Pass-Through Requirements

    Chimney Connector Systems and Clearances System A from Combustible Walls for Residential Heat- Minimum chimney clearance to brick and combustibles 2 in. (51mm) ing Appliances (NFPA 211) - Refer to Figure 9 Minimum clearance 12 in. (305mm) System A. Minimum 3.5 in. (90 mm) thick brick masonry wall framed of brick into combustible wall with a minimum of 12 in.
  • Page 12: Outside Combustion Air Kit Installation

    OUTSIDE COMBUSTION AIR KIT INSTALLATION Outside Air Kits Order: 1 ea. P/N UZIAD Outside Air Coupler Kit (connects outside air ducting, UZI, to stove) 1 ea. P/N UZI Outside Air Ducting Kit (includes 4” insulated flex x 10’ long) Outside Air Coupler 1 ea.
  • Page 13: Brick Installation

    BRICK INSTALLATION CAUTION: Wear gloves during brick installation in case of sharp edges inside the stove. Measure bricks before installing, as per list of dimensions in Figure 15. 1. Install the brick as shown in Figure 15. 2. The baffle boards are pre-installed. Ensure that they have not moved during shipping.
  • Page 14: Post Installation Checks

    FOR MOBILE HOME INSTALLS: POST INSTALLATION CHECKS Be sure the stove is properly grounded Check that all chimney pipe joints are secured and installed according to the Be sure the stove is properly securely manufacturers instruction. fastened to the floor If used, make sure the outside air kit is Be sure the outside air vent is free of properly installed and unobstructed.
  • Page 15: Paint Curing

    Spray can touch-ups should be done only components provided by the manufacturer as replace- with a high temperature stove paint (cat. no. H8159), available from all Earth Stove™ dealers. ment parts. OPERATING HINTS 1. Burn only dry, well-seasoned cord wood. In some states it is illegal to burn wet wood or anything other than clean, dry wood products.
  • Page 16: Starting And Maintaining A Fire

    STARTING AND MAINTAINING A FIRE 3. Place a small amount of crumpled paper in the front of the firebox and cover it with a few pieces of kindling. 4. Light the paper and allow sufficient time for the kindling to become fully engulfed in flames.
  • Page 17: Fuel

    FUEL 5. Once kindling is burning well, larger pieces of wood may be added, then the door should be fully closed if there was the need to keep it slightly open during start up. This appliance is designed and engineered to burn, dry, well-seasoned wood only.
  • Page 18: Getting The Most Out Of Your Stove

    GETTING THE MOST OUT OF YOUR STOVE ACHIEVING CLEAN, LONG BURNS Recent developments in wood-burning technology have made wood- To achieve long burn times, after having thoroughly preheated the stove, burning a cleaner and more convenient way to heat your home. Overall load the firebox without blocking the small air opening found in the efficiency in a wood-burning appliance is a combination of combustion center front of the firebox.
  • Page 19: Optional Blower Kit

    OPTIONAL BLOWER KIT WARNING The optional blower is controlled by a Dial-a-Temp (see Figure 24). It The blower must be plugged directly into a properly contains an On/Off line switch with variable speed control from low to grounded three-prong receptacle, 120 VAC, 60 Hz, single high.
  • Page 20: Do's And Don'ts

    Check the chimney and baffle monthly to make sure they are clean. Burn seasoned, dry wood only! (RAIN = WET WOOD) Open the door frequently during Burn-In Period to keep gasket from adhering to the curing paint. Enjoy the warm feeling of your new Earth Stove ™ appliance.
  • Page 21: Creosote

    DOOR HINGES: If door hinges need lubricating, use an anti-seize com- • Do not use chemical glass cleaners as they may damage the gaskets pound (never use oil) available from your Earth Stove™ dealer. or painted surfaces. DOOR LATCH: Adjustment Instructions - TIPS FOR KEEPING THE GLASS CLEAN 1.
  • Page 22: Troubleshooting

    TROUBLESHOOTING Problem Solution POOR DRAFT: Extend chimney in length or have the chimney realigned to the proper size flue. Oversized chimneys normally have poor drafts. Remember, the stove or fireplace inserts’ draft depends solely on the natural draft of the chimney (See Draft Requirements on Page 4).
  • Page 23: Replacement Parts Lists

    REPLACEMENT PARTS - MODEL ES2100 Contact an Earth Stove™ dealer to obtain any of these parts. Never use substitute materials. Use of non-approved parts can result in poor performance and safety hazards. Cat. No Description H8890 Right side heat shield...
  • Page 24: Accessories

    ACCESSORIES - MODEL ES2100 OUTSIDE AIR KITS OPTIONAL ACCESSORIES Cat. No. Model Description BLOWER H8873 BLWR-ES-S-150 Blower Kit, ES2100 OUTSIDE AIR KIT UZIAD UZIAD Outside Air Coupler Kit (connects outside air UZIAD ducting, UZI, to stove) AND - Outside Air Ducting Kit (includes 4” insulated flex x 10’...
  • Page 25: Venting Components

    VENTING COMPONENTS - MODEL ES2100 Secure Black™ Single Wall Stove Pipe 6” SW Pipe and Accessories Security Chimneys™ Pipe Cat. No. Model Description Pc. / Container 6SWL6 6SWL6 LENGTH 6” X 6” 6SWL12 6SWL12 LENGTH 6” X 12” Tubinox Components 6”...
  • Page 26 VENTING COMPONENTS - MODEL ES2100 Cat. No. Model Description Pc. / Container Supports (continued) TEE SUPPORT Secure Temp® Factory-Built Chimney 6” Secure Temp ASHT and Secure Temp G-ASHT 6SMA 6SMA GALVALUME ADJUSTABLE TEE SUPPORT (2” TO 6”) Cat. No. Model Description Pc.
  • Page 27: Safety / Listing Labels

    Combustible Materials Serial No./Numéro de sérle: Dégagements Minimums Aux Report No./Numéro de Rapport Report Date/Testé le Model / Modèle Manufactured By / Fabriqué Par: Stove ES2100- Matériaux Combustibles Poêle 100854192PRT-001 8/20/2012 ES2100 1502 14th St NW Auburn, WA 98071 USA Floor Tested to/Testé...
  • Page 28: Product Reference Information

    Earth Stove dealer, then please call 1-800-655-2008 for the name and 1. The model number of the appliance. phone number of your nearest Earth Stove dealer who will answer your 2. The serial number of the appliance. questions or address your concerns.
